AXIOMTEK GOT5100T-832 User Manual

All-in-one 10.4” svga tft fanless touch panel computer with intel atom n2600 processor
Hide thumbs Also See for GOT5100T-832:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
GOT5100T-832
All-in-One
10.4" SVGA TFT Fanless
Touch Panel Computer with
®
TM
Intel
Atom
N2600 Processor
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GOT5100T-832 and is the answer not in the manual?

Questions and answers

Related Manuals for AXIOMTEK GOT5100T-832

Summary of Contents for AXIOMTEK GOT5100T-832

  • Page 1 GOT5100T-832 All-in-One 10.4” SVGA TFT Fanless Touch Panel Computer with ® Intel Atom N2600 Processor User’s Manual...
  • Page 2 Axiomtek does not make any commitment to update the information in this manual. Axiomtek reserves the right to change or revise this document and/or product at any time without notice. No part of this document may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Axiomtek Co., Ltd.

  • Page 3: Safety Precautions

    Most electronic components are sensitive to static electrical charge. Disconnect the power cord from the GOT5100T-832 before any installation. Be sure both the system and external devices are turned OFF. A sudden surge of power could ruin sensitive components that the GOT5100T-832 must be properly grounded.

  • Page 4: Table Of Contents

    Table of Contents CHAPTER 1 INTRODUCTION ................1 CHAPTER 2 HARDWARE AND INSTALLATION ............8 ....................9 PEN BACK COVER ..................9 CARD NSTALLATION ................11 UMPER AND WITCH ETTINGS ................... 13 PORT ONNECTOR ....................... 14 THERNET / VESA ..............14 OUNTINGS ANEL HDD I...
  • Page 5 This page is intentionally left blank.

  • Page 7: Chapter 1 Introduction

     Package List General Description The GOT5100T-832 is a fan-less and compact-size touch panel computer, equipped with a 10.4” TFT LCD display and low power consumption Intel® Atom™ N2600 1.6GHz processor. The GOT5100T-832 supports Windows® 7 32-bit, and WES 7. The panel computer provides a Mini card slot for wireless module. Its excellent ID and friendly user interface make it a professional yet easy-to-use panel computer.

  • Page 8: Specifications

    GOT5100T-832 User’s Manual Back Reliable and Stable Design The GOT5100T-832 adopts a fanless cooling system, which makes it suitable for vibration environments. Embedded O.S. Supported The GOT5100T-832 not only supports Windows® 7 32-bit, but also supports embedded OS, such as WES 7. For storage device, the GOT5100T-832 supports CompactFlash™...
  • Page 9 GOT5100T-832 User’s Manual Back  Audio  One Line-out  Expansion  One Mini card  Storage  One slot for CF card  One SATA  Power connector  GOT5100T-832: DC Power input +10~30VDC (phoenix type)  GOT5100T-832-J: AC 100~240V to DC +12V adapter(Screw type) System Specification ...
  • Page 10 GOT5100T-832 User’s Manual Back Dimensions and Outlines The following diagrams show the dimensions and outlines of GOT5100T-832. Introduction...
  • Page 11 GOT5100T-832 User’s Manual Back Introduction...
  • Page 12 GOT5100T-832 User’s Manual Back I/O Outlets Please refer to the following illustration for I/O locations of the GOT5100T-832. Function Function POWER SWITCH (ATX) COM 2 (RS-232) Power Input connector (Screw) Ethernet (RJ-45) Power Input connector (Phoenix) Dual USB 2.0 ports Dual USB 2.0 ports...

  • Page 13: Packing List

    Screws for HDD  HDD Mylar Sticker  Phoenix connector x 1 (for GOT5100T-832)  Power Adapter & Cord x 1 (for GOT5100T-832-J) If you cannot find the package or any items are missing, please contact Axiomtek distributors immediately. Introduction...

  • Page 14: Hardware And Installation

    Back Chapter 2 Hardware and Installation The GOT5100T-832 provides rich I/O ports and flexible expansions for you to meet different demand, for example CF card. The chapter will show you how to install the hardware. It includes: Open Back Cover ...

  • Page 15: Open

    GOT5100T-832 User’s Manual Back Open back cover This section tells users how to open back cover. Please follow the steps below. Step 1 Unscrew 6 screws on the back cover. Please refer the photo below. Step 2 Remove the back cover.

  • Page 16: Cf Card Installation

    GOT5100T-832 User’s Manual Back CF card Installation ™ The GOT5100T-832 provides one CF slot for users to install CompactFlash card. Please refer to the following instructions for installation: Step 1 Turn off the system, and unplug the power cord. Step 2 Find out the cover on the side of the system.

  • Page 17: Jumper And Switch Settings

    2 jumper pins to close. And remove jumper clip from 2 jumper pins to open. The following illustration shows how to set up jumper. Before applying power to GOT5100T-832, please make sure all of the jumpers and switch are in factory default position. Below you can find a summary table and onboard default settings.
  • Page 18 2.3.1 COM1 Configuration The COM1 and COM2 are a standard DB-9 connector. Those connectors are equipped with The GOT5100T-832 has two serial ports. COM1 is RS-232/422/485, while COM2 is RS-232. The following table shows you set COM1 port mode: Description...

  • Page 19: 2.4 Com Port Connector

    GOT5100T-832 User’s Manual Back 2.3.3 Auto Power On (JP4) If JP4 is enabled for power input, the system will be automatically power on without pressing soft power button. If JP4 is disabled for power input, it is necessary to manually press soft power button to power on the system.

  • Page 20: 2.5 Ethernet

    GOT5100T-832 User’s Manual Back 2.5 Ethernet The GOT5100T-832 is equipped with a high performance Plug and Play Ethernet interface, full compliant with IEEE 802.3 standard, and can be connected with a RJ-45 LAN connector. Please refer to detailed pin assignment list below:...
  • Page 21 GOT5100T-832 User’s Manual Back 2.6.2 VESA Mount Step 1 Find out the screws as marked on the back side of chassis. Step 2 Assemble the VESA-ARM to the back side of the chassis, and fix the screws. Hardware and Installation...
  • Page 22 GOT5100T-832 User’s Manual Back 2.6.3 Desktop Mounting The GOT5100T-832 is designed for desktop mounting application. Please refer to the following steps: Step 1 Find out the screws as marked on the back side of chassis. Step 2 Assemble the desktop stand to the chassis, and fix the screws.

  • Page 23: Hdd Installation

    GOT5100T-832 User’s Manual Back 2.6.4 Panel-mount Kit Assembly The GOT5100T-832 is designed for panel mount application. A set of standard mounting kit are bundled with the system package that you can use it to mount the GOT5100T-832. HDD Installation The GOT5100T-832 provides a convenient Hard Disk Drive (HDD) bracket for users to install 2.5”...
  • Page 24 GOT5100T-832 User’s Manual Back Step 2 Unscrew 4 screws to take off the HDD bracket. Screw the 2.5” HDD, together with the HDD Mylar, to the HDD bracket. Step 3 Hardware and Installation...

  • Page 25: Dram Installation

    Fix the HDD bracket into the system, and plug the data and power cable to HDD. Installation completes. DRAM Installation The GOT5100T-832 provides one 204-pin DDR3 SODIMM socket that support system memory up to 2GB. Please follow steps below to install the memory modules: Step 1 Refer to section 2.1 to open the back cover and find out DIMM socket on main...
  • Page 26 GOT5100T-832 User’s Manual Back Step 2 Insert the DRAM to the DIMM socket, and then push it down firmly until it is clipped by the socket. Step 3 Install the memory module into the socket and push it firmly down until it is fully seated.

  • Page 27: Wireless Lan Card Installation

    GOT5100T-832 User’s Manual Back Wireless LAN Card Installation The GOT5100T-832 provides one Mini card slot for user to install one wireless LAN card. When installing the wireless LAN card, refer to the following instructions and illustration: Step 1 Refer to section 2.1 to open the back cover and find out mini-card slot on main board.
  • Page 28 GOT5100T-832 User’s Manual Back Step 3 Find the built-in Antenna cable. Step 4 There are two connectors on wireless LAN card. One is MAIN, and the other is auxiliary. Connect antenna cable to MAIN connector on wireless LAN card. Hardware and Installation...

  • Page 29: Power Input

    GOT5100T-832 User’s Manual Back 2.10 Power Input (Phoenix type) GOT5100T-832 equips with a phoenix type power connector. It adopts 10VDC to 30VDC. Please follow the signs on power connector to connect DC power source. －:Power negative +: Power positive G: Safety ground Note: The safety ground must be connected to ensure the unit working appropriately.

  • Page 30: Ami Bios Setup Utility

    GOT5100T-832 User’s Manual Back Chapter 3 AMI BIOS Setup Utility This chapter provides users with detailed description how to set up basic system configuration through the AMIBIOS BIOS setup utility. Starting To enter the setup screens, follow the steps below: Turn on the computer and press the <Del>...

  • Page 31: Main Menu

    GOT5100T-832 User’s Manual Back Main Menu When you first enter the Setup Utility, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main tab. There are two Main Setup options. They are described in this section. The Main BIOS Setup screen is shown below ...

  • Page 32: Advanced Menu

    GOT5100T-832 User’s Manual Back Advanced Menu  Launch Storage OpROM This item can enable or disable boot option for legacy mass storage devices with option ROM. The Advanced menu also allows users to set configuration of the CPU and other system devices.
  • Page 33 GOT5100T-832 User’s Manual Back  ACPI Settings You can use this screen to select options for the ACPI Configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 34 GOT5100T-832 User’s Manual Back  CPU Configuration This screen shows the CPU Configuration, and you can change the value of the selected option. Hyper-Threading Use this item to enable or disable Hyper-Threading Technology, which makes a single physical processor perform multi-tasking function as two logical ones.
  • Page 35 GOT5100T-832 User’s Manual Back  IDE Configuration SATA Controller(s) The optional settings are: [Disabled]; [Enabled]. Configure SATA as The optional settings are: [IDE]; [AHCI]. AMI BIOS Setup Utility...
  • Page 36 GOT5100T-832 User’s Manual Back  USB Configuration You can use this screen to select options for the USB Configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 37 GOT5100T-832 User’s Manual Back  NCT6627UD Super IO Configuration You can use this screen to select options for the Super IO Configuration, and change the value of the selected option. A description of the selected item appears on the right side of...
  • Page 38 GOT5100T-832 User’s Manual Back  PC Health Status This screen shows the Hardware Health Configuration, and a description of the selected item appears on the right side of the screen. AMI BIOS Setup Utility...

  • Page 39: Chipset Menu

    GOT5100T-832 User’s Manual Back Chipset Menu The Chipset menu allows users to change the advanced chipset settings. You can select any of the items in the left frame of the screen to go to the sub menus: ► Host Bridge Host Bridge For items marked with “”, please press <Enter>...
  • Page 40 GOT5100T-832 User’s Manual Back  Memory Information This item is for memory frequency and timing settings. Press <Enter> to go to the sub menu. AMI BIOS Setup Utility...

  • Page 41: Boot Menu

    GOT5100T-832 User’s Manual Back Boot Menu The Boot menu allows users to change boot options of the system.  Boot Settings Configuration Setup Prompt Timeout Use this item to set number of seconds to wait for setup activation key. Bootup NumLock State Use this item to select the power-on state for the NumLock..

  • Page 42: Security Menu

    GOT5100T-832 User’s Manual Back Security Menu The Security menu allows users to change the security settings for the system. Administrator Password This item indicates whether an administrator password has been set. If the password has been installed, Installed displays. If not, Not Installed displays.

  • Page 43: Save & Exit Menu

    GOT5100T-832 User’s Manual Back Save & Exit Menu The Save & Exit menu allows users to load your system configuration with optimal or fail-safe default values. Save Changes and Exit When you have completed the system configuration changes, select this option to leave Setup and reboot the computer so the new system configuration parameters can take effect.
  • Page 44 GOT5100T-832 User’s Manual Back Discard Changes Select this option to quit Setup without making any permanent changes to the system configuration. Select Discard Changes from the Save & Exit menu and press <Enter>. Select Yes to discard changes. Restore Defaults It automatically sets all Setup options to a complete set of default settings when you select this option.
  • Page 45 GOT5100T-832 User’s Manual Back This page is intentionally left blank. AMI BIOS Setup Utility...

  • Page 46: Chapter 4 Drivers Installation

    Chapter 4 Drivers Installation System GOT5100T-832 supports Windows 7 32-bit and WES 7. To facilitate the installation of system driver, please carefully read the instructions in this chapter before start installing. Insert Driver CD and select the “\Driver”. Step 1 Step 2 Select all files and follow the installing procedure.
  • Page 47  Driver Installation- Windows 7 The GOT5100T-832 provides a touch screen driver that users can install it under the operating system Windows 7. To facilitate installation of the touch screen driver, you should read the instructions in this chapter carefully before you attempt installation.

  • Page 48: Embedded O.s

    WIN 7. Note: For the better system performance, please close the Windows AERO or change to Windows Basic mode. Embedded O.S. The GOT5100T-832 provides the Windows 7 Embedded. The O.S. is supported devices which are listed below. WES 7 ...
  • Page 49 GOT5100T-832 User’s Manual Back PenMount Touch screen Before you can use and calibrate it, here is what you should do: Set up Penmount touch device driver by executing C:\Penmount\ Windows 2000-XP V5.0\setup.exe. When the installation is finished, an icon “PM” appears on the Taskbar.
