- Page 1 INSTRUCTION MANUAL REFRIGERATOR MCSR-6085W MCSR-6085B MCSR-6085BSS MCSR-5585W MCSR-5283W MCSF-5585BSS Please read the following instructions completely before operating this appliance.
- Page 2 ATTENTION: Defrosting—Do not use sharp,pointed objects to remove frost or ice from surfaces of the refrigerator and/or freezer compartment. Doing so could puncture the cooling coil, causing the unit to lose its ability to maintain cold temperatures and voiding the warranty. See the Care and Cleaning section for instructions on defrosting the refrigerator and/or freezer compartment.
-
Page 3: Table Of Contents
CONTENTS Safety instruction……………………………………………………………………………………………………………………………………………………………………………………………………..…………………………………4 USE OF EXTENSION CORDS………………………………………………………………………………………………………………………………………………………………………………………………………………………………… 4 HOW TO CONNECT ELECTRICITY ………………………………………………………………………………………………………………………………………………………………………………………………………..………4 operation instruction ……………………………………………………………………………………………………………………………………………………………………………………………………..…………………………5 Control Settings…………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… 5 About the refrigerator features……………………………………………………………………………………………………………………………………………………………………........…………… 6 Care and cleaning of the refrigerator ………………………………………………………………………………………………………………………………………………………………………………………………….………6 Care and cleaning of the refrigerator ………………………………………………………………………………………………………………………………………………………………………………………….………………6 Care and cleaning of the refrigerator …………………………………………………………………………………………………………………………………………………………………………………………..………7 Preparing to install the refrigerator……………………………………………………………………………………………………………………………………………………………………………………………………………... -
Page 4: Safety Instruction
Safety Instructions getting rid of your old refrigerator, please follow the instructions below to help prevent accidents. IMPORTANT SAFETY INFORMATION. Before You Throw Away Your Old Refrigerator or Freezer: READ ALL INSTRUCTIONS BEFORE USING. • Take off the doors. • Leave the shelves in place so Use this appliance only for its intended purpose as described in this Owner’s Manual. -
Page 5: Operation Instruction
Operating Instructions • This provides the best performance and also prevents overloading house wiring circuits which could cause a fire hazard from overheated wires. • Never unplug your refrigerator by pulling on the power cord. Always grip plug About the control on the refrigerator. firmly and pull straight out from the outlet. -
Page 6: About The Refrigerator Features
24 hours for the refrigerator to reach the temperature you have set. • The top shelf is best for storing fruits and About the refrigerator features. vegetables. Shelves • The bottom shelf is To remove a shelf, lift up the back slightly and pull forward. best for storing Freezer Compartment beverages, deli meats... -
Page 7: Care And Cleaning Of The Refrigerator
Replacing the Light Bulb NOTE: If ice buildup is very thick, it may keep the ice tray Unplug the refrigerator before replacing a burned-out bulb. Setting the controls to 0 compartment door from opening or closing completely. Don’t try to does not remove power to the light circuit. -
Page 8: Preparing To Install The Refrigerator
Installation Instructions Preparing to install the refrigerator. Preparing to install the refrigerator. Read these instructions completely and carefully. Refrigerator Location • Do not install the refrigerator where the temperature will go below 50°F (10°C) because it will not run often enough to maintain proper temperatures. •... - Page 9 7. Remove the two screws from the top cover support. Install top cover support on the opposite side of refrigerator. 8. Remove the middle hinge. Remove plug buttons from the opposite side of refrigerator. Re-install plug buttons in the original hinge mounting holes. Door Reversal (cont.) 9.
-
Page 10: Troubleshooting Tips
Troubleshooting tips. Save time and money! - Page 11 Safety precautions...
-
Page 12: Safety Precautions
Safety precautions... - Page 13 Function Schedule ● Energy efficiency ● Micro foam technology ● Low noise operation ● Thick insulation for energy efficiency System Flow Chart 1. Schematic diagram of System Flow Chart 2 Brief Description of System Flow Chart All models are a direct cooling single-system refrigerator or freezer. When the refrigerator or freezer is just powered o n, the re f r ig e r a n t flo ws in the sequence: 1->2->3->4->5>1...
- Page 14 Circuit Diagram Maintenance Service and Trouble Shooting 1 Schematic Circuit Diagram 1. No cooling Brief Description of Control Principle A mechan ic a l t y p e o f a l l th e c o n tr o l is generally adopted.. The thermostat directly controls the start and stop of compressor, and hence the refrigerator temperature.
- Page 15 2 The compressor doesn›t stop 3 Cooling capacity is insufficient...
- Page 16 4 The compressor doesn›t work 5 Normal Phenomena—Not Troubles for Refrigerators In a domestic refrigerator, there is not only a complicated electric controlsystem, but also a refrigerating system that is difficult to discern whether it is in a good working condition.
- Page 17 4).For the direct cooling refrigerator ,a kind of irregular crack sound can be often heard Three Essentials for Checkup when the compressor is running for a certain period of time or has just stopped its running .This sound is caused by the stress relief due to expansion and contraction when temperature changes ,and will not affect the normal application of refrigerator .
- Page 18 b) Listen to the sound caused by the flowing of gas in the evaporator Open the refrigerator and dew condensation may appear for a very short time period when just starting door while the compressor is in operation, incline your ear and listen attentively the gas the machine ,this is a normal phenomenon ).
- Page 19 severer leak point ,charge the system with nitrogen and detect leak points with the recharge the system with refrigerant . commonly adopted method ,repair them ,evacuate ,charge the system with refrigerant ,and then turn on the refrigerator to make a test run . 4) Low efficiency of compressor Analysis of Trouble Low efficiency of a refrigerating compressor refers to the actual 2) Too much refrigerant charged into the system...
- Page 20 severely affected ,thus causing a poor refrigerating effect . Remedy It is quite difficult to 1) All refrigerant in the system has leaked out Analysis of Trouble Leak points in the determine whether this trouble is caused by the refrigerating oil left in the evaporator refrigerating system have not been found and repaired timely ,thus resulting in the tubing ,because this kind of phenomenon and other several trouble are tends to be total escape of refrigerant .There are two kinds of leakage :I) slow leakage for instance...
- Page 21 caused by ice clogging . Remedy If there is too much moisture in the refrigerating system, suction valve and discharge valve to suck and discharge the refrigerant. If the valve it is advisable to release the refrigerant, purge the tubing with nitrogen, and then charge block is broken, the refrigerant can not be discharged, and hence no refrigerating can the system with the filtered refrigerant.
- Page 22 air is higher gas discharge pressure, higher discharged gas temperature (the gas discharge compressor is generally controlled by a thermostat . When the temperature in the tubing is considerably hot when you feel it with your hand), and poorer refrigerating refrigerator reaches its desired value, the thermostat will shut down the compressor effect.
- Page 23 sensing agent from the temperature sensor. Remedy Remove the relay cover to check and cause the shaft to be seized. Copper plating may also result in seizing of shaft. up its contacts, if they are open, this means that the original setting is not properly set b) Seizing of piston This is caused by too small fit clearance between the piston and or temperature sensing agent has leaked out of the temperature sensor.
- Page 24 the thermostat is unable to cut off the power supply to the compressor and stop it. the resistance between the power cord plug and the case body with an avometer ,the Remedy If it has been found that the refrigerant in the system is insufficient in quantity, reading will be zero (0W);...
