Clare Video Doorbell
Power Requirements
The Clare Video Doorbell will work with mechanical
and digital doorbells that use 16-24VAC power only.
NOTE: If you are unsure what voltage your doorbell uses, please
consult your original doorbell packaging or a licensed electrician.
Mechanical
FRONT
Mechanical vs. Digital Doorbells
The easiest way to know if you currently have a mechanical or digital
doorbell, is to listen to the tone your doorbell makes when you ring it.
If it makes the standard ding-dong sound, it is most likely a mechanical
doorbell. If your doorbell plays a different tone or melody, it's most likely
a digital doorbell and you must install the supplied diode. Refer to Install
Step 4 for more information on installing the diode.
4
TRANS REAR
Digital
Getting
Started
