- Page 1 User Manual 5 Port HDR HDMI Switcher...
- Page 2 Introduction Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Our series of converters, switchers, extenders, matrixes and splitters are designed to make your A/V device use more convenient, more comfortable, more productive and more cost-efficient.
- Page 3 Support 4K@60Hz UHD signal input and output. Support Remote control and HDMI auto switch. LED Status Light shows clearly the working state. In 4K@60Hz HDMI UHD resolution, HDMI Input and Output distance can be up to 5m using the AWG26 standard HDMI Cable.
- Page 4 A: HDMI Input One, Two, Three, Four, Five Port B: HDMI Output Port C: 5V DC Port Remote Button Function Showing “OFF” ：Standby Button, when device is working normally, it will go to Standby status if you press the button and also the Standby Led Status Light will go bright;...
- Page 5 “ON” ：Start Button, when device is Standby status, it will go to working normally if you press the button and also the Standby Led Status Light will go off; 1, 2, 3, 4, 5: HDMI Input Channel Switch Button. When you press the “1” Button, the device will goes to the matched input 1 channel.
- Page 6 Spec: HDSW0015M1 HDMI Resolution…………...24/50/60fs/2160P/1080P/1080i/720p/576p/576i/480P/480i Deep Color …………24/30/36bit/1080P/1080i/720p/576p/576i/480P/480i,24bit/2160P HDMI In/Out Supported Audio Format………………………………………………………… DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3 HDMI Channel Max Bandwidth………………………………………………………450MHz Input / Output DDC signal…………………………………………………….… 5Vp-p(TTL) HDMI Input Cable Length……………….…………..…≤5m AWG26 HDMI standard cable HDMI Output Cable Length……………………..….….≤5m AWG26 HDMI standard cable Max Working Current…………………………………..……………………..…………600mA Working Temperature Range……………………………………..……………(-0 to +40℃)
- Page 7 7. Pls use the original factory power adaptor. 8. .It does not support the conversion between DVI and HDMI signal Pls use your signal source and display following the correct process. Before power on, pls check the connection line carefully. And make sure that all interfaces are normally connected.
