- Page 1 PD1010 Pen Display User Guide Model No. VS15039...
-
Page 2: Compliance Information
Compliance Information For U.S.A. This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 3 CE Conformity for European Countries The device complies with the EMC Directive 2004/108/EC and Low Voltage Directive 2006/95/EC. Following information is only for EU-member states: The mark shown to the right is in compliance with the Waste Electri- cal and Electronic Equipment Directive 2002/96/EC (WEEE). The mark indicates the requirement NOT to dispose the equipment as unsorted municipal waste, but use the return and collection systems according to local law.
-
Page 4: Important Safety Instructions
Important Safety Instructions 1. DO NOT place objects on top of the device, as objects may scratch the screen. 2. DO NOT expose the device to dirty or dusty environments. 3. DO NOT place the device on an uneven or unstable surface. 4. -
Page 5: Declaration Of Rohs Compliance
Declaration of RoHS Compliance This product has been designed and manufactured in compliance with Di- rective 2011/65/EU of the European Parliament and the Council on restric- tion of the use of certain hazardous substances in electrical and electronic equipment (RoHS Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Commit- tee (TAC) as shown below: Proposed Maximum... -
Page 6: Copyright Information
Copyright Information Copyright © ViewSonic ® Corporation, 2013. All rights reserved. ViewSonic and the three birds logo are registered trademarks of ViewSonic Corporation. Disclaimer: ViewSonic Corporation shall not be liable for technical or edito- rial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product. -
Page 7: Table Of Contents
Contents Compliance Information............i Important Safety Instructions ..........iii Declaration of RoHS Compliance ........... iv Copyright Information .............. v Product Registration ..............v 1. Introduction ................1 1.1 Packing List ..................1 1.2 Product Overview ................1 2. Installing and setup.............. 3 2.1 Drivers Installing ................ -
Page 8: Introduction
1. Introduction 1.1 Packing List After unpacking, make sure that all of the following contents are included: Pen Display Pen Kits Package (including pen tip and stand) USB Cable Quick Start Guide Driver and Software CD If there is a defect or missing part, please contact the agency where you purchased the product. - Page 9 1.2.2 Rear View ⑥ Stand (x2) ⑦ Foot rubber (x5) ⑧ Interactive pen holder strap ⑨ Rear label Caution: Avoid the risk of electric shock. Do not open the shell by yourself.. Please contact maintenance personnel if any problem countered. 1.2.3 Interactive Pen Interactive pen uses the electromagnetic resonance technology, and is battery free.
-
Page 10: Installing And Setup
2. Installing and setup 2.1 Drivers Installing Connect the device with PC/ NB through the supplied USB cable as below. The screen is black and the LED indicator shows red. Note: When connecting the device to a PC/NB, plug in both of the USB connectors to make sure there is sufficient power. - Page 11 2) Select Language - Click I Accept to start installing. Then the installation will be completed automatically. 2.1.2 Handwriting driver installing 1) Open Driver CD, and click “viewsonic-xx.exe” to start installation on Windows or “installxx.dmg”on Mac OS), VSTablet InstallShield will appear the launch page.
- Page 12 2) Then do the all steps according setting guide. 3) After complete the installation, you need restart your PC.
-
Page 13: Display Area Setup
2.2 Display area setup Setup environment for Windows 7/8 To access the setup window, click Start → Control Panel → Display → Adjust Resolution. 1) When a Pen Display device installed, you can find one more option item which is Multiple displays. 2) Multiple displays provide 4 options for the digitizer display: a. -
Page 14: Handwriting Area Mapping
2.3 Handwriting Area Mapping 1) Open Control Panel of Windows and click ViewSonic Tablet 2) Enter Mapping and set the Select Monitor as Monitor 2 Note: The pen accurancy has been finetuned in factory. If there is any calibration need, click the Clibrate for manual adjustment. - Page 15 3) Draw the dialog box to the screen of Pen Display (extended display) and try the pressure sensitivity in Try Here window of Pen Setting. The sensitivity parameter can be adjusted by the wheel beside. 4) Save then Exit to complete the setting. Note: The pen support multiple levels pressure.
-
Page 16: Additional Touch Function Settings
2.4 Additional Touch Function Settings This section covers all of the built-in touch functions for Windows 7 and 8 operating systems. 2.4.1 Pen and Touch Click Start icon → Control Panel → Pen and Touch. a. Pen Options: Use the pen to interact with items on the screen. You can adjust the settings for each pen action and pen buttons. - Page 17 2.4.2 Tablet PC Setting Click Start icon → Control Panel → Tablet PC Settings → click Other tab → click Go to Input Panel Settings. These Settings allow you to customize the Tablet PC Input Panel functions listed below: Handwriting: Ink thickness and writing line distance settings. ...
-
Page 18: Troubleshooting
3. Troubleshooting 3.1 Monitor problems Problems Suggested action No picture * Check USB cable should be completely connected to the computer and monitor. * Try another USB port of PC. * Check computer whether are in dormancy mode. Press keyboard or move the mouse to reactivate the system. * Press Screen power button to make sure the screen turned on. -
Page 19: Interactive Pen Problems
3.2 Interactive Pen Problems Problems Suggested action The pen is no * Try using mouse to double check, if mouse also no function function, please restarting your computer or your application. * Try to reinstall the driver. Pen tip is too * Check whether the pen tip is too short. -
Page 20: Product Specification
4. Product Specification 4.1 Monitor Display Type 10.1” TFT LCD, LED backlight, tablet module built in. Resolution 1024 x 600 Brightness 200 cd/m (typical) View angle H 120°, V 80° Response time 16 ms (G-to-G) Connector USB x1 User Controls Control keys Screen power, Brightness up, Brightness down Power supply... -
Page 21: Interactive Pen
4.2 Interactive Pen Type Electromagnetic resonance method Technology method Full screen Active area Technical Specs Resolution 2048 LPI (line per inch) Tracking speed 133 PPS (points per second) Pressure sensitive 1024 levels Accuracy ± 0.5mm (center), ± 3 mm (edge and corner) Height readable 5 mm Type... -
Page 22: Appendix
5. Appendix 5.1 Replacing the Pen tip When the tip gets too short or develops a sharp edge, you can replace it with the spare tips. Please follow below step: 1) Use the tool to pull the old tip straight out of the pen. 2) Insert a new pen tip into the stylus pen and push the tip until it stops. -
Page 23: Customer Support
Renta y Datos, 29 SUR 721, COL. LA PAZ, 72160 PUEBLA, PUE. Tel: 01.222.891.55.77 CON 10 LINEAS Electroser, Av Reforma No. 403Gx39 y 41, 97000 Mérida, Yucatán. Tel: 01.999.925.19.16 Other places please refer to http://www.viewsonic.com/la/soporte/index.htm#Mexico Latin America (Peru) www.viewsonic.com/la/ T= 0800-54565 soporte@viewsonic.com... -
Page 24: Limited Warranty
How long the warranty is effective: ViewSonic Pen Displays are warranted for 1 year for all parts including the light source and 2 years for all labor from the date of the first consumer purchase. - Page 25 Exclusion of damages: ViewSonic's liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable for: 1. Damage to other property caused by any defects in the product, damages based upon inconvenience, loss of use of the product, loss of time, loss of...
