Crux 2.2 pound Touchscreen Air Convection Fryer Instruction Manual
  1. Manuals
  2. Brands
  3. Crux Manuals
  4. Fryer
  5. 2.2 pound Touchscreen Air Convection Fryer
  6. Instruction manual

Crux 2.2 pound Touchscreen Air Convection Fryer Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

2.2 pound Touchscreen Air Convection Fryer
Instruction Manual
Styled for Life
Designed & Engineered in New York City

Advertisement

Table of Contents
loading

Related Manuals for Crux 2.2 pound Touchscreen Air Convection Fryer

Summary of Contents for Crux 2.2 pound Touchscreen Air Convection Fryer

  • Page 1 2.2 pound Touchscreen Air Convection Fryer Instruction Manual Styled for Life Designed & Engineered in New York City...

  • Page 3: Table Of Contents

    Notes on the Plug ..........................6 Notes on the Cord ..........................6 Plasticizer Warning ...........................6 Electric Power.............................6 Getting to Know Your CRUX 2.2 pound Touchscreen Air Convection Fryer ..8 Touchscreen Control ........................9 Before Using for the First Time ....................10 Operating Instructions ........................11 Manual Operation ...........................

  • Page 4: Important Safeguards

    IMPORTANT SAFEGUARDS When using electrical appliances, basic safety precautions should always be followed, including the following: READ ALL INSTRUCTIONS. 2. Do not touch hot surfaces. Use handles or knobs. Use oven mitts or potholders. 3. To protect against electric shock do not immerse cord, plugs, or appliance in water or other liquid.
  • Page 5 10. Do not let cord hang over edge of table or counter, or touch hot surfaces. 11. Do not place on or near a hot gas or electric burner, or in a heated oven. 12. Extreme caution must be used when moving an appliance containing hot oil or other hot liquids.

  • Page 6: Additional Important Safeguards

    ADDITIONAL IMPORTANT SAFEGUARDS CAUTION HOT SURFACES: This appliance generates heat and escaping steam during use. Proper precautions must be taken to prevent the risk of burns, fires, or other injury to persons or damage to property. CAUTION: This appliance is hot during operation and retains heat for some time after turning OFF.
  • Page 7 7. Place the Air Convection Fryer on a flat, heat-resistant work area. 8. Do not obstruct the air outlet or air inlets on the back and sides of the Air Convection Fryer, with any objects. Avoid escaping steam from the air outlet during air frying. 9.

  • Page 8: Notes On The Plug

    NOTES ON THE PLUG This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug will fit in a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug.
  • Page 9 Our signature look is both classic and contemporary—the ideal addition to any countertop. We want you to focus on the things that matter most in your life—family, friends, community, and of course, delicious cooking. Let us get to the CRUX of your kitchen needs.

  • Page 10: Getting To Know Your Crux 2.2 Pound Touchscreen Air Convection Fryer

    Getting to Know Your CRUX 2.2 pound Touchscreen Air Convection Fryer Product may vary slightly from illustration 1. Removable Frying 4. Frying Basket Drawer 8. Air Convection Basket with Cool Fryer Body 5. Touchscreen Control Touch Handle 9. Power Cord with 6.

  • Page 11: Touchscreen Control

    Touchscreen Control 1. There are 7 menu options, each with a preset time and temperature. 2. Press MENU (M) once. The French Fries icon will illuminate. Press MENU (M) to advance to the next menu option. FOOD TEMP AIR FRY ACTION TIME French Fries, Idaho Potatoes,...

  • Page 12: Before Using For The First Time

    Before Using for the First Time Fig. 3 Fig. 2 1. Remove all packing material and labels from the inside and outside of the Air Convection Fryer. Check that there is no packaging underneath and around the frying basket and drawer. 2.

  • Page 13: Operating Instructions

    Operating Instructions WARNING! This Air Convection Fryer should not be used to boil water. NOTE: During first use, the Air Convection Fryer may emit a slight odor. This is normal. 1. Place the Air Convection Fryer on a flat, heat-resistant work area, close to an electrical outlet. 2.

  • Page 14: Manual Operation

    Manual Operation 9. To adjust the air frying TIME, press the (+) or (–) on the left side of the control panel to advance or decrease time in 1 minute increments, from 1 to 60 minutes. 10. Press the (+) or (–) on the right side of the control panel to adjust TEMPERATURE from 180°F to 400°F in 10 degree increments.

  • Page 15: Preset Menu

    Preset Menu (French Fries | Chops | Shrimp | Cake | Poultry | Steak | Fish) Options 13. To use preset menu options, simply press MENU (M). Each time MENU (M) is pressed, the next menu option will illuminate. 14. When the desired menu option icon is illuminated, press the green POWER ( to turn the Air Convection Fryer ON.

  • Page 16: Air Convection Frying Technique

    Air Convection Frying Technique 1. Please consult the Air Frying Chart and/or follow package instructions for suggested TIME and TEMPERATURE. 2. To assure even cooking/browning, ALWAYS open the basket drawer halfway through the cooking time and check, turn or shake foods in the frying basket. Adjust TIME or TEMPERATURE if needed.

  • Page 17: A Note On Air Convection Frying Pre-Packaged Frozen Foods

    8. Unplug the Air Convection Fryer when not in use. A Note on Air Convection Frying Pre-Packaged Frozen Foods 1. CRUX 1500W high performance technology circulates heat for fast air fry and recovery. 2. As a general rule, reduce the package cooking time by 30% to 50% depending on the food and amount to be cooked.

  • Page 18: For Best Results

    For Best Results 1. Use your Air Convection Fryer to cook pre-packaged foods with a fraction of the oil, in a fraction of the time! 2. Always check food halfway though cooking time to determine final cook time and temperature. 3.

  • Page 19: Air Convection Frying Chart

    Air Frying Chart (Includes Preset Menu Items) WARNING! ALWAYS USE A MEAT THERMOMETER TO ENSURE THAT MEAT, POULTRY AND FISH ARE COOKED THOROUGHLY BEFORE EATING. IMPORTANT! For your convenience, your Air Convection Fryer has 7 preset menu options: French Fries, Chops, Shrimp, Cake, Poultry, Steak, Fish. The following chart is intended as a general guide only.
  • Page 20 FOOD TEMP AIR FRY TIME ACTION Root Vegetables, fresh, roasted, 2 cups 370°F 15-20 minutes toss with oil shake 3x Asperagus, fresh thin stems, 3 cups 370°F 7-9 minutes spray with oil, shake 2x Green Beans, Sugar Snap Peas, 2 cups 370°F 7-9 minutes spray with oil, shake 1x...

  • Page 21: User Maintenance Instructions

    User Maintenance Instructions This appliance requires little maintenance. It contains no user-serviceable parts. Any servicing requiring disassembly other than cleaning must be performed by a qualified appliance repair technician. Care & Cleaning Instructions WARNING! Allow the Air Convection Fryer to cool fully before cleaning. 1.

  • Page 22: Recipe Guide

    Recipes Seasoned Kale Chips Makes 2 batches Crunchy, light. . . an incredibly satisfying snack high in calcium, rich with fiber and antioxidants. You can whip up a bowl full of these fabulous kale chips in 3 minutes! • 6 cups raw kale, dry, cleaned, •...
  • Page 23 Spicy Adobo Drumsticks 2 Ways: Roasted / Air Fried Makes: 4-5 chicken drumsticks Serves 2 to 3 Easy to eat. Affordable to serve. A favorite for all ages. Brine • 3 cups water • 1/4 cup Kosher salt • 1/4 cup sugar •...
  • Page 24 Roasted drumsticks 5. Add rubbed drumsticks to the air frying basket. Spray with olive oil. (optional) 6. To begin, press red POWER ( 7. The control panel will appear, POWER ( ) turns green. 8. Press MENU (M) until Poultry ( ) appears on the display.
  • Page 25 Fried Shrimp with Homemade Cocktail Sauce Serves 2 to 4 • 1 lb. raw shrimp, shelled and deveined • 1 tablespoon Old Bay® seasoned salt • 2 eggs, lightly beaten • spray with olive oil • 1 cup panko breadcrumbs Cocktail Sauce •...
  • Page 26 Fresh Salmon with Sweet Chili Sauce Serves 2 to 3 The Air Convection Fryer’s preset menu options make this delicious fish entree absolutely fool-proof! Enveloped in a sweet tangy chilli sauce, the salmon is soft and tender while sesame seeds add crunch and fresh cilantro brightens the taste. Elegant enough for any special dinner or occasion, serve with Roasted Sugar Snap Peas with Sesame Seeds.
  • Page 27 6. The control panel will appear, POWER ( ) turns green. 7. Press MENU (M) until Fish ( ) appears on the display. Press the green POWER ( ) to begin operation. 8. Check the cooking progress when time expires. If more time is needed, cook at 2 minute intervals until fish is flaky.
  • Page 28 Apple Stuffed Pork Chops Serves 2 - 3 • 2 pork chops, • 1 cup seasoned 1/2 – 3/4-inch thick panko breadcrumbs • 1/4 cup flour • spray with olive oil • 1 tablespoon cajun seasoning • toothpicks or metal skewers to seal •...
  • Page 29 Cauliflower-Tots Makes: 22 – 24 tots A lower carb snack or side dish alternative, these tots have a crunchy exterior and a rich, creamy inside. Cauliflower-tots are the perfect accompaniment to burgers or fish. Big kids and little kids alike will love these potato imposters. •...
  • Page 30 Mango Blueberry Ginger Crumble Serves 4 to 6 • 2 cups fresh mango • 1/4 teaspoons ground ginger • 1/2 cup fresh blueberries • 2 tablespoons sugar • 3/4 teaspoons fresh grated ginger Crumble Topping • 7/8 cup flour • 1/2 cup chopped pecans •...

  • Page 31: Warranty

    Limited Two-Year Warranty SENSIO Inc. hereby warrants that for The warranty is only valid for the a period of TWO YEARS from the date original retail purchaser from the of purchase, this product will be free date of initial retail purchase and is from mechanical defects in material not transferable.
  • Page 32 How To Obtain Warranty Service: You must contact Customer Service at Also, include a copy of the original our toll-free number: 1-866-832-4843. sales receipt. Carefully package A Customer Service Representative the tagged product with the sales will attempt to resolve warranty issues receipt, and send it (with shipping over the phone.
  • Page 36 For customer service questions or comments 1-866-832-4843 cruxkitchen.com crux.kitchen CRUX is a registered trademark of Sensio Inc., Montréal, Canada H3B 3X9.
