305cm (10ft) Trampoline

S001964

ATTENTION!

SAFETY INFORMATION, INSTALLATION, CARE

AND MAINTENANCE INSTRUCTIONS.

READ PRIOR TO ASSEMBLING AND USING THE TRAMPOLINE.

WARNING: To ensure your safety, please do not attempt to assemble this trampoline without reading this

instruction manual carefully. Failure to comply with this warning may result in injury and/or property damage.

• Prior to assembly, this trampoline includes small parts/accessories that are not suitable for children under 3

years of age as they may cause a choking hazard.

• This trampoline should be assembled by 2 adults.

• Only use this trampoline on a soft, flat level surface.

• This trampoline has a maximum user weight of 100kg.

• T his trampoline is suitable for users aged 6 years and over.

• Do not allow more than 1 person on the trampoline at any time.

• T his trampoline is designed for domestic use only, it is not intended for gymnastics or high level acrobatic stunts.

For parts and service enquiries, please contact Action Spares on 1800 465 070 or e-mail service@actionspares.com.au

Table of Contents

Need help?

Do you have a question about the S001964 and is the answer not in the manual?

Questions and answers

Summary of Contents for Action S001964

Page 1 305cm (10ft) Trampoline S001964 ATTENTION! SAFETY INFORMATION, INSTALLATION, CARE AND MAINTENANCE INSTRUCTIONS. READ PRIOR TO ASSEMBLING AND USING THE TRAMPOLINE. WARNING: To ensure your safety, please do not attempt to assemble this trampoline without reading this instruction manual carefully. Failure to comply with this warning may result in injury and/or property damage.
