Summary of Contents for Hypercable HYC-4009-30
- Page 1 SeaRake-LandRake HYC-4009-30 300MHz 2x2 MIMO HT‐OFDM Radio Mobile Mesh User Manual Includes install, configuration and trouble shooting information for the broadband wireless access outdoor radio. Version 1.0.4 www.hypercable.fr www.e-rake.us.com Janv.2017...
- Page 2 Hypercable. ATTENTION selon le découplage des antennes et la largeur du canal en version 4x4 le canal CH1 2x2 doit être éloigné du canal Ch2 2x2 de 200 Mhz à 400 Mhz par exemple CH1 sur 5700 MHz et Ch2 sur 5300 MHz pour des antennes omnidirectionnelles découplées dans le plan vertical afin d’éviter interférences et désensibilisation.
-
Page 3: Conventions
This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for preventing accidents. www.hypercable.fr www.e-rake.us.com... -
Page 4: Table Of Contents
NDICATORS CHAPTER 3 CONFIGURATION ....................15 3-1 S ........................15 TART UP AND OG IN SYSTEM / BASIC SETUP ......................23 3-2 M ....................25 ROTOCOL ONFIGURATION 3-3 W ......................... 27 IRELESS ETUP 3-4 M ..........................32 ANAGEMENT www.hypercable.fr www.e-rake.us.com... -
Page 5: Chapter 1 Introduction
MAC address list to build the highest security mechanism to prevent the malicious attacking from the internet. FEATURES o Provides the easy installation for outdoor Mobile Mesh or PTP/PTMP applications with high performance. o ±2 ppm Frequency Stability for Mobility & NLOS Transmit Power Control: www.hypercable.fr www.e-rake.us.com... -
Page 6: Chapter 2 Hardware Installation
Mobile MESH Fast Seamless Roaming High Speed up to 180km/hr IEC61000‐4‐5 Surge Protection IP‐68 Water & Dust Resistant Chapter 2 Hardware Installation This chapter describes initial setup of the 300MHz UHF band 2x2 MIMO HT-OFDM MESH Radio www.hypercable.fr www.e-rake.us.com... - Page 7 The network administrator or other IT professional responsible for installing and configuring the unit is a suitable professional installer. Following installation, access to the unit should be password protected by the network administrator to maintain regulatory compliance. www.hypercable.fr www.e-rake.us.com...
-
Page 8: Product Kit
Category 5 UTP or STP networking cable. (From the PC to POE) Category 5 SSTP or SFTP networking cable. (From the radio to POE) A Web browser for configuration: Google Chrome or Microsoft IE 9.0 or later. Installing TCP/IP protocol to the computer. www.hypercable.fr www.e-rake.us.com... -
Page 9: Mechanical Description
This equipment must be grounded. Never defeat the ground conductor or operate the equipment in the absence of a suitably installed ground conductor. Contact the appropriate electrical inspection authority or an electrician if you are uncertain that suitable grounding is available. www.hypercable.fr www.e-rake.us.com... -
Page 10: Antenna Location Definition Version 4X4
※ Note: 1. When you set the RF to 1x1 instead of 2x2 MIMO, only Primary port works. 2. RF1 = Wireless 1 / RF2 = Wireless 2 in the configuration page. 3. With Daisy chain M12 junction cable www.hypercable.fr www.e-rake.us.com... -
Page 11: Antenna Location Definition Version 2X2
Option WiFi RF1- Primary RF1- Secondary ※ Note: 1. When you set the RF to 1x1 instead of 2x2 MIMO, only Primary port works. 2. RF1 = Wireless 1 / RF2 = Wireless 2 in the configuration page. www.hypercable.fr www.e-rake.us.com... - Page 12 This RJ-45 port (10 / 100 / 1000) is used to connect to the ODU. . DC Input Connect to the Power adaptor for DC input. (Passive 48V DC) LED Indicator Power LED Power Over Ethernet Injector is not a waterproof unit, should not be exposed to the outdoor without any protection. www.hypercable.fr www.e-rake.us.com...
-
Page 13: Hardware Installation
300 MHz UHF 2x2 MIMO HT-OFDM MESH Radio operations first before you mount the radio in a remote location. Power Over Ethernet Injector is not a waterproof unit, should not be exposed to outdoor without any protection. www.hypercable.fr www.e-rake.us.com... -
Page 14: Led Indicators
LED1~2 on: -76dB ≧ RSSI ≧ -80dBm Note 1: when the radio is configured as mesh mode, the RSSI is value is average RSSI which is calculated from all the connected mesh nodes. Note 2: LED indicator showed the status of Wireless1. www.hypercable.fr www.e-rake.us.com... -
Page 15: Chapter 3 Configuration
Logout buttons will be shown in left part. The main menu provides links to the whole sections of the web configuration interface. Information This page shows most of the product information briefly, that includes General Information, Network Information, MESH, Wireless Network 1, Wireless Network 2 and Wired Network www.hypercable.fr www.e-rake.us.com... - Page 16 Information -1 Status This page shows all the status of the radio in one page, such as System, mesh, wireless and port statistics. www.hypercable.fr www.e-rake.us.com...
- Page 17 Status -1 – (Base station mode) Status -2 (Base station mode) www.hypercable.fr www.e-rake.us.com...
- Page 18 Status ‐CPE mode Status – PTP Bridge mode www.hypercable.fr www.e-rake.us.com...
- Page 19 1. You can select “Obtain current position from GPS receiver” with the radio type that integrated GPS module. Attach an external GPS active antenna to the GPS port, you can see the received list of the GPS satellites. www.hypercable.fr www.e-rake.us.com...
- Page 20 2. Enter the coordinates manually (this can also be done in System / Basic Setup) or 3. Drag the location mark of the radio to anywhere in the map you want. www.hypercable.fr www.e-rake.us.com...
- Page 21 MAP – Topology Topology Map – Radio info (IP address/ MAC / operating mode & Frequency) Topology Map – Link status (Data rate / RSSI / Distance / Frequency) Topology Map – Multi-hops repeating Topology Map – Mesh Network www.hypercable.fr www.e-rake.us.com...
- Page 22 Topology Map – PMPT from a Relay repeater in the Mountain www.hypercable.fr www.e-rake.us.com...
-
Page 23: System / Basic Setup
IP Address: Type the IP address you want to set to your 300 MHz 4x4 MIMO HT-OFDM MESH Radio (Default: 192.168.1.1). IP Subnet Mask: The Wireless backhaul’s Subnet Mask must be the same as your Ethernet network. We recommended that you do NOT change the value. (Default: 255.255.255.0). www.hypercable.fr www.e-rake.us.com... - Page 24 Specifies the interval that the bridge waits to hear BPDUs Max Age from the spanning tree root Forward Delay Specifies a forward delay interval on the bridge Note: If you complete the settings, please click on “Apply” for changes to take effect. www.hypercable.fr www.e-rake.us.com...
-
Page 25: Mesh Protocol Configuration
GPS time settings: Sync the time with GPS module. Time Server: the central time of the Time Server. Time Server Port: the port of the Time Server. Time server for a Lan connection to an Orange ADSL router is 192.168.1.1 3-2 Mesh Protocol Configuration www.hypercable.fr www.e-rake.us.com... - Page 26 Maximum Hops (1~30): Define the max repeating hops in the mesh network. Acceptable RSSI (-50~-90dBm): This RSSI threshold is an important reference parameter to decide to hold the link between the Mesh nodes or change to other better optional path. Probe interval time: Configuring the Time Interval between Probes. www.hypercable.fr www.e-rake.us.com...
-
Page 27: Wireless Setup
Operating Mode: Base Station The default mode is Base Station, which can be scanned and connected by other CPEs. Perform as a client station associated to other BS. Be sure that they share the same SSID when connected. www.hypercable.fr www.e-rake.us.com... - Page 28 Client mode can only connect to Client-server model: Server mode and Hybrid model: Server mode. Hybrid model: Server mode Hybrid model: Server mode can connect to Client-server model: Client mode, Hybrid model: Client mode and Unstructured peer to peer mode. www.hypercable.fr www.e-rake.us.com...
- Page 29 RTS Threshold: “Request to send” is the optional mechanism used by the 802.11 wireless networking protocol to reduce frame collisions introduced by the hidden node problem. Set the packet size to trigger RTS/CTS enable. This is normally set in base station side only because the hidden station www.hypercable.fr www.e-rake.us.com...
- Page 30 (This is NOT Available in Mesh mode) Security/Cipher To prevent unauthorized radios from accessing data transmitted over the link, the Encryption Settings window offers WPA2 PSK features, making your data transmission over air more secure and allows you to specify Encryption Key(s). www.hypercable.fr www.e-rake.us.com...
- Page 31 Open System – without encryption WPA2 PSK – AES encryption Wireless Setup / Access control (This is NOT Available in Mesh mode) You can enable the MAC address Access control feature and decide which mode you want to control, Allow or Deny. www.hypercable.fr www.e-rake.us.com...
-
Page 32: Management
Note: After you change password, please take note of your new password. Otherwise, you will not able to access the radio with correct password. Management / Remote Management You can doing the remote Management via Secure Shell (SSH) or SNMP by setting the parameters in this page. www.hypercable.fr www.e-rake.us.com... - Page 33 The current system settings can be saved into a file as a backup by clicking “Backup”. The saved file can be loaded back on the radio by clicking “Browse”. When you have selected the settings file, click “Retrieve” to begin the process. Furthermore, you may click “Restore” to factory default settings. www.hypercable.fr www.e-rake.us.com...
- Page 34 300 MHz 4x4 MIMO HT- OFDM MESH Radio Select the “Yes” check box and click “Apply”. It will take you about 50 seconds to go through reboot. The Web-browser will not be accessible until the Wireless backhaul has finished its reboot process. www.hypercable.fr www.e-rake.us.com...
- Page 35 Then use a stick to press in and hold the RESET button for 6~9 seconds. This will reset the Radio to the factory default settings. If you applied any personal configuration settings, you will need to make the changes again. Reset button Reset button of the radio www.hypercable.fr www.e-rake.us.com...
