WARNING
DO NOT INGEST BATTERY. CHEMICAL BURN HAZARD.
• The remote control supplied with this product contains a coin/button cell battery. If the coin/button cell
battery is swallowed, it can cause severe internal burns in just 2 hours and can lead to death.
• Keep new and used batteries away from children. If the battery compartment does not close securely,
stop using the product and keep it away from children.
• If you think batteries might have been swallowed or placed inside any part of the body, seek immediate
medical attention.
It is important to read this instruction book prior to using your new product for the first time.
User manual
RTS7131B
Advertisement
Related Manuals for RCA RTS7131B
Summary of Contents for RCA RTS7131B
-
Page 1: User Manual
User manual RTS7131B WARNING DO NOT INGEST BATTERY. CHEMICAL BURN HAZARD. • The remote control supplied with this product contains a coin/button cell battery. If the coin/button cell battery is swallowed, it can cause severe internal burns in just 2 hours and can lead to death. • Keep new and used batteries away from children. If the battery compartment does not close securely, stop using the product and keep it away from children. • If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention. It is important to read this instruction book prior to using your new product for the first time. -
Page 2: Safety Instructions
SAFETY INSTRUCTIONS FCC INFORMATION WARNING: • Changes or modifications to this unit not expressly This device complies with Part 15 of the FCC rules. approved by the party responsible for compliance Operation is subject to the following two conditions: could void the user’s authority to operate the (1)This device may not cause harmful interference, equipment. and (2)This device must accept any interference • The AC adapter is used as disconnect device and received, including interference that may cause it should remain readily operable during intended undesired operation. used. In order to disconnect the unit from the NOTE: This equipment has been tested and found to mains completely, the AC adapter should be comply with the limits for a Class B digital device,... -
Page 3: Remote Control
REMOTE CONTROL USING THE REMOTE CONTROL Remove the plastic sheet • Point the remote control at the REMOTE SENSOR before operating located on the unit. • When using this unit in very bright light, the remote control. infrared REMOTE SENSOR may not work properly. BATTERY REpLACEMENT TO CHANGE REMOTE BATTERY When the battery becomes weak, the operating 1. Open the battery door. distance of the remote control will be greatly reduced and you will need to replace the battery. Note: If the remote control is not going to be used for a long time, remove the battery. - Page 4 CONNECTIONS CONNECT AUDIO THROUGH AN ANALOG AUDIO CABLE 1. Connect an Audio Cable (not included) from the AUX IN jacks to the AUDIO OUT jacks of your TV, Set-Top Box or Blu-ray/DVD Player. 2. Connect a 3.5mm Audio Cable (not included) from the LINE IN jack to the AUDIO OUT jacks or from the AUX IN jacks to the Headphone Out jack of your TV, Set-Top Box or Blu-ray/DVD Player. CONNECT AUDIO THROUGH A DIGITAL OpTICAL CABLE 3. Connect an Optical Cable (not included) from the OPTICAL IN jack to the OPTICAL OUT jack of your TV, Set- Top Box or Blu-ray/DVD Player. Note: OPTICAL IN only supports PCM signal. You may need to activate PCM (Downmix) on your source device, e.g. TV, Set-Top Box or Blu-ray/DVD Player. Plug one end of a 3.5mm Audio Cable (not included) into the LINE IN jack and other end into your iPad®, iPhone®, iPod® or other audio devices. pLACEMENT The Soundbar can be placed freestanding on a table or mounted on a wall. pLACING THE SOUNDBAR ON A WALL The Soundbar requires additional mounting hardware that must be purchased separately. 1. Install the Wall Mount Brackets to the Soundbar as shown.
-
Page 5: Bluetooth Pairing
The Bluetooth indicator light on the soundbase will indicate the currently-selected source. will blink. 3. Press VOL / , BASS or TREBLE 2. On your device (mobile phone, MP3 player, etc.), on the remote to adjust Volume, Bass or Treble select RCA RTS7131B from the list of available levels. When adjusting Volume, Bass or Treble, Bluetooth connections. the four LEDs will temporarily display the current Note: If your Bluetooth device (such as, mobile level setting (see illustration). phone) requires a password while pairing, please Note: When mute is enabled, the 4 LED indicators enter 4-digit number: 0000.
