Remote Connection Modules and Antennas

If installed, antennas for WiFi, Cell Modem, and Mesh Radio communication units mount through the access port
on the left side of the pedestal, and include a stainless steel mounting body to protect antenna cabling and raise
antennas above the top of the pedestal for best signal strength. Consult the Resource Library on the Baseline web
site at http://www.baselinesystems.com for CAD details, communications options, and internal locations for
communications modules.
If equipped with a permanently mounted BL Commander handheld remote control receiver kit, the receiver
antenna will be mounted on the upper right side of the pedestal enclosure.
