Operation Manual
16333 Bay Vista Drive • Clearwater, FL 33760 USA
(800) 451-9444 • +1 (727) 530-3602
www.Sensidyne.com • info@Sensidyne.com
REF 360-0132-01 (Rev D)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GILAIR PLUS and is the answer not in the manual?

Questions and answers

Related Manuals for Gilian GILAIR PLUS

Summary of Contents for Gilian GILAIR PLUS

  • Page 1 Operation Manual 16333 Bay Vista Drive • Clearwater, FL 33760 USA (800) 451-9444 • +1 (727) 530-3602 www.Sensidyne.com • info@Sensidyne.com REF 360-0132-01 (Rev D)
  • Page 2 ® Plus Air Sampling Pump – Operation Manual Page II Gilian GilAir GilAir Plus Identifiers: A LCD Display B Status and Notification LED’s C Inlet Filter D Hi/Lo Control Valve E Charging Contacts F Belt Clip G Battery Access Screws...

  • Page 3: Quality Policy Statement

    ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page III Quality Policy Statement At Sensidyne, we are committed to providing products and services that consistently meet customer needs and comply with all applicable statutory and regulatory requirements. Our products are designed and manufactured in accordance with ISO 9001:2008, EN 13980:2002, ATEX Directive 94/9/EEC, and IECEx.

  • Page 4: Warranty

    Gilian GilAir Warranty Sensidyne warrants that, at the time of delivery, the GilAir Plus shall be free of all defects in workmanship and material. Sensidyne will repair or replace, at its sole option, any GilAir Plus found to be defective by Sensidyne, if notified by Purchaser within the Warranty time period.

  • Page 5: Table Of Contents

    ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page V Table of Contents GilAir Plus Identifiers ....................II Quality Policy Statement ..................III Warranty ........................IV SECTION ONE: Preface ................... 1 Warnings ........................3 Certifications, Approvals and Compliances ..............5 SECTION TWO: Introduction ...................
  • Page 6 ® Plus Air Sampling Pump – Operation Manual Page VI Gilian GilAir 4.5.8. STP Display ....................18 4.6. Sensor Calibration ..................19 4.7. Run Mode ....................... 19 4.7.1. Run Mode Descriptions ................19 4.7.2. Locking the Keypad ................... 19 4.7.3.
  • Page 7 ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page VII 5.10.1. Clock ......................38 5.10.2. Date ......................39 5.10.3. Time Format ....................39 5.10.4. Date Format ....................40 5.11. Password ......................40 5.12. Control Mode ....................41 5.13. Run Mode Manual, Timed, Program Name ............ 42 5.14.
  • Page 8 ® Plus Air Sampling Pump – Operation Manual Page VIII Gilian GilAir SECTION NINE: User Maintenance ............... 58 9.1. Battery Maintenance NiMH ................58 9.2. Battery Replacement ..................58 9.3. Pump Filter Maintenance ................59 SECTION TEN: Appendices ................... 60 Appendix A: Menu Outline ..................

  • Page 9: Section One: Preface

    SECTION ONE: Preface Proprietary Notice The intended use of this manual is exclusive to owners of Gilian GilAir Plus air sampling pumps. The material within this manual is proprietary information and is to be used only to understand, operate, and service the instrument. By receiving...
  • Page 10 ® Plus Air Sampling Pump – Operation Manual Page 2 Gilian GilAir Disclaimer THE SELLER ASSUMES NO RESPONSIBILITY WHATSOEVER, TO ANY PARTY WHOSOEVER, FOR ANY PROPERTY DAMAGE, PERSONAL INJURY, OR DEATH RECEIVED BY OR RESULTING FROM, IN WHOLE, OR IN PART, THE IMPROPER USE, INSTALLATION, OR STORAGE OF THIS...

  • Page 11: Warnings

    UNDER NO CIRCUMSTANCES should this product be used except by qualified, trained and technically competent personnel. The GilAir Plus portable air sampling pump is intended for both indoor and outdoor use. The unit is not waterproof. NEVER submerge the unit in water. Pump failure, faulting or user injury may result.
  • Page 12 Page 4 Gilian GilAir If the GilAir Plus pump comes into contact with a destructive substance(s) it is the responsibility of the user to take suitable precautions that prevent the pump from being adversely affected, thus ensuring that the Intrinsic Safety protection is not compromised.

  • Page 13: Certifications, Approvals And Compliances

    ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page 5 Certifications, Approvals and Compliances Declaration of Conformity Sensidyne Document No. 360-0132-01 (Rev D) © 2011 Sensidyne, LP...
  • Page 14 ® Plus Air Sampling Pump – Operation Manual Page 6 Gilian GilAir © 2011 Sensidyne, LP Sensidyne Document No. 360-0132-01 (Rev D)

  • Page 15: Section Two: Introduction

    2.1. Product Description The GilAir Plus is an advanced personal air sampling pump system available in three models: a basic model, a datalogging pump (DL) model, and standard temperature and pressure (STP) model. The STP model corrects the display flow rate and air volume to standard conditions of temperature and pressure.

  • Page 16: Pump Kit Descriptions

    ® Plus Air Sampling Pump – Operation Manual Page 8 Gilian GilAir 2.2. Pump Kit Descriptions Kits are available in one, three and five pump configurations, with power cords in US, Euro and UK versions. A matrix chart for the available kits is provided below.

  • Page 17: Section Three: Set-Up

    ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page 9 SECTION THREE: Set-Up 3.1. Preparation The package includes the pump, dock, dock power supply, and a line cord. The dock serves as the charging base for all models and the communications dock for the datalogging and STP models.

  • Page 18: Setting The Flow Rate

    3.4. Power Options The GilAir Plus comes standard with a rechargeable nickel metal hydride (NiMH) battery. The unit is charged through the dock that is included with all starter kits. An optional alkaline battery pack (P/N 783-0013-01-R) is available that allows the use of over-the-counter alkaline or lithium batteries.

  • Page 19: Section Four: General Operation

    4.1. Overview The GilAir Plus has the capability of generating and controlling flow over the range of 1 cc/min to 5000 cc/min in two flow ranges, 1-449 cc/min, and 450-5000 cc/min, that are selectable using a 2 mm or 5/64 inch hex key (provided with the pump). The actual flow is measured and controlled by the pump‟s internal processor.

  • Page 20: Navigation

    Plus Air Sampling Pump – Operation Manual Page 12 Gilian GilAir 4.3. Navigation The GilAir Plus pump uses an intuitive six-button keypad for menu navigation and pump operation. The buttons and their functions are summarized in the table below. Symbol Name Function...
  • Page 21 ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page 13 General operation of the menu system: Access the menu by pressing the button. The menu is displayed in a vertical column. Some menu items have a ► sign after the menu item and lead to submenus.

  • Page 22: Displays

    Description Menu Display The main menu allows all of the parameters of the operation of the GilAir Plus to be set, by scrolling to the appropriate menu item (Section 4.3. ) Idle Shown when the pump is not conducting an event, Idle displays Flow Set Point,...
  • Page 23 ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page 15 Constant Pressure Displays Back pressure BP (inches water, mmHg, KPa), Run Time RT (minutes) and Projected Run Time PRT (hours) based on battery charge status and back pressure.

  • Page 24: Display Details

    ® Plus Air Sampling Pump – Operation Manual Page 16 Gilian GilAir 4.5.1. Display Details Date and time: Displayed in selectable format mm/dd/yy or dd/mm/yy Battery icon: When using a NiMH battery pack the charge state of the battery is shown. Charge status is approximate and depends on many factors including age, number of charge cycles, temperature and recent charge or discharge history.

  • Page 25: Constant Flow Run Display Details

    ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page 17 Datalog Events: Displays the number of events recorded, and the total number of storage positions. 4.5.4. Constant Flow Run Display Details Flow cc/min: The flow rate, always shown in cc/min at ambient conditions.

  • Page 26: Program Display

    ® Plus Air Sampling Pump – Operation Manual Page 18 Gilian GilAir FT - Fault time: Total time, in seconds, the pump has run while being in a fault status. Current: Active fault condition Last: - Previous fault condition 4.5.7. Program Display...

  • Page 27: Sensor Calibration

    4.6. Sensor Calibration The GilAir Plus pump has a built in automatic sensor calibration feature which allows the pump to maintain an accurate stable flow rate by intermittently calibrating the pump‟s flow sensor to establish the zero flow point. This routine occurs before starting, when the internal temperature of the pump changes more than 3 degrees C, or whenever one hour has elapsed since the last sensor calibration.

  • Page 28: Unlocking The Keypad

    ® Plus Air Sampling Pump – Operation Manual Page 20 Gilian GilAir 4.7.3. Unlocking the Keypad To unlock the keypad: Press and hold down simultaneously the buttons. The lock symbol will disappear from the top middle portion of the screen. Release the buttons, and the pump will be unlocked.
  • Page 29 ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page 21 The illustration below shows the flow range set in the low flow position (20 to 449 cc/min), as indicated by the word Lo at the bottom of the display screen.

  • Page 30: Setting The Flow Rate

    Methods (NMAM). Following these published guidelines for field sampling is highly recommended. The GilAir Plus has a Pre-Cal/Post-Cal mode (See Section 5.3. ) accessible through the Set-up menu. This mode will record a Pre-Cal/Post-Cal value for each sample accessible through the PC interface and upon pump data review. Pre-Cal and Post-...

  • Page 31: Calibration Option (Smartcal )

    Page 23 4.9.2. Calibration Option (SmartCal An optional automatic user calibration kit is available for the GilAir Plus. The automatic field calibration, known as SmartCal, provides communication between the pump and the calibrator allowing the pump to self-adjust its flow rate. Although this capability is enabled on all pump models, a communications capable dock is required to access the SmartCal feature.
  • Page 32 ® Plus Air Sampling Pump – Operation Manual Page 24 Gilian GilAir Calibrating the Displayed Flow Rate: Set up a flow reference instrument (e.g., Gilibrator-2 or Challenger) following the manufacturer‟s instructions and recommendations. Choose a sample media of similar back pressure to that intended for use in the field.

  • Page 33: Causes Of Fault Condition

    There will be no LED illumination during the pause. If fault retry is enabled (See Section 5.4. ), the GilAir Plus will attempt an automatic re-start after three minutes. During that time if the fault cause was corrected (e.g., user sat in a chair and pinched the connection tubing shut...
  • Page 34 Plus Air Sampling Pump – Operation Manual Page 26 Gilian GilAir Valve Fault: If the High Flow/Low Flow mode control valve is not at the correct setting, either positioned between the high and low settings or set at the incorrect setting for the flow rate selected the pump will go into a Valve Fault.

  • Page 35: Section Five: Options

    ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page 27 SECTION FIVE: Options Setup ► 5.1. The Setup submenu has controls that adjust the basic operating parameters of the pump. To change the settings for each item in the Setup submenu: buttons to move the cursor ►...

  • Page 36: Pre/Post-Calibration

    ® Plus Air Sampling Pump – Operation Manual Page 28 Gilian GilAir Event ID 1 will now be displayed. Use the buttons to assign the event any unique identification number from 1 to 999,999. Note: A single press and release of either of these buttons will increment or decrement the ID number by 1.

  • Page 37: Fault Retry

    ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page 29 When you are at Run in the Main Menu and press the button to start a sample run, the calibration screen displays the set flow rate for the sample (See Section 4.8.

  • Page 38: Valve Mode

    The tubing setup is the same as a manual calibration (See Section 4.9.3. ). Using the SmartCal feature requires the GilAir Plus pump to be connected to the Dock with the cable to the calibrator plugged in.

  • Page 39: Gilibrator-2

    Connect the SmartCal cable to the PC Serial connector on the Gilibrator and the Reference Device port on the rear of the Dock. Using the GilAir Plus pump main menu, go to Setup ►SmartCal. Use the buttons to select Gilibrator. Press and release the button.

  • Page 40: Challenger

    Verify the desired calibration flow rate is within the Challenger range. Select the appropriate range if necessary. The Challenger reads flow continuously and reports it for display on the GilAir Plus. When flow stability is reached, the calibration will be calculated and stored in the pump. Calibration Complete will be displayed. The button can be used to return to the main menu.

  • Page 41: Tsi™ Model 4140

    SmartCal Challenger (flow rate) cc/m The GilAir Plus will run for a few minutes adjusting its flow rate to the calibration value using the readings from the Challenger. Calibration Complete will be displayed and the pump will stop. Before removing the pump from the Dock, press and release the button.

  • Page 42: Bios Defender™ 510

    Setup the GilAir Plus and Bios Defender with the SmartCal cable connected to the Data port on the Defender and the Reference Device connector on the rear of the Dock as shown in the photo.

  • Page 43: Clear Datalog

    ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page 35 Set up the BIOS Defender to measure 10 samples continuously. On the GilAir Plus pump, go to Setup, then SmartCal. Use the buttons to select BIOS Dfndr. Press and release the button.

  • Page 44: Run Options

    5.8.1. Standard Temperature (STP Models only) Users may set the temperature that will be used in the calculation of the standard flow and volumes when using a STP Model pump. The GilAir Plus factory default is 25°C (77°F) as the standard temperature.

  • Page 45: Display Options

    ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page 37 To set the Standard Pressure: At the Main Menu screen, use the buttons to move the cursor ► to Setup ►. Press and release the button. The pump will now display the Setup submenu screen.

  • Page 46: Pressure Units

    ® Plus Air Sampling Pump – Operation Manual Page 38 Gilian GilAir To set the units in which temperature is displayed: From the Main Menu screen, use the buttons to move the cursor ► to Setup ►. Press and release the button.

  • Page 47: Date

    ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page 39 The cursor ► will now be at Clock. Use the buttons to set the hour. When the desired hour is selected, press and release the button to complete the hour portion of the Clock Set function. Note: The hour must be selected per the standard 24-hour format (i.e., 1:00PM = 13:00).

  • Page 48: Date Format

    5.11. Password The GilAir Plus offers a password protection feature that can be set but is not required. The password for unlocking the keypad can be set in the menu item. A password may consist of 1-4 numerals.

  • Page 49: Control Mode

    5.12. Control Mode CF (Constant Flow), CPH (Constant Pressure High), CPL (Constant Pressure Low) The Control Mode determines which control parameter the GilAir Plus holds constant during the sample. The two control mode options are holding the flow constant or holding the pressure constant.

  • Page 50: Run Mode Manual, Timed, Program Name

    ® Plus Air Sampling Pump – Operation Manual Page 42 Gilian GilAir To select the Control Mode: buttons to move the cursor ► to At the Main Menu screen, use the Control Mode. Press and release the button. Use the...

  • Page 51: Run Setup

    ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page 43 Note: When the pump is first powered on, it will remember the last set Run Mode, Manual, Timed or selected Program. If a different mode is desired, it must be set before running an event.

  • Page 52: Pressure Set ("H O Or Mmhg Or Kpa)

    ® Plus Air Sampling Pump – Operation Manual Page 44 Gilian GilAir buttons to move the cursor ► to Timed Duration. Use the Use the buttons to set the time for the duration of the run in minutes. When the run time in minutes is selected, press and release the button.

  • Page 53: Section Six: Programming

    ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page 45 SECTION SIX: Programming Program ► 6.1. User programs specify a timed series of actions that control the sampling protocol employed by the pump. The pump can store up to 16 programs, each of which can be created, edited and executed.

  • Page 54: Program Edit

    ® Plus Air Sampling Pump – Operation Manual Page 46 Gilian GilAir The cursor ► will now be at Enable. The default setting displayed for the Enable function is disable. Use the buttons to select enable. When enable is selected, press and release the button to complete.

  • Page 55: Control Mode

    ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page 47 The cursor is now at Prog Name. At the right of Prog Name, PROG 1 is displayed. Use the buttons to select the Prog Name, then press and release the button to complete.

  • Page 56: Program Steps

    ® Plus Air Sampling Pump – Operation Manual Page 48 Gilian GilAir buttons to move the cursor ► to Setpoint. Use the Use the buttons to select the set point flow rate at which you want the pump to run during the execution of the program, then press and release the button to complete.

  • Page 57: Function Value

    ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page 49 buttons to move the cursor ► to Program Edit ►. Press Use the and release the button. buttons to move the cursor ► to Function. Use the Use the...

  • Page 58: Save A Program

    ® Plus Air Sampling Pump – Operation Manual Page 50 Gilian GilAir If the program step you are entering/changing has the On Interval or Off Interval function assigned, use the buttons to select the number of minutes for the duration of that interval, then press and release the button to complete.

  • Page 59: Section Seven: Pc Interface

    This requires a special communications version dock that is supplied in kits with the Datalog and STP pump models. The basic model of the GilAir Plus does not have this capability, nor will the basic Dock supplied with the Basic model pump support this option.

  • Page 60: Section Eight: Maintenance Menu

    Maintenance ► 8.1. The Maintenance submenu has controls that are occasionally used for clearing the GilAir Plus pump memories and calibrating transducers. To change the settings for each item in the Maintenance submenu: buttons to move the cursor ► to At the Main Menu screen, use the Maintenance ►.
  • Page 61 ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page 53 To perform Global Reset: Note: To preserve user programs, go to the Reset menu item instead of Global reset. (See Section 8.2.1. ) buttons to move the cursor ►...

  • Page 62: Reset (Save Programs)

    ® Plus Air Sampling Pump – Operation Manual Page 54 Gilian GilAir 8.2.1. Reset (save programs) Resets all the options as in Global Reset, except that programs are preserved. To perform Reset (save programs): At the Main Menu screen, use the buttons to move the cursor ►...

  • Page 63: Barometric P Cal

    ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page 55 buttons to move the cursor ► to At the Main Menu screen, use the Maintenance ►. Press and release the button. The pump will now display the Maintenance submenu screen. The cursor ►will now be at Factory Defaults ►.

  • Page 64: Pressure

    To perform Pressure calibration: Set up the GilAir Plus pump, load panel and reference meters as shown. For this procedure, the pump must be set to the Lo range of operation. During the calibration, the pump will run and maintain 35 inches of water backpressure. The load valve should be set to allow a flow rate of 100-200 cc/min of flow with this pressure.
  • Page 65 Note: To cancel out of Pressure, press and release the button at this time. Once the GilAir Plus pump is running stable with a flow rate between 100and 200 button to adjust the “Pressure” value cc/min. press and release the to the pressure sensor reference meter reading.

  • Page 66: Section Nine: User Maintenance

    All rechargeable batteries lose charge over time even if not in use. This is called self discharge. The self discharge rate of the NiMH cells used in the GilAir Plus battery pack is about 1% per day. It is important to have the pack fully charged when starting a sample.

  • Page 67: Pump Filter Maintenance

    ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page 59 Step 1 Step 2 Steps 3-4 Steps 5-6 9.3. Pump Filter Maintenance If the flow resistance of the input filter is too high, the sampling load capacity of the pump will be reduced.

  • Page 68: Section Ten: Appendices

    ® Plus Air Sampling Pump – Operation Manual Page 60 Gilian GilAir SECTION TEN: Appendices Appendix A: Menu Outline Underlined option indicates factory default (shipped) settings FLOW SET CALIBRATE ► SETUP ► EVENT ID ENABLE (enable / disable) ► PRE/POST CAL (enable / disable) ►...
  • Page 69 ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page 61 ► RUN SETUP ► TIMED START (00:00 / 00:00) ► TIMED DURATION (01) ► PRESS SET (˝ H (18.0) ► ► PROGRAM ► ENABLE (disable / enable) ►...

  • Page 70: Appendix B: Example Program Setup & Edit

    ® Plus Air Sampling Pump – Operation Manual Page 62 Gilian GilAir Appendix B: Example Program Setup & Edit This example program operates the pump as follows: Constant Flow Mode. 3000 cc/min flow rate calibrated flow rate. The program starts with an On Interval at 4:00 PM (16:00 Hrs).
  • Page 71 ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page 63 buttons to move the cursor ► to Function. Use the Use the buttons to set the function to Time. Press and release the button. buttons to move the cursor ► to Function value. Use the Use the buttons to set the hour to 16:00.
  • Page 72 ® Plus Air Sampling Pump – Operation Manual Page 64 Gilian GilAir buttons to move the cursor ► to Save. Press and release Use the button. Press the button 3 times to exit to the Main Menu. Use the buttons to move the cursor ► to Run Mode. Use the buttons to set the Run Mode to PROG 1.
  • Page 73 ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page 65 To change the number of cycles in Program 1, access the Program Step where the Cycle function was entered. For the existing program, the Cycle function was selected at Program Step 04.

  • Page 74: Appendix C: Troubleshooting Guide

    ® Plus Air Sampling Pump – Operation Manual Page 66 Gilian GilAir Appendix C: Troubleshooting Guide Symptom Possible Cause Corrective Action Battery Pack not fully Charge battery (Sec. 3.1. ) charged. Batteries have Run time too short; Recondition battery pack discharged.
  • Page 75 ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page 67 Symptom Possible Cause Corrective Action Faulty bearing Return for service Faulty motor Return for service Liquid in pump or other Pump runs erratic Return for service matter & faults Don‟t run pump with charger...
  • Page 76 ® Plus Air Sampling Pump – Operation Manual Page 68 Gilian GilAir Symptom Possible Cause Corrective Action Pump stops Normal self-check occasionally and function. Flow control is None (Sec. 4.6. ) restarts after 15 being re-zeroed. seconds Displayed flow rate...

  • Page 77: Appendix D: Parts List

    810-0902-01-R Datalogging Pump Only (No Dock) 810-0903-01-R STP Pump Only (No Dock) 910-0901-US-R GilAir Plus Basic Single Starter Kit, US cord 910-0901-EU-R GilAir Plus Basic Single Starter Kit, Euro cord 910-0901-UK-R GilAir Plus Basic Single Starter Kit, UK cord 910-0902-US-R...
  • Page 78 Plus Air Sampling Pump – Operation Manual Page 70 Gilian GilAir Part Number Description 910-0904-US-R GilAir Plus Basic 5-Pump Starter Kit, US cord 910-0904-EU-R GilAir Plus Basic 5-Pump Starter Kit, Euro cord 910-0904-UK-R GilAir Plus Basic 5-Pump Starter Kit, UK cord 910-0905-US-R...
  • Page 79 ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page 71 Part Number Description 811-0903-US-R Single Station Dock w/Comms 100-240Vac, 50-60 Hz, US Cord (includes Power Supply) 811-0903-EU-R Single Station Dock w/Comms 100-240Vac, 50-60 Hz, Euro Cord (includes Power Supply)
  • Page 80 360-0135-01 Quick Start Guide 360-0143-01 PC Application Manual 811-0913-01-R Outlet Fitting, Bag Fill Adapter 811-0914-01-R Tripod Mount, Adapts pump to camera style tripod, GilAir/GilAir Plus/3500/5000 800573-3 Diagnostic Panel 800783-3 Diagnostic Panel with Stand 800143 Filter Cassette Holder Kit 800149 Single Tube Holder Kit, 6 x 70, for 150 mg...

  • Page 81: Appendix E: Specifications

    ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page 73 Appendix E: Specifications PERFORMANCE Flow Range………………….. 20 - 5000 cc/min (450 - 5000 cc/min in Constant Flow High Flow mode, 20-449 cc/min in Constant Flow Low Flow mode) 1-5000 cc/min in Constant Pressure mode Flow Modes…………………..
  • Page 82 ® Plus Air Sampling Pump – Operation Manual Page 74 Gilian GilAir ENVIRONMENTAL Temperature Ranges Operating……………………… 32°F to 113°F (0°C to 45°C) Storage…………………….…. -4°F to 113°F (-20°C to 45°C) Charging…………………….. 41°F to 104°F (5°C to 40°C) Humidity Ranges Operating……………………. 5-95 %RH, non-condensing Storage……………………….

  • Page 83: Appendix F: Charging/Communications Dock

    Gilian GilAir Page 75 Appendix F: Charging/Communications Dock The Dock provided with the GilAir Plus charges the pump and optionally provides communications capability for a computer connection and connection to an air flow calibrator for automatic calibration (i.e., SmartCal). The Dock is available in one, three or five station basic or communication configurations.
  • Page 84 The USB connection can be used to interface the pumps held on the Dock to a PC for use with the optional GilAir Plus PC Application. This application transfers event data to a PC database, provides pump management capability including the ability to copy pump setups and allows sampling plans (programs) to be created to control the timing and setting of pump operation.

  • Page 85: Appendix G: Factory Calibration And Service

    ® Plus Air Sampling Pump – Operation Manual Gilian GilAir Page 77 Appendix G: Factory Calibration and Service U.S.A. Europe Sensidyne, LP Sysmex Analytical and Medical Systems B.V. 16333 Bay Vista Drive Clearwater, Florida 33760 Deliveries: 800-451-9444 Ecustraat II +1 727-530-3602...
  • Page 86 Intentionally left blank...
  • Page 87 Manufactured by: Sensidyne, LP 16333 Bay Vista Drive Clearwater, Florida 33760 U.S.A. 800-451-9444 • +1 727-530-3602 • [fax] +1 727-539-0550 www.Sensidyne.com • info@Sensidyne.com Authorized EU Representative Schauenburg Electronic Technologies GmbH Weseler Str. 35 · 45478 Mülheim-Ruhr Germany +49 (0) 208 9 99 10 • +49 (0) 208 5 41 10 [fax] www.schauenburg.com •...
