Page 2 Thank you for purchasing this DIS Navigation system. This user’s manual explains how to use the HYUNDAI Motor DIS Navigation system. Before using the product, read the contents of this user’s manual carefully and use this product safely. • The screens shown in this manual may diff er with the actual screens of the product.
Page 3: Precautions For Safety
Precautions for Safety Precautions for Safety Safety notes Always operate the vehicle in a safe manner. When driving your vehicle, be sure to keep the CAUTION Do not become distracted by the vehicle while volume of the unit low enough to allow you to RISK OF ELECTRIC driving and always be fully aware of all driving hear sounds coming from the outside.
Page 4 Precautions for Safety CAUTION: WARNING: • The navigation system does not take the relative safety of the suggested routes into • Don’t use a cellular phone when you are consideration. driving. You must stop at a safe place to use Road blocks, building sites, height or weight a cellular phone.
Page 5: Fcc Warning
Precautions for Safety CAUTION: Caution: Any changes or modifi cations to this FCC Warning device not explicitly approved by manufacturer • Do not keep the navigation system running This equipment has been tested and found could void your authority to operate this with the engine stopped.
Page 6: Table Of Contents
Table of Contents Table of Contents Precautions for Safety Head unit ......16 Radio Text On/Off ....26 Remote control for head unit (Option) - Sound Settings .
Page 7 Table of Contents Subscription status ....35 DVD Settings (Only for DVD) .....42 Subtitle Settings ........49 Go to SiriusXM data (Only for USA) . . 35 Repeat (Only for VCD) ......42 Voice Settings ........
Page 8 Table of Contents Switching to Menu display or Full Pause ............57 Bluetooth Audio Screen Display ........54 Skip ............57 Playing Bluetooth audio ... . 61 Pause ............54 Search ............
Page 9 Table of Contents General operations of [Navigation] menu Edit Route ..... . .80 Deleting call history ......98 ....... . 72 Route Info / Avoid .
Page 10 Table of Contents Radio commands ....... 104 Searching for other region or ski Fade/Balance ........132 Media commands ......105 resort ............119 Treble/Middle/Bass ......132 Audio CD commands ...... 106 Favorites ..........119 Surround Sound ......... 133 MP3 CD/ USB music/ iPod Weather &...
Page 11 Table of Contents Distance Unit .........141 About AVM (Around View Monitor) . . 147 Modem Information ......153 Screen Saver ..........141 Operating front AVM ... . . 147 Wi-Fi Settings ........154 Agreement Screen .......141 Operating rear AVM .
Page 12: General Information
General Information General Information • Do not disassemble the device. Contact a About Disc Types of Playable Discs designated service center in case of malfunction. DVD-VIDEO (12 cm disc) (Complete after service assistance will not be Precautions upon Handling Discs provided if the user disassembles the device.) •...
Page 13: Notes On Copyrights
General Information NOTES ON COPYRIGHTS DVD Region Code About USB It is forbidden by law to copy, broadcast, show, This instrument is manufactured according Connect the USB device after turning on the broadcast via cable, play in public, or rent to the region code number recorded in the engine.
Page 14: Mp3 File Information
General Information • Repeated connecting/disconnecting of USB • Charging through the USB may not work for MP3 file Information devices within short periods of time may some mobile devices. • Sampling frequency: 8 ~ 48 KHz (MP3), 22.5 result in product malfunction. •...
Page 15: Using Ipod Devices
General Information Using iPod Devices Supported iPod devices Cautions upon using SD Cards iPhone5 Precautions upon using iPod Ejecting and Inserting SD Cards iPhone4S iPod® is a registered trademark of Apple Inc. • Ejecting and inserting SD cards while the iPhone4 system is operating may result in SD Card •...
Page 16: Name Of Each Component
Name of Each Component Name of Each Component Head unit 1. Disc slot 4. • PWR PUSH button 5. FM/AM Button Insert a disc into the disc slot. - Power on Selects the FM/AM band. Press this button in power OFF status. 2.
Page 17 Name of Each Component 8. Cover for protecting SD card (SD card SEEK/TRACK button 11. TUNE/FILE button insert slot) - When it is pressed shortly (less than 0.8 sec.) FM/AM/SiriusXM mode: Turn to change Insert the SD card into the slot. the station.
Page 18: Remote Control For Head Unit (Option)
Name of Each Component Remote control for head unit (Option) - Only for USA The remote control for head unit is an option for the customers who selected the option. 1. Controller 4. BACK button 7. MAP VOICE button Moves or selects a menu through joystick Press to move to the previous screen.
Page 19: Remote Control For Head Unit (Option)
Name of Each Component Remote control for head unit (Option) - Only for CANADA The remote control for head unit is an option for the customers who selected the option. 1. Controller 4. BACK button 7. MAP VOICE button Moves or selects a menu through joystick Press to move to the previous screen.
Page 20: Steering Wheel Remote Control
Name of Each Component Steering wheel remote control 4. Seek up/down (W/S) button - When it is pressed shortly (less than 0.8 sec.) • FM/AM/SiriusXM mode: plays previous/next station. • In MEDIA modes: changes the track, fi le, or chapter. - When it is pressed and held (0.8 sec.
Page 21: Basic Operation
Basic Operation Basic Operation Note Starting the system for the AV OFF • You cannot operate the system while it is first time Press “PWR PUSH” on the head unit when the booting up. It may take some time for all of AV is on.
Page 22: Resetting The System
Basic Operation Resetting the System Using the controller Using the Touch screen This feature is used to reset the system in the This feature is used to move or select a menu Press the desired menu on the screen to select occurrence of an unforeseen error or problem.
Page 23: Radio Operation (Fm/Am)
Radio Operation (FM/AM) Radio Operation (FM/AM) Preset tuning: Listening to FM/AM radio Listening to HD Radio (Only 1. Press ""FM/AM" on the head unit. Or press From the 12 presets, select the station you for USA) [HOME] > [FM/AM]. want to listen to. The HD Radio function is not supported for 2.
Page 24: Hd Radio On/Off
Radio Operation (FM/AM) HD Channel Number HD Radio On/Off • HD Channel number saved in preset. 1. Select the band (FM, AM) you want. If HD radio broadcast includes Tag information, then the tag information is displayed on the • Preset tuning: From the 18 presets, select 2.
Page 25: Saving Fm/Am Preset
Radio Operation (FM/AM) Saving FM/AM preset Scanning FM/AM broadcast Scanning all stations station This function scans all stations and plays only 12 preset stations each for FM/AM modes can stations with superior reception for 5 seconds be saved manually. each. Scanning preset stations 1.
Page 26: Reordering Fm/Am Preset
Radio Operation (FM/AM) Reordering FM/AM preset Autostore Radio Text On/Off This function reorders the station saved to A total of 24 stations with twelve preset If current broadcast includes Radio Text presets. stations each for FM/AM modes can be saved. information, the text information is displayed on the screen.
Page 27: Radio Operation (Siriusxm)
Radio Operation (SiriusXM) Radio Operation (SiriusXM) SiriusXM screen (Time difference) Displays the time difference between the song playing and the Live broadcast. 9. c Repeats the previously broadcasted program. • When it is pressed shortly (less than 0.8 sec.): Moves to the previous song. •...
Page 28: Listening To Siriusxm Radio
Radio Operation (SiriusXM) Listening to SiriusXM radio Selecting SiriusXM broadcast Selecting channel through channel channel/category list 1. Press "SXM" on the head unit. Or press [HOME] > [SiriusXM]. 1. Press [List] on the screen. Selecting a channel through manual The SiriusXM radio screen of the most Or press [MENU] >...
Page 29: Adding To Favorites
Radio Operation (SiriusXM) Note Adding to Favorites You can play the song or artist by selecting the You can add the artist or song in the [Favorites] desird item when the song or artist added in menu. [Favorites] menu is playing on other channel. 1.
Page 30: Scanning Siriusxm Broadcast Channel
Radio Operation (SiriusXM) Scanning SiriusXM broadcast Direct Tune Featured Favorites channel This feature is used to search for channels by Featured Favorites feature allows SiriusXM to entering channel numbers. broadcast additional presets. 1. Press [MENU] on the SiriusXM radio screen. 1.
Page 31: Favorites
Radio Operation (SiriusXM) Favorites Viewing Active Alert Deleting the song or artist saved in [Favorites] menu You can listen to live broadcast by selecting You can check the song or artist added in the channel when the song or artist added in 1.
Page 32: Favorites Alert On/Off
Radio Operation (SiriusXM) • [Tune]: Moves to the selected channel. Favorites Alert On/Off Storing SiriusXM preset • [Ignore]: Moves to the previous screen. This feature sets whether to display the pop-up A total of 18 SiriusXM channels can be saved on the screen when the song or artist added in •...
Page 33: Reordering Siriusxm Preset
Radio Operation (SiriusXM) Reordering SiriusXM preset Game Zone (Only for USA) Setting Team You can listen to the game of the favorite team The 18 SiriusXM channels can be reordered in You can check the list of sporting leagues and by marking the favorite team.
Page 34: Viewing Active Alert
Radio Operation (SiriusXM) • [Active Alerts]: Moves to the active alert Viewing Active Alert Alert On/Off list. Select the desired item and you can You can listen to live broadcast by selecting This feature sets whether to display the pop- play the selected item.
Page 35: Subscription Status
Radio Operation (SiriusXM) Subscription status Go to SiriusXM data (Only for USA) This feature is used to check the Subscription status of SiriusXM. The SiriusXM Data Service is a paid 1. Press [MENU] > [More Features] > membership Satellite radio service which [Subscription status] on the SiriusXM radio provides users with Weather, Traffi c, Fuel prices, screen.
Page 36: Audio Cd/ Mp3 Cd Operation
Audio CD/ MP3 CD Operation Audio CD/ MP3 CD Operation Playing an Audio CD/ MP3 CD Pause Search Press [M] on screen or by controller. You can search for the current playing track/ Insert a disc into the disc slot and playback will fi le quickly.
Page 37: Seek
Audio CD/ MP3 CD Operation Seek List Shuffle You can play the track/fi le directly by searching You can play the desired track/fi le by searching All tracks/fi les are played randomly. for the desired music. for track/fi le list included in the disc. 1.
Page 38: Repeat
Audio CD/ MP3 CD Operation 3. Press [ ] to cancel the Scan function. Repeat Scan The current playing track/fi le or folder is played This function scans the beginning parts of repeatedly. each tracks/fi les for 10 seconds. 1. Press [MENU] > [Repeat]. 1.
Page 39: Dvd/Vcd Operation
DVD/VCD Operation DVD/VCD Operation Playing a DVD/VCD Switching to Menu display or Full Skip Screen Display You can play the previous or next chapter/ Insert a disc into the disc slot, with the label track. facing up. Position Description Playback will start automatically. In some cases, Position Description Screen...
Page 40: Search
DVD/VCD Operation Search Seek Title Menu/ Disc Menu (Only for DVD) You can search for the current playing chapter/ You can play the chapter/track directly by track quickly. searching for the desired chapter/track. If the current title has a menu, the menu will appear on the screen.
Page 41: Caption Language (Only For Dvd)
DVD/VCD Operation Caption Language (Only for DVD) Voice Language (Only for DVD) Angle (Only for DVD) If the DVD has a different caption language, If the DVD has a different voice language, you If the DVD has a different angle, you can you can see various caption language.
Page 42: Dvd Settings (Only For Dvd)
DVD/VCD Operation DVD Settings (Only for DVD) Repeat (Only for VCD) Shortcut (Only for VCD) This function sets the language to play a DVD The current playing track is played repeatedly. You can play the track directly by searching for by default.
Page 43: Pbc On/Off (Only For Vcd)
DVD/VCD Operation 2. Press [0]~[9] to select the desired menu. PBC On/Off (Only for VCD) Display Settings When playing VIDEO CD with PBC functions 1. Press [MENU] > [Display Settings] on the (Version 2.0 discs), you can enjoy playing menu display mode. simple interactive software with search 2.
Page 44: Dvd Language Code
DVD/VCD Operation DVD language code Code Country Code Country Code Country Code Country 0101 Afar 0625 Frisian 1222 Latvian 1912 Slovenian 0102 Abkhazian 0701 Irish 1307 Malagasy 1913 Samoan 0106 Afrikaans 0704 Scots 1309 Maori 1914 Shona 0113 Amharic 0712 Gallegan 1311 Macedonian...
Page 45 DVD/VCD Operation Code Country Code Country Code Country Code Country 0315 Corsican 0923 Hebrew 1518 Oriya 2012 Tagalog 0319 Czech 1009 Yiddish 1601 Punjabi 2014 Tswana 0325 Welsh 1001 Japanese 1612 Polish 2015 Tongo 0401 Danish 1022 Javanese 1619 Pushto 2018 Turkish 0405...
Page 46: Jukebox Operation
Jukebox Operation Jukebox Operation Playing Jukebox music Pause Cover Flow View You can pause the playing fi le. You can play the desired album by searching You can play the music fi les saved in Jukebox. for the cover fl ow in Jukebox. For details, refer to “Pause”...
Page 47: List
Jukebox Operation List Shuffle Repeat You can play the desired fi le by searching for All fi les are played randomly. The current playing fi le is played repeatedly. fi le list included in Jukebox. For details, refer to “ Shuffl e” on the page 37. 1.
Page 48: Playing Jukebox Video
Jukebox Operation Playing Jukebox video Switching to Menu display or Full Search Screen Display You can search for the current playing fi le You can play the video fi les saved in Jukebox. quickly. If there is no video fi le in Jukebox, copy the Position Description For details, refer to “Search”...
Page 49: Subtitle Settings
Jukebox Operation Subtitle Settings Voice Settings DivX® VOD 1. Press [MENU] > [Subtitle Settings] on the 1. Press [MENU] > [Voice Settings] on the You must register your device to play DivX® menu display mode. menu display mode. protected videos. 1.
Page 50: Viewing Jukebox Image
Jukebox Operation Viewing Jukebox image Switching to Menu display or Full Zoom in/out Screen Display 1. Turn the controller to the left or right. You can view the image fi les saved in Jukebox. If there is no image fi le in Jukebox, copy the Position Description desired image to Jukebox.
Page 51: Slideshow
Jukebox Operation Slideshow List Slideshow Settings 1. Press [MENU] > [Slideshow] on the menu You can view the desired image by searching You can set the slideshow interval. The display mode. for image list included in Jukebox. slideshow is played according to the time interval.
Page 52: Playing Usb Music
USB Operation USB Operation 2. Press the desired album. Playing USB music Skip You can play the previous or next fi le. • Press [MENU] > [View Default Player] to You can play music fi les saved in a USB move to the current playing screen.
Page 53: List
USB Operation List Shuffle Scan All fi les are played randomly. You can play the desired fi le by searching for This function scans the beginning parts of fi le list included in USB. For details, refer to “ Shuffl e” on the page 37. each fi les for 10 seconds.
Page 54: Playing Usb Video
USB Operation Playing USB video Switching to Menu display or Full Search Screen Display You can search for the current playing fi le You can play video fi les saved in a USB memory quickly. device. Position Description For details, refer to “Search” on the page 36. Connect a USB device to the USB port and Screen Press the screen.
Page 55: List
USB Operation List Repeat Subtitle Settings You can play the desired fi le by searching for The current playing fi le is played repeatedly. You can set the caption. fi le list included in USB. For details, refer to “Repeat” on the page 47. For details, refer to “Subtitle Settings”...
Page 56: Viewing Usb Image
USB Operation Viewing USB image Skip Copying the USB image file to Jukebox You can view the previous or next image. You can play image fi les saved in a USB You can copy the desired fi les to Jukebox. memory device.
Page 57: Ipod Operation
iPod Operation iPod Operation The current playing fi le is played repeatedly. Playing iPod List 1. Press [MENU] > [Repeat]. You can play the desired fi le by searching for Connect an iPod to the USB port by using the fi le list included in iPod.
Page 58: Pandora Radio Operation
Pandora Radio Operation (Only for USA) Pandora Radio Operation (Only for USA) Note Playing Pandora Seek There might be unexpected operation in You can play the desired station by searching it with The Pandora function is not supported for Pandora mode depending on the type of the “TUNE/FILE”...
Page 59: Feature Of This Track
Pandora Radio Operation (Only for USA) 2. Press the desired station. Thumbs Up / Thumbs Down Bookmark • Press [MENU] > [Now Playing] to move to You can rate songs using thumbs up and You can bookmark favorite Track or Artist. the current playing screen.
Page 60: Auxiliary Device Operation
Auxiliary Device Operation Auxiliary Device Operation Playing an AUX source Switching to Menu display or Full Display Settings Screen Display during video playback 1. Connect an auxiliary device to the AUX 1. Press [MENU] > [Display Settings] on the terminal. menu display mode during video playback.
Page 61: Bluetooth Audio
Bluetooth Audio Bluetooth Audio Playing Bluetooth audio Starting the Bluetooth audio Skip 1. Press [HOME] > [Media] > [Bluetooth You can play the previous or next fi le. Before playing the Bluetooth audio Audio]. For details, refer to “Skip” on the page 36. •...
Page 62: Getting Started With Navigation
Getting Started with Navigation Getting Started with Navigation • The position of the vehicle within the Precautions for safe driving About satellite signals navigation may diff er from your actual Please observe and comply with local traffi c Your unit must acquire satellite signals to location depending on various reasons, rules and regulations.
Page 63: Operating Navigation Screen
Getting Started with Navigation Operating Navigation Screen The navigation system displays various information on the screen. Map screen 1. Clock display 4. Navigation voice guidance on/off (north up (2D)): Displays always has north at the top of screen. Displays current clock. Turns the navigation voice guidance On/ GPS signal state display button...
Page 64 Getting Started with Navigation 6. Map scale display 9. Route guidance display 12. Remaining distance display/ Remaining time display • Displays the current map scale. Displays the route guidance to the destinaton when a route is set. Displays the distance to the destination and •...
Page 65 Getting Started with Navigation 15. [Destination] button 17. [Add to Address Book] button 19. [Guidance Volume] button Moves to [Destination] menu. Adds frequently used address to [Address Adjusts the navigation volume. For details, Book] menu. For details, refer to "Adding the refer to “Navigation volume”...
Page 66: Zoom In / Zoom Out
Getting Started with Navigation Zoom In / Zoom Out Map scale Changing the route conditions This function sets the zoom level automatically You can set new route by searching for various Press [ ] or [ ] to set the zoom level on the according to the road class.
Page 67: Searching For Poi
Getting Started with Navigation • Press [MENU] > [Name] to arrange the list Route Info / Avoid Searching for POI in name order. This allows you to check the route information POI search and search for new route by avoiding the •...
Page 68 Getting Started with Navigation 5. Press [Set as Destination]. 6. Press the desired route. • Press [Edit Route] to edit the route. For details, refer to “Edit Route” on the page When a route is set, press [Change Destination]. • If you want to add a waypoint when a •...
Page 69: Adding The Position To Address Book
Getting Started with Navigation Note Editing POI category Adding the position to address book Press [MENU] > [Destination] > [Address Book] You can edit the POI category displayed on POI You can add the current position or the to check the added position. menu screen.
Page 70: Scrolling Map
Getting Started with Navigation Scrolling map Traffic information list Navigation volume 1. Press and drag the map area on the screen. The current traffi c/road event information is Press [MENU] > [ Guidance Volume] to adjust The selected point will be centered on basically displayed on the traffi c information the volume.
Page 71: Settings
Getting Started with Navigation Settings Making a call to POI Guidance to Previous Destinations Press [MENU] > [Settings] to set the screen. After searching for a POI, the POI phone When starting the navigation, the “Guidance number information can be used to make a to Previous Destinations”...
Page 72: General Operations Of Quick Menu
Getting Started with Navigation • [Guidance Volume]: Adjusts the General operations of quick General operations of navigation volume. (Page 70) menu [Navigation] menu • [Settings]: Sets items related with 1. Press [MENU] on the map screen. 1. Press [NAV] on the remote control for head navigation settings.
Page 73: Searching For Destination Of Navigation
Searching for Destination of Navigation Searching for Destination of Navigation 3. Press [Set as Destination]. 4. Press the desired route. Address Search When a route is set, press [Change You can fi nd the destination by searching for Destination]. an address. •...
Page 74: Previous Destinations
Searching for Destination of Navigation page 81. • [Previous Start Points]: Displays previous 1. Press [MENU] or [NAV] > [Destination] > departing places. [Address Book]. • Press [Edit Route] to edit the route. For • [Previous Searches]: Displays previously details, refer to “Edit Route” on the page searched places.
Page 75: Adding To Address Book
Searching for Destination of Navigation Adding to Address Book Deleting Address Book Editing Address Book 1. Press [MENU] > [Add] in address book list. 1. Press [MENU] > [Delete] in address book 1. Press [MENU] > [Edit] in address book list. list.
Page 76: Poi
Searching for Destination of Navigation Searching for POI by name Searching for POI by phone number 1. Press [MENU]> [Destination] > [POI Name]. If you know the phone number of the You can fi nd a destination from various Or press [NAV] > [Destination] > [POI] > destination, you may use this function to fi nd categories.
Page 77: Emergency
You can fi nd a destination by searching for a Please join in Blue Link® service to use for the You can fi nd the destination by searching for Police Station, Hospital, Hyundai Dealership or Local Search. For the details, please refer to the intersection.
Page 78: Freeway Exit / Entrance
Searching for Destination of Navigation Freeway Exit / Entrance Coordinates Home / Office You can fi nd the destination by searching for You can fi nd a destination by inputting the If your home location and offi ce location have the Freeway Exit/Entrance.
Page 79: Using The Route Menu
Using the Route Menu Using the Route Menu • [Use HOV/Carpool Lanes]: Searches for Route menu overview Route Options a route that includes the use of HOV/ This allows you to change the route conditions You can modify the route conditions or Carpool Lanes.
Page 80: Edit Route
Using the Route Menu 4. If you want to add an waypoint, follow Edit Route Deleting Route steps 2~3. 1. Press [NAV] > [Route] > [Edit Route]. This feature allows you to travel through the 5. Press [Done] > [Start Guidance]. 2.
Page 81: Route Info / Avoid
Using the Route Menu Route Info / Avoid Route Overview Route Preview This allows you to check the route information You can check the entire route between your This allows you to check the detailed turn-by- and search for new route by avoiding the current location and your destination.
Page 82 PLEASE READ THIS END USER LICENSE AGREEMENT (“EULA”) CAREFULLY BEFORE USING THE NAVIGATION SYSTEM. This is a license agreement between you and Hyundai MnSoft, INC. including its affi liates (“COMPANY”) regarding a copy of the COMPANY navigable map database together with associated software, media and explanatory printed documentation published by COMPANY(jointly the “Product”). The Product is provided for your personal, internal use only and not for resale.
Page 83 Terms and Conditions Personal Use Only. You agree to use this Product together with COMPANY’s authorized application for the solely personal, non-commercial purposes for which you were licensed, and not for service bureau, time-sharing or other similar purposes. Accordingly, but subject to the restrictions set forth in the following paragraphs, you agree not to otherwise reproduce, copy, modify, decompile, disassemble, create any derivative works of, or reverse engineer any portion of this Data, and may not transfer or distribute it in any form, for any purpose, except to the extent permitted by mandatory laws.
Page 84 THE PRODUCT MAY INCLUDE ENFORCEMENT TECHNOLOGY DESIGNED TO PREVENT (i) UNAUTHORIZED COPYING OF THE PRODUCT ONTO PHYSICAL STORAGE MEDIA OR VIA TRANSFER OVER THE INTERNET OR OTHER ELECTRONIC COMMUNICATION MEANS AND/OR (ii) ILLEGAL USAGE OF THE PRODUCT OTHER THAN BY A SPECIFICALLY AHTORIZED DEVICE. YOU AGREE THAT COMPANY MAY USE THESE MEASURES TO PROTECT COMPANY AND THE LICENSORS AGAINST COPYRIGHT INFRINGEMENT.
Page 85 Personal Information. By using the Product, you agree to the collection, retention and processing of your personal data (including the location of your mobile device) by COMPANY and to the storage and processing of such personal information on computers located outside of the country in which you reside.
Page 86 Disclaimer of Warranty. The Product is provided to you “as is, ” and you agree to use it at your own risk. SUBJECT TO THE APPLICABLE LAWS, COMPANY AND THE LICENSORS MAKE NO GUARANTEES, REPRESENTATIONS OR WARRANTIES OF ANY KIND, EXPRESS OR IMPLIED, ARISING BY LAW OR OTHERWISE, INCLUDING BUT NOT LIMITED TO, content, QUALITY, accuracy, completeness, eff ectiveness, reliability, PERFORMANCE, MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, NON-INFRINGEMENT, usefulness, use or results to be obtained from the Product, or that the Product or server will be uninterrupted or error-free, OR THAT ERRORS IN THE PRODUCT OR NONCONFORMITY TO ITS DOCUMENTATION CAN OR WILL BE CORRECTED.
Page 87 Exclusions. Some jurisdictions do not allow certain warranty exclusions or the limitation or exclusion of liability, so to that extent the above exclusion may not apply to you. To the extent that COMPANY may not, as a matter of applicable law, disclaim any implied warranty or limit its liabilities, the scope and duration of such warranty and the extent of COMPANY’s liability shall be the minimum permitted under such applicable law.
Page 88 Export Control. You agree not to export or re-export from anywhere any part of the Product in any form except in compliance with applicable export laws, rules and regulations, including but not limited to the laws, rules and regulations administered by the Offi ce of Foreign Assets Control of the U.S. Department of Commerce and the Bureau of Industry and Security of the U.S. Department of Commerce.
Page 89 Notice of Use Contractor (Manufacturer/ Supplier) Name: Hyundai MnSoft, Inc. This Product and related documentation are commercial items as defi ned in FAR 2.101 and is subject to this EULA under which this Product is provided. © 20XX Hyundai MnSoft. All rights reserved.
Page 90 La Banca Dati Italiana è stata prodotta usando quale riferimento anche cartografi a numerica ed al tratto prodotta e fornita dalla Regione Toscana. Copyright © 20XX; Norwegian Mapping Authority Source: IgeoE – PortugSpain Información geográfi ca propiedad del CNIG The HERE Data for Sweden is based upon electronic data © National Land Survey Sweden Topografi sche Grundlage: ©...
Page 91 About Map Updates You can contact your HYUNDAI dealer or Call MnSOFT at 888-757-0010. Information • This product requires regular updates for software corrections, new functions and map updates. Updating may require up to 1 hour depending on the data size.
Page 92: Bluetooth® Wireless Technology
Bluetooth® Wireless Technology Bluetooth® Wireless Technology • Park the vehicle when pairing the head unit Before Using the Bluetooth Precautions for Safe Driving with the mobile phone. Handsfree • Bluetooth Handsfree is a feature that enables • Some Bluetooth features may occasionally drivers to practice safe driving.
Page 93: Pairing And Connecting The Unit And A Bluetooth Phone
Bluetooth® Wireless Technology 3. In your phone, initiate a search for Bluetooth 6. When your phone is successfully Pairing and connecting the devices. (The default device name is GENESIS.) connected, the phone screen is displayed unit and a Bluetooth phone on the screen.
Page 94: When A Phone Is Already Paired
Bluetooth® Wireless Technology 2) If the SSP (Secure Simple Pairing) is When a phone is already paired supported, press [Yes] on the pop-up 1. Press [HOME] > [Settings] > [Bluetooth] > screen of the your Bluetooth device. [Bluetooth connection]. (The pop-up screen may diff er from the actual information of the Bluetooth device.) 5.
Page 95: Disconnecting The Connected Phone
Bluetooth® Wireless Technology Disconnecting the connected phone Deleting Bluetooth Devices Making a call by entering phone number 1. Press [MENU] > [Connection Settings] > If you no longer need to use a phone, you can delete the Bluetooth devices. Note that [Bluetooth connection] on the phone Connect your unit and Bluetooth phone before deleting a Bluetooth device will delete all call...
Page 96: Making A Call With Speed Dial Numbers
Bluetooth® Wireless Technology Making a call with speed dial Answering/Rejecting a call Switching call to the mobile numbers phone 1. If there is an incoming call, a popup message will appear. Press and hold speed dial number using the 1. If you want to switch the call to the mobile 2.
Page 97: Using The Menu During A Phone Call
Bluetooth® Wireless Technology Using the menu during a phone Call history Downloading call history call You can download the call history information Making a call from call history from your mobile phone. When making a call, you can use the following 1.
Page 98: Deleting Call History
Bluetooth® Wireless Technology Deleting call history Contacts Downloading mobile phone contacts You can delete the items that you select from Up to 5,000 mobile phone contacts can be 1. Press [ ] on the phone screen. your call history Information. downloaded.
Page 99: Searching For Contacts
Bluetooth® Wireless Technology Searching for contacts Adding as a Favorite Favorites 1. Press [ ] > [MENU] > [Search Contacts] 1. Press [ ] on the phone screen. Calling Favorites on the phone screen. The contacts is displayed on the screen. If the phone number have been already stored 2.
Page 100: Adding As A Favorite
Bluetooth® Wireless Technology Adding as a Favorite Deleting Favorites Setting Bluetooth Connection 1. Press [ ] on the phone screen. 1. Press [ ] on the phone screen. 1. Press [ ], [ ], [ ], or [ ] on the phone screen.
Page 101: Voice Recognition System
Voice Recognition System Voice Recognition System What is voice recognition? Operating voice command Starting voice recognition 1. Shortly press “ ” on the steering wheel Voice recognition technology runs the Condition for voice command system system as ordered by recognizing your voice remote control.
Page 102: Skipping Prompt Messages
Voice Recognition System not want to wait for the full voice guide or when Skipping prompt messages Basic operation for voice command the system does not recognize your voice. (Setting FM) While prompt message is being stated, shortly press “ ”...
Page 103: Voice Command List
Voice Recognition System Voice command list Voice recognition commands are classifi ed as “Global Commands” and “Local Commands. ” • Global commands (X) : Commands that can be used immediately after activating voice recognition. • Local commands ( ) : Commands that can be used in specifi c multimedia/navigation/Bluetooth mode states. Note Some global and local commands will operate properly only when a USB, iPod, Bluetooth or other device has been connected.
Page 104: Radio Commands
Voice Recognition System Call <Name> on You can immediately make a call to (name) in the downloaded mobile phone contacts saved as another phone category except ‘mobile, home, offi ce’ . Ex.) “Call John Smith on other” Other Dial number Displays a screen where you can say a phone number to dial.
Page 105: Media Commands
Voice Recognition System Media commands Check the followings before you use media commands. 1. If no media is connected or if no playable files exist at the time when you use these commands, a voice message will tell you that this is not available at present.
Page 106: Audio Cd Commands
Voice Recognition System Audio CD commands Command Operation Play Plays a stopped track. If it is playing, it remains the current condition. Pause Pauses a playing track. If it is paused, it remains the current condition. Track <1~99> Plays the track having spoken number. Shuffl e Plays randomly all tracks.
Page 107: Mp3 Cd/ Usb Music/ Ipod Commands
Voice Recognition System MP3 CD/ USB music/ iPod commands Command Operation Play Plays a stopped track. If it is playing, it remains the current condition. Pause Pauses a playing track. If it is paused, it remains the current condition. Shuffl e Plays randomly all tracks.
Page 108: Navigation Commands
Voice Recognition System Navigation commands Check the following before you use navigation commands : 1. Search for and find addresses located in the state or province your car is currently in. If you want to search in another state, say the name of state/province and then look it up. Find Address is classified by states/provinces to provide you with faster service.
Page 109 Voice Recognition System Previous Destinations Displays a list of recent destinations that you can return to by saying the number on the list. Previous Searches Displays a list of recent searches, where you can set a destination by saying the number in the list. Previous Starting Displays a list of recent starting points that you can return to by saying the number on the list.
Page 110 Voice Recognition System Police Station Displays a list of the nearest police stations. You can then set a destination by saying the list number. Hospital Displays a list of the nearest hospitals. You can then set a destination by saying the list number. Dealership Displays a list of the nearest car dealerships.
Page 111: Other Commands (Commands Used In List / Help/ Etc.)
Voice Recognition System Other Commands (Commands used in List / Help/ etc.) Command Operation Help Goes to the voice recognition help screen. All available commands can then be identifi ed and used. Yes/No When voice recognition is active, this command is used when an answer is requested for a confi rmation question. Line 1-5 (One-Five) When you cannot select a certain name, such as in Call History, you can select it using numbers.
Page 112: List Of Nearest Locations
Voice Recognition System List of Nearest Locations Navigation location names may be changed after a softwate update. Restaurants • Fast Food • Church's Chicken • White Castle • Seasons 52 • Red Lobster • Coff ee Shop • Dairy Queen •...
Page 113 • Murphy USA • Sears Auto Center • Wineries • Wells Fargo • Motorcycle Dealerships • Petro Stopping Centers • Video & Game Rental • Hyundai Dealerships • PETRO-CANADA • Ski Resorts • ampm • Phillips 66 • Recreation Areas • ARCO •...
Page 114 Voice Recognition System Travel • Airports • Comfort INN • Hotel Indigo • Red Roof Inn • Budget • Hotels • Comfort Suites • Howard Johnson • Regent Hotels & Resorts • Dollar Rent A Car • Rental Car Agencies •...
Page 115 Voice Recognition System Shopping Community Services • Department Stores • ampm • SuperValu • Police Stations • Hospitals • Convenience Stores • BP • Best Buy • Post Offi ces • Medical Services • Shopping Centers • Circle K • Future Shop •...
Page 116: Siri
Siri Siri Operating Siri command Ending Siri • While voice recognition is operating, press What is Siri? and hold “ ” on the steering wheel remote Apple wants to integrate the Siri to specifi c control or say “Exit”. voice control system by working with car •...
Page 117: Siriusxm Data (Only For Usa)
SiriusXM Data (Only for USA) SiriusXM Data (Only for USA) About SiriusXM data SiriusXM Weather Information Weather forecast This service provides weather forecasts for the The SiriusXM Data Service is a paid Current weather information next six days including today in your region. membership satellite radio service which This service provides current weather provides users with weather, traffic, fuel prices,...
Page 118: Weather Information Of Other Region
SiriusXM Data (Only for USA) • Press [MENU] > [Weather & Security Alerts] to move to the Weather & Security Alerts screen. • Press [MENU] > [Weather Map] to move to the Radar Map screen. Weather information of other region This service provides weather information of other region.
Page 119: Searching For Other Region Or Ski
SiriusXM Data (Only for USA) Searching for other region or ski Favorites Adding to Favorites resort A maximum of 10 items can be added. If the city or ski resort have been already stored in the Favorites, it can be easily called. 1.
Page 120: Weather & Security Alerts
SiriusXM Data (Only for USA) Reordering Favorites Deleting Favorites Weather & Security Alerts The added items in Favorites can be reordered 1. Press [Favorites] > [MENU] > [Delete] on This service provides weather warnings and in the desired order. the Location List. advisories, such as Tornado, Storm, Flood, Winter, Wind etc.
Page 121: Siriusxm Traffic Information
SiriusXM Data (Only for USA) 2. Press the desired item. • Press [MENU] > [Weather Front] to set SiriusXM Fuel Prices whether to display the Isobar on the Information radar map. • Press [MENU] > [Isobar] to set whether to Finding gas station display the Isobar on the radar map.
Page 122: Searching For Gas Station
SiriusXM Data (Only for USA) • Press [MENU] > [Search] to search for the Searching for gas station Favorites gas station. For details, refer to “Searching 1. Press [MENU] > [Search] on the Fuel Prices If the gas station have been already stored in for gas station”...
Page 123 SiriusXM Data (Only for USA) Adding to Favorites Sorting Favorites Deleting Favorites A maximum of 10 items can be added. The added items in Favorites can be sorted in 1. Press [Favorites] > [MENU] > [Delete] on the desired order. the Fuel Prices List.
Page 124: Favorites
SiriusXM Data (Only for USA) SiriusXM Stocks Information Adding to Favorites Reordering Favorites A maximum of 100 items can be added. The added items in Favorites can be reordered Stocks is a feature that shows the current value in the desired order. and change of stocks.
Page 125: Siriusxm Sports Information
SiriusXM Data (Only for USA) Deleting Favorites Stock Search SiriusXM Sports Information 1. Press [MENU] > [Delete] on the Stocks 1. Press [Search] on the Stocks main screen. This service provides real-time updated main screen. information on scores and schedules for major 2.
Page 126: Favorites
SiriusXM Data (Only for USA) • Press [Schedule] or [MENU] > [Schedule] Favorites Adding to Favorites to display the schedule list of the team. 1. Press [MENU] > [Add Favorite] on the 1. Press [Favorites] on the Sports main screen. It shows the schedule list for the next Sports main screen.
Page 127: Siriusxm Movie Information
SiriusXM Data (Only for USA) Reordering Favorites Deleting Favorites SiriusXM Movie Information The added items in Favorites can be reordered 1. Press [MENU] > [Delete] on the Sports You can check recent movies and nearby in the desired order. main screen. theaters, and also register your favorite theater locations.
Page 128: Viewing Movie List By Searching For Theater
SiriusXM Data (Only for USA) 2. Press the desired theater. 2. Press the desired theater. Viewing movie list by searching for theater The theater list is displayed on the screen. The movie list is displayed on the screen. 1. Press [Theaters] on the Movies main screen.
Page 129: Favorites
SiriusXM Data (Only for USA) Note Favorites Deleting Favorites When there is no added item in Favorites, a 1. Press [MENU] > [Delete] on the Sports 1. Press [Favorites] on the Movies main screen is displayed for you to add your favorite main screen.
Page 130: [Settings] Menu Overview
Settings Settings 2. Select the desired items. 2. Select the desired items. [Settings] menu overview • [Unit]: Changes the unit between the “mi” • [Map Mode]: Sets the Map Mode to [Full [Settings] menu and “km”. Map] or [Show Turn List]. •...
Page 131: Guidance
Settings Guidance Route Traffic This menu is used to change the guidance This menu is used to change the route settings. This menu is used to change the traffi c settings. information event settings. 1. Press [HOME] > [Settings] > [Navigation] 1.
Page 132: Sound
Settings Sound Fade/Balance Treble/Middle/Bass This menu is used to set the sound position. This menu is used to set the Treble/Middle/ This menu is used to adjust the sound eff ects For example, you can set the sound close to Bass.
Page 133: Surround Sound
Settings Surround Sound Touch Tone Display This menu is used to turn the Surround Sound This menu is used to play a beep sound This menu is used to control the display on/off . whenever you operate the touch screen. brightness and image rate for the whole Press [HOME] >...
Page 134: Set Lcd Brightness
Settings Set LCD Brightness Mode Display Ratio This menu is used to set the LCD brightness. This menu is used to set the display brightness The screen ratio is used to set in video modes, according to mode changes. such as DVD, VCD, Jukebox video, USB video, 1.
Page 135: Reset
Settings Reset Bluetooth Auto Connection Priority This menu is used to reset all [Display] settings. If auto connection priority is turned on, This menu describes Bluetooth settings. a Bluetooth device will automatically be 1. Press [HOME] > [Settings] > [Display] > Bluetooth Connection connected according to the option setting [Reset].
Page 136: Auto Download
Settings Auto Download Audio Streaming Device Information When the Bluetooth device is connected, When audio streaming is set, you can play the This menu allows you to control additional contacts and call history are automatically music stored on a mobile device. When this Bluetooth®...
Page 137: Customer Center (Only For Usa)
Settings 2. Input the passkey using the keypad. Device Name Customer Center (Only for USA) 1. Press [HOME] > [Settings] > [Bluetooth] > This menu is used to check the customer Note [Device Information] > [Device Name]. center information for Bluetooth system. The passkey is a 4-digit authentication code Press [HOME] >...
Page 138: Voice Recognition
Settings Voice Recognition Clock Time Settings 1. Press [HOME] > [Settings] > [Clock] > [Time This menu describes voice recognition settings. This menu describes clock settings. Settings]. 1. Press [HOME] > [Settings] > [Voice GPS Time recongnition]. This menu is used to display time according to 2.
Page 139: Daylight Savings Time
Settings Daylight Savings Time Time Zone Clock Type This menu is used to turn on/off daylight This menu is used to select the time zone. This menu is used to set the type of clock saving time feature. displayed when the system power is turned 1.
Page 140: Time Format
Settings Time Format General This function is used to convert the digital Language clock display between 12 hour/ 24 hour systems. This menu is used to set the language of the system display and voice language. 1. Press [HOME] > [Settings] > [Clock] > [Time Format].
Page 141: Distance Unit
Settings Distance Unit Screen Saver Agreement Screen This menu is used to select the Distance Unit This menu is used to select the screen It sets the Agreement Screen displayed during to [mi] or [km]. displayed when the system power is turned the system booting to automatically disappear off .
Page 142: E-Manual
Settings E-Manual Skip Search You can see the previous or next page. 1. Press [MENU] > [Search] on the E-Manual You can see the E-Manual. screen. Push the controller to the left or right. 1. Press [HOME] > [Settings] > [E-Manual]. Zoom In/Out In the electronic manual screen, if you turn the controller left/right, you can enlarge/reduce,...
Page 143: System Info
Settings System Info Jukebox Info Update This menu is used to display the capacity of To order the latest map and software updates, Version the stored information on the Jukebox. please visit http://www.mapnsoft.com. For details about updates, check out the website before This menu option is used you to view the 1.
Page 144: Reset All
Settings • Turning off the power or ejecting the USB Reset All during the update process may result in This menu is used to reset all settings specifi ed data loss. Make sure to keep the ignition on by the user. and wait until updating is complete.
Page 145: Using Rear Camera - Option
Using Rear Camera - Option Using Rear Camera - Option Note About Rear Camera Rear camera has an optical lens to secure • Rear camera is an option for the customers wide view, so there is a little diff erence in the who selected the option.
Page 146: Using Pgs (Parking Guide System) - Option
Using PGS (Parking Guide System) - Option Using PGS (Parking Guide System) - Option It is the screen looking down the rear About PGS (Parking Guide Normal View direction of the vehicle from above, and System) 1. In top view screen, if you press [Normal the screen composition is as follows.
Page 147: Avm (Around View Monitor) - Option
AVM (Around View Monitor) - Option AVM (Around View Monitor) - Option b Front camera screen: screen of the front of About AVM (Around View Monitor) Operating rear AVM the vehicle is displayed through camera • AVM (Around View Monitor) is an option that After starting the vehicle, if you put gear at R c AVM side camera screen: According to the is provided to the customers who selected...
Page 148: Avm Setting
AVM (Around View Monitor) - Option • [General]: It sets/resets guide line steering Front passenger's door open indicator (Rear + left side display): It displays the interface and approaching obstacle warning vehicle’s rear screen and left rear screen at When the front passenger’s door is open, “ ” display function.
Page 149: Climate Mode
Climate Mode Climate Mode F A/C: It is displayed when A/C button • Rear Climate Control: Turns Climate Operating Climate Mode is selected, and air conditioner is Control for the rear seats on or off . 1. Press the CLIMATE key to display the operated for vehicle cooling.
Page 150: Blue Link (Only For Usa)
What is Blue Link? features can be used only after subscribing to For radio wave transmission/reception status, This is a Hyundai telematics service based the Blue Link service. refer to the status displayed on the Blue Link on our cutting-edge IT system that makes phone screen.
Page 151: Getting Started With Blue Link
Blue Link (Only for USA) 3. SOS button Getting Started with Blue Link Driving Info • Select to make an emergency call Use Blue Link features such as Driving Info and This service can be used while your car is to report a car accident, injury or Vehicle Diagnostics.
Page 152: Send To Car With Google
Blue Link (Only for USA) Send to Car with Google Vehicle Diagnostics Feature Description You can check information about a point of You can have your vehicle inspected only after A Call POI The phone number of a interest (POI) received via Google Local Search. stopping the vehicle because some control selected POI.
Page 153: Apps
Blue Link (Only for USA) Apps Blue Link Settings Downloaded Apps (Expected to Modem Information supporting) This feature is used to show the MEID modem information. Displays the applications that were downloaded through the Download Select [HOME] > [Blue Link] > [Blue Link Center.
Page 154: Wi-Fi Settings
• [Wi-Fi Network]: Registers a network ID/ Wi-Fi Settings Service Activation password to connect to a network AP This feature is used to set the WiFi Application. 1. Select [HOME] > [Blue Link] > [Blue Link (Access Pont). You can share a digital-device network with Settings] >...
Page 155: Before Thinking There Is A Product Defect
Before Thinking There is a Product Defect Before Thinking There is a Product Defect • When driving in heavy traffi c with frequent The current position as shown on the Correct route guidance may not occur starts and stops navigation may differ from the actual due to search conditions or driving position under the following conditions.
Page 156 Before Thinking There is a Product Defect These situations may occur after conducting route calculation. The following occurrences are not malfunctions: • Guidance may be given to a position diff ering from the current position when turning at an intersection •...
Page 157: Before Thinking The Product Has Malfunctioned
Before Thinking the Product has Malfunctioned Before Thinking the Product has Malfunctioned 1. Errors which occur during the operation or installation of the device may be mistaken as a malfunction of the actual device. 2. If you are having problems with the device, try the suggestions listed below. 3.
Page 158: Troubleshooting
Troubleshooting Troubleshooting Problem Possible Cause Countermeasure The power does not The fuse is disconnected. • Replace with a suitable fuse. turn on. • If the fuse is disconnected again, please contact your point of purchase or service center. Device is not properly connected. Check to see that the device has been properly connected.
Page 159 Troubleshooting Problem Possible Cause Countermeasure The sound or image The disc is dirty or scratched. Wipe off water or dirt from the disc. Do not use a disc which has been quality is low. scratched. Vibration is occurring from where the The sound may be short circuited and the image distorted if the device conversion switch has been installed.
Page 160: Trademarks And Licenses
Trademarks and Licenses Trademarks and Licenses DivX® DOLBY Gracenote® • ABOUT DIVX VIDEO: DivX® is a digital video Manufactured under license from Dolby CD, DVD, Blu-ray Disc, and music and video- format created by DivX, LLC, a subsidiary Laboratories. Dolby and double-D symbol are related data from Gracenote, Inc., copyright of Rovi Corporation.
Page 161: Hd Radio™ Technology
Trademarks and Licenses Gracenote® End User License Agreement and Gracenote Servers. Gracenote reserves Gracenote is not obligated to provide you with all rights in Gracenote Data, the Gracenote new enhanced or additional data types or This application or device contains software Software, and the Gracenote Servers, including categories that Gracenote may provide in the from Gracenote, Inc.
Page 162: Specification
Specification Specification AV/Navigation product specification Tuning range 530 kHz ~ 1710 kHz Power Supply DC 14.4 V Sensitivity 35 dBuV Operating Power DC 9 V ~ DC 16 V Frequency response 30 Hz ~ 10000 Hz Current Consumption Maximum 5 A Signal-to-noise ratio Minimum 45 dB Dark Current...
Page 163 Specification • To obtain the source code under GPL, LGPL, MPL and other open 233.95 mm (9.2 inches) source licenses, that is contained in this product, please visit http:// Screen Size 204 (W) x 114.72 (H) mm opensource.lge.com . In addition to the source code, all referred (Active area) license terms, warranty disclaimers and copyright notices are available Resolution...
Page 164: Blue Link Terminal Product Specification
• You can check the contents of open license and legal notice in the equipment (Model Unit Assy I-BOX (TS310B1AX) following sites. name) http://www.mobiszone.co.kr → customer support → download Manufactured date 2014. . . center or http://www.mobiszone.co.kr/front/mall/jsp/manual/ avn_ Manufacturer / download_center_manual.jsp Hyundai Mobis Co., Ltd. / Korea Country...
Page 165 P/N: MFL67720946...

Hyundai Genesis2015 Owner's Manual

Precautions for Safety

Table of Contents

General Information

Name of each Component

Basic Operation

Radio Operation (FM/AM)

Radio Operation (Siriusxm)

Audio CD/ MP3 CD Operation

DVD/VCD Operation

Jukebox Operation

USB Operation

Ipod Operation

Pandora Radio Operation

(Only for USA)

Auxiliary Device Operation

Bluetooth Audio

Getting Started with Navigation

Searching for Destination of Navigation

Using the Route Menu

Bluetooth® Wireless Technology

Voice Recognition System

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hyundai Genesis2015

Summary of Contents for Hyundai Genesis2015
