Tektronix 760A Instruction Manual page 127

Component Tektronix Serial / Assembly Number
Number Part Number Effective
A3R798 322–3097–00
A3R815 321–0720–00
A3R820 322–3289–00
A3R821 322–3289–00
A3R824 322–3001–00
A3R842 321–0418–00
A3R843 322–3097–00
A3R844 322–3289–00
A3R845 322–3097–00
A3R846 322–3097–00
A3R847 321–1720–00
A3R849 322–3289–00
A3R851 322–3289–00
A3R852 322–3289–00
A3R853 322–3314–00 671–2383–02
A3R854 322–3258–00
A3R855 322–3282–00
A3R856 322–3481–00
A3R858 308–0549–00
A3R861 322–3097–00
A3R863 322–3097–00
A3R864 322–3178–00
A3R865 322–3178–00
A3R866 322–3210–00
A3R867 308–0549–00
A3R868 322–3324–00
A3R875 322–3232–00
A3R876 322–3296–00
A3R877 322–3193–00
A3R878 322–3289–00
A3R881 322–3269–00
A3R882 322–3097–00
A3R887 322–3097–00
A3R888 322–3269–00
A3R889 322–3324–00
A3R895 322–3296–00
A3R896 322–3232–00
A3S340 260–2233–00
A3TP151 214–4085–00
A3TP248 214–4085–00
A3TP255 214–4085–00
A3TP323 214–4085–00
A3TP351 214–4085–00
A3TP357 214–4085–00
A3TP454 214–4085–00
A3TP548 214–4085–00
A3TP551 214–4085–00
A3TP552 214–4085–00
760A/760D/760N
Discontinued
Name & Description
RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM
RES,FXD,FILM:60K OHM,1%,0.125W,TC=T0
RES,FXD:METAL FILM;10K OHM,1%,0.2W,TC=100 PPM
RES,FXD:METAL FILM;10K OHM,1%,0.2W,TC=100 PPM
RES,FXD:METAL FILM;10 OHM,1%,0.2W,TC=100 PPM
RES,FXD,FILM:221K OHM,1%,0.125W,TC=T0MI
RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM
RES,FXD:METAL FILM;10K OHM,1%,0.2W,TC=100 PPM
RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM
RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM
RES,FXD,FILM:3.24M OHM,1%,0.125W,TC=T0MI
RES,FXD:METAL FILM;10K OHM,1%,0.2W,TC=100 PPM
RES,FXD:METAL FILM;10K OHM,1%,0.2W,TC=100 PPM
RES,FXD:METAL FILM;10K OHM,1%,0.2W,TC=100 PPM
RES,FXD:METAL FILM;18.2K OHM,1%,0.2W,TC=100
RES,FXD:METAL FILM;4.75K OHM,1%,0.2W,TC=100
RES,FXD,FILM:8.45K OHM,1%,0.2W,TC=T0MI,SMALL BODY
RES,FXD,FILM:1M OHM.1%,0.2W,TC=T0MI,SMALL BODY
RES,FXD,WW:6.3K OHM,1%,3W
RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM
RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM
RES,FXD,FILM:698 OHM,1%,0.2W,TC=T0MI,SMALL BODY
RES,FXD,FILM:698 OHM,1%,0.2W,TC=T0MI,SMALL BODY
RES,FXD:METAL FILM;1.5K OHM,1%,0.2W,TC=100 PPM
RES,FXD,WW:6.3K OHM,1%,3W
RES,FXD,FILM:23.2K OHM,1%,0.2W,TC=T0MI,SMALL BODY
RES,FXD,FILM:2.55K OHM,1%,0.2W,TC=T0MI,SMALL BODY
RES,FXD,FILM:11.8K OHM,1%,0.2W,TC=T0MI,SMALL BODY
RES,FXD:METAL FILM;1K OHM,1%,0.2W,TC=100 PPM
RES,FXD:METAL FILM;10K OHM,1%,0.2W,TC=100 PPM
RES,FXD,FILM:6.19K OHM,1%,0.2W,TC=T0MI,SMALL BODY
RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM
RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM
RES,FXD,FILM:6.19K OHM,1%,0.2W,TC=T0MI,SMALL BODY
RES,FXD,FILM:23.2K OHM,1%,0.2W,TC=T0MI,SMALL BODY
RES,FXD,FILM:11.8K OHM,1%,0.2W,TC=T0MI,SMALL BODY
RES,FXD,FILM:2.55K OHM,1%,0.2W,TC=T0MI,SMALL BODY
SWITCH,ROTARY:DIP;BCD,10 POSITION,30V,125MA,5
PIN,GOLD/NICKEL,GLASSREINFORCED NYLON
TERM,TEST POINT:0.070 ID,0.220 H,0.063 DIAP
CB,0.015 X 0.032 BRASS,W/RED NYLON COLLAR
TERM,TEST POINT:0.070 ID,0.220 H,0.063 DIAP
CB,0.015 X 0.032 BRASS,W/RED NYLON COLLAR
TERM,TEST POINT:0.070 ID,0.220 H,0.063 DIAP
CB,0.015 X 0.032 BRASS,W/RED NYLON COLLAR
TERM,TEST POINT:0.070 ID,0.220 H,0.063 DIAP
CB,0.015 X 0.032 BRASS,W/RED NYLON COLLAR
TERM,TEST POINT:0.070 ID,0.220 H,0.063 DIAP
CB,0.015 X 0.032 BRASS,W/RED NYLON COLLAR
TERM,TEST POINT:0.070 ID,0.220 H,0.063 DIAP
CB,0.015 X 0.032 BRASS,W/RED NYLON COLLAR
TERM,TEST POINT:0.070 ID,0.220 H,0.063 DIAP
CB,0.015 X 0.032 BRASS,W/RED NYLON COLLAR
TERM,TEST POINT:0.070 ID,0.220 H,0.063 DIAP
CB,0.015 X 0.032 BRASS,W/RED NYLON COLLAR
TERM,TEST POINT:0.070 ID,0.220 H,0.063 DIAP
CB,0.015 X 0.032 BRASS,W/RED NYLON COLLAR
TERM,TEST POINT:0.070 ID,0.220 H,0.063 DIAP
CB,0.015 X 0.032 BRASS,W/RED NYLON COLLAR
Replaceable Electrical Parts
Mfr. Mfr. Part
Code Number
91637 CCF501G100R0F
91637 CMF55–116–G–600
91637 CCF50G10001F
91637 CCF50G10001F
91637 CCF501G10R00F
19701 5043ED221K0F
91637 CCF501G100R0F
91637 CCF50G10001F
91637 CCF501G100R0F
91637 CCF501G100R0F
64537 PME55 3.24 MEGO
91637 CCF50G10001F
91637 CCF50G10001F
91637 CCF50G10001F
91637 CCF501G18201F
56845 CCF50–2–G4751FT
91637 CCF501G84500F
91637 CCF501G10003F
91637 RS2B–B63000F
91637 CCF501G100R0F
91637 CCF501G100R0F
91637 CCF50–2G698ROF
91637 CCF50–2G698ROF
91637 CCF501G15000F
91637 RS2B–B63000F
91637 CCF50–2F23201F
91637 CCF501G25500F
91637 CCF501G11801F
91637 CCF501G10000F
91637 CCF50G10001F
91637 CCF501G61900F
91637 CCF501G100R0F
91637 CCF501G100R0F
91637 CCF501G61900F
91637 CCF50–2F23201F
91637 CCF501G11801F
91637 CCF501G25500F
57856 KDS 10–312
26364 104–01–02
26364 104–01–02
26364 104–01–02
26364 104–01–02
26364 104–01–02
26364 104–01–02
26364 104–01–02
26364 104–01–02
26364 104–01–02
26364 104–01–02
8–21
