Installation GUIDE
soft duomatik 2
Before introduction of the softener the installation guide has to be read carefully.
For any disturbances cause by disregarding the instructions evo-water doesn't accept liability.
evo-water oHG
Falkenstraße 2 72589 Westerheim
Tel.: +49 7333/925710
Fax : +49 7333/9257120
www.evo-water.com
info@evo-water.com
Advertisement
Table of Contents
Related Manuals for Evo-water soft duomatik 2
Summary of Contents for Evo-water soft duomatik 2
-
Page 1: Installation Guide
INSTALLATION GUIDE soft duomatik 2 Before introduction of the softener the installation guide has to be read carefully. For any disturbances cause by disregarding the instructions evo-water doesn’t accept liability. evo-water oHG Falkenstraße 2 72589 Westerheim Tel.: +49 7333/925710 Fax : +49 7333/9257120 www.evo-water.com... - Page 2 The room temperature must be at least 7°C and may not cross 50°C. 5. Changes in the system may not be made without consultation and approval with evo-water oHG, for damages no other guarantee is taken over. 6. The system serves exclusively for the removing of undesirable mineral substances which retreat as a scale.
- Page 3 1. A) Parts: BYPASS BLENDING REGULATOR VALVE HOUSING HARDNESS REGULATOR RESIN TANK 10. TO BRINE VALVE SALT CONTAINER 11. CONNECTIONS (1/2", 3/4”, 1") BRINE VALVE (floater) 12. TO DRAIN WATER INLET 13. COMMUNICATION TUBES WATER OUTLET 14. TUBES TO BRINE VALVE...
- Page 4 B) Parts Evo-water Duplex: BYPASS HARDNESS REGULATOR VALVE HOUSING 10. TO BRINE VALVE RESIN TANK 11. CONNECTIONS (1/2", 3/4”, 1") SALT CONTAINER 12. TO DRAIN BRINE VALVE (floater) 13. COMMUNICATION TUBES...
- Page 5 WATER INLET 14. TUBES TO BRINE VALVE WATER OUTLET 15. DEVICE CONTAINER BLENDING REGULATOR 2. Precautions: Make sure you have all necessary tools on hand before you begin with the installation. Follow all local legal regulations. Read this manual carefully. If you have any questions or remarks, please contact your supplier.
- Page 6 3.3.1 with Bypass with direct connections The Evo-water Bypass has a ¾” connection. The direct connections on the water softener are available in ½”, ¾” and 1”. Caution: before installing the softener, set the Bypass in “bypass” mode, not in “service”.
- Page 7 CAUTION: For the installation of the flexible drain hose to the fixed piping, please follow local legislation. maximum height distance of flexible drain hose Pierce a hole (Ø5mm) in the side wall of the salt container for the brine tube. The hole should be located approx.
- Page 8 Make sure to install the supplied overflow tap. First, pierce a hole (Ø21 mm) in the side wall of the salt container. The location of the hole is not important, make sure however that it is approx. 10cm down from the top edge of the salt container.
- Page 9 WHEN INSTALLING A DUPLEX EXTERNAL, PLEASE PROCEED TO “4. Settings”. WHEN INSTALLING A DUPLEX DUET, PLEASE PROCEED TO 3.8 At the bottom of the container there are two supports which the device will rest on. Check the correct location of these supports (refer to the image on the right).
- Page 10 Place the device in the container in such a way that the connections point in the opposite direction of the arrows on both supports at the bottom of the container. 3.10 A hole needs to be drilled in the side wall of the container for the tube which connects the brine valve to the T-piece.
- Page 11 =part number 9 on the illustration on page 1 Measure the hardness of incoming water by means of a hardness test kit (not supplied by evo-water). evo- water uses ppm settings of CaCO (10 ppm CaCO = 1°fh) (1°dh = 1,78°fh)
- Page 12 5. Start up: Leave Bypass in “bypass” mode, open main valve and flush for several minutes in order to avoid impurities from entering the softener. When you do not use a Bypass, open the main valve slowly as described in 5.4. Before filling the salt container with salt, check that the partition wall is correctly in place (between the small brackets, and all the way down to the bottom of the salt container).
- Page 13 Turn bypass slowly “service” mode. Open the main valve when you do not use a Bypass. Open a tap behind the softener so a flow runs through it. Some air may flow from the tap; this comes from the softener. This will happen only once; at start-up. Once only water flows from the tap, and no more air, close the tap.
- Page 14 Let regeneration perform until it stops automatically. The estimated time is approx. 12 minutes. When regeneration has stopped, no more water flows to the drain. This is a clear indication that the regeneration stage is over. 5.6.3 Open a tap behind the softener for several minutes to allow residual water to be flushed from the tubing.
- Page 15 An annual control of your Softener will guarantee optimal functioning and a long operating life. The EVO-WATER oHG is proud of its achievement in having provided in what we believe to be the best softener available today. Moreover, we are proud to have you as a customer. We will do our utmost to deserve your trust.
