PREPARING FOR INSTALLATION
• Unpack the cooktop and read the Installation
Instructions to understand the required countertop
cutout dimensions and location in the countertop,
the cooktop spacing to the front edge of the
countertop, and the required clearances to the
cabinets and walls. The vent system required cutout
width is shown on page 4. Confirm there is enough
side to side counter space to meet the required
spacing and clearances for the cooktop.
• Using the illustrations below and taking
measurements of the cooktop to establish dimension
A, confirm there is enough front to back counter
space (dimension B) to fit both the cooktop and the
vent system. Note the cooktop rear edge will overlap
the vent system front surface (refer to Page 5).
Screw head
Front of cutout
in countertop
of countertop
49-80777-1
Installation Preparation
Front
edge
of
cooktop
C
Dimension C is defined in cooktop Installation Instruction
Front edge Front of cutout
in countertop
the cooktop base to the rear edge of the cooktop. If you cannot find dimension A
Cooktop
4-1/2" Max
Side View: Installed Vent
• Refer to the Creative Solutions section on page 8 if
more counter space is needed.
• Using the illustrations on pages 5 through 7 and
taking measurements of the vent system and its
exhaust vent location, confirm the clearances
needed within the cabinet, the exhaust vent
direction, and the alignment of the exhaust vent with
the ducting. If needed for clearance or duct hookup
alignment, reposition the location of the cooktop,
or modify the cabinetry, or modify the ducting. A
remote blower kit JXR867 is available to move the
blower assembly out of the cabinet area.
• Confirm the electrical receptacles and gas lines are
correctly located, and relocate if needed.
B
B is the minimum dimension of the
flat portion of countertop that is needed
COOKTOP
A
A is the dimension from the screw head on the front surface of
in the cooktop installations instructions, then you must measure it.
Depth of cutout is A + 2 1/8"
Minimum counter depth B = A + C + 2.5"
Cooktop
5-1/2"
5-1/2"
Max
Max
Front View: Installed Vent
Back edge
of cooktop
1/8" minimum
D
o
w
n
d
3/8"
r
minimum
a
f
t
V
e
n
t
2 1/8"
Back of cut
in countertop
