LCI40
®
Series
Signal Converter for Mass Flowmeters
L I Q U I D C O N T R O L S
An IDEX Energy & Fuels Business
LCI40
Series IOM
WWW.LCMETER.COM
Installation and Parts
LC_LCRIIE26:V1-0716
1

Advertisement

Table of Contents
loading

Related Manuals for Liquid Controls LCI40 Series

Summary of Contents for Liquid Controls LCI40 Series

  • Page 1 LCI40 ® Series Installation and Parts Signal Converter for Mass Flowmeters L I Q U I D C O N T R O L S LC_LCRIIE26:V1-0716 An IDEX Energy & Fuels Business LCI40 Series IOM WWW.LCMETER.COM...
  • Page 2 Liquid Controls, LLC. end user to which the products are shipping. If there are questions about the language of any LC manuals, instructions, or specification sheets, please contact your local distributor.

  • Page 3: Table Of Contents

    table oF ContentS 1. SaFetY inStruCtionS 4. eleCtriCal ConneCtionS 1.1 Software History ..........4 4.9 Electrical Connection of the Inputs and Outputs ........24 1.2 Intended Use ........... 5 4.10 Description of the Inputs and Outputs ..25 1.3 Safety Instructions From The Manufacturer ..5 5.

  • Page 4: Safety Instructions

    1. SaFetY inStruCtionS 1.1 Software history The “Electronic Revision” (ER) is consulted to see from the ER whether troubleshooting or larger document the revision status of electronic equipment changes in the electronic equipment have taken place according to NE 53 for all GDC devices. It is easy to and how that has affected the compatibility.

  • Page 5: Intended Use

    1. SaFetY inStruCtionS 1.2 intended use The mass flowmeters are designed exclusively to danGer directly measure mass flow rates, product density and temperature as well to indirectly measure parameters For devices used in hazardous such as the total volume and concentration of areas, additional safety notes dissolved substances as well as the volume flow rate.

  • Page 6: Safety Instructions From The Manufacturer

    Liquid Controls disclaims all liability for damage to The manufacturer can not accept responsibility for any meter or accessories because of corrosion, salting-...

  • Page 7: Safety Instructions From The Manufacturer

    Electrostatic Discharge (ESD) 1.3.6 Publication updates and translations equipment and follow the proper procedures The most current English version of all Liquid Controls • Make sure that all necessary safety precautions have publications are available on our Web site, www.

  • Page 8: Device Description

    2. deviCe deSCriPtion 2.1 Scope of delivery Scope of Delivery 1. Device in the version as ordered Signal Converter / Measuring Sensor Combination Possibilities 2. Documentation Measuring Sensor Signal Converter LCI40 3. Signal cable (only for remote version) Compact Remote Field Housing ®...

  • Page 9: Device Description

    2. deviCe deSCriPtion 2.2 device description The mass flowmeters are designed exclusively to The following versions are available: directly measure mass flow rates, product density and • Compact version (the signal converter is mounted temperature as well to indirectly measure parameters directly on the measuring sensor) such as the total volume and concentration of dissolved substances as well as the volume flow rate.

  • Page 10: Field Housing

    2. deviCe deSCriPtion 2.3 Field housing Construction of the Field Housing 1. Cover for electronics and display information 2. Cover for power supply and inputs/outputs terminal compartment Each time a housing cover is 3. Cover for measuring sensor terminal compartment opened, the thread should be 4.

  • Page 11: Nameplates

    2.4.1 example of a nameplate 2.4.2 electrical Connection data of inputs/outputs (example of basic version) • A = active mode; the signal converter supplies the Liquid Controls LLC ➆ power for connection of the subsequent devices Lake Bluff, IL 60044-2242 ➅ ➀...

  • Page 12: Installation

    3. inStallation 3.1 General notes on installation information information Inspect the cartons carefully Look at the device nameplate to for damages or signs of rough ensure that the device is delivered handling. Report damage to the according to your order. carrier and to the local office of the Check for the correct supply manufacturer.

  • Page 13: Mounting Of The Compact Version

    3. inStallation 3.5 Mounting of the Compact version information The signal converter is mounted directly on the measuring sensor. For installation of the flowmeter, please observe the instructions in the supplied product documentation for the measuring sensor. 3.6 Mounting the Field housing, remote version 3.6.1 Pipe Mounting 3.6.2 Wall Mounting Pipe Mounting of the Field Housing...
  • Page 14 3. inStallation 3.6 Mounting the Field housing, remote version 3.6.3 turning the display of the Field housing version Caution The ribbon cable of the display must not be folded or twisted repeatedly. information Each time a housing cover is opened, the thread should be cleaned and greased.

  • Page 15: Electrical Connections

    4. eleCtriCal ConneCtionS 4.1 Safety instructions DANGER All work on the electrical DANGER Observe without fail the local connections may only be carried out with occupational health and safety regulations. the power disconnected. Take note of the Any work done on the electrical components voltage data on the nameplate! of the measuring device may only be carried out by properly trained specialists.

  • Page 16: Connecting The Signal Cables

    4. eleCtriCal ConneCtionS 4.4 Connecting the Signal Cables DANGER Cables may only be connected 4.4.1 Connection of Signal Cable - Field Housing and when the power is switched off. Connection Box for Sensor DANGER The device must be grounded in accordance with regulations in order to protect personnel against electric shocks.
  • Page 17 4. eleCtriCal ConneCtionS 4.4 Connecting the Signal Cables 4.4.2 Connection Diagram Connection Diagram 1. Terminal compartment for signal converter 2. Terminal compartment for measuring sensor 3. Connect shielding to spring terminal (drain wire and overall shield) Cable Cable danGer Connection Terminal Cable Pair Color The device must be grounded in...

  • Page 18: Grounding The Measuring Sensor

    4. eleCtriCal ConneCtionS 4.5 Grounding the Measuring Sensor • The measuring sensor must be properly grounded. danGer • The grounding cable should not transmit any There should be no difference in interference voltages. potential between the measuring • Do not use the grounding cable to connect more than sensor and the housing or one device to ground.

  • Page 19: Inputs And Outputs, Overview

    4. eleCtriCal ConneCtionS 4.6 Connecting Power, all housing variants 100 to 230 vaC (tolerance range: -15% / +10%) information • Note the power supply voltage and frequency (50 to 60 Hz) on the nameplate. 240 VAC+5% is included in the tolerance range.
  • Page 20 4. eleCtriCal ConneCtionS 4.7 inputs and outputs, overview 4.7.2 description of the CG number CG Number Examples The last 3 digits of the CG number (5, 6 and 7) indicate 100 to 230 VAC & standard display; the assignment of the terminal connections. Please CG 330 11 100 basic I/O: I or I...
  • Page 21 4. eleCtriCal ConneCtionS 4.7 inputs and outputs, overview 4.7.3 Fixed, Non-alterable Input/Output Versions This signal converter is available with various input/ • In the table, only the final digits of the CG no. are output combinations. depicted. • The grey boxes in the tables denote unassigned or •...
  • Page 22 4. eleCtriCal ConneCtionS 4.7 inputs and outputs, overview 4.7.4 Alterable input/output versions This signal converter is available with various input/ • In the table, only the final digits of the CG no. are output combinations. depicted. • The grey boxes in the tables denote unassigned or •...

  • Page 23: Description Of The Inputs And Outputs

    4. eleCtriCal ConneCtionS 4.8 description of the inputs and outputs 4.8.1 Current output • All outputs are electrically isolated from each other and from all other circuits. information • All operating data and functions can be adjusted. The current outputs must be Passive mode: external power Uext ≤...
  • Page 24 4. eleCtriCal ConneCtionS 4.8 description of the inputs and outputs 4.8.2 Pulse and Frequency output • All outputs are electrically isolated from each other and from all other circuits. information • All operating data and functions can be adjusted. Depending on the version, the pulse and frequency outputs must •...
  • Page 25 4. eleCtriCal ConneCtionS 4.8 description of the inputs and outputs 4.8.3 Status output and limit Switch • The status outputs / limit switches are electrically isolated from each other and from all other circuits. information • The output stages of the status outputs/limit Depending on the version, the switches during simple active or passive operation pulse and frequency outputs must...

  • Page 26: Electrical Connection Of The Inputs And Outputs

    4. eleCtriCal ConneCtionS 4.9 electrical Connection of the inputs and outputs 4.9.1 Field housing, electrical Connection of the inputs and outputs information Assembly materials and tools are not part of the delivery. Use the assembly materials and tools In compliance with the applicable occupational health and safety directives.

  • Page 27: Description Of The Inputs And Outputs

    4. eleCtriCal ConneCtionS 4.10 description of the inputs and outputs 4.10.1 important notes • All groups are electrically isolated from each other information and from all other input and output circuits. • Passive mode: An external power supply is Depending on the version, the necessary to operate (activation) the subsequent pulse and frequency outputs must devices (U...
  • Page 28 4. eleCtriCal ConneCtionS 4.10 description of the inputs and outputs 4.10.3 basic inputs/outputs Current output active, basic i/os Pulse/Frequency output Passive, basic i/os • = 24 VDC nominal ≤ 32 VDC • int, nom I ≤ 22 mA • ≤ 100 Hz: •...
  • Page 29 4. eleCtriCal ConneCtionS 4.10 description of the inputs and outputs 4.10.3 basic inputs/outputs Control input Passive, basic i/os Status output / limit Switch Passive, basic i/os 8 V ≤ Uext ≤ 32 VDC • ≤ 32 VDC • ≤ 24 VDC •...
  • Page 30 4. eleCtriCal ConneCtionS 4.10 description of the inputs and outputs 4.10.4 Modular inputs/outputs and bus Systems Current output active, Modular i/os Caution • = 24 VDC int, nom Observe connection polarity. I ≤ 22 mA • RL ≤ 1 kΩ •...
  • Page 31 4. eleCtriCal ConneCtionS 4.10 description of the inputs and outputs 4.10.4 Modular inputs/outputs and bus Systems Pulse/Frequency output active, Modular i/os Pulse/Frequency output Passive, Modular i/os • = 24 VDC • ≤ 32 VDC ≤ 100 Hz: ≤ 100 Hz: •...
  • Page 32 4. eleCtriCal ConneCtionS 4.10 description of the inputs and outputs 4.10.4 Modular inputs/outputs and bus Systems Status output / limit Switch Passive, Status output / limit Switch active, Modular i/os Modular i/os • Any connection polarity. • Observe connection polarity. •...
  • Page 33 4. eleCtriCal ConneCtionS 4.10 description of the inputs and outputs 4.10.4 Modular inputs/outputs and bus Systems Control input active, Modular i/os Control input Passive, Modular i/os ≤ 32 VDC • = 24 VDC • 3V≤U ≤ 24 V I ≤ 32 •...
  • Page 34 4. eleCtriCal ConneCtionS 4.10 description of the inputs and outputs 4.10.5 ex i inputs/0utputs Current output active, ex i i/os danGer • Observe connection polarity For devices used in hazardous • = 20 VDC areas, additional safety notes int, nom apply.
  • Page 35 4. eleCtriCal ConneCtionS 4.10 description of the inputs and outputs 4.10.5 ex i inputs/0utputs Control input Passive, ex i i/os danGer ≤ 32 VDC • 5.5 V≤U For devices used in hazardous ≤ 24 V • = 6 mA at U areas, additional safety notes apply.

  • Page 36: Start-Up

    5. Start-uP 5.1 Switching on the Power before connecting to power, please check that the system has been information correctly installed. this includes: Switching on the power. • The device must be mechanically safe and mounted in compliance with the regulations. •...

  • Page 37: Display And Operating Elements

    6 oPeration 6.1 display and operating elements Caution The use of a jumper is only permitted for custody transfer devices to block access to parameters relevant to custody transfer. When the jumper is set to or removed from the “protected” position, the signal converter restarts to switch into the protected or unprotected operating mode.
  • Page 38 6 oPeration 6.1 display and operating elements Measuring Mode Menu Mode Submenu or Parameter and Function Mode Data Mode > Switch from measuring Access to displayed Access to displayed sub- For numerical values, mode to menu mode; menu, then 1st submenu menu or function move cursor (highlighted press key for 2.5 s,...
  • Page 39 6 oPeration 6.1 display and operating elements 6.1.1 display in Measuring Mode with 2 6.1.2 display for Selection of Submenu or 3 Measured values and Functions, 3 lines Display for Selection oof Submenu and Functions, 3 Lines 1. Indicates a possible status message in the status list 2.
  • Page 40 6 oPeration 6.1 display and operating elements 6.1.3 display when Setting Parameters, 6.1.4 display when Previewing 4 lines Parameters, 4 lines Display When Previewing Parameters, 4 Lines Display When Setting Parameters, 4 Lines Current menu, submenu or function 1. Current menu, submenu or function Number relating to 6 2.
  • Page 41 6 oPeration 6.1 display and operating elements 6.1.5 using an ir interface (option) The optical IR interface serves as an adapter for PC- based communication with the signal converter without information opening the housing. This device is not part of the scope of delivery.

  • Page 42: Zero Calibration (Menu C1.1.1)

    6 oPeration 6.2 Zero Calibration (Menu C1.1.1) Following installation, perform zero calibration prior system or calibration factor) made after the zero to commissioning the device. Finalise the installation calibration may affect the accuracy, making it before performing zero calibration. Changes (pipe necessary to perform zero calibration again.
  • Page 43 6 oPeration 6.2 Zero Calibration (Menu C1.1.1) Zero Calibration log (C1.1.5) Zero calibrations are recorded in the zero calibration • There are still gas bubbles in the measuring sensor. log. Log information includes zero offset, temperature, Remedy: Flush measuring sensor and repeat date and time.

  • Page 44: Menu Structure

    6 oPeration 6.3 Menu Structure Select Menu ↓ ↑ Select Menu And/Or Submenu ↓ ↑ Measure Mode Select Function And Set Data ↓ ↑ > ↵ Press > 2.5 s > ↵ > ↵ A Quick Setup A1 Language A2 Tag >...
  • Page 45 6 oPeration 6.3 Menu Structure Select Menu ↓ ↑ Select Menu And/Or Submenu ↓ ↑ Measure Mode Select Function and Set Data ↓ ↑ > ↵ Press >2.5s B. Test > ↵ B1 Simulation > ↵ B1.1 Mass Flow > ↵ B1.2 Volume Flow B1.3 Density B1.4 Temperature...
  • Page 46 6 oPeration 6.3 Menu Structure Select Menu ↓ ↑ Select Menu And/Or Submenu ↓ ↑ Measure Mode Select Function And Set Data ↓ ↑ > ↵ Press >2.5s C .Setup > ↵ C1 Process Input > ↵ C1.1 Zero and Offset >...

  • Page 47: Function Tables

    6 oPeration 6.4 Function tables 6.4.1 Menu a, Quick Setup Function Setting / Description A1 Language Language Language selection depends on the device version. A2 Tag Measuring point identifier (Tag no.) appears in the LCD header (maximum 8 digits). A3 Reset Reset A3.1 Reset Errors...
  • Page 48 6 oPeration 6.4 Function tables 6.4.1 Menu a, Quick Setup Function Setting / Description A4 Station Address Station Address For PROFIBUS / FF / Modbus devices. A5 Digital Outputs Digital Outputs Valid for all pulse outputs (terminals A, B and/or D) and Totalizer 1. A5.1 Measurement 1) Select: Volume Flow / Mass Flow / Concentration Flow 1...
  • Page 49 6 oPeration 6.4 Function tables 6.4.2 Menu b, test Function Setting / Description B1 Simulation Simulation Displayed values are simulated. B1.1 Mass Flow Simulation of mass flow Set value (range and units depend on measurement) Break (exit function without simulation) Query: start simulation? Settings: Yes (start simulation) / No (exit function without simulation) B1.2...
  • Page 50 6 oPeration 6.4 Function tables 6.4.2 Menu b, test, continued Function Settings / Descriptions B3 Information Information B3.1 Status Log Log with date and time of status messages that occurred B3.2 Status Details Details about the status messages displayed B3.3 C Number CG number, cannot be changed (input/output version) B3.4...
  • Page 51 6 oPeration 6.4 Function tables 6.4.3 Menu C, Setup, continued Function Settings / Descriptions C1.2 Density Set the slope for the reference density option C1.2.4 Ref. Density Slope Appears only if density mode “Referred” has been selected in Fct. C1.2.2. Standard Density Appears only if density mode “Standard”...
  • Page 52 6 oPeration 6.4 Function tables 6.4.3 Menu C, Setup, continued Function Settings / Descriptions C1.5 Diagnosis C1.5.11 Proc: System Control Selection of status signal (Failure, Out of Specification, Function Check, Maintenance Required and Information) for the group “Proc: System Control” C1.5.12 Config: Totalizer Selection of status signal (Failure, Out of Specification, Function Check,...
  • Page 53 6 oPeration 6.4 Function tables 6.4.3 Menu C, Setup, continued Function Settings / Descriptions C3 I/O (Inputs/Outputs) C3.1 Hardware C3.1 Hardware Configuration of connection terminals. Selection depends on signal converter version. C3.1.1 Terminal A Select: Off (switched off) / Current Output / Frequency Output / Pulse Output / Status Output / Limit Switch / Control Input C3.1.2 Terminal B...
  • Page 54 6 oPeration 6.4 Function tables 6.4.3 Menu C, Setup, continued Function Settings / Descriptions C3._ Current Output X C3._.7 Polarity Set polarity; the flow direction in C1.3.2 must be noted! Select: Both Polarities (plus and minus values are displayed) / Positive Polarity (display for negative values = 0) / Negative Polarity (display for positive values = 0) / Absolute Value (always displays positive, with both negative and positive values)
  • Page 55 6 oPeration 6.4 Function tables 6.4.3 Menu C, Setup, continued Function Settings / Descriptions C3._ Frequency Output X C3._ Frequency Output X X stands for one of the connection terminals A, B, or D_ stands for Fct. C3.2 (A) / C3.3 (B) / C3.5 (D) C3._.1 Pulse Shape...
  • Page 56 6 oPeration 6.4 Function tables 6.4.3 Menu C, Setup, continued Function Settings / Descriptions C3._ Frequency Output X C3.3.11 Special Functions This function is only available at the terminal B frequency output. At the same time, 2 frequency outputs must be available: 1st output at terminal A or D / 2nd output at terminal B The B output is operated as a slave output, controlled and set using master output A or D Select:...
  • Page 57 6 oPeration 6.4 Function tables 6.4.3 Menu C, Setup, continued Function Settings / Descriptions C3._ Pulse Output X C3._.7 Polarity Set polarity; the flow direction in C1.3.2 must be noted! Select: Both Polarities (plus and minus values are displayed) / Positive Polarity (display for negative values = 0) / Negative Polarity (display for positive values = 0) / Absolute Value (always displays positive, with both negative and positive values)
  • Page 58 6 oPeration 6.4 Function tables 6.4.3 Menu C, Setup, continued Function Settings / Descriptions C3._ Status Output X C3._ Status Output X X (Y) stands for one of the connection terminals A, B, C or D _ stands for Fct. C3.2 (A) / C3.3 (B) / C3.4 (C) / C3.5 (D) C3._.1 Mode...
  • Page 59 6 oPeration 6.4 Function tables 6.4.3 Menu C, Setup, continued Function Settings / Descriptions C3._ Limit Switch X C3._ Limit Switch X X stands for one of the connection terminals A, B, C or D_ stands for Fct. C3.2 (A) / C3.3 (B) / C3.4 (C) / C3.5 (D) C3._.1 Measurement...
  • Page 60 6 oPeration 6.4 Function tables 6.4.3 Menu C, Setup, continued Function Settings / Descriptions C4 I/O Totalizers C4.1 Totalizer 1 Set function of counter._ stands for 1, 2, 3 (= Totalizer 1, 2, 3) The basic version (standard) has only 2 Totalizer! C4.2 Totalizer 2 C4.3...
  • Page 61 6 oPeration 6.4 Function tables 6.4.3 Menu C, Setup, continued Function Settings / Descriptions C5 I/O C5.1 PV is Current output (primary variable) C5.2 SV is (secondary variable) C5.3 TV is (tertiary variable) C5.4 4V is (4th variable) C5._.1 Current Output X Shows the current analogue measured value of the linked current output.
  • Page 62 6 oPeration 6.4 Function tables 6.4.3 Menu C, Setup, continued Function Settings / Descriptions C6 Device C6.1 Device Info C6.1 Device Info C6.1.1 Settable characters (max. 8 digits): A - Z; a - z; 0 - 9; / - + , . C6.1.2 V No.
  • Page 63 6 oPeration 6.4 Function tables 6.4.3 Menu C, Setup, continued Function Settings / descriptions C6.3 & C6.4 1st Measurement Page & 2nd Measurement Page Limitation before applying the time constant C6._.4 Limitation ±xxx to ±xxx%; range: -150 - +150% Sets low flow values to “0” C6._.5 Low Flow Cutoff x.xxx±x.xxx %;...
  • Page 64 6 oPeration 6.4 Function tables 6.4.3 Menu C, Setup, continued Function Settings / Descriptions C6.5 Graphic Page C6.5 Graphic Page C6.5.1 Select Range Graphic page always shows trend curve of the measurement of the 1st page / 1st line, see Fct.
  • Page 65 6 oPeration 6.4 Function tables 6.4.3 Menu C, Setup, continued Function Settings / Descriptions C6.6 Special Functions C6.6.8 GDC IR Interface After this function has been activated an optical GDC adapter can be connected to the LC display. After 60 seconds pass without a connection being established or after the adapter is removed, the function is exited and the optical keys are active again.
  • Page 66 6 oPeration 6.4 Function tables 6.4.3 Menu C, Setup, continued Function Settings / Descriptions C6.8 Set required text: C6.8.1 Message A - Z ; a - z ; 0 - 9 ; / - + , . * Set required text: C6.8.2 Description A - Z ;...

  • Page 67: Description Of Functions

    6 oPeration 6.5 description of Functions 6.5.1 reset totalizer in the Menu “Quick Setup” Display Description and Setting > Quick Setup Press and hold for 2.5 s, then release the key > Language 2 x ↓ Reset > Reset Errors ↓...
  • Page 68 6 oPeration 6.5 description of Functions 6.5.3 operation Mode (Menu a9) The device can be switched to “Standby”. In this mode, There is also a “Stop” mode. In this mode, the all flow values are set to zero and the counter values measuring sensor is switched off and is no longer are “frozen”.
  • Page 69 6 oPeration 6.5 description of Functions 6.5.4 density Calibration (Menu C1.2.1) Mass flowmeters are calibrated for density in the saved in the converter electronics and stored in the factory. Density calibration is based on two calibration factory settings. Regardless, various applications points.
  • Page 70 6 oPeration 6.5 description of Functions 6.5.4 density Calibration (Menu C1.2.1) on-site density Calibration: 1 Point Calibration • Ensure that the device has been properly installed • See examples for “Calibration with town water and and functions smoothly. other.”. Select the function using ↓ and ↑ and then confirm •...
  • Page 71 6 oPeration 6.5 description of Functions 6.5.5 temperature/density table Temperature Density Temperature Density °F °C lb/ft kg/m °F °C lb/ft kg/m 62.41999 999.8396 32.9 62.42197 999.8712 33.8 62.42367 999.8986 34.7 62.42509 999.9213 35.6 62.42625 999.9399 36.5 62.42714 999.9542 37.4 62.42777 999.9642 38.3 62.42814...
  • Page 72 6 oPeration 6.5 description of Functions 6.5.5 temperature/density table Temperature Density Temperature Density °F °C lb/ft kg/m °F °C lb/ft kg/m 91.4 62.09975 994.71 92.3 33.5 62.08950 994.5458 93.2 62.07912 994.3796 94.1 34.5 62.06861 994.2113 62.05799 994.0411 95.9 35.5 62.04724 993.8689 98.6 62.03637...
  • Page 73 6 oPeration 6.5 description of Functions 6.5.5 temperature/density table Temperature Density Temperature Density °F °C lb/ft kg/m °F °C lb/ft kg/m 150.8 61.19233 980.1751 151.7 66.5 61.17552 979.9057 152.6 61.15862 979.6351 153.5 67.5 61.14165 979.3632 154.4 61.1246 979.0901 155.3 68.5 61.10748 978.8159 156.2...
  • Page 74 6 oPeration 6.5 description of Functions 6.5.6 density Mode (Menu C1.2.2) there are Four available operating Modes For density that Can be Set here • Process: The device measures and displays the current operating density of the product. • Fixed: The device displays a fixed density value.
  • Page 75 6 oPeration 6.5 description of Functions 6.5.7 Pipe diameter (Menu C1.1.3) 6.5.9 Flow direction (Menu C1.3.1) This function allows the operator to set the direction The converter can also provide the flow velocity based of flow in relation to the arrow on the housing. If on a pipe diameter which the customer can freely “Forwards”...
  • Page 76 6 oPeration 6.5 description of Functions 6.5.10 Pressure Suppression The pressure suppression eliminates any disruption In most cases, the amplitude of this vibration is in the measurement in the event of an abrupt flow below the low flow cutoff and thus does not affect switch-off e.g.

  • Page 77: System Control

    6 oPeration 6.5 description of Functions 6.5.11 System Control Menu C1.4.1 - Function Menu C1.4.2 - Condition This menu makes it possible to switch off certain Selecting the process measurement which activates measuring functions depending on a programmable the system control. Density and temperature can be process state.
  • Page 78 6 oPeration 6.5 description of Functions 6.5.13 diagnosis Messages 6.5.16 Save Settings (Menu C6.6.2) (Menu C1.5.7 to .C1.5.14) This function allows all settings to be stored in a memory. These settings make it possible to change the status signal of the respective diagnosis message (status •...
  • Page 79 6 oPeration 6.5 description of Functions 6.5.21 low flow cutoff 6.5.23 dual Phase Pulse output The low flow cutoff can be individually set for each A dual phase pulse or frequency output is often output and each display line. If the low flow cutoff has required for custody transfer applications.

  • Page 80: Status Messages And Diagnostic Information

    6 oPeration 6.6 Status Messages and diagnostic information The error messages for the device are divided into The variable status signal can be changed in menu status groups, each with one status signal. There are C1.5.7 to C1.5.14. Changing the status signal to 16 status groups with fixed status signals and 8 groups “Information”...
  • Page 81 6 oPeration 6.6 Status Messages and diagnostic information Error Type Event Group Single Event Description Actions to Eliminate the F Sensor Event Sensor Containment Dam. High pressure detected in housing. Faulty Exchange measuring tube. measuring sensor. Sensor Error The measuring sensor signals are out of Check connection range.
  • Page 82 6 oPeration 6.6 Status Messages and diagnostic information Error Type Event Group Single Event Description Actions to Eliminate the Event Fieldbus Config. Inadmissible Fieldbus settings Check Fieldbus settings or load factory settings. PROFIBUS Config. Inadmissible PROFIBUS settings Check PROFIBUS settings or load factory settings.
  • Page 83 6 oPeration 6.6 Status Messages and diagnostic information Error Type Event Group Single Event Description Actions to Eliminate the Event C Configuration Sensor in Stop Mode The device is in stop mode. No flow Switch to measuring measurement is being performed. mode for normal All flowrelated values displayed are operation.
  • Page 84 6 oPeration 6.6 Status Messages and diagnostic information Error Type Event Group Single Event Description Actions to Eliminate the Event S Electronics Electr.Temp.A Out of Temperature of the signal converter Protect signal converter Spec electronics is out of range. from process effects and sunlight.
  • Page 85 6 oPeration 6.6 Status Messages and diagnostic information Error Type Event Group Single Event Description Actions to Eliminate the Event M Configuration Backup 1 Data Faulty Error when checking the data record for Use “Setup > Device > Backup 1. Special Functions >...
  • Page 86 6 oPeration 6.6 Status Messages and diagnostic information Error Type Event Group Single Event Description Actions to Eliminate the Event S Proc: Signal Sensor signal low The sensor signals do not reach the Check the product expected amplitude. This can influence for viscosity and gas the measuring accuracy.
  • Page 87 6 oPeration 6.6 Status Messages and diagnostic information Error Type Event Group Single Event Description Actions to Eliminate the Event I Config: No Meas.Value IO A No Meas. Values The measurement value for the Select another measurement for IO terminals A is not active. IO A in menu C3.2 or activate the measurement in C5.1 for diagnosis values or in menu...
  • Page 88 6 oPeration 6.6 Status Messages and diagnostic information Error Type Event Group Single Event Description Actions to Eliminate the Event I Electr. Operation Info. Zero Calibr. Running A zero calibration is performed. PROFIBUS: no data No data exchange via Set up cyclical PROFIBUS.

  • Page 89: Function Tests And Troubleshooting

    6 oPeration 6.7 Function tests and troubleshooting Min. and Max. recorded temperature (Menu C1.5.1 / C1.5.2) Stores the minimum and maximum value for the temperature occurring during sensor operating time. Measuring Sensor Type Operating Temperature Minimum Maximum ® LCMass 600 - Standard version -94°F / -70°C +446°F / +230°C ®...
  • Page 90 6 oPeration 6.7 Function tests and troubleshooting Typical frequency values (at 68°F / 20°C; ±5Hz) Size All Materials Empty Water ® LCMass 600 - 08 ® LCMass 600 - 10 ® LCMass 600 - 15 ® LCMass 600 - 25 ®...

  • Page 91: Diagnostic Functions

    6 oPeration 6.8 diagnostic Functions The following diagnostic functions are available in test menu B2. 6.8.1 temperature (Menu b2.7) 6.8.4 Sensor levels a and b (Menu b2.12, b2.13) Temperature display in °F or °C. Normal display values: • This value should be steadily displayed. •...

  • Page 92: Service

    7 ServiCe 7.1 replacing the Signal Converter electronics • Remove the front panel. Use a small screwdriver to danGer open the plastic clips that hold the display. Work on the signal converter • Remove the 2 locking screws. electronics may only be performed •...

  • Page 93: Sensor Or Drive Coil Fault

    7 ServiCe 7.2 Sensor or drive Coil Fault The specified values are for guidance only. Typical Values For Sensor Or Drive Coils Size Resistance (Ohm) Driver Sensor A - Sensor B Black/Grey Purple/Green - White/Yellow Cryo 446°F / 230°C 752°F / 400°C Cryo 446°F / 230°C / 752°F / 4 00°C ®...

  • Page 94: Technical Data

    8 teChniCal data 8.1 Measuring Principle (twin tube) Static Meter Not Energized and with No Flow 1. Measuring tubes 2. Drive coil 3. Sensor 1 4. Sensor 2 A Coriolis twin tube mass flowmeter consists of two measuring tubes 1 a drive coil 2 and two sensors (3 and 4) that are positioned either side of the drive coil.

  • Page 95: Technical Data

    8 teChniCal data 8.1 Measuring Principle (twin tube) Energised Meter With Process Flow 1. Process flow 2. Sine wave 3. Phase shift When a fluid or gas passes through the tubes, the coriolis effect causes a phase shift in the sine wave that is detected by the two sensors.
  • Page 96 8 teChniCal data 8.2 technical data Measuring System Measuring Principle Coriolis principle Application Range Measurement of mass flow, density, temperature, volume flow, flow velocity, concentration Design Modular Construction The measuring system consists of a measuring sensor and a signal converter. Measuring Sensor ®...
  • Page 97 8 teChniCal data 8.2 technical data Display And User Interface Graphic Display LC display, backlit white. Size: 128 x 64 pixels, corresponds to 59 x 31 mm = 2.32” x 1.22” Display turnable in 90° steps. Ambient temperatures below -13°F / -25°C may affect the readability of the display.
  • Page 98 8 teChniCal data 8.2 technical data Measuring Accuracy Reference Conditions Medium: water Temperature: +68°F / +20°C Pressure: 14.5 psi / 1 bar Maximum Measuring Error Mass (Standard) Liquid (≥ 20:1 of nominal flow rate): ±0.1% of actual measured flow rate (depending on the measuring sensor) Liquid (<...
  • Page 99 8 teChniCal data 8.2 technical data Materials Signal Converter Housing Standard: die-cast aluminium (polyurethane coated) Option: stainless steel 316 (1.4408) Measuring Sensor For housing material, process connections, measuring tubes, accessories and gaskets, refer to technical data for the measuring sensor. Electrical Connection General Electrical connection is carried out in conformity with the VDE 0100 directive “Regulations...
  • Page 100 8 teChniCal data 8.2 technical data Inputs and Outputs General All outputs are electrically isolated from each other and from all other circuits. All operating data and output values can be adjusted. Description of Abbreviations = external voltage; R = load + resistance; = terminal voltage;...
  • Page 101 8 teChniCal data 8.2 technical data Pulse or Frequency Output Output Data Pulse output: volume flow, mass flow, mass or volume of dissolved substance during activated concentration measurement Frequency output: flow velocity, mass flow, temperature, density, diagnostic value Optional: concentration, flow of the dissolved substance Function Can be set as a pulse output or frequency output Pulse Rate/Frequency...
  • Page 102 8 teChniCal data 8.2 technical data Pulse or Frequency Output ≤ 32 VDC Passive ≤ 100 Hz: in operating menu set to f I ≤ 100 mA open: I ≤ 0.05 mA at U = 32 VDC closed: = 0.2 V at I ≤ 10 mA 0, max = 2 V at I ≤1 00 mA 0, max...
  • Page 103 8 teChniCal data 8.2 technical data Status Output / Limit Switch Function and Settings Adjustable as automatic measuring range conversion, display of flow direction, overflow, error, switching point Valve control with activated dosing function Status and/or control: ON or OFF Operating Data Basic I/Os Modular I/Os...
  • Page 104 8 teChniCal data 8.2 technical data Control Input Function Hold value of the outputs (e.g. for cleaning work), set value of the outputs to “zero”, counter and error reset, stop counter, range conversion, zero calibration Start of dosing when dosing function is activated. Operating Data Basic I/Os Modular I/Os...
  • Page 105 8 teChniCal data 8.2 technical data PROFIBUS DP Description Galvanically isolated acc. to IEC 61158 Profile version: 3.02 Automatic data transmission rate recognition (max. 12 MBaud) Bus address adjustable via local display at the measuring device Function Blocks 8 x analogue input, 3 x Totalizer Output Data Mass flow, volume flow, mass counter 1 + 2, volume counter, product temperature, several concentration measurements and diagnostic data...
  • Page 106 8 teChniCal data 8.2 technical data Approvals and Certificates Non-Ex Standard Hazardous Areas Option FM / CSA FM: Class I, Div 1 groups A, B, C, D CSA: Class I, Div 1 groups C, D Class II, Div 1 groups E, F, G Class III, Div 1 hazardous areas FM: Class I, Div 2 groups A, B, C, D CSA: Class I, Div 2 groups C, D...

  • Page 107: Dimensions And Weights

    8 teChniCal data 8.3 dimensions and Weights 8.3.1 housing Dimensions for Field Housing (F) - Remote Version 8.3.2 Mounting Plate, Field housing Dimensions in inches and mm Inch Millimeter Ø0.4 Ø9 LCI40 Series IOM WWW.LCMETER.COM...

  • Page 108: Www.lcmeter.com
