RX-V595/R-V905/
n CONTENTS
To Service Personnel ........................................... 1
Remote Control Panels ....................................... 1
Front Panels ............................................................. 2
Rear Panels ........................................................... 3~4
Specifications ....................................................... 5~6
Internal View ............................................................ 7
Disassembly Procedures .................................... 7
Self Diagnosis Function ................................ 8~19
Factory Preset ...................................................... 20
Amp Adjustment ..................................................... 21
This Service Manual uses recycled paper.
1 0 0 6 5 4
RX-V595RDS
SERVICE MANUAL
This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel.
It has been assumed that basic service procedures inherent to the industry, and more specifically YAMAHA
Products, are already known and understood by the users, and have therefore not been restated.
WARNING:
Failure to follow appropriate service and safety procedures when servicing this product
may result in personal injury, destruction of expensive components, and failure of the
product to perform as specified. For these reasons, we advise all YAMAHA product
owners that any service required should be performed by an authorized YAMAHA
Retailer or the appointed service representative.
IMPORTANT:
The presentation or sale of this manual to any individual of firm does not constitute
authorization, certification or recognition of any applicable technical capabilities,
or establish a principle-agent relationship of any form.
The data provided is believed to be accurate and applicable to the unit(s) indicated on the cover. The research,
engineering, and service departments of YAMAHA are continually striving to improve YAMAHA products.
Modifications are, therefore, inevitable and specifications are subject to change without notice or obligation
to retrofit. Should any discrepancy appear to exist, please contact the distributor's Service Division.
WARNING:
Static discharges can destroy expensive components. Discharge any static electricity
your body may have accumulated by grounding yourself to the ground buss in the unit
(heavy gauge black wires connect to this buss).
IMPORTANT:
Turn the unit OFF during disassembly and part replacement. Recheck all work before
you apply power to the unit.
Tuner Adjustment ........................................... 22~25
Ic Data .................................................................. 26~35
Display Data ........................................................... 36
Block Diagram .................................................. 37~39
Printed Circuit Board ................................... 40~55
Schematic Diagram ......................................... 56~63
Parts List ............................................................ 64~79
PRINTED CIRCUIT BOARD ................................... 80~81
REMOTE CONTROL TRANSMITTER ......................... 82
AV RECEIVER

IMPORTANT NOTICE

Advertisement

Table of Contents
loading

Summary of Contents for Yamaha RX-V595

  • Page 1: Important Notice

    SERVICE MANUAL IMPORTANT NOTICE This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel. It has been assumed that basic service procedures inherent to the industry, and more specifically YAMAHA Products, are already known and understood by the users, and have therefore not been restated.
  • Page 2: To Service Personnel

    RX-V595/R-V905/RX-V595RDS TO SERVICE PERSONNEL 1. Critical Components information. Components having special characteristics are marked and must be replaced with parts having specifications equal to those originally AC LEAKAGE installed. WALL EQUIPMENT TESTER OR 2. Leakage Current Measurement (For 120V Model only).
  • Page 3: Front Panels

    RX-V595/R-V905/RX-V595RDS FRONT PANELS RX-V595 (U, C, R, T, A and L models) R-V905 (U, C, R, T and A models) RX-V595RDS (B and G models)
  • Page 4: Rear Panels

    RX-V595/R-V905/RX-V595RDS REAR PANELS RX-V595/R-V905 U model RX-V595/R-V905 C model RX-V595/R-V905 R model RX-V595/R-V905 T model...
  • Page 5 RX-V595/R-V905/RX-V595RDS RX-V595/R-V905 A model RX-V595RDS B model RX-V595RDS G model RX-V595 L model...
  • Page 6: Specifications

    RX-V595/R-V905/RX-V595RDS SPECIFICATIONS RIAA Equalization Deviation AUDIO SECTION PHONO (MM) 0±0.5dB Minimum RMS Output Power Per Channel Total Harmonic Distortion(20Hz to 20kHz) (Power Amp. Section) PHONO (MM) to REC OUT (1V) 0.02% U, C models CD etc.(EFFECT OFF) to MAIN SP OUT(35W/8Ω) MAIN L/R, REAR L/R 0.025%...
  • Page 7 RX-V595/R-V905/RX-V595RDS DIMENSIONS AM SECTION Tuning Range U, C models 530 to 1710kHz R, T models (Frequency Step : 10kHz) 530 to 1710kHz (Frequency Step : 9kHz) 531 to 1611kHz A, B, G, L models 531 to 1611kHz Usable Sensitivity 300µV/m...
  • Page 8: Internal View

    RX-V595/R-V905/RX-V595RDS INTERNAL VIEW 1 POWER TRANSFORMER 1 2 3 4 5 6 2 P.C.B. MAIN (3) 3 P.C.B. OPERATION (7) (R, T models only) 4 P.C.B. OPERATION (3) 5 P.C.B. MAIN (4) 6 P.C.B. MAIN (8) 7 P.C.B. OPERATION (6) 8 P.C.B.
  • Page 9: Self Diagnosis Function

    SELF DIAGNOSIS FUNCTION 1. PURPOSE AND OPERATION The RX-V595/R-V905/RX-V595RDS has a Self Diagnosis Function to locate a faulty part, if any, by inspecting and taking measurements. There are 11 main items in the diagnostic menu and some of them have sub-menu items as listed below.
  • Page 10 RX-V595/R-V905/RX-V595RDS 2. BEGINNING AND CANCELLATION (1) STARTING UP THE FUNCTION AND THE DISPLAY After starting up, menu No. 1 is selected. A. How to start diagnostic program Using the front panel keys of the main unit. Hold down the "INPUT MODE" and "FM/AM" keys simultaneously, and press the "STANDBY/ON" key; submenu No.
  • Page 11 RX-V595/R-V905/RX-V595RDS FL display at start-up of diagnostic program When the diagnostic program has started, the history (*2) of the protection function (*1) is displayed. If the protection function has been activated in the past, the type and voltage value are displayed. After a few seconds the diagnosis function menu will appear.
  • Page 12 RX-V595/R-V905/RX-V595RDS 3. OPERATION AND DISPLAY WHEN STARTING DIAGNOSIS FUNCTION (1) Selection of diagnostic menu The diagnostic menu and the sub-menu can be selected by using the front panel keys of the main unit or the remote control unit. Selection by using the front panel keys The main menu can be changed cyclically by using the "TUNING UP/DOWN"...
  • Page 13 RX-V595/R-V905/RX-V595RDS 4. CONTENTS OF DIAGNOSIS FUNCTION This section describes the contents of the self diagnosis function in detail. No.1 ANALOG THROUGH The input is fixed to analog (A/D). There are two submenus. 1 DVD/LD MAIN BYPAS 1. MAIN BYPASS The MAIN L/R signals bypass the analog circuits to be output.
  • Page 14 RX-V595/R-V905/RX-V595RDS No.2 DSP THROUGH The input is automatically discriminated by signal detection and switched with priorities AC3>PCM Audio>analog. There are the following three submenus. 2 DVD/LD YSS908SRAM 1. YSS908-SRAM MAIN L/R are input to the DSP via AC3Dav, pass through SRAM, and are then output to all channels without being processed.
  • Page 15 RX-V595/R-V905/RX-V595RDS No.3 AC3 THROUGH The input is digital signal only. AC3 (DOLBY DIGITAL) decoding operation is executed, according to the input source. 3 DVD/LD 3T00000001 1. STATUS(BINARY FORM) AC3 (DOLBY DIGITAL) decoded signals are output to each channel via AC3Dav.
  • Page 16 RX-V595/R-V905/RX-V595RDS No.5 SPEAKERS SET The input is automatically discriminated by AC3>PCM>analog. There are the following 9 submenu items: The signal from the DSP block is normally in the effect off status for menu items 1-4. For other menu items, the same signal as in 2. DSP THROUGH: YSS908 menu is output.
  • Page 17 RX-V595/R-V905/RX-V595RDS No.6 DISPLAY CHECK Check program for FL display. The display status will change as follows with submenu operation. The signal is processed with EFFECT OFF. 6 DVD/LD DISP CHECK Initial displayed. All segments are turned off All segments are turned on...
  • Page 18 RX-V595/R-V905/RX-V595RDS No.9 AD DATA CHECK The A/D conversion values of the main CPU which detects key scan, protection, etc. are displayed in % (100%: 5V). All signal processing before this menu is executed will be held. The keys on the main unit cannot be operated to detect the values of all keys in the K1/K2/K3/K4.
  • Page 19 RX-V595/R-V905/RX-V595RDS No.10 STATUS FROM DSP MICOM The status data from the DSP microprocessor is sequentially displayed in a hexadecimal number. All signal processing before this menu is executed will be held. 1st 2nd 3rd 4th 10 DVD/LD 0 00000000 10 DVD/LD 1 00000000...
  • Page 20 RX-V595/R-V905/RX-V595RDS No.11 CPU VERSION/CHECK SUM/PORT INFO/EXIT DIAG The check sum, version and port setting of main CPU/DSP CPU are displayed. The signal is EFFECT OFF. Operating the submenu will finish self-diagnosis, and ordinary operation mode will be restored. The suffix letter ("B" in the following) of version indication is for compatibility of communications between the main and DSP microprocessors.
  • Page 21: Factory Preset

    RX-V595/R-V905/RX-V595RDS FACTORY PRESET All the settings of the system are initialized on shipping. The settings are as follows. INPUT (VIDEO) DVD/LD (DVD/LD) EFFECT LEVEL EFFECT CHANNEL PRESET VALUE CENTER 0 dB RIGHT SURROUND 0 dB LEFT SURROUND 0 dB SUB WOOFER...
  • Page 22: Amp Adjustment

    RX-V595/R-V905/RX-V595RDS AMP ADJUSTMENT Confirmation of Idling Current of Main Amplifier • Right after power is turned on, confirm that the voltage across the terminals of R688(Main Lch),R690(Main Rch), R692(Center), R694(Rear Lch), R696(Rear Rch) are between 0.1mVand 5.0mV. • If it exceeds 5.0mV, open (cut off) R571 (Main Lch), R577 (Main Rch), R589 (Center), R595 (Rear Lch), R583 (Rear Rch) and reconfirm the voltage again.
  • Page 23: Tuner Adjustment

    RX-V595/R-V905/RX-V595RDS TUNER ADJUSTMENT 1. Measuring Instruments Dummy antenna FM signal generator (FM SG) FM dummy antenna Stereo signal generator (SSG) AM signal generator (AM SG) 10Ω 45Ω Distortion meter (DIST. M) FM SG RECEIVER AC Voltmeter (ACVM) (75Ω) (50Ω) DC Voltmeter (DCVM)
  • Page 24 RX-V595/R-V905/RX-V595RDS FM Adjustment 1. Before Adjustment Set each switch to the following position unless otherwise For dBµ, 1µV=0dBµ applies. specified. Example : 60dBµ=1mV INPUT SELECTOR ..TUNER 100% modulation means that the frequency deviation is TUNING MODE ..... AUTO ±75kHz.
  • Page 25 RX-V595/R-V905/RX-V595RDS See page 22 for TP locations & adjustment points. Reception Adjustment Step Adjustment item Signal (ANT IN) Test point Rating frequency point Adjustment of FM ANT (75Ω) 98.1MHz Front end IFT Pin 16 of IC1 Adjust so that the meter is front end IFT 98.1MHz...
  • Page 26 RX-V595/R-V905/RX-V595RDS AM Adjustment (This should be done after FM adjustment.) 1. Connection diagram (Measuring instruments) Adjustment of sensitivity. AM loop antenna AM ANT ACVM TUNER AM SG AM SG P. C. B. DIST. M Oscilloscope See page 22 for TP locations & adjustment points.
  • Page 27 RX-V595/R-V905/RX-V595RDS IC DATA IC800 : LC87F65C8A (LC876564A-5K19) µ 8 bit -COM S48/PG0 S19/PC3 S49/PG1 S18/PC2 S50/PG2 S17/PC1 S51/PG3 S16/PC0 VDD3 S15/T15 S14/T14 S13/T13 VSS2 S12/T12 VDD2 S11/T11 TOP VIEW S10/T10 S9/T9 S8/T8 S7/T7 P10/SO0 S6/T6 P11/SI0 S5/T5 P12/SCK0 S4/T4 P13/SO1...
  • Page 28 RX-V595/R-V905/RX-V595RDS IC800 : LC87F65C8A (LC876564A-5K19) µ 8 bit -COM Port Function Port Function Name Name FLA-CLK I/O Flush clock 26 P70/INT0 I Power down detect FLA-I/O I/O Flush input/output 27 P71/INT1 O Full mute (L : ON) FLA-SEL I/O Flush select...
  • Page 29 RX-V595/R-V905/RX-V595RDS IC800 : LC87F65C8A (LC876564A-5K19) µ 8 bit -COM Port Function Port Function Name Name 76 S43/PF3 POWER-RY O Power relay 52 S20/PC4 O FL Segment 5 77 S44/PF4 –10dB O –10 dB select (L : –10dB) 53 S21/PC5 O FL Segment 6...
  • Page 30 RX-V595/R-V905/RX-V595RDS IC14 : LC87F5164A (LC875164A-5K20) µ 8 bit Sub -COM PWM1 SI2P3 SCK2 P17/PWM P16/PWL VSS3 P15/SCK1 VDD3 P14/SI1 P13/SO1 TOP VIEW P12/SCK0 P11/SI0 P10/SOO P87/AN7 P86/AN6 INTERRUPT CONTROL STANDBY /RES CONTROL CLOCK GENE- RATOR Xtal SERIAL I/O 0 BUS INTERFACE...
  • Page 31 RX-V595/R-V905/RX-V595RDS IC14 : LC87F5164A (LC875164A-5K20) µ 8 bit Sub -COM Port Function Port Function Name Name I Receive data from DIR2 PWM0 OL Unconnected /ICDI O Initial clear for DIR2 VDD2 VDD2 +5V +5V power supply /KM1 O Switching DIR2 forced (analog) mode...
  • Page 32 RX-V595/R-V905/RX-V595RDS IC3 : YM3436DK (DIR2) Digital Format Interface Receiver 24 26 28 25 17 15 14 13 12 31 EXTW DOM0 SYSTEM CLOCK EXTW DOM1 TIMING DDIN DIM0 SYNC GENERATOR DIM1 D DIN TOP VIEW DATA CLOCK EIAJ (AES/EBU) CONTROLLER...
  • Page 33 RX-V595/R-V905/RX-V595RDS IC4 : YSS908-F (AC3Dav) Digital Dolby Pro Logic Decoder +DSP PVSS SDWCK0 SDWCK1 SDBCK0 SDBCK1 SDIA0 SDOB0 SDIA1 SDOB1 RAMA1 SDOB2 RAMA0 RAMA7 RAMWEN RAMA8 RAMOEN RAMA9 TOP VIEW IPORT7 OPORT7 IPORT6 OPORT6 IPORT5 OPORT5 IPORT4 OPORT4 IPORT3 OPORT3...
  • Page 34 RX-V595/R-V905/RX-V595RDS IC4 : YSS908-F (AC3Dav) Digital Dolby Pro Logic Decoder +DSP Name Function PVDD +5V power supply RAMCEN RAM chip enable output terminal, connected to external 1M SRAM chip enable RAMA16 RAM address output terminal 16, connected to external 1M SRAM address...
  • Page 35 RX-V595/R-V905/RX-V595RDS IC4 : YSS908-F (AC3Dav) Digital Dolby Pro Logic Decoder +DSP Name Function +3V power supply AC3DATA AC-3 data output terminal, AC-3 bit stream data detect CRC output terminal (normally unconnected) MUTE Mute output terminal, output data mute detect KARAOKE...
  • Page 36 RX-V595/R-V905/RX-V595RDS IC5 : M5M51288BKJ-20LTEL (1M SRAM) 131072-word x 8 bit High Speed Static RAM 131072-word x 8 bit MEMORY ARRAY (512-row X 2048-column) 2048 TOP VIEW COLUMN I/O COLUMN ADDRESS /CE1 DECODER COLUMN INPUT BUFFER /CE1 CHIP SELECT WRITE CONTROL...
  • Page 37: Display Data

    RX-V595/R-V905/RX-V595RDS DISPLAY DATA V800 : 16-BT-59GK (V2421800) PATTERN AREA • PIN CONNECTION Pin No. CONNECTION Pin No. CONNECTION NOTE 1) F1, F2 ..Filament Pin No. 2) NP ....No pin CONNECTION 3) NC ....No connection 4) DL ....Datum Line 5) 1G~16G ..
  • Page 38 RX-V595/R-V905/RX-V595RDS BLOCK DIAGRAM (1/2)
  • Page 39 RX-V595/R-V905/RX-V595RDS BLOCK DIAGRAM (2/2) PHONES MAIN MAIN SELECTOR POWER AMP LEVEL IC10A IC102 VR401 IC103 Q506,511,512, IC103 IC351 521,529,Q527A/C IC108B IC401A IC802A INPUT MAIN COAX SELECTOR H,P,F Q810 Q501 DVD/LD IC352 IC103 TONE IC10B IC103 TV/DBS CONTROL RY501 OPTICAL SIGNAL...
  • Page 40 RX-V595/R-V905/RX-V595RDS PRINTED CIRCUIT BOARD (Foil side) P. C. B. ASS'Y TUNER LIST Model Markets Lead Type Lead & SMD Lead & SMD : See page 80~81, PRINTED CIRCUIT BOARD There are two types of P. C. B. Assembly Tuner for this models in items of construction of components.
  • Page 41 RX-V595/R-V905/RX-V595RDS PRINTED CIRCUIT BOARD (Foil side) P. C. B. DSP P. C. B. DSP TO: INPUT (1) TO: INPUT (3) TO: INPUT (1) LC87F5164A HD74HC02FP YSS908-F YM3436DK AK4526 AK4320 Semiconductor Location Point Point Pin 13 of IC4 Ref. No. Location Ref.
  • Page 42 RX-V595/R-V905/RX-V595RDS B, G models only PRINTED CIRCUIT BOARD (Foil side) P. C. B. OPERATION (1) PTY SEEK – PROGRAM MODE START Semiconductor Location Ref. No. Location D800 B, G D801 models only D802 EFFECT D803 MENU D805 TIME/ LEVEL D806...
  • Page 43 RX-V595/R-V905/RX-V595RDS P. C. B. OPERATION (6) PRINTED CIRCUIT BOARD (Foil side) P. C. B. OPERATION (5) • U, C, R and T models SWITCHED TO: MAIN (7) 100W MAX. TOTAL P. C. B. OPERATION (3) AC OUTLETS R, T models only...
  • Page 44 RX-V595/R-V905/RX-V595RDS PRINTED CIRCUIT BOARD (Foil side) P. C. B. MAIN (1) B, G models only NFRL NFRR –B A, B, G, L only SPRY PRV1 A, B, G, L only W803 W504 TO: MAIN (3) TO: OPERATION (1) W761 W815...
  • Page 45 RX-V595/R-V905/RX-V595RDS PRINTED CIRCUIT BOARD (Foil side) P. C. B. MAIN (7) P. C. B. MAIN (6) P. C. B. MAIN ( 3 ) P. C. B. MAIN (4) TO: INPUT (1) TO: MAIN (1) W761 TO: MAIN (1) OPERATION (5) W504 –B2...
  • Page 46 RX-V595/R-V905/RX-V595RDS PRINTED CIRCUIT BOARD (Foil side) P. C. B. INPUT (1) Semiconductor Location Ref. No. Location D101 D102 D103 D104 TO: TUNER TO: DSP TO: DSP IC101 IC102 IC103 IC104 IC105 IC106 IC107 IC108 A, L, B, G only IC109...
  • Page 47 RX-V595/R-V905/RX-V595RDS PRINTED CIRCUIT BOARD (Foil side) P. C. B. INPUT (2) P. C. B. INPUT (3) P. C. B. INPUT (4) TO: INPUT (1) W102 INPUT (1) –12 +12A LFEO W101 LA7956 +12A /VCR TO: DSP VSEL1 VSEL0 TO: INPUT (1)
  • Page 48 RX-V595/R-V905/RX-V595RDS SCHEMATIC DIAGRAM (INPUT) S-VIDEO SELECTOR & AMP 11.6 10.9 VCR-IN VCR-OUT S VIDEO MONITOR 11.6 10.9 : NOT USED VIDEO SELECTOR & AMP VIDEO SIGNAL IC301~303 : LA7956 Video Switch VCR-IN 11.6 VCR-OUT PIN CONNECTION DIAGRAM OF VIDEO TRANSISTORS AND IC’s.
  • Page 49 RX-V595/R-V905/RX-V595RDS SCHEMATIC DIAGRAM (INPUT) TO OPE(4) CB802 VOLUME AMP FRONT L REAR L TO DSP CB6 MAIN L MAIN L MAIN L MAIN L (DSP) (DSP) 11.7 CENTER PHONO(MM) CENTER/SUB WOOFER/FRONT/REAR AMP CENTER EQ AMP 23.3 11.4 MAIN L MAIN L CENTER -11.6...
  • Page 50 RX-V595/R-V905/RX-V595RDS SCHEMATIC DIAGRAM (MAIN) REGULATOR MAIN POWER AMP 29.4 12.8 43.5 13.4 43.4 43.5(30.2) OUTPUT MAIN POWERAMP 43.5(30.2) MAIN L 43.3 -0.5 MAIN MUTE -1.1 -11.6 SPEAKERS -42.5 -41.7 -0.6 -0.6 -1.1 -43.5 (-30.3) -41.7 -43.5 MAIN (-30.3) -42.3 MAIN RELAY 43.5(30.2)
  • Page 51 RX-V595/R-V905/RX-V595RDS SCHEMATIC DIAGRAM (OPERATION) IC801, 802 : NJM2068LD • IC800→See page 26~28, IC DATA Dual OP-Amp – – S.VIDEO 2 3 4 5 6 VIDEO AUDIO -22.7 -29.7 OPE(2),(3),(4) TONE CONTROL -11.7 11.8 11.8 -19 .6 -11.7 SYSTEM & DSP -8.9...
  • Page 52 RX-V595/R-V905/RX-V595RDS TO INPUT(3) CB354 SCHEMATIC DIAGRAM (DSP) DIGITAL L.P.F 3. 1 2. 4 DOLBY DIGITAL 2. 4 2. 7 11.9 PRO-LOGIC DECODER MAIN L 2. 4 (DSP) 0. 9 ADC/ -11.7 4. 7 2. 4 0. 2 2. 4 2. 7 11.9...
  • Page 53 RX-V595/R-V905/RX-V595RDS Each voltage given here repressents that in the FM (98.1MHz STEREO) reception mode SCHEMATIC DIAGRAM (TUNER) U, C, R, T, A and L models but the one in the parentheses ( ) is that in the AM (1080kHz, MAN’L) reception mode.
  • Page 54 RX-V595/R-V905/RX-V595RDS Each voltage given here repressents that in the FM (98.1MHz STEREO) reception mode SCHEMATIC DIAGRAM (TUNER) B, G models but the one in the parentheses ( ) is that in the AM (1080kHz, MAN’L) reception mode. IC1 : LA1266...
  • Page 55 RX-V595/R-V905/RX-V595RDS WARNING P ARTS LIST Components having special characteristics are marked and must be replaced with parts having specifications equal to those originally installed. ELECTRICAL PARTS Carbon resistors (1/6W or 1/4W) are not included in the ELECTRICAL PARTS List. For the part Nos. of the carbon resistores,refer to the last page.
  • Page 56 RX-V595/R-V905/RX-V595RDS P. C. B. DSP Schm Schm PART NO. Description PART NO. Description V3005700 P.C.B. UB245100 C.CE.M.CHP 0.1uF UR818330 C.EL 330uF 6.3V VQ044200 CN.BS.PIN VQ044500 CN.BS.PIN UB245100 C.CE.M.CHP 0.1uF UB245100 C.CE.M.CHP 0.1uF VQ044600 CN.BS.PIN UB245100 C.CE.M.CHP 0.1uF UR818330 C.EL 330uF 6.3V...
  • Page 57 RX-V595/R-V905/RX-V595RDS P. C. B. DSP & P. C. B. INPUT Schm Schm PART NO. Description PART NO. Description C124 UR847100 C.EL 10uF VV655300 TR.DGT DTA144EKA C125 UR837220 C.EL 22uF VV655300 TR.DGT DTA144EKA C126 UA952100 C.MYLAR 100pF VD303700 TR 2SC3326 A,B C127 UR847100 C.EL...
  • Page 58 RX-V595/R-V905/RX-V595RDS P. C. B. INPUT Schm Schm PART NO. Description PART NO. Description C109 VK533900 C.PP 100pF 200V C166 UA954270 C.MYLAR 0.027uF C112 UA952100 C.MYLAR 100pF C167 UR847100 C.EL 10uF C113 UA952100 C.MYLAR 100pF C168 UR847100 C.EL 10uF C114 FG651470 C.CE...
  • Page 59 RX-V595/R-V905/RX-V595RDS P. C. B. INPUT Schm Schm PART NO. Description PART NO. Description C318 UR837330 C.EL 33uF 16V(BG) C425 VG287600 C.EL 100uF C319 UR837100 C.EL 10uF C426 VG277000 C.CE.TUBLR 33pF 50V(BG) C320 VF467000 C.CE.TUBLR 1000pF C427 UR838100 C.EL 100uF C321 UR829100 C.EL...
  • Page 60 RX-V595/R-V905/RX-V595RDS P. C. B. INPUT & P. C. B. MAIN Schm Schm PART NO. Description PART NO. Description Q302 iC1815I0 2SC1815 Y(BG) C510 FG651330 C.CE 33pF 50V(URTC) Q303 iA1015I0 2SA1015 Y(BG) C510 UA952220 C.MYLAR 220pF 50V(ABGL) Q304 iC1815I0 2SC1815 Y(BG) C510 UA952220 C.MYLAR...
  • Page 61 RX-V595/R-V905/RX-V595RDS P. C. B. MAIN Schm Schm PART NO. Description PART NO. Description C558 UA954680 C.MYLAR 0.068uF D501 VM975700 DIODE.ZENR HZS12C2TD 12V C559 UA954680 C.MYLAR 0.068uF D502 VD631600 DIODE 1SS133,176,HSS104 C560 UA954680 C.MYLAR 0.068uF D503 VD631600 DIODE 1SS133,176,HSS104 C561 UA954680 C.MYLAR 0.068uF...
  • Page 62 RX-V595/R-V905/RX-V595RDS P. C. B. MAIN Schm Schm PART NO. Description PART NO. Description Q524 iC174020 2SC1740S R,S R584 HV756100 R.CAR.FP 1KΩ 1/4W Q525 iC174020 2SC1740S R,S R585 VP941500 R.MTL.OXD 4.7KΩ Q526 VP872700 TR 2SC4488 S,T R586 VP941500 R.MTL.OXD 4.7KΩ Q527 VR355900 TR.PAIR...
  • Page 63 RX-V595/R-V905/RX-V595RDS P. C. B. MAIN & P. C. B. OPERATION Schm Schm PART NO. Description PART NO. Description RY501 VK438300 RELAY DH24D2-OT/M2 C807 UR819100 C.EL 1000uF 6.3V RY502 VU566700 RELAY DG24D2-OS/M C808 VU545000 C.EL 47000uF 5.5V RY503 VK438300 RELAY DH24D2-OT/M2 C809 VJ599100 C.CE.TUBLR 0.1uF...
  • Page 64 RX-V595/R-V905/RX-V595RDS P. C. B. OPERATION Schm Schm PART NO. Description PART NO. Description D813 VM974500 DIODE.ZENR HZS6C2TD 6.0V SW822 VG392900 SW.TACT SKHVAA D814 VD631600 DIODE 1SS133,176,HSS104 SW823 VG392900 SW.TACT SKHVAA D815 VR253700 DIODE.BRG S1NB20 1.0A SW824 VG392900 SW.TACT SKHVAA D816 VM975300 DIODE.ZENR HZS11B2TD 11V(RT)
  • Page 65 RX-V595/R-V905/RX-V595RDS P. C. B. TUNER (Lead Type) P. C. B. TUNER (Lead Type & SMD) Schm Schm Schm Schm PART NO. Description PART NO. Description PART NO. Description PART NO. Description UA953220 C.MYLAR 2200pF 50V(UCRT) V2518600 P.C.B. TUNER/TU-01(UC) UA953220 C.MYLAR...
  • Page 66: Exploded View

    RX-V595/R-V905/RX-V595RDS EXPLODED VIEW MECHANICAL PARTS Ref. PART NO. Description Remarks Markets 1- 1 V2463700 FRONT PANEL RX-V595 GD 1- 1 V2463800 FRONT PANEL RX-V595RDS BL (BG) 1- 1 V2463900 FRONT PANEL RX-V595RDS TI 1- 1 V2464100 FRONT PANEL R-V905 1- 1...
  • Page 67 V2461100 SHIELD CASE BATTERY, MANGANESE SUM-3,AA,R06 VZ332800 SHIELD CASE COVER V2460900 FRAME V0042500 LEG D60xH21 R-V905 VS025000 LEG D60xH21 RX-V595 BL/TI VV544300 LEG D60xH21 RXV595GD R-V905 (UCA) V3346400 KNOB D40 BL V3346500 KNOB D40 TI V3346600 KNOB D40 GD V2467600 KNOB, ENC...
  • Page 68 RX-V595/R-V905/RX-V595RDS PRINTED CIRCUIT BOARD (Foil side) P. C. B. ASS'Y TUNER LIST Model Markets Lead & SMD Lead Type Lead Type : See page 40~41, PRINTED CIRCUIT BOARD There are two types of P. C. B. Assembly Tuner for this models in items of construction of components.
  • Page 69: Remote Control Transmitter

    RX-V595/R-V905/RX-V595RDS REMOTE CONTROL TRANSMITTER SCHEMATIC DIAGRAM K10 K20 K30 ROTARY SW Key arrangement K19 K29 MODE 9:AMP/TUNER K18 K28 8:MD/TAPE IC2: K17 K27 SC501054DW(U,C,L,R,T) 7:CD K16 K26 SC501055DW(A,B,G) 6:DSP 1MΩ K15 K25 5:DVD/LD K14 K24 OSC1 4MHz 0.1µF 4:DVD_MENU OSC2...
  • Page 70 RX-V595/R-V905/RX-V595RDS Parts List for Carbon Resistors Value 1/4W Type Part No. 1/6W Type Part No. Value 1/4W Type Part No. 1/6W Type Part No. 1.0 Ω 3100 7100 3100 10 kΩ 7100 HJ35 HF85 HF45 HF45 1.8 Ω 3180 7110 11 kΩ...
