Page 2: Technical Support
Replicating copyrighted material without the permission of the publisher may be u n l a w f u l . QPS does not condone, support, or encourage the violation of copyright laws. Please obtain proper authorization prior to replicating copyright protected material. - Page 3 C O N G R AT U L AT I O N S THANK YOU for Choosing QPS! Congratulations on your purchase of the Que! Internal DVDBurner Drive. In this manual, you’ll find information designed to help you understand the capability of your new drive as well as a step-by-step explanation of how to install your hardware and software.
-
Page 4: Getting Started
GETTING STA RT E D W H AT YOU SHOULD HAV E ! • What’s in the Package Refer to the provided package list on the following page and verify that you have received all of the appropriate parts. Okay, if all the right parts were in the package, then you just need to make sure your system will support the Que! DVDBurner Drive. -
Page 5: Package List
PACKAGE LIST Quick Start Guide Audio Cable Ribbon Cable: 40 pin IDE cable Drive Software Disc Media... -
Page 6: Ide Insta L L At I O N
IDE INSTA L L AT I O N IDE INSTA L L AT I O N The figure below shows the front panel controls and indicator for the Que! Drive for IDE/ATAPI. Note: The front panel may vary slightly. Note: The location of jumpers may vary from one model to another. - Page 7 IDE INSTA L L AT I O N Step 1. Unpack the drive accessory box. The accessory box should have a disc with the included software, a QPS DVD-R disc, an audio cable, an IDE ribbon cable and mounting screws. Step 2.
- Page 8 IDE INSTA L L AT I O N Step 6. Set the Master/Slave jumper as appropriate for your system. When connecting a second IDE device to the same IDE interface connector cable you should designate the first device as the Master and the second device as the Slave. This is done by placing the jumpers over the corresponding pins on the back of your DVDBurner drive.
- Page 9 IDE INSTA L L AT I O N Step 7. Insert your Que! Drive into the available bay. Note: The Que! Drive must be mounted in a HORIZONTAL position. Step 8. Put the mounting screws in just tight enough to hold the drive in the system but loose enough to be able to move the drive back and forth.
- Page 10 Step 11. Line up the front bezel of your QPS drive with the front panel of your system and then tighten the mounting screws. Step 12.
- Page 11 H A N D L I N G HANDLING GUIDELINES Media Insertion and Removal Step 1. To insert the DVD-R media or DVD-RAM cartridge, press the EJECT button. Step 2. Once the disc tray has fully extended, place the disc or DVD-RAM cartridge into the center of the tray.
- Page 12 H A N D L I N G NOTE: Location of the drive LED's may differ from that which is shown here. Step 3. The busy lamp will light and or change colors for a few seconds to indicate that a disc or cartridge has been loaded and the drive has accepted the disc. Step 4.
- Page 13 H A N D L I N G The NUMBER ONE cause of premature disc failure with recordable media is contamination of the recording surface before recording is completed. To minimize disc failure, use the following disc-handling guidelines. • Keep the media in its sealed package until you are ready to record. •...
- Page 14 N OT E S...
- Page 15 N OT E S...
- Page 16 For Customer Use: Enter below the Model Number and Serial Number which are located either on the rear, bottom or side of the unit. QPS Inc. 8015 East Crystal Drive Model No._____________________ Anaheim, CA 92807 Serial No._____________________ http://www.qps-inc.com Appearance and specifications of the actual...
