- Page 1 Preston Ceiling Fan OWNER’S MANUAL 052-6971-8 Caution! For your safety, please read and understand this manual before installing or operating this product.
-
Page 2: Table Of Contents
Exploded view ......................... 1 Important safety instructions ..................2 Rules for safe installation .................... 2 Tools required for assembly ..................3 Assembly ........................... 3 Operation .......................... 7 Maintenance ........................8 Care and cleaning ......................8 Troubleshooting ......................8 Environmental protection ................... 9 Warranty .......................... -
Page 3: Exploded View
EXPLODED VIEW Description Qty. Description Qty. Mounting Bracket Glass Shade Downrod Remote Control Canopy Receiver Motor Bulbs (E12x60W) Switch Housing Extra Switch Cap Parts Pack Switch Cap Light Kit Balance Pack Finial Blade Blade Arm... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Please retain this manual for future reference. Note: · A dry dust cloth is suitable for most cleanings. · Should the ceiling fan become wet, have a qualified electrician inspect it before next use. · In order to comply with safety regulations and to avoid safety hazards, ceiling fan repairs must be ·... -
Page 5: Tools Required For Assembly
TOOLS REQUIRED FOR ASSEMBLY This manual is designed to make it as easy as possible for you to assemble, install, operate and maintain the ceiling fan. The following tools listed are required for assembly and installation: 1x stepladder 1x star-head screwdriver 1x flat screwdriver 1x wire stripper/pliers 1x electrical tape... - Page 6 ASSEMBLY Installation 1. Mounting bracket Note: The mounting bracket depicted will vary depending on the model . Mounting . Remove the four sets of side screws from mounting bracket Flat bracket and save for future use. washer Wooden ceiling Wood screw .
- Page 7 ASSEMBLY 4. Wiring instructions IMPORTANT: If you are not sure if the electrical outlet box and fan are grounded, contact a licensed electrician for advice. They must be grounded for safe operation. WARNING: before wiring. Remote and Receiver Pairing Codes are set by pushing the location of the dip switches located on the transmitter and receiver up or down.
- Page 8 ASSEMBLY · When wires are matched up, connect them by twisting frayed ends together (see Fig. 8a). · Screw wire connectors (3 are provided) onto the tops of the twisted wires (see Fig. 8b). · Fasten them with electrical tape (see Fig. 8c). WARNING: Be sure no bare wire or wire strands are visible after making connections.
-
Page 9: Operation
ASSEMBLY IMPORTANT NOTE: Your fan has an energy-saving wattage limiter. If you replace the bulbs with over 190 w, your light will automatically turn o , Ensure bulb wattage is always below 190 W! OPERATION Install the 9 V battery (included). To prevent damage to transmitter remove the battery if not used for long periods . -
Page 10: Maintenance
MAINTENANCE Because of the fan’s natural movement, some connections may become loose. Check the support connections, brackets and blade attachments twice a year. Make sure they are secure. There is no need to oil your fan. The motor has permanently-lubricated bearings. CARE AND CLEANING Dust your fan periodically with a soft, dry cloth. -
Page 11: Environmental Protection
TROUBLESHOOTING Problem Solution Possible reason Light does · Wires are not properly connected. · Ensure wire connector in switch not work housing is connected. · Light bulbs are faulty. · Unscrew light bulbs and discard properly. · This fan is equipped with a 190 W ·... -
Page 12: Warranty
WARRANTY This Likewise product carries a one (1) year warranty against defects in workmanship and materials. Trileaf Distribution agrees to replace the defective product free of charge within the stated warranty period, when returned by the original purchaser with proof of purchase. This product is not guaranteed against wear or breakage due to misuse and/or abuse.
