Plus Air Sampling Pump – Operation Manual
Page 34
Gilian GilAir
2. On the GilAir Plus pump, go to Setup, then SmartCal. Use the
buttons to select TSI. Press and release the
the
button. Go to Calibrate, then press and release the
begin to run in the SmartCal mode.
3. While running in the SmartCal mode, the TSI 4140 displays the flow rate, and the
following is displayed on the pump:
SmartCal
TSI
4. When flow stability is reached, the calibration will be calculated and stored.
Calibration Complete will be displayed.
5. Before removing the pump from the Dock, press and release the
The Main Menu screen is displayed. Remove the pump from Dock. Go to Run.
Press and release the
5.6.4. Bios Defender™ 510
The Defender has a limited flow range, verify that the desired calibration flow rate is
within range. The Defender is set to cycle continuously and read flow. When
adequate samples are collected to guarantee flow stability, the calibration will be
calculated and stored. Calibration complete will be displayed. The
be used to return to the main menu.
1. Setup the GilAir Plus and Bios Defender with the SmartCal cable connected to
the Data port on the Defender and the Reference Device connector on the rear of
the Dock as shown in the photo.
© 2011 Sensidyne, LP
and buttons to set the desired flow rate. Press and release the
(flow rate) cc/m
button. The pump begins to run at the set flow rate.
button. Go to Flow set. Use
button. The pump will
Sensidyne Document No. 360-0132-01 (Rev D)
and
button.
button can
