Skyline Furniture 410SH Series Assembly Instructions Manual

Bed

Advertisement

Quick Links

headboard components

(1) Headboard*
*images might vary from actual product

headboard hardware

(8) 2" x 5/16" bolts
(20) 1¼" washers
If you have any questions, please call us at 1.800.542.7553
LIMITED WARRANTY
SKYLINE FURNITURE INC. guarantees
its upholstered furniture against defects in
construction for a period of one (1) year.
When a structural defect is brought to our
attention, we will repair or replace it at our
option at no charge to the customer (includes
parts and labor, not transportation costs).
Fabric wearability for upholstered furniture
is not covered by the warranty. Vacuum for
regular cleaning.
PLEASE DISPOSE OF PLASTIC BAG (S) AND
CARTON (S) RESPONSIBLY.
Assembly Instructions for 410SH Series
(2) wings*
(8) 1½" x 5/16" bolts
(4) 5/16" nuts
LIMITE DE GARANTIA
SKYLINE FURNITURE INC. garantiza
sus muebles tapizados contra defectos en
construccion por un periodo de un (1) ano.
Cuando un problema de estructura es traido
a nuestra atencion, nosotros repararemos o
remplazaremos sin ningun cargo a nuestro
cliente (incluye partes y trabajo, no costo en
transportacion). Descoloramiento del materi-
al de muebles tapizados no es cubierto por la
garantia. Regularmente puede aspirar.
POR FAVOR TIRAR BOLSA (S) Y CAJA (S)
RESPONSABLEMENTE.
41 0S H BE D
(2) wooden legs*
You will need:
• phillips screwdriver
• flat head screwdriver
• pliers
*Open all hardware packets
in both packages before
starting assembly.
GARANTIE LIMITÉE
SKYLINE FURNITURE INC. garantit ses
meubles rembourrés contre les défauts de
construction pendant une période d'un (1)
an. Lorsqu'un vice de construction nous est
signalé, nous réparons ou remplaçons le
meuble, selon notre choix, sans frais pour le
client (incluant les pièces et la main-d'oeu-
vre, mais excluant les frais de transport). La
durabilité du tissu des meubles rembourrés
n'est pas couverte par la garantie. Nettoyer
régulièrement avec un aspirateur.
VEUILLEZ JETER LE OU LES SAC(S)
EN PLASTIQUE ET BOÎTE(S) DE FAÇON
RESPONSABLE.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 410SH Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Skyline Furniture 410SH Series

  • Page 1 41 0S H BE D Assembly Instructions for 410SH Series headboard components (1) Headboard* (2) wings* (2) wooden legs* *images might vary from actual product headboard hardware You will need: • phillips screwdriver • flat head screwdriver • pliers (8) 2” x 5/16” bolts (8) 1½”...
  • Page 2 upholstered side rails hardware *Open all hardware packets in both packages before starting assembly. Wingbacks come with two additonal bolts/washers (6) 1” x 5/16” bolts (6) 1¼” washers which are listed in the chart in Step 7. bed components (2) side rails for all sizes support rails (1) Twin/ Full/ Queen...
  • Page 3 LIMITE DE GARANTIA GARANTIE LIMITÉE SKYLINE FURNITURE INC. guarantees SKYLINE FURNITURE INC. garantiza SKYLINE FURNITURE INC. garantit ses its upholstered furniture against defects in sus muebles tapizados contra defectos en meubles rembourrés contre les défauts de construction for a period of one (1) year.
  • Page 4 Step 1 Attach each wing to headboard using: 1. (1) 2” x 5/16” bolt and (1) 1¼” washer 2. (1) 2” x 5/16” bolts and (1) 1¼” washer 3. (1) 2” x 5/16” bolts and (1) 1¼” washer 4. Repeat process for the other wing. Step 2 Insert wooden legs through the holes in the headboard.
  • Page 5 Step 3 1. Attach side rail and end rail to corner bracket. Make sure to align holes and snap into thinner slot. Continue this action until you have a rectangular frame. 2. Attach corners to rails using (8) ¼” bolts and (8) ¼” nuts. 3.
  • Page 6 Step 4 1. Attach each support bar using (2) ¼” bolts and (2) ¼” nuts. Make sure to attach the support bar underneath the bed frame. Note: Twin/ Full/ Queen = 1 support bar King/California King = 3 support bars 2.
  • Page 7 Step 6 Connect assembled bed frame and rails to your headboard. Attach pieces using (4) 1½” x 5/16” bolts, (8) 1¼” washers*, and (4) 5/16” nuts. * Use a washer on each side of the metal legs when attaching headboard to the bed frame.
  • Page 8 Step 8 With a phillips screwdriver, attach (2) L brackets and (8) ¾” self-tapping screws in the corners of the foot rail. This is needed to increase stability of upholstered rails.
