- Page 1 Air-powered Brad Nailer Model No. 058-9340-0 IMPORTANT: INSTRUCTION Please read this manual carefully before MANUAL using this product, and save it for reference.
-
Page 2: Table Of Contents
TABLE OF CONTENTS TECHNICAL SPECIFICATIONS SAFETY GUIDELINES KEY PARTS DIAGRAM TECHNICAL INFORMATION TYPES OF NAILS OPERATING INSTRUCTIONS MAINTENANCE TROUBLESHOOTING EXPLODED VIEW PARTS LIST WARRANTY NOTE: If any parts are missing or damaged, or if you have any questions, please call our toll-free helpline at 1-888-670-6682. -
Page 3: Technical Specifications
058-9340-0 | contact us 1-888-670-6682 SAFETY GUIDELINES TECHNICAL SPECIFICATIONS This manual contains information that relates to PROTECTING PERSONAL MAGAZINE CAPACITY 100 nails SAFETY and PREVENTING EQUIPMENT PROBLEMS. It is very important to read this manual carefully and understand it thoroughly before using NAILS 18-gauge brad nails (5/8–2") -
Page 4: Safety Guidelines
058-9340-0 | contact us 1-888-670-6682 SAFETY GUIDELINES Risk of burns. The pump and the manifold generate high temperatures. In order to avoid burns or other injuries, do not • Do not use oxygen or any other combustible or bottled gas to touch the pump, the manifold or the transfer tube while the power air-powered tools. - Page 5 058-9340-0 | contact us 1-888-670-6682 Carry the tool by the handle only. Do not carry the tool with Disconnect the tool from the air supply before a finger on the trigger. Do not carry the tool by the hose, loading or changing nails in order to prevent a nail the magazine nor any other part.
- Page 6 Description GUIDELINES FOR PROPER USE AND OPERATION Air inlet plug Quick release handle Be sure to use a proper air compressor with MAXIMUM Air-powered tools. ® The compressor that is being used must be able to supply appropriate Magazine latch Depth adjustment dial amount of pressure (PSI) to the tool.
- Page 7 (70 to 110 PSI). Inspect the Air-powered Brad Nailer prior to each use in order to: • Do not exceed the maximum or minimum pressures. Operating the – Ensure that the proper power source is being used. tool at inappropriate pressure (too low or too high) will cause –...
-
Page 8: Types Of Nails
058-9340-0 | contact us 1-888-670-6682 Loading Nails This MAXIMUM ® Brad Nailer drives 18-gauge 5/8-2" (15-50 mm) long brad nails. Fig. A ACCEPTABLE NAILS 1. Disconnect the tool (1) from the air Length: 5/8 - 2" (15 to 50 mm) supply (2) (Fig. - Page 9 058-9340-0 | contact us 1-888-670-6682 Fasteners depth adjustment 4. Plug in compressor, turn it on, set the Fig. D Fig. F pressure regulator to 90 PSI, and attach The MAXIMUM Air-powered Brad Nailer ® one end of the air hose to the compressor...
- Page 10 058-9340-0 | contact us 1-888-670-6682 Cold weather operation Maintenance When operating any air-powered tool below freezing MAXIMUM SERVICE INTERVAL TOOLS OR temperature: MAINTENANCE MATERIALS DESCRIPTION REQUIRED Each use or REQUIRED Monthly • Verify that the compressor tanks have been properly drained...
- Page 11 058-9340-0 | contact us 1-888-670-6682 Troubleshooting POSSIBLE CAUSES SOLUTIONS PROBLEM The following chart lists common issues and solutions. Please The tool does The air supply is Verify that the air supply is read it carefully and follow all instructions carefully.
- Page 12 058-9340-0 | contact us 1-888-670-6682 Description Description Movable driver guide cover Pin 3 x 26 O-ring 1.9 x 1.2 Adjustable washer II Compressed spring Driver guide Push stem Safety nozzle Adjustable seat Pin 1.5 x 8 Inlay slice Movable magazine Steel ball Dw=2.5...
-
Page 13: Operating Instructions
058-9340-0 | contact us 1-888-670-6682 This MAXIMUM product is guaranteed for a period of 5 years This warranty will not apply to any parts other than original parts, from the date of original retail purchase against defects in... -
Page 14: Warranty
Maximum Canada will maintain this product and replace critical parts Neither the retailer, Maximum Canada, nor the manufacturer shall be liable for which have worn beyond reasonable use through normal use of such any other expense, loss or damage, including, without limitation, any indirect, product, any time during the first year after purchase.
