Page 1: User Manual
User Manual HD-HU-SP-TX / HD-HU-SP-RX HDBaseT 2.0 and USB Transmitter / Receiver 244 Bergen Boulevard, Woodland Park, NJ 07424 • Tel 973-785-4347 • FAX 973-785-3318 • Web: www.fsrinc.com 43154 LIT1639A... -
Page 2: Important Safety Instructions
4. Do not install near any heat 9. Only use sources such as radiators, heat attachments/accessories registers, stoves, or other device specified by FSR. (including amplifiers) that produce heat. 5. Do not place sources of open 10. Refer all servicing to... -
Page 3: Table Of Contents
Table of Contents Overview ....................4 Features ....................5 Package Contents ..................6 Typical Application ..................7 Panel Layout .................... 8 Hardware Installation................16 USB Connections ................... 18 RS-232 Control and Firmware Updates ..........20 Specifications ..................21... -
Page 4: Overview
Overview Based on HDBaseT 2.0 Technology, these true HDBaseT 5-Play devices transmit HD Video (up to 4k @60hz.), Audio, Bi-Directional Control (IR & RS-232), Ethernet, and Bi-directional Power via 1 CAT-6A shielded cable up to 100 Meters. Long Reach Mode and increases the usable CAT6A shielded cable length of up to150m / 492ft with up to a 1920x1080p HD video@60Hz / 24bit Deep Color signal. -
Page 5: Features
Features True HDBaseT 5-Play HDMI transmissions using single cable Cat5e cable under recommended conditions: 90m/295ft: 4096 x 2160 video@30Hz / 24bit True Color with Chroma subsampling color palette 4K@60Hz 4:2:0 - 100m/328ft: 1920x1080p HD video@60Hz / 36bit Deep Color Via Cat6/6a/7 cables: 100m/328ft: 4096 x 2160 video@30Hz / 24bit True Color with Chroma subsampling color palette 4K@60Hz 4:2:0... -
Page 6: Package Contents
Package Contents One HD-HU-SP-TX Transmitter One HD-HU-SP-RX Receiver One Power Supply 12VDC / 2A Two 3.5mm Phoenix Male Connectors (2 Pin) Two 3.5mm Phoenix Male Connectors (3 Pin) Two IR Emitters Two Wide-band IR Receivers (30KHz~50KHz) ... -
Page 7: Typical Application
Typical Application NOTE: It is only necessary to power one side (Tx or Rx) -
Page 8: Panel Layout
Panel Layout Transmitter Front Panel Name Description Enables/disables the Long Reach Mode, RS232 updates /pass-through the device Choose USB Device or USB Host mode ON: The transmitter is powered on Power LED OFF: The transmitter is powered off Flashing Slowly: Status LED The transmitter is working properly OFF: The transmitter is not working properly... - Page 9 SET DIP switch Settings The SET DIP switch is capable of setting the RS232 firmware update or RS232 pass through function, choosing USB device or USB Host mode and enabling/disabling the Long Reach Mode. NOTE: SET switches that are marked in grey indicate the switch can be in any position.
- Page 10 The second switch is used for controlling the USB HOST/DEVICE mode on the Rx and Tx Units: NOTE: The second switch must be in the same position on both the Transmitter and Receiver: Set Tx Unit to be USB Host and Rx Unit to be USB Device Note: Reboot the device to make the change effective.
- Page 11 Rear Panel Name Description 12V DC power input, Threaded port for standard or locking connection DC 12V 2-pin phoenix port for alternate power connection HDBT OUT Connects to HDBT IN port of HDBT receiver Analog audio input, 3.5mm analog audio pass through from transmitter input to receiver output LINE IN over HDBaseT.
-
Page 12: Front Panel
Receiver Front Panel Name Description Enables/disables the Long Reach Mode, RS232 updates /pass-through the device Dip Switch Choose USB Device or USB Host mode ON: The receiver is powered on Power OFF: The receiver is powered off Flashing Slowly: The receiver is working properly. Status OFF: The receiver is not working properly ON: HDCP video is being transmitted... - Page 13 SET DIP switch Settings The SET switch is capable of setting the RS232 function, choosing USB device or USB Hose mode, enabling/disabling the Long Reach Mode. Note: SET switches that are marked in grey indicate the switch can be in any position.
- Page 14 Set Rx Unit to be USB Host and Tx Unit to be USB Device Note: Reboot the device to make the change effective. NOTE: The second switch must be in the same position on both the Transmitter and Receiver: The third switch is used for controlling the Long Reach Mode: This increases the usable CAT6A shielded cable length of up to150m/492ft when using up to a 1920x1080p HD video@60Hz / 24bit Deep Color signal.
- Page 15 Rear Panel Name Description 12V DC power input, DC 12V -threaded port for standard or locking connection -two-pin phoenix port for alternate power connection HDBT IN Connects to HDBT OUT port of HDBT transmitter Analog audio output, 3.5mm analog audio pass LINE OUT through from transmitter in to receiver out over HDBT.
-
Page 16: Hardware Installation
Hardware Installation Using quality HDMI cables, connect an HDMI source (such as Blu-ray, games console, satellite/cable TV, media server etc.) to HDMI IN of the Transmitter. Connect a good quality, well terminated, shielded Catx cable between the HDBT OUT of the Transmitter to the HDBT IN of the Receiver. Connect the HDMI display device (LED/LCD display or projector) to the HDMI OUT of the Receiver. - Page 17 Check Power, Status, and HDCP & Link lights are illuminated on both units to indicate successful connection, with a lit HDCP light illustrating the presence of encryption within the signal. Power and Link are status lights. Status should be blinking.
-
Page 18: Usb Connections
USB Connections NOTE: The USB 1 and USB 2 signal paths shown above cannot be used at the same time. Only one USB host is allowed at any one time. SET switches that are marked in grey indicate the switch can be in any position. Mode 1: Transmitter in USB Host Mode and Receiver in USB Device Mode The second switch must be up on both Transmitter and Receiver: Mode 2: Transmitter in USB Device Mode and Receiver in USB Host Mode... - Page 19 IR and RS-232 Operation...
-
Page 20: Rs-232 Control And Firmware Updates
RS-232 Control and Firmware Updates The RS-232 port can be used as pass-through to control a device connected to the Transmitter from the Receiver or vice versa. In addition, the RS-232 port on the Transmitter or Receiver can be connected to a computer to update the firmware. -
Page 21: Specifications
Specifications Transmitter Technical 1 x HDMI IN Input 1 x Analog Stereo Audio IN HDMI 1.4, and compatible with HDMI 2.0 Input Signal Type (4K 60Hz with 4:2:0 coding) HDCP 2.2 800x600@60Hz, 848x480@60Hz, 1024x768@60Hz, 1280x768@60Hz, 1280x800@60Hz, 1280x960@60Hz, 1280x1024@60Hz, 1360x768@60Hz, 1366x768@60Hz, 1440x900@60Hz, 1600x900@60Hz, 1600x1200@60Hz, 1680x1050@60Hz, 1920x1200@60Hz, Input Resolution Support... - Page 22 800x600@60Hz, 848x480@60Hz, 1024x768@60Hz, 1280x768@60Hz, 1280x800@60Hz, 1280x960@60Hz, 1280x1024@60Hz, 1360x768@60Hz, 1366x768@60Hz, 1440x900@60Hz, 1600x900@60Hz, 1600x1200@60Hz, 1680x1050@60Hz, 1920x1200@60Hz, Output Resolution Support 2048x1152@60Hz, 3840x2160@24Hz, 3840x2160@25Hz,3840x2160@30Hz, 3840x2160@60Hz, 4096x2160@24Hz, 4096x2160@60Hz, 720x480@60Hz (480p), 720x576@50Hz (576p), 1280x720@50Hz (720p50), 1280x720@60Hz (720p60), 1920x1080@50Hz (1080p50), 1920x1080@60Hz (1080p60) Video Impedance 100 Ω Cat 5e: 1080p 36bit : 100m ...
- Page 23 -20 to +70°C (-4 to + 158 °F), Storage Temperature 10% to 90%, non-condensing Humidity 10% to 90%, non-condensing Power Supply DC 12V 16.08W Power Consumption Transmitter supply power to Receiver Human-body Model: ESD Protection ±8kV(Air-gap discharge)/ ±4kV(Contact discharge) Device Dimension 271.8mm x 20mm x 98.8mm (W x H x D) 10.70"...
- Page 24 Receiver Technical Input 1 x HDBT Input Signal Type HDBT 2.0 800x600@60Hz, 848x480@60Hz, 1024x768@60Hz, 1280x768@60Hz, 1280x800@60Hz, 1280x960@60Hz, 1280x1024@60Hz, 1360x768@60Hz, 1366x768@60Hz, 1440x900@60Hz, 1600x900@60Hz, 1600x1200@60Hz, 1680x1050@60Hz, 1920x1200@60Hz, Input Resolution Support 2048x1152@60Hz, 3840x2160@24Hz, 3840x2160@25Hz, 3840x2160@30Hz, 3840x2160@60Hz, 4096x2160@24Hz, 4096x2160@60Hz, 720x480@60Hz (480p), 720x576@50Hz (576p), 1280x720@50Hz (720p50), 1280x720@60Hz (720p60), 1920x1080@50Hz (1080p50), 1920x1080@60Hz (1080p60)
- Page 25 1024x768@60Hz, 1280x768@60Hz, 1280x800@60Hz, 1280x960@60Hz, 1280x1024@60Hz, 1360x768@60Hz, 1366x768@60Hz, 1440x900@60Hz, 1600x900@60Hz, 1600x1200@60Hz, 1680x1050@60Hz, 1920x1200@60Hz, 2048x1152@60Hz, 3840x2160@24Hz, 3840x2160@25Hz, 3840x2160@30Hz, 3840x2160@60Hz, 4096x2160@24Hz, 4096x2160@60Hz, 720x480@60Hz (480p), 720x576@50Hz (576p), 1280x720@50Hz (720p50), 1280x720@60Hz (720p60), 1920x1080@50Hz (1080p50), 1920x1080@60Hz (1080p60) Video Impedance 100 Ω Cat 5e: 1080p 36bit : 100m ...
-
Page 26: Cable Specifications
Human-body Model: ESD Protection ±8kV(Air-gap discharge)/ ±4kV(Contact discharge) Voltage: ±1 kV (Ten times respectively for the positive and Surge Protection negative voltage) Data communication cord: 1 kV Electrical Fast Power cord : 2 kV Transient/Burst Power Supply DC 12V 16.2W Power Consumption Receiver supply power to Transmitter Human-body Model:... -
Page 27: Limited Warranty
FSR factory or Authorized Repair Stations. This warranty shall be cancelable by FSR at its sole discretion if the unit has been subjected to physical abuse or has been modified in any way without written authorization from FSR.
