GE DGP Instruction Manual

Digital generator protection relay
Hide thumbs
Table of Contents

Advertisement

Quick Links

g
NOTE
GE Power Management
215 Anderson Avenue, Markham, Ontario
Canada L6E 1B3
Tel: (905) 294-6222 Fax: (905) 294-8512
Internet: http://www.GEindustrial.com/pm
Digital Generator Protection Relay™
All relays must be powered up at least once per year
to avoid deterioration of electrolytic capacitors and
subsequent relay failure.
DGP
Instruction Manual
DGP Revisions: V210.12000P
V210.10000F
V211.32000J
V210.22000D
Manual P/N: GEK-100666D
Copyright © 2000 GE Power Management
GE Power Management
Manufactured under an
ISO9002 Registered system.
