Exploded Panel View

CUSTOMER
MOUNTING PANEL
(HOLE CUT-OUT FOR CONTROL
HOUSING APPROXIMATELY
3.622" WIDE BY 1.770" HIGH)
SUPPLIED WITH EACH CONTROL:
1) GASKET
2) (2) 6-32 X 3/4 PANHEAD BLACK OXIDE STAINLESS SCREWS
3) (2) #6 NUT WITH LOCKWASHER

Cut-out and Mounting Dimensions

4.000"
CONTROLS Page Ite Valu Tach
Page Item Val Tac
Neg Rev Fwd Alarm
m
MICRO-DRIV
DIGITAL POT

Mechanical Installation

ENTER
"
.140 x 2
5.000"
2.289"
4.625"
PANEL MOUNTING GASKET
(WITH THE ADHESIVE SIDE OF
GASKET FACING THE CUSTOMER
MOUNTING PANEL)
DP4
CONTROL
4.000"
3.622"
DP4
HOUSING DEPTH
4.625"
PANEL CUT-OUT
1.656"
4
0.885"
1.770"
