SERVICE MANUAL
Ver 6-2004H
Revision History
Area
Model
Lineup
Japanese
Japanese
PCG-X505CP
American
US/Canadian
VGN-X505ZP
European
AEP/UK
VGN-X505VP
Asian/Oceania/
Chinese
VGN-X505AP
South Africa
9-876-368-06
[MA]
1
[MA]
4
Illust : PCG-X505CP
PCG-X505CP
VGN-X505ZP
VGN-X505VP
VGN-X505AP
•
Design and specifications are subject to
change without notice.
本機の仕様および外観は, 改良のため予告なく
●
変更することがありますが, ご了承ください。
NOTEBOOK COMPUTER
Advertisement
Table of Contents
Related Manuals for Sony VAIO PCG-X505CP
Summary of Contents for Sony VAIO PCG-X505CP
-
Page 1: Service Manual
PCG-X505CP VGN-X505ZP VGN-X505VP VGN-X505AP SERVICE MANUAL Ver 6-2004H Revision History Area Model Lineup Japanese [MA] Japanese PCG-X505CP American US/Canadian VGN-X505ZP European AEP/UK VGN-X505VP Asian/Oceania/ Chinese [MA] VGN-X505AP South Africa • Design and specifications are subject to change without notice. 本機の仕様および外観は, 改良のため予告なく ●... - Page 2 Obey precautionary markings and Inspect after completing service Sony, VAIO and CLIE are trademarks or instructions operating and the service instructions. After servicing, inspect to make sure that all screws, registered trademarks of Sony.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Section Title Page CHAPTER 1. SPECIFICATIONS ............1-1 (to 1-1) CHAPTER 2. BLOCK DIAGRAM ............2-1 (to 2-1) CHAPTER 3. FRAME HARNESS DIAGRAM ......3-1 (to 3-1) CHAPTER 4. EXPLODED VIEWS AND PARTS LIST Main Section MS-1 ......................4-2 L-1 ......................... -
Page 4: Chapter 1. Specifications
CHAPTER 1. SPECIFICATIONS 1-1. Specifications PCG-X505CP VGN-X505ZP VGN-X505VP VGN-X505AP PM-1.1 ULV PM-1.1 ULV PM-1.1 ULV PM-1.1 ULV ChipSet Intel 855GM Intel 855GM Intel 855GM Intel 855GM Graphic Intel 855GM Intel 855GM Intel 855GM Intel 855GM 10.4"XGA 10.4"XGA 10.4"XGA 10.4"XGA 20GB 20GB 20GB 20GB... -
Page 5: Chapter 2. Block Diagram
Intel AD1981B with Close ICH4-m DC out (33MHz) (33MHz) 1394 Bridge 1394 PHY DVD±RW Drive EPSON_SPC7281 FFM_MD8408B SONY UJ-820 i.LINK PC Card I/F PC Card 1-796-904-21 Debug IC200 IC202 EEPROM 1394+POWER Connector & EC/KBC (typeII x 1) (8Mb) (password) -
Page 6: Chapter 3. Frame Harness Diagram
CHAPTER 3. FRAME HARNESS DIAGRAM FPC POWER DISPLAY VANADIUM-LITHIUM RECHARGEABLE Side R INVERTER BATTERY HARNESS (PWR) UNIT AUDIO J2250 JACK LITHIUM ION STANDBY BATTERY PACK CN5100 POWER HARNESS (LCD) HARNESS Side L (INV) Rear SPEAKER CN2270 PC CARD HARNESS (WITH DC JACK) FPC-7Z CN4170 CN4502... -
Page 7: Chapter 4. Exploded Views And Parts List
CHAPTER 4. EXPLODED VIEWS AND PARTS LIST • The parts list is compiled by blocks of a palmrest and ･ 分解図と部品表は, パームレスト, ボトムなどの bottom etc. The sections of the parts list are different ブロックごとに分かれています。機種によって部品表 depending on the model. Please refer to list of contents のセクションが異なりますので, 詳細は右下の一覧表... - Page 8 MS-1. Main Section MS-1 Ref.No. Part No. Description Ref.No. Part No. Description A-8118-089-A $ # HDD (20GB) (TO1.8) ASSY (S) 4-680-444-01 GASKET (HDD) A-1061-232-A $ # ASSY MBX-96 (P1100) (S) 4-680-565-01 CUSHION (LED) 1-756-424-11 BATTERY, VANADIUM-LITHIUM 4-680-857-01 CUSHION LED PWR 4-642-711-01 SHEET (BATTERY), ADHESIVE 4-680-874-01...
- Page 9 L-1. LCD 10.4-inch XGA - Made by TS- Ref.No. Part No. Description 4-658-789-02 TAPE (HARNESS) 4-680-857-01 CUSHION LED PWR 101 A-1074-821-A $ # LCD UNIT(J)(S) 102 1-478-476-11 INVERTER UNIT 103 1-861-165-21 FPC (POWER DISPLAY) 104 1-962-652-21 LCD HARNESS 105 1-962-653-11 INV HARNESS 106 1-962-654-21 DC HARNESS...
- Page 10 A-1. Accessories Ref.No. Part No. Description AC Adaptor DVD+-RW ! 801 1-477-749-52 $ & ADAPTOR, AC 802 A-8119-547-A & COMPLETE PWB FPC-VGA ADP (S) (PCGA-DDRW2) 803 4-680-464-01 & BAG (CAP POINTER) Ref. No. Part No. Description [MA] ! 804 1-790-732-32 &...
- Page 11 A-2. Accessories [ADD] [ADD] [ADD] VGN-X505VP, X505AP Ref. No. Part No. Description X-2021-041-1 BEZEL ASSY 1-796-904-21 $ # DVD+-RW (UJ-820) * 903 4-657-336-11 REINFORCEMENT * 904 4-657-338-11 SUPPORT, PC BOARD A-1068-578-A $ IFX-236 MOUNT (S) 1-823-520-11 FLEXIBLE FLAT CABLE X-2021-042-1 CABINET (UPPER) ASSY A-1068-579-A $ # IFX-235 COMPLE (S)
-
Page 12: Chapter 5. Others
CHAPTER 5. OTHERS 5-1. The Barcode Label The hatched portion of the barcode label is used as the repair data. バーコードラベルの網掛け部は，修理データとして使用いたします。 [ PCGA-DDWR2 ] (Bottom) [ IFX-235 Board ] (Side [MBX-96 Board] [HDD] (Side B) (Top) A, B A, B [ DVD±RW Drive ] (T [HDD Sheet]... - Page 13 VGN-X505ZP VGN-X505VP VGN-X505AP : Additional Models This manual and the constituent data may not be replicated, copied nor reprinted in whole or in part without prior written authorization of Sony Corporation. 本マニュアルの一部，または全部について，無断で データの複製，複写，転載することを禁じます。 English / Japanese Sony Corporation 2004H2700-1 © 2004 Sony Corporation –...
-
Page 14: Revision History
Revision History Suffix Ver. Date Contents QM No. Ver. 1 2004.06.04 First Edition Ver. 2 2004.07.05 Front Page (Model Line Up), Page 1-1, Page 4-1, Page 4-2, Page 4-3, Page 4-4, Back Cover N2004_070AK Ver. 3 2004.07.20 Front Page, Page 4-2, Back Cover N2004_078CK Ver.
