  • Page 1 SCP Series Routing Switcher Control Panels User’s Guide...
  • Page 2 • Printed in U.S.A. Copyrights and Trademarks © 2004 Utah Scientific, Inc. All rights reserved. Any use or reproduction of this guide's contents without the prior written consent of Utah Scientific, Inc. is strictly prohibited. • UTAH-200 and UTAH-300 are trademarks of Utah Scientific, Inc.

  • Page 3: Declaration Of Conformity

    Declaration of Conformity Utah Scientific 4750 Wiley Post Way Salt Lake City, Utah 84116-2878 USA declare our sole responsibility that the SCP Series Routing Switcher Control Panels are in conformity with the following standards: • EN50081-1 Generic Emission Standard •...
  • Page 4 Important Safeguards and Notices This section provides important safety guidelines for both the Operator and Service Personnel. Specific warnings and cautions are found throughout the guide where they apply, but may not appear here. Please read and follow the important safety information, noting especially those instructions related to risk of fire, electric shock or injury to persons.
  • Page 5 • Dangerous voltages exist at several points in this product. To avoid personal injury, do not touch exposed connections and components while power is on. Do not insert anything into either of the system's two power supply cavities with power connected. •...
  • Page 6 For the SCP panels, refer to the “Connecting and Disconnecting Power” section on page 2-11 for important information regarding the power connector. Company Information Utah Scientific, Inc. 4750 Wiley Post Way, Suite 150 Salt Lake City, Utah 84116-2878 USA •...
  • Page 7 Warranty Policies Hardware Warranty Utah Scientific, Inc. warrants to the original purchaser that the Utah Scientific hardware is free from defects in materials and workmanship and will perform substantially in accordance with the accompanying written materials under normal use and service for a period of ten (10) years from the date of shipment.
  • Page 8 No liability for consequential damages. To the maximum extent permitted by applicable law, in no event shall Utah Scientific or its suppliers be liable for any damages whatsoever (including without limitation, damages for loss of business profits, business interruption, loss...

  • Page 9: Table Of Contents

    Conventions ......................1-2 Abbreviations ......................1-3 Terms ........................1-3 Routing Switcher Basics ..................1-5 Switching Matrix ....................1-5 Router Levels ....................1-6 Introducing the SCP Series Panels ................1-7 SCP 2/8 ........................1-7 SCP 32/8 ......................1-8 SCP 64/8 ......................1-8 SCP XY/16 ......................1-9 SCP SX/16 ......................1-10 SCP MX/16 ......................1-11 2 Installation In This Chapter ......................2-1...
  • Page 10 3 SCP 2/8 Operations In This Chapter ..................... 3-1 About the SCP 2/8 ....................3-2 Displaying Level Status ..................3-5 Defaulting the Level Select Buttons ..............3-6 Performing an All-follow Take ................3-6 All-follow with the Direct Source Select Buttons ..........3-6 All-follow with the Group Select Buttons ............
  • Page 11 Performing an All-follow Take ................4-4 Performing a Breakaway Take ................4-5 Breaking Away One Level From One Source ..........4-5 Breaking Away Multiple Levels From One Source ........4-6 Breaking Away Multiple Levels From Different Sources ......4-7 Canceling a Breakaway Take ..............4-7 Monitor Matrix Mode ....................4-8 Changing Panel LED Intensity ..................4-10 Panel Lock ........................4-10 General Panel Notes ....................4-11...
  • Page 12 Performing an All-follow Take in Mnemonic Mode ..........6-13 Performing an All-follow Take in Numeric Mode ..........6-14 Cancelling an All-follow Take ................6-14 Performing a Breakaway Take ................6-15 Breaking Away One Level From One Source ............ 6-15 Breaking Away Multiple Levels From One Source ..........6-16 Breakaway with the Direct Source Select Buttons ..........
  • Page 13 Performing an All-follow Take in Mnemonic Mode ..........7-12 Performing an All-follow Take in Numeric Mode .........7-13 Cancelling an All-Follow Take ..............7-13 Performing a Breakaway Take ..................7-14 Breaking Away One Level From One Source ..........7-14 Breaking Away Multiple Levels From One Source ........7-15 Breaking Away Multiple Levels From Different Sources ......7-16 Breakaway Take (Starting in All-Follow Mode) ...........7-17 Cancelling a Breakaway Take ..............7-18...
  • Page 14 8 SCP MX/16 Operations In This Chapter ..................... 8-1 About the SCP MX/16 ................... 8-2 Displaying Level Status ..................8-11 Level Status in Single Mode ................8-11 Level Status in Multi Mode ................8-12 A Word About Custom Status Labels ..............8-12 Selecting, Storing and Clearing Destinations ............
  • Page 15 Changing Panel LED Intensity ..............8-40 Verifying the Panel Node ................8-40 Verifying the Panel ID .................8-40 Verifying the Software Version ..............8-41 Using E or L ....................8-41 Using F or R ....................8-42 Custom All-follow Mode ................8-43 Enable/Disable Protect Mode ..............8-44 Status at a Glance ..................8-45 General Panel Notes ....................8-46 Specifications In This Appendix ......................A-1...
  • Page 16 viii Table of Contents...

  • Page 17: Scp 2/8 Operations

    In This Guide Introduction In This Guide This guide provides instructions for installing, configuring and operating the SCP Series of Routing Switcher Control Panels. The following chapters and appendices are included: • Chapter 1, “Introduction” summarizes the guide, provides important terms, conventions, and background information on the SCP panels.

  • Page 18: How To Use This Guide

    Press TAKE to perform... Take • On the SCP Panel LED displays, labels and commands are indicated in bold-faced upper and lower case text, using a sans-serif font. For example: The label DST indicates... Destination DST 001 SCP Series • User’s Guide...

  • Page 19: Abbreviations

    “Chassis” refers to the metal enclosure that houses an SCP panel. • “Input” refers to an audio or video signal that is connected to a routing switcher. One video input represents a single output from an analog or digital video source. SCP Series • User’s Guide...
  • Page 20 “Protect” refers to a special condition whereby a source-to-destination routing can only be changed by the user at the originating panel (the panel on which the Protect was entered). A Protect can be cleared from the panel that originally set the Protect (or by the RMS). SCP Series • User’s Guide...

  • Page 21: Routing Switcher Basics

    You can switch in an “all-follow” mode (where audio and video switch together), or in a “breakaway” mode (where audio is taken from one source and video from another). • Routing switchers can be switched manually from control panels (such as the SCP series), or automatically via computer control. Switching Matrix A switching matrix is the internal array of inputs, outputs and crosspoints that allows a routing switcher to perform the task of moving signals from sources to destinations.

  • Page 22: Router Levels

    The figure below illustrates a multi-router level 10x10 system. Analog Audio R Analog Audio L Analog Video Digital Audio 7/8 Digital Audio 5/6 Digital Audio 3/4 Digital Audio 1/2 Digital Video Signal Level Figure 1-2. Multi-router Level 10x10 Routing Switcher System SCP Series • User’s Guide...

  • Page 23: Introducing The Scp Series Panels

    Introducing the SCP Series Panels The SCP Series control panels from Utah Scientific are designed for easy and straightforward operation, using a minimum number of keystrokes for each switch or status operation. The panels connect to an SC-3 controller over high-speed U-Net communication lines (using standard RJ-45 connectors).

  • Page 24: Scp 32/8

    Level 3 Shift 1 - 4 PROTECT Level 5 Level 7 Shift 5 -8 SCP - 64 / 8 Level 2 Level 4 Dest 1 Level 6 Level 8 Dest 2 Figure 1-5. SCP 64/8 Panel SCP Series • User’s Guide...

  • Page 25: Scp Xy/16

    Introducing the SCP Series Panels In addition to the basic SCP 32/8 feature set, the SCP 64/8 can function either as a single destination 64 source panel or as a dual destination 32 source panel. A bright status LED is provided for alerting the user to any “Lock”...

  • Page 26: Scp Sx/16

    Audio/video attribute switching is standard, without requiring an extra level. • Salvos (essentially multiple source/destination functions grouped under one key) can be performed from the panel. Refer to Chapter 7 for complete setup and operating instructions. 1-10 SCP Series • User’s Guide...

  • Page 27: Scp Mx/16

    Introducing the SCP Series Panels SCP MX/16 The SCP MX/16 is a 16 level XY panel that includes the core features and button layout of the SCP SX/16, plus the ability to operate in single or multi-destination modes. View SrcGrp 1...
  • Page 28 Introduction 1-12 SCP Series • User’s Guide...

  • Page 29: In This Chapter

    In This Chapter Installation In This Chapter This chapter provides installation instructions for all panels in the SCP series. The following topics are discussed: • Rear Panel Layout ......... . 2-2 •...

  • Page 30: Rear Panel Layout

    The remaining U-Net port connects to the next standalone control panel, or it is terminated with a special U-Net Terminator plug (if it is the last panel in the chain). Refer to the “Connecting U-Net” section on page 2-4 for instructions. SCP Series • User’s Guide...

  • Page 31: Panel Installation

    — any place where you are required to route or monitor audio and video signals Use the following steps to install each control panel: Determine the location for each SCP control panel in your facility. SCP Series • User’s Guide...

  • Page 32: Connecting U-Net

    U-Net Cables are not supplied. You can purchase Ethernet cables, or you can construct a custom cable. See Appendix A, “Specifications” for cable specifications and pinouts. • One U-Net Terminator plug is supplied per SCP panel. SCP Series • User’s Guide...
  • Page 33 Repeat step 4 for each additional SCP control panel. On the last control panel in the chain, connect the U-Net Terminator plug to the open U-Net connector. This completes the interconnection of each control panel. SCP Series • User’s Guide...

  • Page 34: Setting The Panel Address

    The table below provides several examples. Table 0-1. ID Number Examples Switch Positions 8 up, 1-7 down 7 up, 1-6, 8 down 5-6 up, 1-4, 7, 8 down 5-7 up, 1-4, 8 down 4-5 up, 1-3, 6-8 down SCP Series • User’s Guide...

  • Page 35: Panel Installation (Ethernet)

    Repeat steps 1 and 2 for each panel that you want to install. This completes the installation of each SCP control panel. Please continue with the procedure for connecting the Ethernet panel. SCP Series • User’s Guide...

  • Page 36: Connecting The E-Net Panels

    9-pin-D serial cable. Connect the male connector of the cable to the SCP Ethernet panel and the female connector to the terminal or PC. Set the terminal serial connection for 19200 baud, with 8 data bits, no parity and one stop bit. SCP Series • User’s Guide...

  • Page 37: Using The Pcon Utility

    When the SC4 is in control, the second host address should be set to 0.0.0.0. Node address is the address that is used to re-program the panel from the Configurator software, and must be unique with no other panels having the same number. SCP Series • User’s Guide...

  • Page 38: Connecting The Panel To The Network

    IP address below with the IP address of your controller. /> ping 192.168.4.221 If the panel cannot “ping” the controller successfully, it will not be able to work in the system. Contact your network administrator to troubles. 2-10 SCP Series • User’s Guide...

  • Page 39: Connecting And Disconnecting Power

    Depending upon the model, some Universal Power Supplies may include a small Power Switch. Be sure to check how your specific model is configured. If this is the case, toggle the switch to the ON position to enable panel power. SCP Series • User’s Guide 2-11...
  • Page 40 Repeat this procedure for each control panel in your system. Refer to Appendix A for connector pinout diagrams, and details on individual SCP panel power supplies. Refer to Appendix B for instructions on opening a panel to change the PROM, if required. 2-12 SCP Series • User’s Guide...

  • Page 41: In This Chapter

    General Panel Notes ........page 3-27 SCP Series • User’s Guide...

  • Page 42: About The Scp 2/8

    (assigned) from the routing switcher’s RMS tool (Router Management System). The lit half of the button indicates the selected destination. Note: When you press the Destination Select button, the selected source (and the associated level) may change accordingly. SCP Series • User’s Guide...
  • Page 43 Only one of the eight half-button segments can be blinking, but any number of segments can be lit steadily. Blinking Level 1 Level 3 Level 5 Level 7 Level 2 Level 4 Level 6 Level 8 Figure 0-2. Typical Level Select Section Display SCP Series • User’s Guide...
  • Page 44 1000 sources, providing you with a convenient and simple way to address large numbers of devices. For example, if your facility has 100 VTRs, you could select VTR 98 with two easy steps: • Select the group name (VTR). • Select the desired extension (98). SCP Series • User’s Guide...

  • Page 45: Displaying Level Status

    Press another Level Select button to check its status, or repeat the procedure from step 1 to select a level in the opposite group. Only one level can display status at a time. SCP Series • User’s Guide...

  • Page 46: Defaulting The Level Select Buttons

    Direct Source Select buttons are properly labeled. Ensure that the buttons in the Level Select Section are in the default “all-follow” mode. Refer to the “Defaulting the Level Select Buttons” section on page 3-6 for instructions. SCP Series • User’s Guide...

  • Page 47: All-Follow With The Group Select Buttons

    If you press a keypad button a fifth time, the cycle repeats and a group name is selected again (as if it was the first press). SCP Series • User’s Guide...

  • Page 48: Cancelling An All-Follow Take

    Ensure that the buttons in the Level Select Section are in the default “all-follow” mode. Refer to the “Defaulting the Level Select Buttons” section on page 3-6 for instructions. Press the Destination Select button to choose the desired destination. SCP Series • User’s Guide...
  • Page 49 Source Display for the selected level. Refer to the “Cancelling a Breakaway Take” section on page 3-13 for additional important information. SCP Series • User’s Guide...

  • Page 50: Breaking Away Multiple Levels From One Source

    You can remove levels from the breakaway group simply by toggling Level Select buttons. Pressing a steadily lit button toggles it off. Pressing the blinking button toggles it off, and causes the last-selected button to blink. 3-10 SCP Series • User’s Guide...

  • Page 51: Breakaway With The Direct Source Select Buttons

    Source Display for each selected level. There is no need to press Take. Refer to the “Cancelling a Breakaway Take” section on page 3-13 for additional information. SCP Series • User’s Guide 3-11...

  • Page 52: Breaking Away Multiple Levels From Different Sources

    Source Display for each selected level. Refer to the “Cancelling a Breakaway Take” section on page 3-13 for more information. 3-12 SCP Series • User’s Guide...

  • Page 53: Cancelling A Breakaway Take

    Press any unused or invalid button (such as the blank button below Attribute) at any • time prior to pressing Take, or prior to pressing a Direct Source Select button. • Toggle all blinking Level Select buttons off. Both methods safely cancel the data entry procedure. SCP Series • User’s Guide 3-13...

  • Page 54: Using The Protect Mode

    Setting a “Clear” removes either the enabled Lock or Protect. When you set the Clear mode, it is indicated by the “CLRLOCK” label in the Source Display. Source CLRLOCK Figure 0-11. Clear Mode Source Display Label Each procedure is discussed in detail in the following sections. 3-14 SCP Series • User’s Guide...

  • Page 55: Setting A Protect

    With the Protect mode set, please note: • All other panels are prevented from routing sources to the destination. • Only the current panel (the one that originally set the Protect) can perform takes. SCP Series • User’s Guide 3-15...

  • Page 56: Setting A Lock

    Press Take to send the new Lock mode to the selected destination. To exit the Protect Mode, press the blinking Protect button. The button will remain lit if the current destination has a Protect or a Lock enabled. 3-16 SCP Series • User’s Guide...

  • Page 57: Clearing A Lock Or Protect

    SrcGrp 12 SrcGrp 13 SrcGrp 14 SrcGrp 15 Figure 0-14. Keypad “Clear Lock” Button Location In the Source Display, the “CLRLOCK” label appears. Press Take to send the Clear mode to the selected destination. SCP Series • User’s Guide 3-17...

  • Page 58: Using The Direct Protect Mode

    To exit the Protect Mode, press the blinking Protect button. There is no need to press Take using the “direct” method. Refer to the “Cancelling a Protect Mode Selection” section on page 3-19 for additional important information. 3-18 SCP Series • User’s Guide...

  • Page 59: Cancelling A Protect Mode Selection

    Refer to the “Defaulting the Level Select Buttons” section on page 3-6 for instructions. Press the Destination Select button to choose the desired destination. Press the Attribute button. The button blinks to show that the Attribute Mode is active. SCP Series • User’s Guide 3-19...
  • Page 60 Note: Video data rate changes are specific to the UTAH-300 routing switcher, in which the data rate must be “set” for the output modules. Refer to the UTAH-300 User’s Guide for additional information. 3-20 SCP Series • User’s Guide...

  • Page 61: Using The Chop Mode

    When you select a number, the current chop rate appears in the Source Display. Source CHOP .25 Figure 0-16. Chop Mode Display Release the Take button to complete the procedure. The panel is now set to chop between two selected sources at the chosen rate. SCP Series • User’s Guide 3-21...

  • Page 62: Performing An All-Follow Or Breakaway Chop

    Take to a signal level that is not chopping — without affecting the levels that are chopping. This action can be performed on any other panel except the one that initiated the Chop Mode. 3-22 SCP Series • User’s Guide...

  • Page 63: Monitor Matrix Mode

    “MMTRX” entered. The feature will not operate otherwise. On the panel, ensure that the correct portion of the Destination Select button is clearly labeled (for example, MMTRX or Mon Mtrx). Ensure that the desired destination “groups” are programmed from the RMS. SCP Series • User’s Guide 3-23...
  • Page 64 The selected destination is now routed to the Monitor Matrix output, allowing you to monitor the audio and video signals that are routed to the destination’s input. Repeat the procedure from step 6 to monitor additional destinations as required. 3-24 SCP Series • User’s Guide...

  • Page 65: Miscellaneous Panel Modes

    While holding, press one of the first seven keypad buttons, as shown in Figure 0-17. Button 1 is the brightest setting; button 7 is the dimmest setting. Note: Even on the dimmest setting the LEDs are never completely off. Release the Level Shift button to complete the procedure. SCP Series • User’s Guide 3-25...

  • Page 66: Verifying The Software Version

    Since the Source Display is only eight characters long, it is recommended that you truncate Panel IDs for the SCP 2/8. Use the following steps to verify the panel ID. Press and hold the Level Shift button. 3-26 SCP Series • User’s Guide...

  • Page 67: General Panel Notes

    SCP 2/8, even though the changes were not made on the local panel itself. Changes made on your panel will also track on a remote panel (that is assigned to the same destination). Each panel will display the same status information in regards to levels and sources. SCP Series • User’s Guide 3-27...
  • Page 68 SCP 2/8 Operations 3-28 SCP Series • User’s Guide...

  • Page 69: In This Chapter

    General Panel Notes ........page 4-11 SCP Series • User’s Guide...
  • Page 70 The top half of a button displays its level 1-4 assignment, while the bottom half displays the button’s level 5-8 assignment (for example, Video, Audio1, Audio2, Timecode, etc.). The Level Shift button switches between the two groups of levels (1-4 and 5-8). SCP Series • User’s Guide...

  • Page 71: Displaying Level Status

    Press Level Shift to select the group of levels that you wish to “status” (either 1-4 or 5-8). The lit portion of the button indicates the selected group. In the Level Select Section, press the desired level button. The source button currently associated with that level lights in the Source Section. SCP Series • User’s Guide...

  • Page 72: Defaulting The Level Select Buttons

    Press the desired button in the Source Section. All assigned levels from the selected source are routed to the destination. Once the all-follow take has been performed, all buttons in the Level Select Section will status the source that was just chosen. SCP Series • User’s Guide...

  • Page 73: Performing A Breakaway Take

    In the Source Section, press the desired button to complete the procedure. Only the selected level from the source (that you just pressed) is routed to the destination. Once the breakaway take has been performed, the buttons in the Level Select Section return to the default “all-follow” mode. SCP Series • User’s Guide...

  • Page 74: Breaking Away Multiple Levels From One Source

    In the Source Section, press the desired button to complete the procedure. All selected levels from the source (that you just pressed) are routed to the destination. Once the breakaway take has been performed, the buttons in the Level Select Section return to the default “all-follow” mode. SCP Series • User’s Guide...

  • Page 75: Breaking Away Multiple Levels From Different Sources

    If more than one Level Select button is lit, press each steadily lit button to toggle it off, then press the remaining blinking button to return to the all-follow mode. Use the Level Shift button as necessary to change groups. SCP Series • User’s Guide...

  • Page 76: Monitor Matrix Mode

    Refer to the “Defaulting the Level Select Buttons” section on page 4-4 for instructions. To perform an all-follow Monitor Matrix take, press the desired button in the Source Section. Remember that the buttons now apply to destinations rather than sources. SCP Series • User’s Guide...
  • Page 77 For both all-follow and breakaway procedures, the selected destination is now routed to the Monitor Matrix output, allowing you to monitor the audio and video signals that are routed to the destination’s input. Repeat the procedure from step 4 to monitor additional destinations as required. SCP Series • User’s Guide...

  • Page 78: Changing Panel Led Intensity

    To Unlock the panel repeat the sequence above. Press Press and Hold Level 1 Level 3 Shift 1-4 Level 5 Level 7 Shift 5-8 Level 2 Level 4 Level 6 Level 8 Figure 0-5. Panel Lock Sequence 4-10 SCP Series • User’s Guide...

  • Page 79: General Panel Notes

    Changes made on your panel will also track on a remote panel (that is assigned to the same destination). Each panel will display the same status information in regards to levels and sources. SCP Series • User’s Guide 4-11...
  • Page 80 SCP 32/8 Operations 4-12 SCP Series • User’s Guide...

  • Page 81: In This Chapter

    General Panel Notes ........page 5-13 SCP Series • User’s Guide...

  • Page 82: About The Scp 64/8

    Each of the four buttons in the Level Select Section is divided in half, and each half can be lit independently. Only one of the eight half-button segments can be blinking, but any number of segments can be lit steadily. SCP Series • User’s Guide...
  • Page 83 Each destination is programmed (assigned) from the routing switcher’s RMS tool (Router Management System). The lit half of the button indicates the selected destination. Note: When you press the Destination Select button, the selected source (and the associated level) may change accordingly. SCP Series • User’s Guide...
  • Page 84 The Source Select button (Single Destination panels only) switches the source buttons between sources 1-32 and 33-64. All sources are programmed (assigned) from the routing switcher’s RMS tool (Router Management System). The lit half of the button indicates the active group of sources. SCP Series • User’s Guide...

  • Page 85: Displaying Level Status

    Level Select button segment, and if necessary, press Level Shift to switch level groups. When all button segments light (and the button that you pressed continues to blink), the default “all-follow” mode has been restored. SCP Series • User’s Guide...

  • Page 86: Performing An All-Follow Take

    Ensure that the buttons in the Level Select Section are in the default “all-follow” mode. This is the preferred starting point for a breakaway take. Refer to the “Defaulting the Level Select Buttons” section on page 5-5 for instructions. SCP Series • User’s Guide...

  • Page 87: Breaking Away Multiple Levels From One Source

    The section is now in the breakaway mode. If the blinking button is one of the levels that you want to break away, please continue with step 5. SCP Series • User’s Guide...

  • Page 88: Breaking Away Multiple Levels From Different Sources

    SCP 64/8 panels. Follow the procedure for breaking away one level from one source, as outlined in the “Breaking Away One Level From One Source” section on page 5-6. SCP Series • User’s Guide...

  • Page 89: Cancelling A Breakaway Take

    “MMTRX” into one of the panel’s available destination entry boxes. Once the panel is programmed in this manner, the entire SCP 64/8 panel functions in the special Monitor Matrix mode — allowing you to monitor any of the panel’s available destinations. SCP Series • User’s Guide...
  • Page 90 For single-destination panels only, press the Source Select button to choose the desired group of destinations (1-32 or 33-64). To perform an all-follow Monitor Matrix take, in the Source Section (which now applies to destinations rather than sources) press the button for the desired destination device. 5-10 SCP Series • User’s Guide...

  • Page 91: Changing Panel Led Intensity

    The first button is the brightest setting; the seventh button is the dimmest setting. Note: Even on the dimmest setting the LEDs are never completely off. Release the Level Shift button to complete the procedure. SCP Series • User’s Guide 5-11...

  • Page 92: About The Protect Led

    Press and Hold Press Level 1 Level 3 Shift 1 - 4 Shift 5 - 8 Level 5 Level 7 Level 2 Level 4 Dest Level 6 Level 8 Dest Figure 0-9. Panel Lock Sequence 5-12 SCP Series • User’s Guide...

  • Page 93: General Panel Notes

    Changes made on your panel will also track on a remote panel (that is assigned to the same destination). Each panel will display the same status information in regards to levels and sources. SCP Series • User’s Guide 5-13...
  • Page 94 SCP 64/8 Operations 5-14 SCP Series • User’s Guide...

  • Page 95: In This Chapter

    General Panel Notes ........page 6-35 SCP Series • User’s Guide...

  • Page 96: About The Scp Xy/16

    The Destination Display is an eight-segment LED readout that shows the currently selected destination. The display can be switched between numeric and mnemonic (alphanumeric) modes using the Display Type button. The figure below illustrates a typical mnemonic destination display. Destination VTR--098 Figure 0-2. Mnemonic Destination Display SCP Series • User’s Guide...

  • Page 97: About The Scp Xy/16

    If the Destination Select button is pressed while a valid destination is displayed, • the button stops blinking, the new destination is accepted, and the display updates with the new destination name. SCP Series • User’s Guide...
  • Page 98 Level 10 Level 14 Source Source Level 3 Level 7 SRC 001 Level 11 Level 15 Source Source Level 4 Level 8 SRC 001 Level 12 Level 16 Level Select Buttons Figure 0-6. Source Display Section SCP Series • User’s Guide...
  • Page 99 RMS. Salvos are similar to “macro” keys that you can program on a PC. For example, a Salvo Take might be programmed to route bars and tone to 10 different VTRs — at the touch of one button. SCP Series • User’s Guide...
  • Page 100 RMS tool, and used on the SCP XY/16 panel. Each group can contain up to 1000 sources or destinations, providing you with a convenient and simple way to address large numbers of devices. SCP Series • User’s Guide...
  • Page 101 Press the Take button to conclude a pending procedure, such as an All-follow take, a Breakaway take, a Salvo selection, an Attribute selection or a Protect take. Take Figure 0-9. Take Button The button blinks to indicate that a procedure is pending. SCP Series • User’s Guide...

  • Page 102: Displaying Level Status

    Each panel can be customized differently in its own custom status table that resides on the RMS. For example, a custom display such as *ON-AIR* could be programmed in your panel’s custom status table — to be used SCP Series • User’s Guide...

  • Page 103: Selecting A Destination

    Use the following steps to select a destination manually, with the panel in the mnemonic (alphanumeric) mode. Ensure that the desired destination “groups” are programmed from the RMS, and that all panel group buttons are properly labeled. SCP Series • User’s Guide...
  • Page 104 Destination Display. In the Source Display Section, complete level status for the new destination automatically appears (including breakaways). Refer to the “Cancelling a Destination Selection” section on page 6-11 for additional important information. 6-10 SCP Series • User’s Guide...

  • Page 105: Selecting A Destination In Numeric Mode

    Press Clear at any time prior to pressing the Destination Select button. This safely cancels the data entry procedure and returns the Destination Display back to its previous assignment. • Press the Destination Select button while an invalid destination is displayed to exit the mode safely. SCP Series • User’s Guide 6-11...

  • Page 106: Performing An All-Follow Take

    The button lights, the source is automatically selected, and its name (or numeric ID) appears in all valid levels in the Source Display Section. There is no need to press Take. Note: This procedure works the same in both the numeric and mnemonic modes. 6-12 SCP Series • User’s Guide...

  • Page 107: Performing An All-Follow Take

    With a valid extension entered, press Take to conclude the procedure. The Take button stops blinking and the new source assignments appear in all valid Source Displays. Refer to the “Cancelling an All-follow Take” section on page 6-14 for additional important information. SCP Series • User’s Guide 6-13...

  • Page 108: Performing An All-Follow Take In Numeric Mode

    Source Displays back to their previous assignments. Note: If you press Take but the source ID is invalid, the Take button stops blinking and all levels revert to their previous assignments — without taking the new source. 6-14 SCP Series • User’s Guide...

  • Page 109: Performing A Breakaway Take

    Press the button for the desired group of devices (for example, EDIT, VTR, MON, CAM, etc.). In the selected Source Display, the “question mark” readout appears with the selected group name written as the prefix. SCP Series • User’s Guide 6-15...

  • Page 110: Breaking Away Multiple Levels From One Source

    Press the button for the desired group of devices (for example, EDIT, VTR, MON, CAM, etc.). In each selected Source Display, the “question mark” readout appears with the selected group name written as the prefix. 6-16 SCP Series • User’s Guide...

  • Page 111: Breakaway With The Direct Source Select Buttons

    (or numeric ID) appears in all appropriate displays. There is no need to press Take. Refer to the “Cancelling a Breakaway Take” section on page 6-20 for additional important information. SCP Series • User’s Guide 6-17...

  • Page 112: Breaking Away Multiple Levels From Different Sources

    Level Select buttons stop blinking, all selected source levels are routed to the destination, and new status is shown in the display for all selected levels. Refer to the “Cancelling a Breakaway Take” section on page 6-20 for additional important information. 6-18 SCP Series • User’s Guide...

  • Page 113: Breakaway Take (Starting In All-Follow Mode)

    Refer to the “Cancelling a Breakaway Take” section on page 6-20 for additional important information. Note: You can also break away multiple levels and sources in this mode. Refer to the “Breaking Away Multiple Levels From Different Sources” section on page 6-18 for instructions. SCP Series • User’s Guide 6-19...

  • Page 114: Using The Protect Mode

    RMS) can clear the Lock. The Lock mode is indicated by the “LOCKALL” label on all protected levels (mnemonic mode), or by the number “2” (numeric mode). Source LOCKALL Figure 0-17. Lock Mode Source Display Label 6-20 SCP Series • User’s Guide...

  • Page 115: Setting A Protect

    Level Select buttons for the desired levels (just as you would do for breakaway selections). Use the Level Shift button as required to choose the group of levels (1-8 or 9-16). Each selected button blinks, and the “dots” display appears. SCP Series • User’s Guide 6-21...

  • Page 116: Setting A Lock

    Refer to the “Selecting a Destination” section on page 6-9 for instructions. • If you want to set or change a Lock for the current destination, please continue with step 4. 6-22 SCP Series • User’s Guide...
  • Page 117 All panels (including the current panel) are prevented from routing sources to the destination. • All panels (and the RMS) can clear the Lock. Refer to the “Cancelling a Protect Mode Selection” section on page 6-26 for additional important information. SCP Series • User’s Guide 6-23...

  • Page 118: Clearing A Lock Or Protect

    To exit the Protect Mode, press the blinking Protect button. The button will remain lit if the current destination has a Protect or a Lock enabled. Refer to the “Cancelling a Protect Mode Selection” section on page 6-26 for additional important information. 6-24 SCP Series • User’s Guide...

  • Page 119: Using The Direct Protect Mode

    To exit the Protect Mode, press the blinking Protect button. There is no need to press Take using the “direct” method. Refer to the “Cancelling a Protect Mode Selection” section on page 6-26 for additional important information. SCP Series • User’s Guide 6-25...

  • Page 120: Performing A Salvo Take

    Press Clear to cancel any pending source or destination procedure. Press the Salvo button. The button blinks to indicate that the Salvo Select Mode is active. In the Destination Display, the Salvo label appears: Destination SALVO Figure 0-23. Salvo Display, Awaiting Data 6-26 SCP Series • User’s Guide...

  • Page 121: Changing Attributes

    Use the Level Shift button as required to choose the group of levels (1-8 or 9-16). Each Level Select button blinks, and the “dots” display appears in each adjacent Source Display. SCP Series • User’s Guide 6-27...
  • Page 122 Note: Video data rate changes are specific to the UTAH-300 routing switcher, in which the data rate must be “set” for the output modules. Refer to the UTAH-300 User’s Guide for additional information. 6-28 SCP Series • User’s Guide...

  • Page 123: Using The Chop Mode

    When you select a number, the current chop rate appears in the Source Display. Destination CHOP .25 Figure 0-25. Chop Mode Display Release the Take button to complete the procedure. The panel is now set to chop between two selected sources at the chosen rate. SCP Series • User’s Guide 6-29...

  • Page 124: Performing An All-Follow Or Breakaway Chop

    Take to a signal level that is not chopping — without affecting the levels that are chopping. This action can be performed on any other panel except the one that initiated the Chop Mode. 6-30 SCP Series • User’s Guide...

  • Page 125: Monitor Matrix Mode

    The Display Type button functions in the normal way. However, even in numeric mode, the Destination Display label reads “MMTRX.” • The Scroll buttons function in the normal way, allowing you to scroll through the list of available destinations. SCP Series • User’s Guide 6-31...
  • Page 126 The selected destination is now routed to the Monitor Matrix output, allowing you to monitor the audio and video signals that are routed to the destination’s input. Repeat the procedure from step 5 to monitor additional destinations as required. 6-32 SCP Series • User’s Guide...

  • Page 127: Miscellaneous Panel Modes

    While holding, press one of the first seven keypad buttons, as shown in Figure 0-26. Button 1 is the brightest setting; button 7 is the dimmest setting. Note: Even on the dimmest setting the LEDs are never completely off. Release the Level Shift button to complete the procedure. SCP Series • User’s Guide 6-33...

  • Page 128: Verifying The Panel Node

    While holding, press the keypad Group 20 button as shown in Figure 0-26. In the first three Source Displays, the panel’s ID appears. Source This is Source Panel Nu Source mber One Figure 0-28. Panel ID Display Release the Level Shift button to complete the procedure. 6-34 SCP Series • User’s Guide...

  • Page 129: Verifying The Software Version

    Changes made on your panel will also track on a remote panel (that is assigned to the same destination). Each panel will display the same status information in regards to levels and sources. SCP Series • User’s Guide 6-35...
  • Page 130 SCP XY/16 Operations 6-36 SCP Series • User’s Guide...

  • Page 131: In This Chapter

    General Panel Notes ........page 7-48 SCP Series • User’s Guide...

  • Page 132: About The Scp Sx/16

    The display can be switched between numeric and mnemonic (alphanumeric) modes using the Display Type button. The figure below illustrates a typical mnemonic destination display. VTR--098 Destination Figure 0-2. Mnemonic Destination Display SCP Series • User’s Guide...

  • Page 133: About The Scp Sx/16

    Level Select button. Moving from left to right, display 1 provides status for levels 1 or 9, display 2 provides status for levels 2 or 10, etc. The Level Shift button switches the eight displays between the two groups of levels (1-8 and 9-16). SCP Series • User’s Guide...
  • Page 134 Shift button (located immediately to the right of the section) switches the eight displays between the two groups of levels (1-8 and 9-16). Each button is positioned directly below its associated status display for convenience when checking status or programming a take. SCP Series • User’s Guide...
  • Page 135 The Panel Mode button toggles the function of the Level Select Section and the Source Display Section between the “XY” and “Direct” modes. The lit portion of the button indicates the current mode. Direct Figure 0-8. Panel Mode Button SCP Series • User’s Guide...
  • Page 136 For example, if your facility has 100 VTRs, you could select VTR 98 with two easy steps: • Select the group name (VTR). • Select the desired extension (98). SCP Series • User’s Guide...
  • Page 137 RMS. Salvos are similar to “macro” keys that you can program on a PC. For example, a Salvo Take might be programmed to route bars and tone to 10 different VTRs — at the touch of one button. SCP Series • User’s Guide...

  • Page 138: Displaying Level Status

    — whether or not there is a source assigned to that level. Valid implies that the destination can accept an input on the specific level. For example, on a Type-C VTR, the analog video level is valid but the digital video level is not. SCP Series • User’s Guide...

  • Page 139: Selecting A Destination

    Press the Destination Select button. The button blinks and the “dots” display appears in the Destination Display, indicating that the panel is now in the destination select mode and waiting for data entry. Destination Figure 0-13. Destination “Dots” Display, Awaiting Data Entry SCP Series • User’s Guide...

  • Page 140: Selecting A Destination In Numeric Mode

    Press Clear to cancel any pending source or destination procedure. Press the Destination Select button. The button blinks and the “dots” display appears in the Destination Display, indicating that the panel is now in the destination select mode and waiting for data entry. 7-10 SCP Series • User’s Guide...

  • Page 141: Performing An All-Follow Take

    Performing an all-follow take in numeric mode. • Performing an all-follow take using the “Direct Selection” method. Refer to the “Using Direct Selection” section on page 7-30 for instructions. The first two selection methods are described below. SCP Series • User’s Guide 7-11...

  • Page 142: Performing An All-Follow Take In Mnemonic Mode

    With a valid extension entered, press Take to conclude the procedure. The Take button stops blinking and the new source assignments appear in all valid Source Displays. Refer to the “Cancelling an All-Follow Take” section on page 7-13 for additional important information. 7-12 SCP Series • User’s Guide...

  • Page 143: Performing An All-Follow Take In Numeric Mode

    Source Displays back to their previous assignments. Note: If you press Take but the source ID is invalid, the Take button stops blinking and all levels revert to their previous assignments — without taking the new source. SCP Series • User’s Guide 7-13...

  • Page 144: Performing A Breakaway Take

    Press the button for the desired group of devices (for example, EDIT, VTR, MON, CAM, etc.). In the selected Source Display, the “question mark” readout appears with the selected group name written as the prefix. 7-14 SCP Series • User’s Guide...

  • Page 145: Breaking Away Multiple Levels From One Source

    Press the button for the desired group of devices (for example, EDIT, VTR, MON, CAM, etc.). In each selected Source Display, the “question mark” readout appears with the selected group name written as the prefix. SCP Series • User’s Guide 7-15...

  • Page 146: Breaking Away Multiple Levels From Different Sources

    Once the first source has been entered for the first set of levels, repeat steps 5 through 7 (as often as required) for each additional set of levels and sources that you want to add to the multiple breakaway. You can breakaway up to 16 levels from 16 different sources. 7-16 SCP Series • User’s Guide...

  • Page 147: Breakaway Take (Starting In All-Follow Mode)

    In each selected Source Display, the “question mark” readout appears with the selected group name written as the prefix. Using the keypad buttons (within the Group Select Section), enter the extension of the desired breakaway source device — up to three digits. SCP Series • User’s Guide 7-17...

  • Page 148: Using The Protect Mode

    (and the RMS) can clear the Protect. The Protect mode is indicated by the “LOCKOTHR” label on all protected levels (mnemonic mode), or by the number “1” (numeric mode). LOCKOTHR Level / Source Figure 0-16. Protect Mode Source Display Label 7-18 SCP Series • User’s Guide...

  • Page 149: Setting A Protect

    Refer to the “Selecting a Destination” section on page 7-9 for instructions. • If you want to set or change a Protect for the current destination, please continue with step 4. SCP Series • User’s Guide 7-19...
  • Page 150 Only the current panel (the one that originally set the Protect) can perform takes. • Only the current panel (and the RMS) can clear the Protect. Refer to the “Cancelling a Protect Mode Selection” section on page 7-23 for more details. 7-20 SCP Series • User’s Guide...

  • Page 151: Setting A Lock

    Keypad “Set Lock” Button Location In all selected displays, the “LOCKALL” label appears (mnemonic mode) or the number “2” appears (numeric mode). Press Take to send the new Lock mode to the selected destination. SCP Series • User’s Guide 7-21...

  • Page 152: Clearing A Lock Or Protect

    SrcGrp 8 SrcGrp DstGrp 6 DstGrp 7 DstGrp 8 DstGrp Figure 0-21. Keypad “Clear Lock” Button Location In all selected displays, the “CLRLOCK” label appears (mnemonic mode) or the number “3” appears (numeric mode). 7-22 SCP Series • User’s Guide...

  • Page 153: Performing A Salvo Take

    Use the following steps to perform a Salvo Take. The procedure is identical in both mnemonic or numeric modes. Ensure that the desired Salvo command lists are properly programmed in the RMS. Press Clear to cancel any pending source or destination procedure. SCP Series • User’s Guide 7-23...

  • Page 154: Changing Attributes

    Use the Level Shift button as required to choose the group of levels (1-8 or 9-16). Each Level Select button blinks, and the “dots” display appears in each associated Source Display. 7-24 SCP Series • User’s Guide...
  • Page 155 Note: Video data rate changes are specific to the UTAH-300 routing switcher, in which the data rate must be “set” for the output modules. Refer to the UTAH-300 User’s Guide for additional information. SCP Series • User’s Guide 7-25...

  • Page 156: Using The Chop Mode

    When you select a number, the current chop rate appears in the Source Display. CHOP .25 Destination Figure 0-23. Chop Mode Display Release the Take button to complete the procedure. The panel is now set to chop between two selected sources at the chosen rate. 7-26 SCP Series • User’s Guide...

  • Page 157: Monitor Matrix Mode

    You have the ability to see and hear the source that is routed to the destination, but you can not determine what the actual source is from the SCP SX/16 panel itself. SCP Series • User’s Guide 7-27...
  • Page 158 Select Section) is clearly labeled (for example, MMTRX or Mon Mtrx). Ensure that the desired destination “groups” are programmed from the RMS. Select numeric or mnemonic mode as desired with the Display Type button. Press Clear to cancel any pending source or destination procedure. 7-28 SCP Series • User’s Guide...
  • Page 159 The selected destination is now routed to the Monitor Matrix output, allowing you to monitor the audio and video signals that are routed to the destination’s input. Repeat the procedure from step 5 to monitor additional destinations as required. SCP Series • User’s Guide 7-29...

  • Page 160: Using Direct Selection

    For example, if you are currently working in mnemonic mode but you recall a direct register that was stored in numeric mode, the panel automatically switches to numeric mode when the “recall” occurs. 7-30 SCP Series • User’s Guide...
  • Page 161 Clear. • The “store” procedure only functions when there is a pending take. If you press Store/Recall when a take is not pending, the panel enters the “recall” mode. SCP Series • User’s Guide 7-31...
  • Page 162 Clear. • The “store” procedure only functions when there is a pending take. If you press Store/Recall when a take is not pending, the panel enters the “recall” mode. 7-32 SCP Series • User’s Guide...
  • Page 163 Press Clear to cancel any pending source or destination procedure. Select the Direct mode of operation by toggling the Panel Mode button until the label “DIRECT” is lit. The Source Display Section changes to show the contents of each direct source register SCP Series • User’s Guide 7-33...
  • Page 164 The SCP SX/16 panel remains in the direct mode until changed. To view the status of all levels in the Source Displays (for the take that you just performed), press the Panel Mode button to re-select the “XY” mode. 7-34 SCP Series • User’s Guide...

  • Page 165: Working With Direct Destinations

    The “direct” destination is now stored and available for use, and the Source Display Section returns to its previous level status display. Note: There is no “Recall” mode associated with direct destination selection. SCP Series • User’s Guide 7-35...
  • Page 166 Destination Select button stops blinking. Please note the following important point. • If the selected destination register was stored in the numeric or mnemonic mode, the panel automatically switches to the respective mode upon selection. 7-36 SCP Series • User’s Guide...

  • Page 167: Working With Direct Protects And Attributes

    • To store a Lock, press Keypad Button 2. In all selected displays, the “LOCKALL” label appears. To store a Clear, press Keypad Button 3. In all selected displays, the • “CLRLOCK” label appears. SCP Series • User’s Guide 7-37...
  • Page 168 The SCP SX/16 panel remains in the direct mode until changed. To view the status of all levels in the Source Displays (for the take that you just performed), press the Panel Mode button to re-select the “XY” mode. 7-38 SCP Series • User’s Guide...
  • Page 169 In addition, if you store a special attribute such as “Mix” in one register, be sure to store a “Normal” on the same level(s) in another register. SCP Series • User’s Guide 7-39...
  • Page 170 The SCP SX/16 panel remains in the direct mode until changed. To view the status of all levels in the Source Displays (for the selection that you just performed), press the Panel Mode button to re-select the “XY” mode. 7-40 SCP Series • User’s Guide...

  • Page 171: Miscellaneous Panel Modes

    DstGrp 18 DstGrp 19 DstGrp 20 Verify Panel ID Use One or Two Use F Use E Verify Destinations or R or L Panel Node Figure 0-26. Panel Buttons used for Miscellaneous Panel Modes SCP Series • User’s Guide 7-41...

  • Page 172: Changing Panel Led Intensity

    Level / Source Level / Source Level / Source Level / Source Level / Source Level / Source This is mber One Figure 0-28. Panel ID Display Release the Level Shift button to complete the procedure. 7-42 SCP Series • User’s Guide...

  • Page 173: Verifying The Software Version

    The panel allows you to toggle the function of the F button (the Group 16 button) between extensions F and R. For example, you could select VTR--21F or AUDIO33R (e.g., an abbreviation for the Right channel or for Record). SCP Series • User’s Guide 7-43...

  • Page 174: Use One Or Two Destinations

    — either “USE ONE” or “USE TWO.” USE TWO Destination Figure 0-32. Current Number of Panel Destinations in Use Release both buttons to complete the procedure. Repeat the procedure from step 1 to toggle to the alternate destination mode. 7-44 SCP Series • User’s Guide...

  • Page 175: Custom All-Follow Mode

    To complete the procedure, release the Protect button. The next time an all-follow take is performed, only the enabled levels will accept data. Repeat the procedure from step 1 to change the custom settings, or to restore all levels to “Enabled.” SCP Series • User’s Guide 7-45...

  • Page 176: Enable/Disable Protect Mode

    To enable or disable the Lock mode, press the keypad Group 2 button for 2 seconds. • The Destination Display label reads “LOCK OFF” or “LOCK ON” respectively. LOCK OFF Destination Figure 0-37. Lock Mode Disabled Indication 7-46 SCP Series • User’s Guide...

  • Page 177: Status At A Glance

    On or Off On or Off Custom or Normal Figure 0-38. Status at a Glance Display Release the Level Shift button to complete the procedure, and return the displays to the previous level status view. SCP Series • User’s Guide 7-47...

  • Page 178: General Panel Notes

    Changes made on your panel will also track on a remote panel (that is assigned to the same destination). Each panel will display the same status information in regards to levels and sources. 7-48 SCP Series • User’s Guide...

  • Page 179: In This Chapter

    General Panel Notes ........page 8-46 SCP Series • User’s Guide...

  • Page 180: About The Scp Mx/16

    Group Select Section 1) Destination/Level Display The Destination / Level Display is an eight-segment green LED readout that shows the currently selected destination (in Single Destination mode), or the currently selected level (in Multi-destination mode). SCP Series • User’s Guide...

  • Page 181: About The Scp Mx/16

    Destination / Level Figure 0-5. Destination “Question Mark” Display, Awaiting Extension Note: Each of the four examples shown above also apply to the eight displays in the Source Display Section — mnemonic, numeric, dots and question mark. SCP Series • User’s Guide...
  • Page 182 Select Section. When pressed initially in Single mode, the lower portion blinks to indicate that the panel is in the “destination select” mode. You can now enter a destination in the normal manner. SCP Series • User’s Guide...
  • Page 183 — or to a selected level of a particular destination. When you press Protect, the button blinks and allows you modify the current mode. Refer to the “Using the Protect Mode” section on page 8-26 for more information. SCP Series • User’s Guide...
  • Page 184 If a button segment is not lit, no destination is stored in the register. Pressing a valid Select button causes the button segment to blink, allowing you to include that destination in a take. SCP Series • User’s Guide...
  • Page 185 It indicates the group of levels or destinations that can be chosen with the Select • buttons — for including a level in a pending breakaway take (in Single mode), or for selecting a destination for an all-follow take (in Multi mode). SCP Series • User’s Guide...
  • Page 186 If an entry was in progress, the Destination/Level Display or the array of eight Source Displays return to their previous assignment(s). The Clear button effectively allows you to begin an entry procedure again. SCP Series • User’s Guide...
  • Page 187 DstGrp 18 DstGrp 19 DstGrp 20 Figure 0-14. Keypad Location Note: The buttons marked A through F are also used for entering valid “letter” extensions (if programmed as such from the RMS) such as VTR-23A. SCP Series • User’s Guide...
  • Page 188 Attribute Mode, you could mute analog audio on a particular level, or change the digital video data rate. All attribute parameters must be pre-mapped on the RMS. Refer to the “Changing Attributes” section on page 8-32 for instructions. 8-10 SCP Series • User’s Guide...

  • Page 189: Displaying Level Status

    Ensure that none of the eight Select buttons are blinking (as they would in preparation for • a breakaway take). If any are blinking, the associated display will not show proper status. In this case, press Clear to return to the default “all-follow” mode. SCP Series • User’s Guide 8-11...

  • Page 190: Level Status In Multi Mode

    *ON-AIR* could be programmed in your panel’s custom status table, to be used whenever VTR--015 is taken. When you send VTR--015 as a take and the controller takes the source, the panel displays *ON-AIR* as status, instead of VTR--015. 8-12 SCP Series • User’s Guide...

  • Page 191: Selecting, Storing And Clearing Destinations

    Destination / Level Figure 0-18. Destination “Dots” Display, Awaiting Data Entry In the Source Display Section, all displays momentarily change to show you the contents of each destination register. SCP Series • User’s Guide 8-13...

  • Page 192: Selecting A Destination In Numeric Mode

    Ensure that the panel is in the numeric mode. If not, toggle the Display Type button until the label “Numeric” is lit. Press Clear to cancel any pending source or destination procedure. Press the Destination/Level Select button. The button blinks and the “dots” display appears in the Destination/Level Display. 8-14 SCP Series • User’s Guide...

  • Page 193: Selecting And Storing Destinations In Single Destination Mode

    For Numeric operations, enter the destination’s numeric ID (up to 3 digits). Press and hold the View/Store button, then press one of the eight Select buttons to store the pending destination in that register. SCP Series • User’s Guide 8-15...

  • Page 194: Selecting And Storing Destinations In Multi-Destination Mode

    Release the View/Store button to complete the procedure. The displays return to their default status mode, and the newly stored destination is now available for use. Refer to the “Destination Selection Notes” section on page 8-17 for additional information. 8-16 SCP Series • User’s Guide...

  • Page 195: Clearing A Destination Register

    Press the Destination/Level Select button while an invalid destination is displayed to exit the mode safely. • In both Single and Multi-destination modes, to cancel the destination “storage” procedure, release the View/Store button prior to pressing a Select button, then press Clear. SCP Series • User’s Guide 8-17...

  • Page 196: Performing An All-Follow Take

    Once the first digit of the extension is entered, the Take button blinks to let you know that a “take” is pending. 8-18 SCP Series • User’s Guide...

  • Page 197: Performing An All-Follow Take In Numeric Mode

    With a valid source ID entered, press Take to conclude the procedure. The Take button stops blinking and the new source assignments appear in all valid Source Displays. Refer to the “Cancelling an All-Follow Take” section on page 8-21 for more information. SCP Series • User’s Guide 8-19...

  • Page 198: Performing An All-Follow In Multi-Destination Mode

    With a valid source ID entered, press Take to conclude the procedure. The Take button stops blinking and the new source assignment(s) appear in all selected Source Displays. Refer to the “Cancelling an All-Follow Take” section on page 8-21 for more information. 8-20 SCP Series • User’s Guide...

  • Page 199: Performing A Breakaway Take

    Ensure that the panel is set to Single Destination mode. If not, toggle the Panel Mode button until the label “Single” is lit. Ensure that the desired destination “groups” are programmed from the RMS. SCP Series • User’s Guide 8-21...

  • Page 200: Breaking Away Multiple Levels From One Source

    “Single” is lit. Ensure that the desired destination “groups” are programmed from the RMS. Ensure that the panel is in the mnemonic mode. If not, toggle the Display Type button until the label “Mnemonic” is lit. 8-22 SCP Series • User’s Guide...

  • Page 201: Breaking Away Multiple Levels From Different Sources

    Ensure that the desired destination “groups” are programmed from the RMS. Ensure that the panel is in the mnemonic mode. If not, toggle the Display Type button until the label “Mnemonic” is lit. Press Clear to cancel any pending source or destination procedures. SCP Series • User’s Guide 8-23...

  • Page 202: Breakaway Take (Starting In All-Follow Mode)

    Ensure that the panel is set to Single Destination mode. If not, toggle the Panel Mode button until the label “Single” is lit. Ensure that the desired source “groups” are programmed from the RMS. 8-24 SCP Series • User’s Guide...

  • Page 203: Cancelling A Breakaway Take

    To cancel the breakaway take procedure, two methods are available: • Press Clear at any time prior to pressing Take. • Toggle all blinking Select buttons off. Both methods safely cancel the data entry procedure. SCP Series • User’s Guide 8-25...

  • Page 204: Using The Protect Mode

    “CLRLOCK” label on all protected levels (mnemonic mode), or by the number “3” (numeric mode). CLRLOCK Source Figure 0-23. Clear Mode Source Display Label Each procedure is discussed in detail in the following sections. 8-26 SCP Series • User’s Guide...

  • Page 205: Setting A Protect

    SrcGrp 2 SrcGrp 3 SrcGrp Keypad DstGrp 1 DstGrp 2 DstGrp 3 DstGrp Buttons SrcGrp 6 SrcGrp 7 SrcGrp 8 SrcGrp DstGrp 6 DstGrp 7 DstGrp 8 DstGrp Figure 0-24. Keypad “Set Protect” Button Location SCP Series • User’s Guide 8-27...

  • Page 206: Setting A Lock

    If there are no Protects or Locks currently set for the destination, all Source • Displays will be blank. • If a Protect or a Lock is currently set for the destination, the appropriate label will appear in each affected Source Display. 8-28 SCP Series • User’s Guide...

  • Page 207: Clearing A Lock Or Protect

    Ensure that the panel is set to Single Destination mode. If not, toggle the Panel Mode button until the label “Single” is lit. Use the Display Type button to set the panel to either mnemonic or numeric mode. SCP Series • User’s Guide 8-29...

  • Page 208: Cancelling A Protect Mode Selection

    • prior to pressing Take. Then press the blinking Protect button to exit the mode. • If there are no “breakaway” Protect Mode selections pending, press the blinking Protect button to exit the mode. 8-30 SCP Series • User’s Guide...

  • Page 209: Performing A Salvo Take

    Press the Salvo button. The button blinks to indicate that the Salvo Select Mode is active. In the Destination/Level Display, the Salvo label appears: SALVO Destination / Level Figure 0-27. Salvo Display, Awaiting Data SCP Series • User’s Guide 8-31...

  • Page 210: Changing Attributes

    In the Select Section, press the Select buttons for the audio or video levels on which you want to change attributes. Use the Shift button as required to choose the group of levels (1-8 or 9-16). Each Select button blinks, and the “dots” display appears in each associated Source Display. 8-32 SCP Series • User’s Guide...
  • Page 211 Note: Video data rate changes are specific to the UTAH-300 routing switcher, in which the data rate must be “set” for the output modules. Refer to the UTAH-300 User’s Guide for additional information. SCP Series • User’s Guide 8-33...

  • Page 212: Using The Chop Mode

    Table 0-2. Chop Rate Selections Keypad Button Chop Rate (seconds) When you select a number, the current chop rate appears in the Source Display. CHOP .25 Destination / Level Figure 0-28. Chop Mode Display 8-34 SCP Series • User’s Guide...

  • Page 213: Performing An All-Follow Chop In Single Destination Mode

    Ensure that the panel is set to Single Destination mode. If not, toggle the Panel Mode button until the label “Single” is lit. Program the first Breakaway Take in the normal manner. Refer to the “Performing a Breakaway Take” section on page 8-21 for instructions. SCP Series • User’s Guide 8-35...

  • Page 214: Monitor Matrix Mode

    Because the SCP MX/16 is a full XY panel, any of the 20 available destination groups can be assigned to the Monitor Matrix function from the RMS. This is accomplished by typing the keyword “MMTRX” into the desired destination group’s entry box on the RMS itself. 8-36 SCP Series • User’s Guide...
  • Page 215 Press Clear to cancel any pending source or destination procedure. Select the Monitor Matrix destination — using either the numeric or mnemonic methods. Refer to the “Selecting, Storing and Clearing Destinations” section on page 8-13 for instructions. The Destination/Level Display label reads “MMTRX.” SCP Series • User’s Guide 8-37...
  • Page 216 The selected destination is now routed to the Monitor Matrix output, allowing you to monitor the audio and video signals that are routed to the destination’s input. Repeat the procedure from step 8 to monitor additional destinations as required. 8-38 SCP Series • User’s Guide...

  • Page 217: Miscellaneous Panel Modes

    SrcGrp 20 DstGrp 16 DstGrp 17 DstGrp 18 DstGrp 19 DstGrp 20 Verify Panel ID Use F Use E Verify or R or L Panel Node Figure 0-29. Panel Buttons used for Miscellaneous Panel Modes SCP Series • User’s Guide 8-39...

  • Page 218: Changing Panel Led Intensity

    Using the RMS, you can enter a panel ID (or “name”), up to 32 characters in length. Use the following steps to verify the panel ID on the SCP MX/16 panel. Press and hold the Shift button. 8-40 SCP Series • User’s Guide...

  • Page 219: Verifying The Software Version

    (the Group 18 button) between extensions E and L. For example, you could select VTR--19E or AUDIO33L (e.g., an abbreviation for the Left channel). Use the following steps to toggle between alpha extensions E and L. Press and hold the Shift button. SCP Series • User’s Guide 8-41...
  • Page 220 USE R Destination / Level Figure 0-34. Alpha Extension “Use R” Display Release the Shift button to complete the procedure. Repeat the procedure from step 1 to toggle to the alternate function. 8-42 SCP Series • User’s Guide...

  • Page 221: Custom All-Follow Mode

    While holding in the Protect button, press the desired Select button(s) to enable or disable levels. Each associated display toggles between “Enabled” and “Disabled. Use the Shift button to switch between the two groups of levels (1-8 and 9-16). SCP Series • User’s Guide 8-43...

  • Page 222: Enable/Disable Protect Mode

    To enable or disable the Protect mode, press the keypad Group 1 button for 2 • seconds. The Destination/Level Display label reads “PROT OFF” or “PROT ON” respectively. PROT OFF Destination / Level Figure 0-38. Protect Mode Disabled Indication 8-44 SCP Series • User’s Guide...

  • Page 223: Status At A Glance

    On or Off On or Off Custom or Normal Figure 0-40. Status at a Glance Display Release the Shift button to complete the procedure, and return the displays to the previous level status view. SCP Series • User’s Guide 8-45...

  • Page 224: General Panel Notes

    Changes made on your panel will also track on a remote panel (that is assigned to the same destination). Each panel will display the same status information in regards to levels and sources. 8-46 SCP Series • User’s Guide...

  • Page 225: Specifications

    SCP MX/16 Specifications....... . page A-4 SCP Series • User’s Guide...

  • Page 226: Scp 2/8 Specifications

    Dimensions Weight 3.5 lbs. 10-45 degrees C Environmental 0-90% relative humidity, (non condensing) 117/220 VAC, 50/60 Hz Power 36 to 72V DC, (5V @ 1.5A) Low Voltage Port Connections (2) RJ-45 Looping Control LAN connectors SCP Series • User’s Guide...

  • Page 227: Scp 64/8 Specifications

    Dimensions Weight 5 lbs. 10-45 degrees C Environmental 0-90% relative humidity, (non condensing) 117/220 VAC, 50/60 Hz Power 36 to 72V DC, (5V @ 5.0A) Low Voltage Port Connections (2) RJ-45 Looping Control LAN connectors SCP Series • User’s Guide...

  • Page 228: Scp Sx/16 Specifications

    Dimensions Weight 5 lbs. 10-45 degrees C Environmental 0-90% relative humidity, (non condensing) 117/220 VAC, 50/60 Hz Power 36 to 72V DC, (5V @ 5.0A) Low Voltage Port Connections (2) RJ-45 Looping Control LAN connectors SCP Series • User’s Guide...

  • Page 229: In This Appendix

    Ordering Parts......... . page B-6 SCP Series • User’s Guide...

  • Page 230: Changing Button Legends

    Use the following steps to change or modify button legends: Locate the (supplied) Utah Scientific floppy disk that contains the template document ), and insert the disk in your PC’s floppy drive. Open the drive’s 08101-0046.DOC...
  • Page 231 Spray the template lightly and uniformly with the fixative, and allow it to dry completely. Use a scissors (or Exacto-knife) to cut each new legend cell at its boundaries. This completes the procedure for modifying legends. Please continue with the “Inserting Legends in Buttons” procedure. SCP Series • User’s Guide...

  • Page 232: Inserting Legends In Buttons

    Remove the old legend, and replace it with the new one. Replace the lens in the rubber bezel, then re-attach the bezel onto the switch case. Repeat the procedure from step 1 for each legend that you want to change. SCP Series • User’s Guide...

  • Page 233: Changing The Panel Prom

    Changing the Panel PROM Changing the Panel PROM If you need to change the PROM in the event of a software update from Utah Scientific, the following procedure can be used. Note: This procedure applies to all SCP panels. Disconnect the panel’s power and U-Net connection(s), and remove the panel from the equipment rack.

  • Page 234: Button Parts List

    Bezel, Elastic White....................55345-15 Ordering Parts Utah Scientific, Inc. 4750 Wiley Post Way Salt Lake City, Utah 84116-2878 USA • Telephone: +1 (801) 575-8801 • Customer Support (Voice): +1 (800) 447-7204 • Customer Support (Fax): +1 (801) 537-3009 SCP Series • User’s Guide...
  • Page 235 Index direct take, SCP SX/16 7-40 store direct, SCP SX/16 7-39 table SCP 2/8 3-20 Abbreviations 1-3 SCP MX/16 About the 8-33 routing switchers 1-5 SCP SX/16 7-25 SCP 2/8 3-2 SCP XY/16 6-28 SCP 32/8 4-2 SCP 64/8 5-2 SCP MX/16 8-2 SCP SX/16 7-2 Basics 1-5...
  • Page 236 SCP XY/16 SCP SX/16 7-18 6-24 SCP XY/16 6-20 Change SCP 2/8 3-14 button legends B-2 SCP MX/16 panel LED intensity 8-26 SCP 2/8 SCP SX/16 3-25 7-19 SCP 32/8 SCP XY/16 4-10 6-21 SCP 64/8 5-11 Config Commands USI panel 1-9, 2-1, 2-9 SCP MX/16 8-40 Connecting...
  • Page 237 SCP SX/16 SCP MX/16 7-4, 7-9, 7-35 SCP XY/16 SCP SX/16 6-9, 6-10 SCP XY/16 single 8-2 store direct, SCP SX/16 7-35 Displays 1-2 store, SCP MX/16 Documentation multi mode 8-16 conventions 1-2 single mode terms 1-3 8-15 Dots display use 1 or 2, SCP SX/16 7-44 SCP MX/16 8-3 DIP 1-3...
  • Page 238 Legends, change button B-2 Level 1-4, 1-6 I/O 1-3 section SCP 2/8 panel 2-3 setting 2-6 SCP 32/8 Input 1-3 SCP 64/8 Insert button legends B-4 Installation section, default button legends B-4 SCP 2/8 Ethernet 2-7 SCP 32/8 mounting holes 2-4 SCP 64/8 panel PROM B-5 SCP panels 2-3...
  • Page 239 SCP SX/16 Mnemonic mode 7-42 SCP MX/16 8-3, 8-8 SCP XY/16 6-34 SCP SX/16 7-3, 7-5 installation 2-3 SCP XY/16 6-3, 6-7 LED intensity, change on Mode SCP 2/8 multi-destination 8-2 3-25 single destination 8-2 SCP 32/8 4-10 Monitor matrix mode SCP 64/8 5-11 SCP 2/8 3-23...
  • Page 240 SCP XY/16 SCP MX/16 6-12, 6-13 8-26 SCP SX/16 breakaway take 7-18 SCP 2/8 SCP XY/16 6-20 SCP 32/8 4-5, 4-6, 4-7 SCP 64/8 SCP 2/8 5-6, 5-7, 5-8 3-14, 3-15 SCP MX/16 SCP MX/16 8-21, 8-22, 8-23 8-26, 8-27 SCP SX/16 SCP SX/16 7-14...
  • Page 241 attribute SCP 32/8 button about the 4-2 breakaway selection 4-3 table 3-20 cancel breakaway take 4-7 breakaway selection 3-4 features 1-8, 4-2 cancel general panel notes 4-11 breakaway take 3-13 introduction 1-8, 4-2 level section 4-2 protect 3-19 default change level shift 4-3 attributes 3-19...
  • Page 242 8-40 introduction 1-11, 8-2 software version keypad 8-9 8-41 level status view/store button 8-10 multi mode 8-12 SCP series single mode installation 2-3 8-11 introduction 1-7 misc. panel modes 8-39 unpacking and inspection 2-3 mnemonic mode 8-3 SCP SX/16 monitor matrix mode 8-36...
  • Page 243 breakaway take protect mode 7-18 7-18 recalling direct source register 7-33 protect 7-23 salvo take 7-23 change select destination 7-9, 7-35 attributes 7-24 clear LED intensity 7-19 7-42 lock chop mode 7-26 7-19, 7-21 perform protect 7-27 7-18, 7-19 rate 7-26 specifications A-4 status at a glance 7-47...
  • Page 244 protect SCP MX/16 6-26 SCP MX/16, labeling tip change attributes 6-27 destination LED intensity multi mode 6-33 8-16 single mode chop mode 6-29 8-15 perform 6-30 section, SCP MX/16 8-6 rate 6-29 chop mode rate clear SCP 2/8 3-21 button SCP MX/16 8-34 lock or protect...
  • Page 245 Status SCP MX/16 8-46 at a glance SCP SX/16 7-48 SCP MX/16 SCP XY/16 6-35 8-45 SCP SX/16 7-47 display U-Net 1-3 SCP 2/8 cable 2-5 SCP 32/8 connecting 2-4 connection loss SCP 64/8 SCP 2/8 3-27 LEDs, rear panel 2-3 SCP 32/8 4-11 Store destination...
  • Page 246 SCP SX/16 7-42 SCP XY/16 6-34 panel node SCP 2/8 3-26 SCP MX/16 8-40 SCP SX/16 7-42 SCP XY/16 6-34 software version SCP 2/8 3-26 SCP MX/16 8-41 SCP SX/16 7-43 SCP XY/16 6-35 View/Store button, SCP MX/16 8-10 VTR 1-3...

Table of Contents
