Modal MD-HPBT01 User Manual

Modal bluetooth headphone
Hide thumbs Also See for MD-HPBT01:
Table of Contents

Advertisement

Quick Links

Download this manual
MD-HPBT01
Modal Bluetooth Headphone
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MD-HPBT01 and is the answer not in the manual?

Questions and answers

Related Manuals for Modal MD-HPBT01

Summary of Contents for Modal MD-HPBT01

  • Page 1 MD-HPBT01 Modal Bluetooth Headphone User Manual...
  • Page 2 MD-HPBT01 Modal Bluetooth Headphone eatures Volume Up/Down Play/Pause Logo with LED Reflective FF/RW film Next/Previous Power/Talk Microphone Receiver...
  • Page 3 Modal Bluetooth Headphone MD-HPBT01 otice ▮ MD-HPBT01 has a rechargeable Lithium-ion battery. Please Charge your headphone before using. ackage Contents ▮ Bluetooth Stereo Headphone ▮ A/C wall adapter ▮ USB charging cable User Manual ▮ ▮ Replacement ear pads Bluetooth Stereo Headphone...
  • Page 4 Power/Talk button for two seconds. The LED flashes blue or red and Voice prompt is “Hello” or “Bye”. ▮ MD-HPBT01 supports easy pairing, there is no need to enter 0000 (four zeros). ▮ When being connected, voice prompt is “ Connected” . And then, your headphone lets you know “apt-X mode”...
  • Page 5 Modal Bluetooth Headphone MD-HPBT01 How to change apt-X to 3D mode ▮ If your device supports the apt-X codec, MD-HPBT01 will be automatically activated. ▮ You may also press and hold Talk, Play button simultaneously for 4 seconds to select 3D mode or apt-X mode. Once 3D mode is selected, you can enjoy 5 different 3D sound effects.

  • Page 6: Playing Music

    Modal Bluetooth Headphone MD-HPBT01 laying Music Do this: Press Play/Pause to launch the phone’s MP3 player Play/Pause/Stop and begin playing music. Press this button to pause and resume playback. Double click Play/Pause to stop playback. Select a song Press and release ◀ ◀ or ▶ ▶ .

  • Page 7: M Ulti Pairing

    Modal Bluetooth Headphone MD-HPBT01 ulti Pairing ▮ Before you can connect the headphone to two devices, you must pair to each device individually. The device you are pairing must support one of the following Bluetooth profiles: • A2DP (Advanced Audio Distribution Profile)—Provides high quality Audio (stereo and mono) communication between the headphone and a phone’...
  • Page 8 MD-HPBT01 Modal Bluetooth Headphone ow to pair the MD-HPBT01 esetting the MD-HPBT01 ▮ In case the MD-HPBT01 needs to be reset, press Play, Talk and Volume Up button simultaneously. eplacing the ear pads ▮ To remove ear pad - Rotate the earphone cover counterclockwise.
  • Page 9 4. With the headphone turned off, press and hold Talk for four seconds. The LED blinks blue and red rapidly and then pairing mode is activated. 5. Double-click the MD-HPBT01 icon on the computer or highlight the icon and click Next.
  • Page 10 4. With the headphone turned off, press and hold Talk for four seconds. The LED blinks blue and red rapidly and then pairing mode is activated. 5. Double-click the MD-HPBT01 icon on the computer or highlight the icon and click Next.
  • Page 11 6. Double-click the MD-HPBT01 icon on the computer or highlight the icon and click Next. Note: If you are unable to locate the MD-HPBT01 icon, click the Search Again button. 7. Enter “ 0000” (four zeros) in the Bluetooth security code field, then click Next.

  • Page 12: Mac Computer

    5. Select Headset as the device type, then click Continue. 6. With the headphone turned off, press and hold Talk for four seconds. The LED blinks blue and red rapidly and then pairing mode is activated. 7. Select MD-HPBT01, then click Continue. The computer gathers information. 8. Click Continue.
  • Page 13 MD-HPBT01 Modal Bluetooth Headphone ow to use the MD-HPBT01 with Skype Notes: Purchase a Bluetooth adapter for your model of Bluetooth headphone at a tech store. Some computers (especially new computers and laptops) have a Bluetooth adapter installed already. If not, you can purchase a Bluetooth adapter that plugs into a USB connection on your computer.
  • Page 14 Modal Bluetooth Headphone MD-HPBT01 aintaining ▮ Do not place the headphone near fire. The battery may explode. ▮ Do not drop or apply excessive force to the headphone. You may damage it. ▮ When storing the headphone for an extended period of time, store it in a dry place and avoid extreme temperatures.

  • Page 15: Troubleshooting

    Modal Bluetooth Headphone MD-HPBT01 roubleshooting The Battery does not stay charged • Charge the headphone for at least three hours the first time it is charged. • Allow the battery to fully charge each time you charge it. - The indicator light turns solid red when recharging.
  • Page 16 No sound comes from the headphone • See “How to pair the MD-HPBT01” and try re-pairing the headphone. • You may need to turn off the paired Audio source’ s internal speakers before the Audio source can send Audio to the headphone. See the documentation for the Audio source.
  • Page 17 Modal Bluetooth Headphone MD-HPBT01 roubleshooting The sound has static or breaks up - Windows 7 or 8: 1 Click Start, then click Control Panel. 2 Click Hardware and Sound, then under Sound, click Manage Audio devices. 3 On the Recording tab, select Headset Microphone Bluetooth Hands-free Audio, then click Set Default.
  • Page 18 - Change the computer Audio settings to play Audio through the headphone. - Mac: 1 Click the System Preferences, then click Sound. 2 Under Output and Input, select MD-HPBT01. - Windows 7 or 8: 1 Click Start, then click Control Panel.
  • Page 19 - Change the computer Audio settings to play Audio through the headphone. - Mac: 1 Click the System Preferences, then click Sound. 2 Under Output and Input, select MD-HPBT01. - Windows 7 or 8: 1 Click Start, then click Control Panel.
  • Page 20 Modal Bluetooth Headphone MD-HPBT01 roubleshooting The headphone microphone is not working 4 On the Playback tab, select Speakers Bluetooth Hands-free Audio, then click Set Default. 5 Click OK. - Windows Vista: 1 Click Start, then click Control Panel. 2 Click Hardware and Sound.

  • Page 21: Led Indicator Messages

    MD-HPBT01 Modal Bluetooth Headphone ED indicator Messages Headphone Status LED Status Power On Blue LED flashes Turning Off Red LED dims and disappears Low Battery Red LED blinks continuously Recharging Red LED stays on Recharging Complete Blue LED stays on...
  • Page 22 MD-HPBT01 Modal Bluetooth Headphone FCC Information to User This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rul es. These limits are de signed to pro vide reasonable protection against harmful interference in a re sidential installation.
  • Page 23 MD-HPBT01 Modal Bluetooth Headphone IMPORTANT NOTE: FCC RF Radiation Exposure Statement: This equipment complies with FCC RF radiation e xposure limits set forth fo r an un controlled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
