Power Supply/Chargers
Installation Guide
Models Include:
eFlow3NV/eFlow3NXV
- 2A @ 12VDC or 24VDC
eFlow3N4V/eFlow3NX4V
- 2A @ 12VDC or 24VDC
- Four (4) Fused Outputs
Rev. 3NVRP122713
Installing Company: _____________________ Service Rep. Name: __________________________________________
Address: ________________________________________________________ Phone #: _________________________
eFlow3N4DV/eFlow3NX4DV
- 2A @ 12VDC or 24VDC
- Four (4) PTC Outputs
More than just power.™
Advertisement
Table of Contents
Related Manuals for EFLOW eFlow3NV
Summary of Contents for EFLOW eFlow3NV
-
Page 1: Installation Guide
Power Supply/Chargers Installation Guide Models Include: eFlow3NV/eFlow3NXV - 2A @ 12VDC or 24VDC eFlow3N4V/eFlow3NX4V eFlow3N4DV/eFlow3NX4DV - 2A @ 12VDC or 24VDC - 2A @ 12VDC or 24VDC - Four (4) Fused Outputs - Four (4) PTC Outputs More than just power.™... -
Page 2: Specifications
Overview: The eFlow3NV power supply/chargers convert a 220VAC (working range 198VAC - 256VAC), 50/60Hz input to a 12VDC or 24VDC nominal output (see Power Supply Configuration Reference Chart and Specifications). eFlow3NV Series Power Supply Configuration Reference Chart: Nominal DC Outputs... -
Page 3: Installation Instructions
5. Connect devices to be powered: a. For eFlow3NV/eFlow3NXV: connect devices to the terminals marked [- DC +] (Fig. 1h, pg. 3). b. For other Power Distribution Models: connect devices to be powered to the terminal pairs 1 to 4 marked [1P &... -
Page 4: Led Diagnostics
– BAT + Stand-by battery connections. Maximum charge current 1.54A (non power-limited) (Fig. 1g, pg. 5). Power Distribution Module Terminal Legend Function/Description PD4/PD4CB 1P to 4P Positive DC power outputs. 1N to 4N Negative DC power outputs. - 4 - eFlow3NV Series... - Page 5 Fig. 1 - eFlow3NV Board configuration 3A 32V 5A 250V 5A 250V BAT FAIL AC FAIL AC DELAY SHUTDOWN 1 min. enable TRIGGER EOL NC C NO NC C NO + AUX – 2 hr. disable SUPERVISED RESET Trouble/Time Limited Warning of Stand-by Batteries: The Time Limited Warning circuit must be connected for local or remote annunciation with an Amber or Red LED to indi- cate DC Trouble (low battery, loss of battery or when 95% of the stand-by battery has been depleted).
-
Page 6: Power Distribution Module(S)
INPUT POWER OUTPUTS DC Output to devices DC Output to devices From Power Supply From Power Supply 1P-4P Power Outputs, Board 1P-4P Power Outputs, Board 1N-4N Common Outputs 1N-4N Common Outputs (Factory Installed) (Factory Installed) - 6 - eFlow3NV Series... - Page 7 Fig. 4 - eFlow3NV configuration Edge of Enclosure Enclosure to Access Control Sentrol Panel or model # 3012 Reporting Tamper Switch Device or equivalent (Not Included) Ground Door Wire 220VAC Strap power mains (from Enclosure to Door) PD4/PD4CB Switch Detail Switch On - 12V Battery &...
- Page 8 NEC Power-Limited Wiring Requirements for eFlow3NV Models: Power-limited and non power-limited circuit wiring must remain separated in the cabinet. All power-limited circuit wiring must remain at least 0.25” away from any non power-limited circuit wiring. Furthermore, all power-limited circuit wiring and non power-limited circuit wiring must enter and exit the cabinet through different conduits.
- Page 9 Keep power-limited wiring separate from non power-limited. Use minimum 0.25" spacing. 12AH Rechargeable batteries are the largest batteries that can fit in this enclosure. An external battery enclosure must be used if using the 40AH or 65AH batteries. eFlow3NV Series - 9 -...
- Page 10 Power Distribution (power-limited) Battery Connections DC Output (non power- (power-limited) limited) Incorrect Wire Correct Wire Handling Handling Fig. 7a External Jacketed Shield Wire Insulation Pull back Solid Copper external jacketed Conductors shield approx. 1/2”. - 10 - eFlow3NV Series...
- Page 11 Enclosure Dimensions (BC300): eFlow3NV, eFlow3N4V, eFlow3N4DV 13.5” x 13” x 3.25” (342.9mm x 330.2mm x 82.55mm) 1.40” 4.85” 4.85” 1.40” (36mm) (123mm) (123mm) (36mm) 1.20” (31mm) 3.25” (83mm) 12.5” (318mm) 1.20” 1.20” 0.75” 0.75” (31mm) 11.0” (31mm) (19mm) (19mm) (279mm) 0.9375”...
- Page 12 0.91” (23.114mm) (23.114mm) 1.5” 1.5” (38.1mm) (38.1mm) 2.0” 15.5” (50.8mm) (393.7mm) 2.0” (50.8mm) 5.0” 5.0” (127.0mm) (127.0mm) 0.79” 1.1” (20.06mm) 1.25” 1.25” (27.94mm) (31.75mm) (31.75mm) 1.75” (44.45mm) 1.5” 4.615” 4.615” 1.5” (38.1mm) (117.22mm) (117.22mm) (38.1mm) - 12 - eFlow3NV Series...
-
Page 13: Appendix A - Compatible Devices
Appendix A - Compatible Devices A.1 Four (4) Wire Smoke Detectors Table A-1 below lists four (4) wire smoke detectors compatible with eFlow3NV output. System Sensor Max Stand-by Alarm Detector Type Smoke Detector/Base Current (mA) Current (mA) B112LP Base 0.12... - Page 14 Notes: - 14 - eFlow3NV Series...
- Page 15 Altronix is not responsible for any typographical errors. Product specifications are subject to change without notice. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IIeFlow3NV Series F02P eFlow3NV Series - 15 -...
- Page 16 2.1A 960mV eFlow3NXV, eFlow3NX4V, eFlow3NX4DV Overview: The eFlow3NV series power supply/chargers convert a 220VAC 50/60Hz input to a 12VDC or 24VDC output. Stand-by Specifications: Fire Applications Access Control Burg. Applications Battery 24 hr. Stand-by/5 min. Alarm Applications Stand-by 4 hr.
