DANTA
installation, servicing and user instructions
500 - 800 - 1100 - 1400 - Koto
includes Front, Corner, Bay and Room Divider
This appliance has been tested and certified for other counties (see technical data). However
to install appliance in other countries, modification of the appliance and its method
of installation may be necessary in order to use the appliance safely and correctly. The
manual for the local language must be obtained. Contact Wanders for further information.
v.3.3-082017
GB
IE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DANTA 500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for WANDERS DANTA 500

  • Page 1 The manual for the local language must be obtained. Contact Wanders for further information.
  • Page 3: Table Of Contents

    5.2.4 Danta 1400 6. Electric wiring © Copyright 2014 Wanders res & stoves The information contained herein is subject to change without notice. Wanders res & stoves shall not be liable for technical or editorial errors or omissions contained herein.
  • Page 4: General Notes

    1. General Notes This Wanders gas appliance is a High Efficiency, Balanced Flue Live Fuel Effect appliance. It provides radiant and convected heat using the latest burner technology. As well as having a variable heat output, these fires also utilise a special control system that allows the appliance to use two burners for high output or a single burner for lower outputs.
  • Page 5: User Instructions

    Operation (optional Wanders EcoWave app) It is possible to order the optional Wi-Fi module in order to operate the fireplace using the Wanders EcoWave app, The app can be downloaded for free at the Apple App Store and/or the Google Play Store. Incidentally, the app can only be used in combination with the SYMAX EcoWave remote control.
  • Page 6: Batteries

    An alternative AC Mains Adaptor may be used to power the Receiver instead of the 4 AA batteries. Only an AC Mains Adapter supplied by Wanders may be used. The Mains Adaptor is plugged into the DC 6V socket on the end of the receiver.
  • Page 7: To Turn The Appliance Off

    installation, servicing and user instructions manual | GB + IE • Simultaneously press and hold buttons B & C (Star and Large Flame), until a short acoustic beep confirms the start sequence has begun; release the buttons. • Continuing signals confirm the ignition is in process. •...
  • Page 8: Installation Instructions

    3. Installation instructions Before commencing Installation, confirm that the details on the appliance data plate correspond to the local distribution conditions, gas type and pressure to which the appliance is to be installed. Ensure that gas supply and supply pipe is capable of delivering the required volume and pressure of gas and is in accordance with the rules in force.
  • Page 9: Built-In Fireplace Sizing (Assuming A Cement Board Lining Is Used)

    installation, servicing and user instructions manual | GB + IE 3.3.2 Built-In Fireplace Sizing (assuming a Cement Board Lining is used) Free Vent Area 200 cm² Control Access Door Cut-out Detail Y Max. Plaster point Max plaster Built in fireplace sizing Bay and Room Divider Free Vent Area 200 cm²...
  • Page 10 A min B min C min D min E min F min G min G2 min H min Danta 500 Front Danta 500 Bay Danta 500 Corner Danta 800 Front Danta 800 Bay Danta 800 Corner Danta 1100 Front 1115 1150...
  • Page 11: Mantel Clearances

    installation, servicing and user instructions manual | GB + IE 3.3.4 Mantel Clearances 3.3.4.a Combustible Mantel – Side view Ceiling Mantel Projection (from face of Cement Board) (2") (4") (6") (8") (10") (12") 450 (18") 400 (16") 350 (14") 300 (12") Cement Board Minimum 250 (10")
  • Page 12 3.3.4.b Combustible Mantel/Side Wall – Top view Fireplace Opening Cement Board Minimum Thickness 12mm Area denotes allowable location for combustible mantel 25 (1") 50 (2") Face of Finished 75 (3") Wall Wall 100 (4") Detail A Min. 150 (6") between edge of opening and wall...
  • Page 13: Flue Connection

    This appliance may only be used with Balanced Flue (otherwise known as Concentric Flue) parts as specified by Wanders. The Wanders specified flue parts have been approved with the appliance. If the appliance is installed on non-Wanders approved parts, Wanders cannot guarantee or accept and responsibility for the proper and safe working of the appliance.
  • Page 14: Terminal Locations

    3.4.5 Terminal Locations Dimension Terminal Position Distance (mm) Directly below an opening, air brick, opening window etc. Above an opening, air brick, opening window etc. Adjacent to an opening, air brick, opening window etc. Below gutters, soil pipes or drain pipes Below eaves Below balconies of car port roof From a vertical drain pipe or soil pipe...
  • Page 15: Horizontal Wall Vent Termination Type C11

    | GB + IE 3.4.6 Horizontal Wall Vent Termination type C11 Flue sizing: Danta 500: Ø100/150 Connector on Appliance. Ø100/150 to be used Throughout. Flue Terminal: Ø100/150 Part No. INK.4330 Danta 800, 1100, 1400 & Koto: Ø130/200 Connector on Appliance.
  • Page 16: Vertical Roof Vent Termination C31

    Ø130/200 Connector on Appliance,Ø130/200 to be used Throughout. Flue Terminal: Ø130/200 Part No. n/a Minimum Vertical Flue Height: 0.5m Vertical Rise (m) (Max.) MAXIMUM VERTICAL FLUE FOR DANTA 500 AND FLUE RESTRICTOR SELECTION 100/150 FLUE USED THROUGHOUT 3-11m 50mm RESTRICTOR 50mm RESTRICTOR...
  • Page 17 installation, servicing and user instructions manual | GB + IE Vertical Rise (m) (Max.) MAXIMUM VERTICAL FLUE FOR DANTA 800 AND 7-11m 60mm FLUE RESTRICTOR SELECTION RESTRICTOR 200/130 SPIGOT ON APPLIANCE 200/130 - 150/100 REDUCER ONTO SPIGOT, 150/100 FLUE USED THERE AFTER.
  • Page 18 Vertical Rise (m) (Max.) MAXIMUM VERTICAL FLUE 8-11m 60mm FOR DANTA 1100 (& KOTO) AND RESTRICTOR FLUE RESTRICTOR SELECTION 200/130 SPIGOT ON APPLIANCE 200/130 - 150/100 REDUCER ONTO SPIGOT, 150/100 FLUE USED THERE AFTER. 3-8m 50mm RESTRICTOR 60mm RESTRICTOR 50mm 1-3m 35mm RESTRICTOR RESTRICTOR...
  • Page 19 installation, servicing and user instructions manual | GB + IE Vertical Rise (m) (Max.) MAXIMUM VERTICAL FLUE FOR DANTA 1400 AND 7-11m 60mm FLUE RESTRICTOR SELECTION RESTRICTOR 200/130 SPIGOT ON APPLIANCE 200/130 FLUE USED FOR 1st METRE (Min), THEN 200/130 - 150/100 REDUCER 150/100 FLUE USED THERE AFTER.
  • Page 20: Typical Installations Roof Vent Termination C31

    3.4.8 Typical Installations Roof Vent Termination C31...
  • Page 21: Fuel Bed Media And Arrangements

    installation, servicing and user instructions manual | GB + IE 3.5 Fuel Bed Media and Arrangements When arranging the Media in the Fire, it is always important to keep the Pilot area clear and ensure smooth cross lighting from the Pilot to the Main Burner and of the Eff ect burner from the Main burner. Prevent that the embers block the pilot fl ame (A) and the burner holes (B) to keep the fi re safe and free from soothing.
  • Page 22: Danta 500

    Used logs: B - D - D - G (See page 26 for additional information) 3.5.1 Danta 500 Used logs: A - D - D - G - G - E - F (See page 26 for additional information) 3.5.2 Danta 800...
  • Page 23: Danta 1100

    installation, servicing and user instructions manual | GB + IE Used logs: A - D - D - G - G - E - F (See page 26 for additional information) 3.5.3 Danta 1100...
  • Page 24: Danta 1400 & Koto

    Used logs: A - D - D - G - G - E - F - H - H (See page 26 for additional information) 3.5.4 Danta 1400 & Koto...
  • Page 25: Pebbles

    installation, servicing and user instructions manual | GB + IE 3.5.5 Pebbles • Scatter the bag of Pebbles over the top of the Burners and Grate, making sure that the Pilot area is left clear. • Ensure smooth cross lighting of the Burners. 3.5.6 Stones •...
  • Page 26: Commissioning The Appliance

    3.6 Commissioning the Appliance 3.6.1 Pilot Ignition Check 1. Ignite the pilot light as described in the User Instructions 2. Check that the pilot fl ame stays alight 3. Extinguish the pilot light 3.6.2 Main Burner Check 1. Ignite the pilot light as described in the User Instructions 2.
  • Page 27: Servicing

    Turn the appliance OFF and isolate the gas supply. Ensure the appliance is fully cold before attempting to start servicing the appliance. No liability can be accepted by Wanders for injury caused by burning or scolding by a hot appliance.
  • Page 28: Spare Parts

    4.3 Spare parts Part description Partnumber for Partnumber for Partnumber for Partnumber for Partnumber for Danta 500 Danta 800 Danta 1100 Danta 1400 Koto Glass (front) GLA.00.0770 GLA.00.0750 GLA.00.0720 GLA.00.0700 GLA.00.0798 Glass (side) GLA.00.0730 Glass (back) GLA.00.0780 GLA.00.0760 GLA.00.0740 GLA.00.0710 GLA.00.0798...
  • Page 29: Technical Information

    installation, servicing and user instructions manual | GB + IE 5. Technical Information 5.1 Countries of Use Code Country Natural Austria I2H, G20 at 20 mbar I3P(50),G31 at 50 mbar; I3B/P(50),G30/G31 at 50 mbar Belgium I2E+, G20/G25 at 20/25 mbar I3+,G31/G31 at 28/37 mbar;...
  • Page 30: Technical Data

    5.2 Technical Data Product Identification Number: • 0359CO1364 for Danta, • 0359CP1411 for Koto 5.2.1 Danta 500 G20/G25 G25/G25.3 G20/G25 G30/G31 Gas type I3B/P I2H, I2E I2E+ I2L/I2EK I2ELL I3P (30) (30/50) (37/50) Supply pressure mbar 20/25 30/50 28-30/37 37/50...
  • Page 31: Danta 1100 & Koto

    installation, servicing and user instructions manual | GB + IE 5.2.3 Danta 1100 & Koto G20/G25 G25/G25.3 G20/G25 G30/G31 Gas type I3B/P I2H, I2E I2E+ I2L/I2EK I2ELL I3P (30) (30/50) (37/50) Supply pressure mbar 20/25 30/50 28-30/37 37/50 Nominal heat input gross (Hs) 10,8 10,8 10,8...
  • Page 32: Electric Wiring

    6. Electric wiring...
  • Page 33 installation, servicing and user instructions manual | GB + IE...
  • Page 35 De garantie vervalt and change of owner. The guarantee is also disclaimed par WANDERS , d’un défaut d’ e ntretien et en cas où le poêle serait Installateur, Vernachlässigung des Ofens und bei einem ook bij gebruik van een verkeerde brandstof.
  • Page 36 Amtweg 4 Fax: +31 (0)315 - 386 201 7077 AL NETTERDEN info@wanders.nl Type- en zetfouten voorbehouden. Wanders fi res & stoves is een onderdeel van de Wanders Groep The Netherlands www.wanders.nl © 2014 Wanders Metaalproducten B.V. - All rights reserved...
