Quick Start Guide

HS8000 Hardened
10/100 Ethernet Switch

Overview

This document provides instructions for installation and initial configuration of the Canoga
Perkins model HS8000 Hardened 6-port 10/100 Ethernet Switch. The HS8000 is suitable for use
in environments with inhospitable high / low temperatures providing two built-in 100Mbps full
duplex switched fiber ports. These fiber ports are coupled with six switched 10/100Mbps copper
(RJ45) ports for easy connectivity to local nodes and devices.
The HS8000 is available with AC or DC power, which can be easily deployed in an existing and
mixed vendor Ethernet network. The software supports managed edge-switch functions including
Menu-driven User Interface for ease of use, SNMP, QoS, Telnet, Password Security, Port
Settings Control, Spanning Tree Protocol, Port-based VLAN, BootP / DHCP etc. The two built-in
fiber ports are designed with full-duplex 100Mbps switched capability, and the six copper (RJ-45)
ports come with full / half-duplex-10/100 auto-negotiating ability.

Parts List

1 x HS8000-S-MP62-AC (Six UTP ports, two 20km singlemode optical ports, AC power)
or
1 x HS8000-S-MP62-12VDC (Six UTP ports, two 20km singlemode optical ports, DC power)
1 x AC power cord
1 x DB9 EIA 232 null modem cable (female to female, not included)
1 x Small flat head screwdriver (for DC powered switches)

Step 1: Unpacking

Unpack the HS8000 and check the unit for damage. If the unit is damaged, contact Canoga
Perkins' Tech Support line, (800) 360-6642, and ask for an RMA.

Step 2: Power Up

Initial set up consists of power up and configuring the unit through the user interface. To power
up the AC powered HS8000, install the output cord from the Power Source module to the switch
and hand tighten it. See figure 1. Plug in the provide AC power cord to an AC outlet and the
input of the HS8000 Power Source.
Canoga Perkins Corporation, 20600 Prairie Street, Chatsworth, CA 91311-6008
Phone: (818) 718-6300, FAX (818) 718-6312 www.canoga.com
P/N 6943465 Rev A
Page 1 of 7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HS8000 and is the answer not in the manual?

Questions and answers

Related Manuals for Canoga Perkins HS8000

Summary of Contents for Canoga Perkins HS8000

  • Page 1: Quick Start Guide

    These fiber ports are coupled with six switched 10/100Mbps copper (RJ45) ports for easy connectivity to local nodes and devices. The HS8000 is available with AC or DC power, which can be easily deployed in an existing and mixed vendor Ethernet network. The software supports managed edge-switch functions including Menu-driven User Interface for ease of use, SNMP, QoS, Telnet, Password Security, Port Settings Control, Spanning Tree Protocol, Port-based VLAN, BootP / DHCP etc.
  • Page 2 This section describes the proper connection of the DC leads to the DC power terminal block on the HS8000. The DC terminal block is located on the left front of the unit and is equipped with three screw-down lead posts. The power terminals are identified as positive (+) and negative (-), and they are floating inside the unit so that either may be grounded by the user if desired.
  • Page 3 After a name and icon is assigned, the COM port properties menu will appear. Configure the connection settings to the following values: Canoga Perkins Corporation, 20600 Prairie Street, Chatsworth, CA 91311-6008 Phone: (818) 718-6300, FAX (818) 718-6312 www.canoga.com P/N 6943465 Rev A...
  • Page 4 6. Event Log 7. Log Out 0. Close Connection Enter Selection by number: Figure 6. Main Menu screen Canoga Perkins Corporation, 20600 Prairie Street, Chatsworth, CA 91311-6008 Phone: (818) 718-6300, FAX (818) 718-6312 www.canoga.com P/N 6943465 Rev A Page 4 of 7...
  • Page 5 0. Discard Values and Exit this Menu Enter Selection by number: Figure 8. IP Parameters Configuration Canoga Perkins Corporation, 20600 Prairie Street, Chatsworth, CA 91311-6008 Phone: (818) 718-6300, FAX (818) 718-6312 www.canoga.com P/N 6943465 Rev A Page 5 of 7...
  • Page 6 Step 8: UTP Port Set-up The HS8000 comes with two optical ports and six 10/100 UTP ports. The optical ports are set for 100Mbps full duplex and can not be altered. However, the UTP ports can be configured for 10 or 100Mbps, half duplex or full duplex, or auto negotiation.
  • Page 7 Category 5 or better UTP cables for 100Mbps circuits. Figure 11. Cable connection This concludes the initial set up of the HS8000. For detailed information on other functions of the HS8000, consult the user manual or contact Canoga Perkins’ Tech Support line at (818) 718- 6300.
