- Page 1 Choose the #42551 Alekto “Smart One®” Adjustable Tri-Level Computer Workstation Assembly Instructions...
- Page 2 #42551 Alekto-3 Computer Workstation Part Drawing Description Part Drawing Description 2 EA Hardware List Flat Head Screw 28 EA Bottom Shelf 1 EA Long Wood Screw 4 EA Stability Panel 1 EA Wood Screw 3 EA Right Top Support 1 EA Interior Threaded Post 20 EA Left Top Support...
-
Page 3: Assembly Diagram
Missing Parts or UPS Damaged Parts #42551 ALEKTO-3 For Your Convenience you can EMAIL us at Assembly Diagram furniture@baltinc.com 24HOURS 7 DAYS A WEEK To Assemble: Illustration # 1 1. Identify and Separate all the Parts and Hardware. 2. Attach Bottom Shelf (P2) and... - Page 4 Illustration # 3 6. Attach Top Panel (P7) to the Top Supports (P4 & P5), and Shelf Panel (P8) to the Shelf Supports (P6) using 8 Flat Head screws (A) as shown in Illustration # 3. 7. Attach cable Tray (P9) to the Top Panel (P7) using 3 Wood Screws (A3).
- Page 5 11. Tighten all screws securely. Important The Balt product you have purchased is guaranteed against material and workmanship defects. This guarantee extends 1 year from date of purchase. Should this product fail to function satisfactorily under normal use due to defect or imperfection, the defective part or product will be replaced. Damage caused by common carriers during shipment is not included in this guarantee.
- Page 6 #42551 ALEKTO-3 Adjustable Tri-Level For more information Computer Workstation 1-800-749-2258 Shelf Panel Top Panel Top Panel Shelf Panel 52" Option # 1 Option # 2 25-½" 8-10" ADJ. Height adjustable ranging from 23½” to 47½” for Keyboard shelf and 27½” to 51½” for Monitor Shelf.
