Installation Guide

Follow the simple steps outlined in this section to install and start using
the Metrobility 100Mbps Delta Class "twister" media converter.
Unpack the "twister" and
Accessories
Check that the following parts are included in your box:
• 100Mbps Delta Class "twister"
• Power supply
• Power supply cord (North American shipments only)
• Four (4) rubber feet
Your order has been provided with the safest possible packaging, but
shipping damage occasionally does occur. Inspect your order carefully. If
you discover any shipping damage, notify your carrier and follow
instructions for damage and claims. Save the original shipping carton if
return or storage of the unit is necessary.

Attach the Rubber Feet

The "twister" is shipped with four rubber feet located on the black
adhesive strip. To install the rubber feet, first turn the "twister" upside-
down. Peel the feet from the adhesive strip, then attach one foot to each
circular indentation on the unit. This provides an air gap which helps to
cool the unit, and also adds stability for desktop operation.
If you are stacking the "twister" on top of another unit, the rubber feet
must be attached to the bottom of the "twister".

Choose an Appropriate Location

The "twister" is intended for use in either an office or a residential
environment. The unit must be located within six (6) feet of the AC power
source being used and placed as far away as possible from electrical
noise generating equipment such as copiers, electrostatic printers, and
other motorized equipment. If exposed twisted-pair wiring is used nearby,
the wiring should be routed as far away as possible from power cords
and data cables to minimize interference.
Installation Guide 5
