- Page 1 MODEL: CFI-100-1 www.tsicustomerservice.com 1-866-661-1218 Twin-Star International, Inc; Delray Beach, FL 33445 Made in China • Printed in China A313 www.tsicustomerservice.com...
-
Page 2: Getting Started
Model Number MOVABLE HEATER (+1) 866-661-1218 CFI-100-1 Serial Number www.tsicustomerservice.com 120V ~, 1500W, 60Hz Twin-Star International, Inc. SN #: AE-12345-A www.twinstarhome.com MADE IN CHINA Date Code/ Code de Date/ Código Fecha: CONFORMS TO UL STD. 1278 4005554 CERTIFIED TO CSA STD. C22.2 NO.46 2 . -
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electrical shock, and injury to persons including the following: 1. Read all instructions before using this appliance. 2. This appliance is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. If provided, use handles when moving this appliance. -
Page 4: Installation Instructions
INSTALLATION INSTRUCTIONS 1. Open fireglass box cover by holding and pressing hook in the middle of box; 2. Carefully remove tray cover and place fireglass in; then re-install the tray cover. A313 www.tsicustomerservice.com... -
Page 5: Operation Instructions
OPERATION INSTRUCTIONS Display Control Panel The heater can be operated by either the remote control or the control panel. TIMER A313 www.tsicustomerservice.com... - Page 6 OPERATION INSTRUCTIONS FUNCTION ICON DESCRIPTION The POWER button supplies power to all the functions of POWER the heater. Pressing the POWER button again the heater will be put in standby mode. With the power on press and hold the POWER button on the control panel for 10 seconds to disable the heater funtion.
- Page 7 OPERATION INSTRUCTIONS FUNCTION ICON DESCRIPTION Press BLUE button on the remote to switch to Bluetooth input. BLUE Press LINE IN button on the remote to switch to Line input. LINE IN CLOCK Press CLOCK button on remote to show the current time. For manual time setting: Hold “CLOCK”...
-
Page 8: Troubleshooting
TROUBLESHOOTING Problem Root Cause Corrective Action Display shows “ ” The thermostat sensor is Unplug the fireplace, remove the back panel of the fireplace and check that the broken or disconnected. thermostat is plugged into the main circuit board. If this does not solve the problem contact customer service for a replacement thermostat sensor. -
Page 9: Exploded View
EXPLODED VIEW Part Part Name Part Number Blower/Heater Assembly Y15-S157-P01 Main Circuit Board Y15-S157-P15 Power Circuit Board Y15-S157-P78 Upper Flame Y15-S157-UF Circuit Board Main Speaker Y15-S157-MS Bass Speaker Y15-S157-BS Spinner Y15-S157-P11 Spinner Motor Y15-S157-P10 Lower Flame Circuit Board Y15-S157-LF Uplight PCBA Y15-S157-UP Fireglass Tray Y15-S157-FT... -
Page 10: Fcc/Ic Information
FCC/IC INFORMATION Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 11: Year Limited Warranty
3-YEAR LIMITED WARRANTY The manufacturer warrants that your new Speaker is free from manufacturing and material defects for a period of three years from date of puchase, subject to the following conditions and limitations. 1. Install and operate this Electric Appliance in accordance with the installation and operating instructions furnished with the product at all times. - Page 13 EF 100*250MM WARNING – TO REDUCE THE RISK OF FIRE: 1) Do not place any objects such as furniture, papers, clothes, and curtains closer than 3 feet(0.9 m) to the front of the heater and keep them away from the sides and rear when the heater is plugged in.
- Page 14 This device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
