Summary of Contents for J-TECH RS232
- Page 1 Website: www.jtechdigital.com Toll Free: 1-888-610-2818[US] Email:Support@jtechdigital.com USER MANUAL J-Tech Digital ® ProAV ® HDMI2.0 8X8 matrix with IP RS232 Coaxial RoHS JTD-ID:279...
- Page 2 Operating Instruction Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc.
-
Page 3: Table Of Contents
1. Features..................4 2. Package Contents..............4 3. Specifications................4 4. Panel Descriptions..............5 5. Connecting and Operating............7 6. Application Diagrams...............7 7. Remote Control Description.............8 8. RS232 Pin Assignment.............8 9. RS232 Control................9 ...............9 9.1 Software Control ..............12 9.2 Command Control 10. Web Control................15 Warranty Policy................17... -
Page 4: Features
Any one of the 8 Ultra HD sources to any one of the 8 Ultra HD displays Support Panel Button, Local IR, RS232 Control with command, IP Control, Web GUI Control Support Dolby True HD and DTS-HD master audio ... -
Page 5: Panel Descriptions
② Input button IN1~8: choose the desired input port from ports 1~8. ③ Output button OUT1~8: choose the desired output port from ports 1~8. ① IP control. ② RS232 for control. ③ For IR external receiver cable. ④ SPDIF Audio output. - Page 6 Operating Instruction Check the EDID Information by Panel button Press “In4”for 3 seconds ,then press “In1”or “Out1” to check the EDID information for each HDMI input. Press “In5” for 3 seconds, then press “In1” or “Out1” to check the device name , IP address and DHCP status.
-
Page 7: Connecting And Operating
1. Connect source devices to input ports of the matrix 2. Connect HDMI output ports to TV or other HDMI sink devices. 3. Optional: connect RS232 cable from PC RS232 port. 4. Optional: connect an Ethernet cable from the TCP/IP port on the matrix to a local area network. -
Page 8: Remote Control Description
④ Cancel Button: Cancel the switching operation ⑤ PTP button: Mirror all inputs and outputs (Ex. Input 1 to output 1, input 2 to output 2, etc): Press PTP button in Zone OUTPUT. 8. RS232 Pin Assignment Matrix Remote Control Console Assignment... -
Page 9: Rs232 Control
9. RS232 Control 9.1 Software control Connect the 8x8 Matrix to PC with a RS232 cable, open the software on your PC. On the COM Setting session, select the COM port according to your PC and click Connect to get connected. - Page 10 Operating Instruction The EDID session helps us to Read and Configure EDID for each input, such as HDR, 3D, Data rates and Audio channel. Picture 2 The IP configure session helps to read and configure the IP address and MAC of the Matrix.
- Page 11 Operating Instruction The Net Config session allows us to configure the PC and Matrix in the same LAN with the IP Address and connection. Click “Net config” → “Connect” → “Search Device” → “Sel Device Number” →“Connect” then you can see the device name, it meas connect successfully. Picture 4 You can also click “IE”, easy and click to enter into web.
-
Page 12: Command Control
Operating Instruction The last session is System Config, which allows power ON/OFF or reset, default the Matrix. Picture 6 9.2 Command Control 1). Open CommUart Assistant. 2). Comport setting: Baud Rate: 115200 bps Parity: None Data Bits: 8 bit Stop Bits: 1 bit... - Page 13 Operating Instruction 3). Enter Port Command in Send options. Picture 7 4). Command Command Function Note Mirror all inputs and outputs @W 04 00 01 02 03 ...# PTP Function (Ex. Input 1 to output 1, input 2 to output 2, etc) @W 50 # Reboot @W 51 #...
- Page 14 Operating Instruction 5). Select HDMI input for HDMI output Command Description Output1 Output2 Output3 Output4 Output5 Output6 Output7 Output8 All Output Input1 Input2 Input3 Input4 Input5 Input6 Input7 Input8 E.g: @W 00 00 #: Ouput 1 display Input1 Ouput 1 Input1 6).
-
Page 15: Web Control
Operating Instruction 10. Web Control 1). Connect the HDMI Matrix and PC to the LAN. 2). Open the PC tool (included in the CD). 3). Search the IP address of HDMI Matrix, please refer to picture 4 & picture 5. 4). - Page 16 Operating Instruction Picture 9: EDID Setting Page Picture 10: IP Configuration Page...
-
Page 17: Warranty Policy
Operating Instruction MAINTENANCE Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner of benzine to clean this unit. PRODUCT SERVICE （1）Damage requiring service: The unit should be serviced by qualified service personnel if: (a) The DC power supply cord or AC adaptor has been damaged; (b) Objects or liquids have gotten into the unit;... - Page 18 Operating Instruction installation, set-up adjustments, misadjustment of consumer controls, improper maintenance, power line surge, lightning damage, modification, or service by anyone other than a Factory Service center or other Authorized Servicer, or damage that is attributable to acts of God. 2) THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER "LIMITED WARRANTY COVERAGE".
