Proline Prowirl F 200 PROFIBUS PA
Endress+Hauser
DN
[in]
Order code for "Housing", option C
Aluminum, AlSi10Mg, coated
8
10
12
1) For high-temperature/low-temperature version: values + 0.4 lbs
Transmitter remote version
Wall-mount housing
Depends on the material of the wall-mount housing:
• Aluminum, AlSi10Mg, coated: 2.4 kg (5.2 lb)
• Stainless steel, 1.4404 (316L): 6.0 kg (13.2 lb)
Sensor remote version
Weight data:
• Including the connection housing:
– Aluminum, AlSi10Mg, coated: 0.8 kg (1.8 lb)
– Stainless cast steel, 1.4408 (CF3M): 2.0 kg (4.4 lb)
• Excluding the connecting cable
• Excluding packaging material
Weight in SI units
All values (weight) refer to devices with EN (DIN), PN 40 flanges. Weight information in
[kg].
DN
[mm]
Connection housing
Aluminum, AlSi10Mg, coated
15
25
40
50
80
100
150
200
250
300
1) For high-temperature/low-temperature version: values + 0.2 kg
Weight [lbs]
1)
167.9
240.6
357.5
Weight [kg]
1)
4.1
6.1
8.1
10.1
15.1
20.1
36.1
71.1
110.1
157.1
Technical data
Order code for "Housing", option B
Stainless steel, 1.4404 (316L)
173.8
246.6
363.4
Connection housing
Stainless cast steel, 1.4408 (CF3M)
5.3
7.3
9.3
11.3
16.3
21.3
37.3
72.3
111.3
158.3
1)
1)
