- Page 1 MN-H-C5-8211 HDMI Extender over Single Cat6 Cable, 120m User's Manual i-Tech Company LLC TOLL FREE: (888) 483-2418 EMAIL: info@itechlcd.com WEB: www.iTechLCD.com...
-
Page 2: Safety Warnings And Guidelines
SAFETY WARNINGS AND GUIDELINES Please read this entire manual before using this device, paying extra attention to these safety warnings and guidelines. Please keep this manual in a safe place for future reference. This device is intended for indoor use only. ... - Page 3 INTRODUCTION Thank you for purchasing this MN-H-C5-8211 HDMI® Extender Kit! This extender transmits a HDMI® video signal and an analog audio signal to distances up to 394 feet (120 meters) over a single Cat6 Ethernet cable. It supports HDMI resolutions up to 1080@60Hz, uses the MN-H-C5-8211 transmission protocol, and supports the IEEE 802.3af Power over Ethernet (PoE) feature.
-
Page 4: Package Contents
PACKAGE CONTENTS Please take an inventory of the package contents to ensure you have all the items listed below. If anything is missing or damaged, please contact i-Tech Customer Service for a replacement. 1x Transmitter 1x Receiver 2x AC Power Adapters... - Page 5 7. Data Transmission LED: The LED flashes slowly when a connection is being established, then flashes rapidly when successfully connected and transmitting data. 8. Connection LED: The LED illuminates when there is a solid connection with the receiver. Receiver 1. Reset: Button for restarting the receiver. 2.
-
Page 6: Point-To-Point Operation
INSTALLATION AND OPERATION Point-to-Point Operation The extender can be operated in standalone mode, with a single receiver connected directly to the transmitter. In this configuration, the two included AC power adapters must be used because there is no power source for the Power over Ethernet (PoE) feature. - Page 7 7. Plug the DC barrel connector on one of the AC power adapters into the DC 5V (4) jack on the transmitter, then plug the adapter into a nearby AC power outlet. The Power LED (5) on the transmitter front panel will illuminate. 8.
- Page 8 Ethernet switch with PoE support is required. It is highly recommended to use a Gigabit (1000Mbps) Ethernet switch. Perform the following steps to connect the MN-H- C5-8211 system for one-to-many operation: 1. Place or mount the transmitter, all receivers, and your Ethernet switch (not included) in their desired locations.
- Page 9 9. Using the AC power adapter that came with your Ethernet switch (not included), plug the DC barrel connector into the power input jack, then plug the other end into a nearby AC power outlet. 10. If you are not using an Ethernet switch with PoE support or if you want to power the transmitter using the included AC power adapter, plug the DC barrel connector on the other AC power adapter into the DC 5V (4) jack on the transmitter, then plug the adapter into a nearby AC power outlet.
- Page 10 AC power adapters. To use the PoE feature, a direct connection to an Ethernet switch with PoE support is required. It is highly recommended to use Gigabit (1000Mbps) Ethernet switches. Perform the following steps to connect the MN-H-C5-8211 system for "unlimited" operation: 1.
- Page 11 on one of the AC power adapters into the DC 5V (4) jack on the receiver, then plug the adapter into a nearby AC power outlet. The Power LED (5) on the receiver front panel will illuminate. Repeat for each receiver as needed or desired.
-
Page 12: Troubleshooting
TROUBLESHOOTING Q1: The television only shows "waiting for connection" in the bottom right corner. A1: Verify that the AC adapters for both the transmitter and receiver are plugged in and that the Power LED (5) on each unit is illuminated. Try swapping out the HDMI®... -
Page 13: Specifications
SPECIFICATIONS Model 16228 Video Standard HDMI® with HDCP Maximum Video Resolution 1080p@60Hz Transmission Protocol MN-H-C5-8211 394 feet (120 meters) using Cat6 cable Maximum Transmission Distance 328 feet (100 meters) using Cat5e cable 262 feet (80 meters) using Cat5 cable IR Extender Bandwidth 20 ~ 60 kHz Maximum Transmitter Power 3.5 watts... -
Page 14: Regulatory Compliance
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. is a trademark of MN-H-C5-8211 i-Tech HDMI®, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
