Logic3 Scuderia FS1 (2LFS001) User Manual page 4

Controls
Power / Pairing / Function
Volume -
AUX(Green) / Bluetooth(Blue)
/ iPod(Red) indicator
AC socket
Composite video jack
AUX jack
USB charge port
Play / Pause
Next
Previous
English
TOP PANEL
FRONT PANEL
BOTTOM PANEL
REMOTE CONTROL
Remote control batteries
1. Open the batter door with the with the side the arrowhead
Power
pointed.
2. Fit the battery observing polarity as shown with the same
CR2025 type specified.
Function
Volume +
Volume -
Docking Connector
Volume +
Remote sensor
CR2025
3V
+
4
