Replacing a GLM
Use this procedure for the following configurations:
HSG80 ACS Version 8.2 Dual-Redundant Controller
Use the following steps in "Removing a GLM" and "Installing a
GLM" to replace a GLM.
Removing a GLM
Use the following steps to remove a GLM:
1. Connect a PC or terminal to the operational controller. The
controller to which you're connected is "this controller"; the
controller whose GLM you are replacing is the "other
controller."
2. Disable failover with the following command:
SET NOFAILOVER
3. Start FRUTIL with the following command:
RUN FRUTIL
FRUTIL displays the following:
Do you intend to replace this controller's cache
battery? Y/N
4. Enter N(o). FRUTIL displays the FRUTIL Main menu:
FRUTIL Main Menu:
1. Replace or remove a controller or cache module
2. Install a controller or cache module
3. Replace a PVA module
4. Replace an I/O module
5. Exit
Enter choice: 1, 2, 3, 4, or 5 ->
5. Enter option 1, Replace or remove a controller or cache
module, from the FRUTIL Main menu. FRUTIL displays the
Replace or Remove Options menu:
Replace or remove Options:
1. Other controller and cache module
2. Other controller module
3. Other cache module
4. Exit
Enter choice: 1, 2, 3, or 4 ->
6. Enter option 2, Other controller module, from the Replace or
Remove Options menu. FRUTIL displays the following:
Slot Designations
[ --- EMU ---
[ -------- Controller A
[ -------- Controller B
[ Cache Module A
Remove the slot A [ or B ] controller? Y/N
(front view)
][ --- PVA ---
-------
-------
][ Cache Module B
7. Enter Y(es) and press return. FRUTIL displays the
following:
Quiescing all device ports.
Device Port 1 quiesced.
Device Port 2 quiesced.
Device Port 3 quiesced.
Device Port 4 quiesced.
Device Port 5 quiesced.
Device Port 6 quiesced.
All device ports quiesced.
Remove the slot A [ or B ] controller (the one without
a blinking green LED)
See Figure 3 for location of the controller.
Memory module A
Figure 3. Location of Controllers and Cache Module
CAUTION: The device ports must quiesce before removing the
cache module. Failure to allow the ports to quiesce may result
in data loss. Quiescing may take several minutes.
ESD can easily damage a controller or GLM. Wear a snug-fitting,
grounded ESD wrist strap.
NOTE: A countdown timer allows a total of two minutes to
remove the cache module. If you exceed two minutes, "this
controller" will exit FRUTIL and resume operations. If this
happens, go back to step 3.
8. Remove the program card's ESD cover and program card.
Save them for reinstallation later.
9. Disconnect the host bus cables from the "other controller"
using needle nose pliers (see Figure 2).
NOTE: One or two host bus cables may be attached, depending
on the configuration.
]
10. Disengage both retaining levers, and remove the "other
]
]
controller." Place the controller onto a grounded antistatic
]
mat.
11. Once the controller is removed, FRUTIL displays the
following:
Restarting all device ports. Please wait...
Device Port 1 restarted.
Device Port 2 restarted.
Device Port 3 restarted.
Device Port 4 restarted.
Device Port 5 restarted.
Device Port 6 restarted.
Do you have a replacement controller? Y/N
3
Please wait...
EMU PVA
Controller A
Controller B
Memory module B
CXO6283A
