LENGA
Installation, Servicing and User instructions
500 - 800 |
Front, Bay and Corner
This appliance has been tested and certified for other counties (see technical data). However to install
EN
appliance in other countries, modification of the appliance and its method of installation may be
necessary in order to use the appliance safely and correctly. The manual for the local language must be
obtained. Contact Wanders for further information.
v.1.0-112016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lenga 500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for WANDERS Lenga 500

Summary of Contents for WANDERS Lenga 500

  • Page 1 The manual for the local language must be obtained. Contact Wanders for further information. v.1.0-112016...

  • Page 2: Table Of Contents

    5.3.2.d Lenga 800 ABE Electrical diagram © Copyright 2016 Wanders res & stoves The information contained herein is subject to change without notice. Wanders res & stoves shall not be liable for technical or editorial errors or omissions contained herein.

  • Page 3: General Notes

    1. General Notes • This Wanders gas appliance is a High Efficiency, Balanced Flue Live Fuel Effect appliance. It provides radiant and convected heat using the latest burner technology. As well as having a variable heat output, these fires also utilise a special control system that allows the appliance to use two burners for high output or a single burner for lower outputs.

  • Page 4: User Instructions

    Please refer to the separately added manual for the SYMAX remote control system. 2.3 Wanders Eco Wave App control (optional) Please refer to the separately added manual for the Wanders Eco Wave control system. 2.4 Cleaning and Maintenance This appliance should be inspected and serviced once a year by a qualified, competent and registered person.

  • Page 5: Building The Fireplace

    Provide ventilation from the fireplace to the minimum amount quoted in 3.3 above. • Provide a cut-out for the Control Access Door. 3.3.2 Built-In Fireplace Sizing (assuming a Cement Board Lining is used) Appliance Lenga 500 A 1235 Lenga 500 ABC 1235 Lenga 500 AB/AC 1235...

  • Page 6: Mantel Clearances

    3.3.3 Mantel Clearances 3.3.3.a Combustible Mantel - side view...
  • Page 7 Installation, Servicing and User Instructions | EN 3.3.3.b Combustible Mantel/Side Wall - top view...

  • Page 8: Flue Connection

    This appliance may only be used with Balanced Flue (otherwise known as Concentric Flue) parts as specified by Wanders. The Wanders specified flue parts have been approved with the appliance. If the appliance is installed on non-Wanders approved parts, Wanders cannot guarantee or accept and responsibility for the proper and safe working of the appliance.

  • Page 9: Terminal Locations

    Installation, Servicing and User Instructions | EN 3.4.5 Terminal Locations Dimension Terminal Position Distance (mm) Directly below an opening, air brick, opening window etc. Above an opening, air brick, opening window etc. Adjacent to an opening, air brick, opening window etc. Below gutters, soil pipes or drain pipes Below eaves Below balconies or car port roof...

  • Page 10: Horizontal Wall Vent Termination Type C11

    3.4.6 Horizontal Wall Vent Termination type C11 Flue sizing and regulations. Lenga 500 • Ø100/150 Connector on appliance. • Ø100/150 to be used throughout. • Maximum horizontal length is 3 meters. • Minimum vertical length directly on appliance is 1 meter.

  • Page 11: Typical Installations

    Installation, Servicing and User Instructions | EN Lenga 800 Wall terminal: • Ø130/200, vertical rise 1 meter, no restrictor • Ø130/200, vertical rise 1-2 meter, 35 mm restrictor • Ø130/200, vertical rise > 2 meter, 50 mm restrictor Roof terminal: •...

  • Page 12: Fuel Bed Media And Arrangements

    3.5 Fuel Bed Media and Arrangements Please note that all arrangements are viewed from the front of the appliance, with the main burner at the front (eff ect burner at the rear). Lenga 500 01 -  02 - ...
  • Page 13 Installation, Servicing and User Instructions | EN When arranging the media in the fi re, it is always important to keep the mainburner (MAIN) clear from media unless otherwise instructed. The main burner needs to have an uninterupted connection with the pilot burner (PILOT) and with with logs of the eff...
  • Page 14 Place log 04 on the burner plate as shown on the image. The log leans on log 03 and against log 02. Place log 01 on burner port BP 2 as shown on the image. The log leans against log 02 at the top. Make absolutely sure the log slides all the way over the connection.
  • Page 15 Installation, Servicing and User Instructions | EN Place log 08 in the left front corner on the burner as shown on the image. Place log 06 on the right side of the burner as shown on the image. Place log 07 in front left of the middle as shown on the image.
  • Page 16 Place the ceramic fi bers (10). on the main burner (MAIN) and secure them with some small embers (09). Make absolutely sure the ember don’t block the main burner (MAIN). Scatter the remaining embers (09) evenly on the burnerplate. Make absolutely sure the embers don’t block the main burner (MAIN).

  • Page 17: Lenga 800

    Installation, Servicing and User Instructions | EN Lenga 800 01 -  02 -  03 -  04 -  05 -  06 -  07 -  08 -  09 -  10 -  11 -  12 - ...
  • Page 18 13 -  14 -  15 -  When arranging the media in the fi re, it is always important to keep the mainburner (MAIN) clear from media unless otherwise instructed. The main burner needs to have an uninterupted connection with the pilot burner (PILOT) and with with logs of the eff...
  • Page 19 Installation, Servicing and User Instructions | EN Place log 06 on the burner plate as shown on the image. Place log 09 on the left side of the burner plate as shown on the image. Place log 08 on the right side of the burner plate as shown on the image. The log leans against log 04.
  • Page 20 Place log 05 on the back of the burner plate as shown on the image. Place log 07 on the left of the burner plate as shown on the image. Place log 01 on burner port BP 3 as shown on the image. The log leans against log 04. Make absolutely sure the log slides all the way over the connection.
  • Page 21 Installation, Servicing and User Instructions | EN Place log 02 on burner port BP 2 as shown on the image. The log leans against log 01. Make absolutely sure the log slides all the way over the connection. Place log 03 on burner port BP 1 as shown on the image. The log leans against log 02. Make absolutely sure the log slides all the way over the connection.
  • Page 22 Scatter the remaining embers (13) evenly on the burnerplate. Make absolutely sure the embers don’t block the main burner (MAIN). Place log 10 on the front of the burner plate as shown on the image. Place log 11 on the embers between log 02 and 09 as shown on the image.
  • Page 23 Installation, Servicing and User Instructions | EN Place log 12 on the embers in the left back corner as shown on the image. Scatter the vermiculite grains (15) evenly over the burnerplate. Make absolutely sure the grains don’t block the main burner (MAIN). At this last step also ensure that the front of the burner plate, as marked on the image, is free of decoration.

  • Page 24: Commissioning The Appliance

    Turn the appliance OFF and isolate the gas supply. Ensure the appliance is fully cold before attempting to start servicing the appliance. No liability can be accepted by Wanders for injury caused by burning or scolding by a hot appliance.

  • Page 25: Cleaning The Ceramics

    Gently clean the ceramics in the open air, using a soft brush and a vacuum cleaner. Where necessary replace damaged components only with genuine Wanders specifi ed parts. Seal any scrap ceramics in plastic bags and dispose at proper refuse sites. When using a vacuum cleaner, it is recommended that one with a HEPA fi ltering system is used.

  • Page 26: Technical Information

    5. Technical Information 5.1 Countries of use Code Country Natural Austria I2H, G20 at 20 mbar I3P(50), G31 at 50 mbar; I3B/P(50), G30/G31 at 50 mbar I3+, G31/G31 at 28/37 mbar; I3P(37), G31 at 37 mbar; Belgium I2E+, G20/G25 at 20/25 mbar I3B/P(30), G30/G31 at 30 mbar Bulgaria I2H, G20 at 20 mbar...

  • Page 27: Technical Data

    Installation, Servicing and User Instructions | EN 5.2 Technical Data Product Identification Number: 0359CO0001254 5.2.1 Lenga 500 G20/G25 G25/G25.3 G20/G25* G30/G31 Gas type I3B/P I2H, I2E I2E+ I2L/I2K I2ELL I3P (30) (30/50) (37/50) Supply Pressure mbar 20/25 30/50 28-30/37 37/50...

  • Page 28: Dimensions

    5.3 Dimensions 5.3.1.a Lenga 500 A 488,00 554,00 388,30 366,00 100/150 M&G 469,00 5.3.1.b Lenga 500 AB 488,00 575,00 100/150 388,30 368,00 M&G 254,80 479,00...

  • Page 29: Lenga 500 Ae

    Installation, Servicing and User Instructions | EN 5.3.1.c Lenga 500 AE 488,00 575,00 388,30 100/150 M&G 254,80 479,00 5.3.1.d Lenga 500 ABE 488,00 288,50 600,00 376,00 554,00 100/150 M&G 254,80 500,00 554,00...

  • Page 30: Lenga 800 A

    5.3.2.a Lenga 800 A 788,00 854,00 390,30 130/200 M&G 368,00 769,00 5.3.2.b Lenga 800 AB 788,00 875,00 388,30 130/200 M&G 368,00 254,80 779,00...

  • Page 31: Lenga 800 Ae

    Installation, Servicing and User Instructions | EN 5.3.2.c Lenga 800 AE 788,00 875,00 130/200 M&G 368,00 390,30 254,80 779,00 5.3.2.d Lenga 800 ABE 854,00 900,00 130/200 M&G 376,00 800,00 254,80...

  • Page 32: Electrical Diagram

    Electrical diagram  OPTIONAL WiFi/APP (excl. tablet and router)  OPTIONAL MODULE (INK.3255)
  • Page 33 Installation, Servicing and User Instructions | EN...
  • Page 35 De garantie vervalt and change of owner. The guarantee is also disclaimed par WANDERS , d’un défaut d’ e ntretien et en cas où le poêle serait Installateur, Vernachlässigung des Ofens und bei einem ook bij gebruik van een verkeerde brandstof.
  • Page 36 Tel: +31 (0)315 - 386 414 Amtweg 4 Fax: +31 (0)315 - 386 201 7077 AL NETTERDEN info@wanders.nl Type- en zetfouten voorbehouden. Wanders fi res & stoves is een onderdeel van de Wanders Groep Nederland www.wanders.nl © 2014 Wanders Metaalproducten B.V. - All rights reserved...

This manual is also suitable for:

Lenga 800
