81L Upright Freezer
/
GVAUF81
Instruction Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GVAUF81 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for GVA GVAUF81

  • Page 1 81L Upright Freezer GVAUF81 Instruction Manual...
  • Page 2: General Safety

    General Safety Your safety and the safety of others are very important. We have provided many important safety messages in this manual for your appliance. Always read and obey all safely messages. This is the Safely Alert Symbol. This symbol alerts you to potential hazards that can be fatal or injure you and others.
  • Page 3: Important Safeguides

    Important Safe Guides Before the freezer is used, it must be properly positioned and installed as described in this manual, so read the manual carefully. To reduce the risk of fire, electrical shock or injury when using the refrigerator, follow basic precautions, including the following : •...
  • Page 4 FOLLOW WARNING CALL OUTS BELOW ONLY WHEN APPLICABLE TO YOUR MODEL agents or abrasives on the interior. These • Use two or more people to move and install the freezer. Failure to do so can cleaners may damage or discolour the interior.
  • Page 5: Before Using Your Unit

    Before using your unit • Remove the exterior and interior packaging. • Check to be sure you have all of the following parts 4 Drawers 1 Instruction Manual and a warranty certificate. Before connecting the unit to the power source, let it stand upright for approximately 2 hours.
  • Page 6: Electrical Connection

    Electrical Connection Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is damaged, have it replaced by an authorised products service centre or repair agent. This unit should be properly grounded for your safety. The power cord of this unit is equipped with a three-prong plug which connects with standard three prong wall outlets to minimise the possibility of electrical shock.
  • Page 7: Reversing The Door

    Reversing the Door The freezer can be opened either from the left or right side. The default way of opening the door is from the right side. If you want to open the door from the left side, please follow the instructions below to remove the door and place it on the other side.
  • Page 8: Operating Your Unit

    Operating your unit Setting the temperature control The temperature control is located at the rear bottom corner of the appliance. The first time you turn the unit on, set the temperature control to the maximum position, using a flat head screwdriver. The range of the temperature control is from position “1”...
  • Page 9 Parts Cabinet Hinge hole cover Upper hinge part Flange screw M5x16 Upper hinge cover Upper right limited block of shelf Upper left limited block of shelf Right limited block of shelf Left limited block of shelf Drawer A Evaporator Evaporator decorative bar Drawer B Lower door hinge part Short levelling leg...
  • Page 10: Care And Maintenance

    Care and Maintenance Cleaning your unit • Turn the temperature control to “OFF”, unplug the unit, and remove the food, shelf, and tray. • Wash the inside surfaces with a warm water and baking soda solution. The solution should be about 2 tablespoons of baking soda to 1.2 litres of water. •...
  • Page 11 Moving your unit • Remove all the food • Securely tape down all loose items inside your unit • Turn the levelling legs up to the base to avoid damage • Tape the door shut Be sure the unit stays secure in the upright position during transportation. Protect the outside of unit with a blanket, or similar item.
