- Page 1 9171 Metro Ethernet Routing Switch Installation Guide...
- Page 2 Cet équipement contient des composants sensibles aux décharges électrostatiques. Il doit absolument être manipulé en respectant les règles de mise à la terre afin de prévenir de telles décharges. Proprietary & Confidential Canoga Perkins Metro Ethernet Routing Switch Page 2 of 26...
-
Page 3: Table Of Contents
Table of Content ..........................4 Chapter 1 Product Introduction ..............................4 Model ............................5 Front Panel ............................6 Chapter 2 Installation .......................6 Preparation for Installation ........................6 2.1.1 Safety Precaution ........................6 2.1.2 Installation Site ..................7 2.1.3 Temperature/Humidity Requirements .....................7 2.1.4 Cleanliness Requirements: ....................8 2.1.5 Electromagnetic Susceptibility 2.1.6 Laser Use Safety ........................8... -
Page 4: Chapter 1 Product Introduction
Metro Ethernet Services and L2VPN / L3VPN services at the customer premises. The Canoga Perkins 9171 Series NIDs terminate and provide User to Network (UNI) functions for 10Mbps, 100Mbps and 1Gbps Metro Ethernet Services and L2VPN / L3VPN services. To ensure service offered is service delivered, Service Availability Monitoring (SAM) makes sure that the services is up and running, and Performance Measuring (PM) makes sure the services is up to speed. -
Page 5: Front Panel
9171 Installation Guide 1.2 Front Panel Fig. 1-1: Front Panel Sketch Map of 9171-1 (1) AC Power Module (2) DC Power Module (3) System Status LED (4) Fan Status LED Console Port (5) Power 1 Status LED (6) Power 2 Status LED... -
Page 6: Chapter 2 Installation
Anti-static gloves must be worn when replacing interface board to prevent static electricity from damaging veneer. 2.1.2 Installation Site To ensure a normal work environment, 9171 series routing switches should have the following requirements for workplace: Ensure that there are some spaces at the inlet and outlet of switch for heat dispersion of switch chassis. -
Page 7: Temperature/Humidity Requirements
SO2, H2S, NH3, and Proprietary & Confidential Canoga Perkins Metro Ethernet Routing Switch Page 7 of 26... -
Page 8: Electromagnetic Susceptibility
9171 series of routing switches are Class 1 laser devices. Do not stare at the optical interfaces directly when the optional optical interfaces of 9171 series of routing switches are in operating mode, since light beam emitting from fiber has high energy which may be harmful to retina. -
Page 9: Installation Tools
Note: The installation tools are not provided with 9171 Series Routing Switch 2.2 Installation 2.2.1 Installing Device onto Rack 9171 series of switches can be installed in a 19” standard rack in the following way: Installation of Front Hangers Coupling with Tray Note: Front hangers are only used to fix switches, but unable to bear the weight. - Page 10 Front Hangers Front Panel Front Hangers Fig. 2-3: Installation Sketch Map of Front Hangers Coupling with Tray Proprietary & Confidential Canoga Perkins Metro Ethernet Routing Switch Page 10 of 26...
-
Page 11: Installing Device Onto Desktop
Removal Process: The power modules for 9171 series of routing switches are pluggable. Removal process of power modules is as follows: Step 1: Wearing anti-static wrist strap, and confirm that the anti-static wrist strap is well earthed. ... -
Page 12: Power Wire And Grounding Connection
Note: it is an incorrect option to be grounded with fire mains and a lightning rod in a building, so the ground wires of Ethernet switches should be connected to the works in switch room and grounded. Proprietary & Confidential Canoga Perkins Metro Ethernet Routing Switch Page 12 of 26... - Page 13 Fig. 2-6：Grounding the device through a grounding strip Description: (1) Power input of switch (2) Ground terminal of switch (3) Protective grounding cable (4) Ground (5) Angle steel Proprietary & Confidential Canoga Perkins Metro Ethernet Routing Switch Page 13 of 26...
-
Page 14: Post-Installation Checking
Check the interface cables are arranged indoors instead of outdoors, if some cables are arranged outdoors, check if they are connected with an AC power lightning protection strip and network port lightning protector. Proprietary & Confidential Canoga Perkins Metro Ethernet Routing Switch Page 14 of 26... -
Page 15: Chapter 3 Fiber Interface Module And Cable Connection Description
CAT 6 non-unshielded twisted pair wires. While the transmission of 10 Base-T can use CAT 3 or CAT 4 twisted pair wires. By default, 10/100/1000M auto-negotiation are enabled for RJ45 connectors for 9171 Series Routing Switch. By this setting, when two switches are connected, the switches can automatically negotiate work environment and parameters to be used in automatic configuration. - Page 16 Table 3-2 Definition of Ethernet RJ45 Port Cross-Over Line: Pin No. Description Description Pin No. Crossover Cable You may refer to the following standard line sequence for making straight-through line and cross-over line: Proprietary & Confidential Canoga Perkins Metro Ethernet Routing Switch Page 16 of 26...
-
Page 17: Ethernet Port
9171 Installation Guide Fig. 3-2: Ethernet Line Sequence 3.1.2 Ethernet Port 9171 series of routing switches are integrated with out-of-band Ethernet ports whose interfaces are 100 Base-TX or 10 Base-T. It is recommended to use the net line included. 3.1.3 Console Port Console port uses an 8-pin RJ-45 connector. -
Page 18: Chapter 4 Initial Power-On & Start-Up Of Switch
Chapter 4 Initial Power-on & Start-up of Switch 4.1 Building Configuration Platform and Connecting Cable: Fig. 4-1: Building Local Configuration Platform Through Console Port Step 1: Connect DB-9 hole-type plug of configuration cable to the serial port for configuring switch. ... -
Page 19: Switch Power-On
Type a command, configure Ethernet switches or view the running state of Ethernet switches. Enter "?" whenever you need a help. See the subsequent chapters of this manual for specific configuration commands. Proprietary & Confidential Canoga Perkins Metro Ethernet Routing Switch Page 19 of 26... -
Page 20: Chapter 5 Switch Software Loading
To enter uBoot operation mode, press the combined key Ctrl + B during the switch startup when Press ctrl + b to stop autoboot: is prompted; startup information is as follows: Restarting system U-Boot 1.1.4 9171 v1.1 (Nov 19 2007 - 16:11:08) MPC8247 Reset Status: MPC8247 Clock Configuration - Bus-to-Core Mult 3.5x, VCO Div 2, 60x Bus Freq 30-85 , Core Freq 100-300... -
Page 21: Chapter 6 Upgrade Of Operating System
9171 Installation Guide Chapter 6 Upgrade of Operating System 9171 series of Ethernet switches can support new features and enhance system performance without replacing hardware by upgrading the operating system. Fig. 6-1: Upgrade Operating System Copy the upgrading mirror to switch In the privilege mode of switch, use the command COPY to copy the mirror files on TFTP server to the boot directory of switch flash;... - Page 22 9171-1.2(4), beta3 CanogaOS-v1.2.4.beta3-9171.r.bin * 2008-01-27 10:08:38 9171-1.2(5), fcs1 CanogaOS-v1.2.5.fcs1-9171.r.bin Among them, the files marked with * are image files that will be loaded when switch starts next time. Proprietary & Confidential Canoga Perkins Metro Ethernet Routing Switch Page 22 of 26...
-
Page 23: Chapter 7 Maintenance And Troubleshooting
Chapter 7 Maintenance and Troubleshooting 7.1 Loading Failure Processing: After loading fails, the system will keep running in the original version. At this time, users should re-check if physical port connections are good firstly. If some ports are not connected, then re-connect them to ensure that physical connections are correct, and begin re-loading. - Page 24 Please confirm the parameter setting of terminal (such as super terminal): baud rate: 9600, data bit: 8, parity: no, stop bit: 1, flow control: NA, selecting terminal emulation: VT100 Proprietary & Confidential Canoga Perkins Metro Ethernet Routing Switch Page 24 of 26...
- Page 25 9171 Installation Guide Proprietary & Confidential Canoga Perkins Metro Ethernet Routing Switch Page 25 of 26...
- Page 26 9171 Installation Guide CANOGA PERKINS CORPORATION 20600 Prairie Street Chatsworth, California 91311-6008 USA Phone: (818) 718-6300 FAX: (818) 718-6312 Web Site: www.canoga.com Email: fiber@canoga.com Proprietary & Confidential Canoga Perkins Metro Ethernet Routing Switch Page 26 of 26...
