  • Page 1 Local Service Organization Service Manual BE INSPIRED Our innovation shapes the future...

  • Page 2: Table Of Contents

    S I E M E N S P T E L T D MC 60 Level 2 Service Manual Table of Contents G P R S ( G E N E R A L P A C K E T R A D I O S E R V I C E ) … … … . 3 K JAVA APPLICATION……………………………………………………………….4...

  • Page 3: Gprs (General Packet Radio Service)

    S I E M E N S P T E L T D MC 60 Level 2 Service Manual GPRS (General Packet Radio Service) GPRS is a new non-voice value added services that allows information to be sent and received across a GSM mobile telephone network. It supplements today’s Circuit Switched Data (CSD) and Short Message Services (SMS).

  • Page 4: Key Features

    S I E M E N S P T E L T D MC 60 Level 2 Service Manual Java-based game system Java Application Manager Application launcher (JAM) download manager. Supports HTTP-based download of applications over GPRS and CSD. RAM for Java applications...
  • Page 5 S I E M E N S P T E L T D MC 60 Level 2 Service Manual • Nominal Voltage : 3.6V • Nominal Capacity : 750 mAh • GSM Capacity : 700 mAh • Power Input : 1.8A (0.6 ms) / (4 ms) •...

  • Page 6: Comparison With Previous Product

    S I E M E N S P T E L T D MC 60 Level 2 Service Manual Transmitter set points will be specified for GSM and PCN when typical values and statistical values become available. Speech Codec • Triple Rate (...

  • Page 7: Accessories

    Min. 95 dB(A) @ 5 cm Min. 95 dB(A) @ 5 cm Typ. > 100 dB(A) @ 5 cm Typ. > 100 dB(A) @ 5 cm Accessories For MC 60, the following accessories will be available. Description Part number Li-Ion Battery EBA-510 L36880-N5601-A100 Copyright ©...
  • Page 8 Serial Data Cable L36880-S5601-A800 5.1 Interface MC 60 to accessories The I/O Connector of MC 60 is the slim Lumberg (identical to SL55, S55/57, C55/2128, A55/52, and M55). It is the only electrical interface to the Accessories. Also, it has only one mechanical interface which is integrated in the design parts.
  • Page 9 S I E M E N S P T E L T D MC 60 Level 2 Service Manual Slim Lumberg I/O Connector Copyright © Siemens Pte Ltd. Siemens Technical Support Centre All Rights Reserved ICM MP CCQ ASP/ASC Page 9 of 37...

  • Page 10: Unit Description Mc60

    MC 60 Level 2 Service Manual Unit Description MC 60 The MC 60 is the first Siemens mobile phone with integrated CIF-Camera. It is designed as a single-PCB phone with a partly bridgeless keypad, color display, exchangeable covers and exchangeable keypads. The upper and lower covers are designed as two-colored parts, which is realized in 2-shot-moulding technology.
  • Page 11 S I E M E N S P T E L T D MC 60 Level 2 Service Manual Exploded View of MC 60 Earpiece Cover with mesh Display window Upper Case Antenna Mounting frame Sim Slider Microphone Vibra Motor...
  • Page 12 S I E M E N S P T E L T D MC 60 Level 2 Service Manual Camera Module Camera Module Explode View of Camera Module: Camera Unit Flex (C-MOS Chip with housing and lens; lens hood and cover glass)
  • Page 13 S I E M E N S P T E L T D MC 60 Level 2 Service Manual Display Module PCB Back View Assembly of Camera Module Camera Module MC 60 Final Assemblies: Copyright © Siemens Pte Ltd. Siemens Technical Support Centre...

  • Page 14: Disassemblyof Mc 60

    S I E M E N S P T E L T D MC 60 Level 2 Service Manual Upper Case Inner Unit Keypad Lower case Disassembly of MC 60 Copyright © Siemens Pte Ltd. Siemens Technical Support Centre All Rights Reserved...
  • Page 15 S I E M E N S P T E L T D MC 60 Level 2 Service Manual Note: ESD concept; the internal circuits will be more susceptible to ESD because of the use of exchangeable housing. The construction of the internal block must be/is designed, in the best possible way, to protect the circuit against sparks.
  • Page 16 S I E M E N S P T E L T D MC 60 Level 2 Service Manual Step 5 Step 6 To remove the SIM card, push the SIM slider upwards To remove the CLIPit cover, gently pull the cover upwards as indicated by the arrow.
  • Page 17 S I E M E N S P T E L T D MC 60 Level 2 Service Manual Step 11 Step 12 To detach the camera module with a pair of tweezers to Remove the Vibrator motor and MIC from the Lower disconnect the flex cable from the connector.

  • Page 18: Reassembly Of Mc 60

    MC 60 Level 2 Service Manual Reassembly of MC 60 For the reassembly of the MC 60, reverse the disassembly procedures from Step 12 to Step 1. However there are some areas to be taken note of during reassembling of the phone.

  • Page 19: Mobile Software Programming

    - Software update to actual version and appropriate language group - Programming of CUSTOMER SPECIFIC INITIALIZATION Slim Lumberg Cable Boot Adapter AC Adapter Figure 1. MC 60 Software Programming Setup Copyright © Siemens Pte Ltd. Siemens Technical Support Centre All Rights Reserved ICM MP CCQ ASP/ASC...

  • Page 20: Mobile Software Updating

    S I E M E N S P T E L T D MC 60 Level 2 Service Manual 9.1 Mobile Software Updating The software of the mobile, L55 series is loaded from a PC directly. Hardware interconnection between the mobile and the PC is shown in Figure 1. Because of the new type of external connector used in X55 series (Slim-Lumberg type) an additional adaptor cable between mobile and boot adaptor is required.
  • Page 21 S I E M E N S P T E L T D MC 60 Level 2 Service Manual 9.2 Flow Chart for Software Upgrading Plug in the Boot Start the SWUP S/W upgrading in Adaptor to the PC program...

  • Page 22: Siemens Service Equipment User Manual

    2. Sets, which pass the test, will be good enough to return to customer. Starting from the P35 Series, Siemens will introduce a simpler and faster testing platform for testing a repaired Siemens mobile phone. The testing platforms are either base on R&S CMD 53/55 or CTS55 GSM test set.
  • Page 23 PICS-TRUST- Center at department ICP MP OI Kamp-Lintfort. In case of any questions or requests concerning chip cards or administration of the databases please ask your responsible Siemens Customer Care Manager. Copyright © Siemens Pte Ltd. Siemens Technical Support Centre...
  • Page 24 PICS Websites (and a password which gives you access to your chip card). Chip cards can be ordered via your responsible Customer Care Manager within Siemens. 3. A supported chip card reader (Smarty or Siemens B1) in order to access your chip card. Remark: We recommend using Siemens B1 reader.
  • Page 25 S I E M E N S P T E L T D MC 60 Level 2 Service Manual Master - Phonecodes The Master – Phonecode is used to unlock blocked mobiles. Master – Phonecodes can only be supplied for mobiles which have been delivered in a regular manner.
  • Page 26 S I E M E N S P T E L T D MC 60 Level 2 Service Manual Simlock Unlock - Code The Simlock-Unlock-Codes can only be generated if the following conditions are given: - Mobile must have an active Simlock inside.
  • Page 27 S I E M E N S P T E L T D MC 60 Level 2 Service Manual If there's no such authorization you'll get the following screen: In this case please contact your responsible Siemens Customer Care Manager. Copyright © Siemens Pte Ltd. Siemens Technical Support Centre...
  • Page 28 S I E M E N S P T E L T D MC 60 Level 2 Service Manual Printing IMEI label The module “Print IMEI label” offers the possibility to print IMEI labels for mobiles again. You are able to print up to six labels in just one step.
  • Page 29 S I E M E N S P T E L T D MC 60 Level 2 Service Manual Hint: For correct printing of IMEI labels you must have a Zebra – label printer with special material that fits for label printing. This printer has to be connected to local LPT1 printer port (also see Installation of IMPRINT) and MUST feature a printing resolution of 300dpi.

  • Page 30: International Mobile Equipment Identity, Imei

    2 digits. 6 digits have been allocated for the equipment serial number for manufacturer and the last digit is spare. The part number for the MC 60 is S30880-S5760-Axxx where the last 4 letters specify the housing and software variant.

  • Page 31: General Testing Information

    The technical instruction for testing GSM mobile phones is to ensure the best repair quality. Validity This procedure is to apply for all from Siemens AG authorized level 2 up to 2.5e workshops. Procedure All following checks and measurements have to be carried out in an ESD protected environment and with ESD protected equipment/tools.
  • Page 32 S I E M E N S P T E L T D MC 60 Level 2 Service Manual !! Verify the customers fault description!! After a successful verification pass the defective item to the responsible troubleshooting group. If the fault description can not be verified, perform additional tests to save time and to improve repair quality.
  • Page 33 S I E M E N S P T E L T D MC 60 Level 2 Service Manual GSM Test: Connect the mobile/board via internal antenna (antenna coupler) and external antenna (car cradle) to a GSM tester. Use a Test SIM.
  • Page 34 S I E M E N S P T E L T D MC 60 Level 2 Service Manual Copyright © Siemens Pte Ltd. Siemens Technical Support Centre All Rights Reserved ICM MP CCQ ASP/ASC Page 34 of 37 Internal Use Only...
  • Page 35 S I E M E N S P T E L T D MC 60 Level 2 Service Manual Final Inspection: The final inspection contains: 1) A 100% network test (location update, and set up call). 2) Refer to point 3.3.

  • Page 36: Annex 1

    S I E M E N S P T E L T D MC 60 Level 2 Service Manual Annex 1 Test SIM Card There are two different “Test SIM Cards” in use: 1) Test SIM Card from the company “ORGA”...

  • Page 37: Annex 2

    S I E M E N S P T E L T D MC 60 Level 2 Service Manual Annex 2 Battery Date Code overview Varta Date code example N 9 A VA Year (N:2001, O:2002...) Supplier Code Month (1:Jan, 2:Feb,…9:Sep, O:Oct, N:Nov, D:Dec) (Maker’s marking)
