- Page 1 CCE900-IP-TR CCE900-IP-T & CCE900-IP-R User’s Guide i-Tech Company LLC TOLL FREE: (888) 483-2418 • EMAIL: info@iTechLCD.com • WEB: www.iTechLCD.com...
-
Page 2: Specification
1. Introduction The CCE900-IP-T & CCE900-IP-R is a solution of Audio/Video extension over IP Ethernet. It is useful in a wide range of digital signage applications that require one-to-many, many-to-many distribution, such as: informational displays, corporate signage, boardrooms, courtrooms, medical, military, and education. The Transmitter connects with a PC or any device with VGA/DVI/Audio outputs. - Page 3 Input video can be VGA or DVI-D in all standard resolutions from 640 x 480 to 1920 x 1200 @ 60Hz ~ 70Hz and the following special resolutions 1440 x 900, 1400 x 1050, 1680 x 1050, 1360 x 768. Output video &...
-
Page 4: Installation Setup
2. Installation Setup 2.1 Install CCE900-IP-T Transmitter 1. The DVI input of the CCE900-IP-T is [DVI-I] (VGA + DVI-D). You use the accessory of VGA-to-DVI cable to connect CCE900-IP- T to the PC VGA-Out. Or you can prepare a DVI-to-DVI cable to connect CCE900-IP-T to the PC DVI-Out. - Page 5 System OK, network overload The [Reset] button on the CCE900-IP-T Rear panel can be used for entering “Advance Setup Mode”, please refer to Chapter 4. The CCE900-IP-T panel diagram is shown as below: 2.2 Install CCE900-IP-R Receiver 1. The DVI output of the CCE900-IP-R is [DVI-I] (VGA + DVI-D). You can use the accessory of VGA-to-DVI cable to connect CCE900- IP-R to the VGA monitor.
- Page 6 CCE900-IP-R must be put in the same network and should not be inter-connected with router. 7. Connect the included DC 5V 2A power adapter to the DC-IN and plug the power supply to wall. To avoid damage to the CCE900- IP-R, please use power adapter in the package.
- Page 7 OSD menu showing a list of all CCE900-IP-T Transmitters as below picture: The above menu shows 4 x CCE900-IP-T are found in the network with name of KV-9001-PC1, KV-9001-PC2, …KV-9001-PC4. The 2, 0, 1, 3 in the right column indicates the number of Receivers are currently connected with that Transmitter.
-
Page 8: System Menu
When the CCE900-IP-R Receiver is turned on, it will search CCE900-IP-T transmitters on the network as below: Searching CCE900-IP-T … When the CCE900-IP-R found one or more CCE900-IP-T on the network, it will show all the CCE900-IP-T Transmitters on the System menu as below: >CCE900-IP-T-0337 (192.168.168.201, 03:27) >CCE900-IP-T-0428 (192.168.168.202, 04:28) - Page 9 IP-T is connected with VGA input, and sometimes the picture shifts from screen, this function is used to auto adjust the picture. 3.3.2 REFRESH: To refresh the CCE900-IP-T Transmitters list. 3.3.3 CCE900-IP-T SETTING: Use this function to setup CCE900- IP-T: >MULTI/ONE CCE900-IP-R >BANDWDITH SETTING >INFORMATION...
- Page 10 >By Priority >Dedicated >EXIT 3.3.5.1 First Available: This function sets the CCE900-IP-R to connect to the first available CCE900-IP-T which it found first. 3.3.5.2 By Priority: This function sets the CCE900-IP-R to connect to the CCE900-IP-T according to the priority. You...
- Page 11 CCE900-IP-R and navigate to the “>REFRESH”, the display will show as below: Searching CCE900-IP-T … Please push the button again during the system is still searching the CCE900-IP-T. The OSD menu with “CCE900-IP-R SETTING” will be shown as below: >CCE900-IP-T-0337 (192.168.168.201, 03:27) >REFRESH >CCE900-IP-R SETTING...
- Page 12 > AUDIO INPUT > IR INPUT > Connection Method > RETURN 3.4.1 AUDIO INPUT: To enable/disable the microphone input function. 3.4.2 IR INPUT: There are 3 options for IR input: IR DISABLE: Turn off the IR function. INTERNAL IR: To set the IR receiver from internal socket. EXTERNAL IR: To set the IR receiver from extension cable.
-
Page 13: Advanced Setup
The factory default IP is shown on the label under the box. That means, you should remember the final IP, otherwise, you will not be able to configure the CCE900-IP-T. In case of missing the final IP, you should use a special software tool to find IP out. - Page 14 Use IE browser to open the setup page. For CCE900-IP-R, the URL is http://192.168.168.22. CCE900-IP-T, the URL is http://[TX IP]. In this page, you can setup IP address, subnet mask, gateway, device name, network protocol and destination.
-
Page 15: Firmware Upgrade
Network protocol: To be on the safe side, always use IP Layer, and don’t use MAC Layer. Destination: this setting is for CCE900-IP-T only. For one-to-one application, you can use Unicasting. For one-to-many application, you must use Multicasting. Step 8: After click [Save] button, the settings will be saved and the device will restart. - Page 16 Step 8: Ping the connected device through the sequence, Start > Run > cmd > ping 192.168.168.22 or ping [CCE900-IP-T IP]. You will receive the reply if the connection is established. Disable the antivirus and firewall software and use IE browser to get access the web server.
-
Page 17: Management Software
5. Management Software The system provides a Windows-based Management software for the system administrator to manage all CCE900-IP-T and CCE900-IP-R devices from his/her PC. You should download and install the below software before installing this Management software. .Net Framework 2.0 or above WinPcap 4.1.2, Downloadable at:... - Page 18 The Management screen is split into two frames: on the left is a Tree view of the Transmitters (TX) and the connected Receivers (RX); on the right is a two-tab view, one is a List view of the RX, and the other is a Matrix view of TX and RX; the former lists all of RX but no TX, and the latter displays a matrix table in a coordinate style: the horizontal axis is a list of RX and the vertical axis is of TX.
-
Page 19: Reboot The Device
If the intersected cell shows a light bulb, it means the RX and TX is connected. 5.1 Change IP and change Name Right-click the device you desire to change, and a context menu will show up: Select [Change IP] or [Change Name] and type the IP or name on the pop-up window, and click [Submit]: 5.2 Reboot the device Right-click the device you desire to reboot, select [Reboot] from... - Page 20 CCE900-IP-T screen sources. The default frame rate for the CCE900-IP-T is 30 frames per second. You can change the frame rate by clicking [Setting] > [Tx Frame Rate Setting] on the upper left corner of the Management Main screen.
- Page 21 5.5 Switch from one Transmitter to another There are two ways you can switch RX from one TX to another TX. There are two-Tab views on the Management main screen: List view and Matrix view. In List view, select one or more RX items, then right-click it to bring up a context menu.
- Page 22 5.6 Set the CCE900-IP-R RS232 Baud Rate Select Receiver(s), right-click to get the context menu. Then mouse- over the “Setting UART Baudrate” item, the sub-menu will show up. Select one from the list to set the baud rate.
- Page 23 5.7 Send Messages to the CCE900-IP-R RS-232 port Select Receiver(s), right-click to get the context menu. Then mouse-over the “Send UART Messages” item, and click it to bring up a window. First, specify the message format: ASCII or Binary. If you specify Binary, the message is supposed to be like “00 01 …...
- Page 24 You could also type the message and save it as a template, so that you could load it from the template without having to re-type it again. Click “Save as Template”, and a window will pop-up; type the name of the template and click “Submit”. To load a template you previously saved, just click “Load from Template”...
- Page 25 “Submit”. “Dedicated” means the RX will connect to the specified TX. Click “Dedicated” and a window will pop up. Select one TX from the list and click “Submit”. i-Tech Company LLC TOLL FREE: (888) 483-2418 • EMAIL: info@iTechLCD.com • WEB:...
