Tally Dascom DL-210
Print Position
On, Off
Detection
Auto Calibrate
On, Off
Label
Top Form Sensing On. Off
Paper Sensor Gap sensor,
Selection Reference sensor
Print Home Offset User-defined
Cutting position
User-defined
offset
Black mark AD
User-defined
value

Explanation for Buttons
Button Description
When printer is powering on, click this button for acquiring the current setup menu. It
Get Printer Setting
will display on the screen.
Print Self-test Click this button for printing current settings for the printer.
Restore All Setting Click this button for restore to default setting.
Send Setting Make the new settings effective.
Calibrate label Click this button to calibrate label.

After setting, the printer will beep once, then the setting become valid.

In order to enhance print head lifetime, it is recommended that set the low print
density if the printing quality is acceptable.
Off Enable print position detection or not
On: It will auto calibrate the label when you use a
Off different size/format of label.
Off: Disable auto calibrate label
Before the printer begins to detect the label length,
it will feed and print based on the printing data so
Off
as to avoid unnecessary waste of media during
length detection.
Gap Choose between the gap sensor and the reference
sensor sensor.
Set the vertical distance between print home
position and the top of black mark. When the value
0 is positive, the media moves inward towards the
printer, and vice versa.
Range: -5~+5 (mm)
Set the vertical distance of the tearing position.
When the value is positive, the media moves inward
0
towards the printer, and vice versa.
Range: -5~+5 (mm)
0 Adjust the black mark detection accuracy.
37
