Dared LP-100 User Manual

Mm/mc audiophile grade tube phono preamplifier

Table of Contents

Download this manual

Enlarged version

Technical Specifications

LP-100 MM/MC Audiophile Grade Tube Phono Preamplifier

Power Supply Input: 50W

Voltage Range: 100-120V, 220-240V

Max. Current Draw Indicated: 50W

Power Consumption: 50W

Distortion Spec.: 0.07% (1kHz)

Tube compliment: (1)ECC85(6N1) (2)12AX7

Inputs: one pair MC (RCA); one pair MM (RCA)

Outputs: one pair RCA outs

MC gain: max. 63dB (adjustable to 66dB and 60dB)

MM Capacitive Loading: 10pF, 20pF, 47pF, 100pF

MM Resistive Loading: 47K fixed

MC Resistive Loading: adjustable 20 , 50 , 75 , 100 , 200 , 500

Frequency Response: 10Hz – 25kHz (±2dB)

Power sequence: Mute delay power up squence with soft start for

improved tube life

Dimensions: 380x280x125mm (WxDxH)

14.96''x11.02x4.92''

Weight: 8kg / 17.64lbs

Thank-you for selecting DARED as your choice

for your audio entertainment system and

listening pleasure.

Experience The Art of Tube

Tube

The Purity of Sound

LP-100 User Manual

MM/MC Audiophile Grade Tube Phono Preamplifier

Table of Contents

Do you have a question about the LP-100 and is the answer not in the manual?

Page 1 Technical Specifications LP-100 MM/MC Audiophile Grade Tube Phono Preamplifier Power Supply Input: 50W Voltage Range: 100-120V, 220-240V Max. Current Draw Indicated: 50W Power Consumption: 50W LP-100 User Manual Distortion Spec.: 0.07% (1kHz) Tube compliment: (1)ECC85(6N1) (2)12AX7 Inputs: one pair MC (RCA); one pair MM (RCA) Outputs: one pair RCA outs MC gain: max.
Page 2 At this time also please locate the Product Registration Card and write down the serial number of your new LP-100 in the space provided on the card as well as below for future reference. Serial No.: ________________ Date of Purchase:___________________...
Page 3 2) Change out tube for same model other connecting cables during transportation. turned on, power number 10. Only use attachments and accessories specified by DARED or your indicator on, tube does Authorized DARED Dealer. not light 11. Use a surge protector on the main AC-Line to this component as well as all other components connrcted to this product.
Page 4 Connection Diagram FAMILIARIZING YOURSELF WITH YOUR LP-100 Front Panel 1. Power On/Off Button 2. MM or MC input selector 3. Subsonic filter selector 4. MM capacitance selector 5. MC impedance selector 6. Gain Control Rear Panel Connections (a) Before making connections, ensure that the power switch is turned off.
