- Page 1 42" Hugger Ceiling FAN OWNER’S MANUAL 052-4328-4 052-4329-2 Caution! For your safety, please read and understand this manual before installing or operating this product. Toll-free: 1-866-788-7389 V 1. 2016...
-
Page 2: Table Of Contents
Exploded view ......................... 1 Important safety instructions ..................2 Rules for safe installation .................... 2 Tools required for assembly ..................3 Assembly ........................... 3 Operation .......................... 7 Maintenance ........................8 Care and cleaning ......................8 Troubleshooting ......................8 Environmental protection ................... 9 Warranty .......................... -
Page 3: Exploded View
EXPLODED VIEW Description Qty. Description Qty. Hugger Housing Parts Pack Mounting Bracket Motor Support Bar Motor Switch Housing Fan Pull Chain Light Kit Light Pull Chain Blade Arm Glass Shade Blade... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Please retain this manual for future reference. Note: · A dry dust cloth is suitable for most cleanings. · Should the ceiling fan become wet, have a qualified electrician inspect it before next use. · In order to comply with safety regulations and to avoid safety hazards, ceiling fan repairs must be ·... -
Page 5: Tools Required For Assembly
TOOLS REQUIRED FOR ASSEMBLY This manual is designed to make it as easy as possible for you to assemble, install, operate and maintain the ceiling fan. The following tools listed are required for assembly and installation: 1x stepladder 1x star-head screwdriver 1x flat screwdriver 1x wire stripper/pliers 1x electrical tape... - Page 6 ASSEMBLY · Insert the “T” bar end of motor support bar through rectangular opening on mounting bracket for hands-free wiring and later motor assembly (see Fig. 4). Mounting bracket Motor support bar 2. Wiring Instructions IMPORTANT: If you are not sure if the electrical outlet box and fan are grounded, contact a licensed electrican for advice.
- Page 7 ASSEMBLY 3. Motor Assembly Mounting · Remove the mounting screws and washers from the bracket Mounting mounting bracket and the motor support bar (see Fig. 6). screw Motor support bar Mounting bracket · Lift motor support bar to mounting bracket. Align holes and secure with washers and screws (see Fig.
- Page 8 ASSEMBLY 6. Attach blade assembly to motor Motor · If there are plastic tabs shaped like bottle caps, remove and discard them. These are stabilizers that protect the motor during shipping. Screw · Remove the screws on the bottom of the motor and use them to attach the blade assembly to the motor.
-
Page 9: Operation
ASSEMBLY 10. Install bulb · Install three 60 W candelabra base bulbs (not included) (see Fig. 16). IMPORTANT NOTE: If you use bulbs that total over 190 W, the ceiling fan can be damaged. 11. Extend pull chain · Assemble decorative fob chain from hardware bag to fan and light kit pull chain. -
Page 10: Maintenance
MAINTENANCE Because of the fan’s natural movement, some connections may become loose. Check the support connections, brackets and blade attachments twice a year. Make sure they are secure. There is no need to oil your fan. The motor has permanently-lubricated bearings. CARE AND CLEANING Dust your fan periodically with a soft, dry cloth. -
Page 11: Environmental Protection
TROUBLESHOOTING Problem Solution Possible reason Light does · Wires are not properly connected. · Ensure wire connector in switch not work housing is connected. · Light bulbs are faulty. · Unscrew light bulbs and discard properly. Fan does · Fan is in reverse (blades are moving in ·... -
Page 12: Warranty
WARRANTY This Likewise product carries a one (1) year warranty against defects in workmanship and materials. Trileaf Distribution agrees to replace the defective product free of charge within the stated warranty period, when returned by the original purchaser with proof of purchase. This product is not guaranteed against wear or breakage due to misuse and/or abuse.
