Summary of Contents for Planar PL150
- Page 1 PLANAR LCD MONITOR PL150 MANUAL www.planar.com...
-
Page 2: Important Safety Instructions
Important Safety Instructions Read the Safety Instructions carefully and keep it for later use. Be aware of all warnings and instruction signs marked on the products. When cleaning, cut off the electrical supply at all times. Never use liquid or aerosol detergent, use a damp rag instead. -
Page 3: Table Of Contents
Contents Note: To access our Users Guide Homepage (Page 2) at anytime, simply click on the below Homepage icon or use the arrow icon(s) to browse through each page. When in Homepage, clicking on your desired topic will automatically open each Important Safety Instructions ...1 Getting Started...3 Package Contents...3... -
Page 4: Getting Started
Getting Started Congratulations on your purchase of this TFT LCD Monitor. Please read this section carefully to get instant understanding of this product and its correct operations. Important! Please keep the original carton and all packing materials for future shipping needs. Package Contents Your TFT LCD Monitor package includes the following items: 15”... -
Page 5: Precautions
Precautions Sit at least 18"(45 cm) away from the screen when in use. Do not press on the LCD panel as it is very fragile. Do not touch the LCD panel with your bare hands. Oil from your skin is difficult to remove and may damage the screen. -
Page 6: Adjusting The Monitor
Adjusting the Monitor Standing Up the Monitor Press down on the stand with one hand, and lift up the screen gently (see Figure A below). Adjusting the Monitor Press down on the stand and gently adjust the monitor to a suitable viewing angle (see Figure B below). -
Page 7: Quick Installation
Quick Installation Make sure the computer is turned off. Attach the female end of the power cord (Indication A) to the adapter (Indication B), then plug the adapter connector to the power “DC-IN (Indication D)” jack of the LCD monitor. When using a power cord, plug the male end into the wall socket. -
Page 8: Operations
Operations Push the power button (Indication E) on the front of the LCD monitor to turn it on. When the power light (Indication F) turns green, the LCD is ready to use. Push the power switch button to turn off. Function Keys Menu A. -
Page 9: Osd Main Menu
OSD Main Menu For screen adjustments, press the [Menu] button to display the OSD (On-Screen Display) Main Menu shown below. Press the [+] or [ ] button to scroll up or down the menu to your required options. Please note that the OSD will automatically turn off in 30 seconds without any manipulation or by simply pressing the [Menu] button for 2 seconds. -
Page 10: Color Sub-Menu
COLOR Sub-Menu Under the Main Menu, select COLOR using the [+] or [ ] button, then press [Menu] button to activate the COLOR Sub-Menu shown as above. Under the COLOR Sub-Menu, press [+] or [ ] button to scroll up or down to your desired preset color mode. -
Page 11: Misc Sub-Menu
H SIZE Adjusting the width of the screen image. Select H-SIZE, using [+] or [ ] button, then press [Menu] button to activate the function. Press [+] button to increase the width of the screen image, press [ ] button to decrease the width of the screen image shown below. Press [Menu] to return to LCD ADJUST Sub-Menu. - Page 12 H OSD POSITION Moving the OSD position on the screen to the right or left. Select H-OSD POSITION using [+] or [ ] button, then press [Menu] button to activate the function. Press the [+] button to move the OSD position to the right, [ ] button to move left. Then Press [Menu] to return to MISC Sub-Menu after adjustment.
-
Page 13: Easy Wall-Mounting Instructions
Easy Wall-Mounting Instructions The design of this monitor not only allows you to mount the display on the wall with wall mounting kit, but also offers you another easy wall-mounting option without any mounting kit. Please refer to the easy wall-mounting operations below. First, please fold back the display. -
Page 14: Technical Data
Technical Data Specifications Size Type Color Glass surface Input Signal Video Video Sync Sync Compatibility Macintosh® Resolution Primary Mode Power Voltage Connector Input Signal Display Area Full screen Operating Temperature Conditions Humidity Altitude Storage Temperature Conditions Humidity Altitude Dimensions Physical Package Weight Gross... -
Page 15: Factory Preset Timings
Factory Preset Timings Timing VGA 640 X 350 VGA 720 X 400 VGA 640 X 400 VESA 640 X 480 VESA 640 X 480 VESA 640 X 480 VESA 640 X 480 VESA 800 X 600 VESA 800 X 600 VESA 800 X 600 VESA 800 X 600 VESA 832 X 624... -
Page 16: Appendix
Appendix FCC Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 17 Tel: 1-866-PLANAR-1 (1-866-752-6271) Hours: M-F, 7am - 6pm Pacific Time © 2002 Planar Systems, Inc. 04/02 Planar is a registered trademark of Planar Systems, Inc. Other brands and names are the property of their respective owners. Technical information in this document is subject to change without notice.
