- Page 1 BLT-82493 ERGO-E.EAZY True Adjust® Pneumatic Computer Desk Assembly Instructions...
- Page 2 ERGO-E.EAZY Computer Desk Part Drawing Description Part Drawing Description Top Platform 1 EA Cable Management Tray 1 EA Keyboard Platform 1 EA Upper Leg Insert 2 EA Metal Keyboard Track 1 EA Leg Receiver (Right) 1 EA Keyboard Mechanism 1 EA Metal Mouse Platform 1 EA Leg Receiver (Left)
- Page 3 ERGO-E.EAZY Computer Desk Hardware List Part Drawing Description Cylinder w/Plastic cover 1 EA Screw 6MM x 13 19 EA Rubber Bumber 2 EA Screw 6MM x 40 8 EA Screw 8MM x 40 4 EA Desk Glide 2 EA Short Wood Screw 21 EA Large CPU Glide 2 EA...
-
Page 4: Assembly Diagram
Missing Parts or UPS Damaged Parts Ergo E.Eazy For Your Convenience you can EMAIL us at Assembly Diagram furniture@baltinc.com 24HOURS 7 DAYS A WEEK Place the Top Platform (P-1) with the insert nuts facing up. Attach Cable Management Tray (P-11) to the Top Platform (P-1) using 3 ( A) Screws as shown in illustration #2. Attach Height Adjust Bracket (P-5) to the Top Platform (P-1) using 4 ( A) Screws as shown in illustration #2. - Page 5 ERGO-E.EAZY Computer Desk Illustration # 3 P-16 Attach 2 each Upper Leg Inserts (P-2) to the Top Platform (P-1) using 4 ( A) Screws as shown in (Do not tighten screws all the way) illustration #3. Align the Keyboard Track (P-13) in desired location on the Top Platform (P-1) and attach it using 8 Short Wood Screws (B) as shown in illustration # 3.
- Page 6 ERGO-E.EAZY Illustration # 4 Slide the Adjustment Mechanism (P-14) towards the back end of the Track (P-13) and rotate 30 degrees as shown. Attach the second Rubber Bumper (F) at the front end of Track (P-13) using1 each Long Wood Screw (B1) as shown in illustration # 4.
- Page 7 ERGO-E.EAZY Illustration # 6 Assembly P-10 Be sure the Adjustment Knobs (L) are secured before rotating unit to the upright position. Insert Cylinder w/Plastic Cover (E) into Height Adjust Bracket (P-5) as shown in illustration #6. Slide Cylinder Extension (P-10) over Cylinder(E). Slide Lower Leg Assembly over the Upper Leg Inserts (P-2) as shown in illustration #5.
- Page 8 EazyShelf Assembly Diagram Illustration # 7 23. Place the Printer Platform (P-18) with the insert nuts facing up. Attach 2 each Shelf Brackets (P-19) to the Top Platform (P-18) using 8 each ( A) Screws as shown in illustration #7. Printer Shelf Desktop...
- Page 9 ERGO-E.EAZY Adjustable Pneumatic For more information Computer Desk 1-800-749-2258 29-½" 7-¾" 25-½" 9"Clearance 11-¾" 41-½" 29” to 39" 7” X 8" 20” X 11" Shipping Information 7.3 Total Cubic Feet 99 lbs. total weight Wood Top Leg Base 1.7 Cubic Feet 5.6 Cubic Feet 10”...
