Summary of Contents for Küppersbusch IG6504
- Page 1 User Manual Dishwasher IG6504...
-
Page 2: Table Of Contents
CONTENTS Safety information Before first use Safety Instructions Daily use Product description Hints and tips Control panel Care and cleaning Programmes Troubleshooting Settings Technical information Subject to change without notice. SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. -
Page 3: Safety Instructions
The appliance is to be connected to the water mains using • the new supplied hose-sets. Old hose sets must not be reused. Children and vulnerable people safety This appliance can be used by children aged from 8 years • and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning... - Page 4 • The first time you use the appliance, completed. There can be detergent on make sure that there is no leakage. the dishes. • The water inlet hose has a safety valve • The appliance can release hot steam if and a sheath with an inner mains cable.
-
Page 5: Product Description
PRODUCT DESCRIPTION Upper spray arm Detergent dispenser Lower spray arm Cutlery basket Filters Lower basket Rating plate Upper basket Salt container Air vent Rinse aid dispenser... -
Page 6: Control Panel
CONTROL PANEL On/off indicator Start button Programme marker Programme knob Indicators Indicators Indicator Description Washing phase. It comes on when the washing phase operates. Drying phase. It comes on when the drying phase operates. End indicator. Salt indicator. It is always off while the programme operates. -
Page 7: Programmes
PROGRAMMES Programme Degree of Programme Consumption values soil phases Type of load Dura- Energy Water tion (kWh) (min) Normal soil • Prewash 1.02 Crockery and • Wash 50 °C cutlery • Rinses • Dry Heavy soil • Prewash 130 - 1.3 - 1.4 13 - 15 Crockery, cut-... -
Page 8: The Water Softener
detrimental effect on the washing results How to set the programme and on the appliance. selection mode The higher the content of these minerals, The appliance is in programme selection the harder your water is. Water hardness is mode when the on/off indicator comes on measured in equivalent scales. -
Page 9: Before First Use
press the Start button the level number • The intermittent flashing of refers increases. After level 10 you will start to the current set level, e.g. 5 flashes again from level 1. + pause + 5 flashes = level 5. 4. -
Page 10: Daily Use
How to fill the rinse aid 1. Turn the cup (C) counterclockwise to dispenser open the dispenser. 2. Pour the rinse aid in the dispenser (A) until the liquid reaches the fill level 'max'. 3. Remove the spilled rinse aid with an absorbent cloth to prevent too much foam. -
Page 11: End Of The Programme
• Start indicator starts to flash. Make sure that there is detergent in the 4. Press Start. detergent dispenser before you start a new • The programme starts and the programme. indicator of the washing phase is on. • On/off indicator and start indicator End of the programme are on. -
Page 12: Care And Cleaning
• Do not use more than the correct • Make sure that glasses do not touch quantity of detergent. Refer to the other glasses. instructions on the detergent packaging. • Put cutlery and small items in the cutlery basket. What to do if you want to stop •... - Page 13 5. Make sure that there are no residues of food or soil in or around the edge of the 1. Turn the filter (B) counterclockwise and sump. remove it. 6. Put back in place the flat filter (A). Make sure that it is correctly positioned under the 2 guides.
-
Page 14: Troubleshooting
• Only use neutral detergents. CAUTION! An incorrect position • Do not use abrasive products, abrasive of the filters can cause bad cleaning pads or solvents. washing results and damage to the appliance. Internal cleaning Cleaning the spray arms • Carefully clean the appliance, including the rubber gasket of the door, with a soft Do not remove the spray arms. -
Page 15: Technical Information
Problem and alarm code Possible solution The appliance does not drain the water. • Make sure that the sink spigot is not clogged. • The end indicator flashes 2 times in- • Make sure that the drain hose has no kinks or termittently. -
Page 16: Environmental Concerns
Power consumption Left-on mode (W) 0.50 Power consumption Off-mode (W) 0.50 1) Refer to the rating plate for other values. 2) f the hot water comes from alternative source of energy, (e.g. solar panels, aeolian energy), use the hot water supply to decrease energy consumption. - Page 20 Küppersbusch Hausgeräte GmbH Postfach 10 01 32, D-45801 Gelsenkirchen, Küppersbuschstr. 16, D-45883 Gelsenkirchen Telefon: (02 09) 4 01-0, Telefax: (02 09) 4 01-3 03 www.kueppersbusch.de 156977690-A-042014...
